Introducing the bonoch Baby Monitor 1080P

The Baby Monitor 1080P is a high-definition, wireless baby monitoring system that offers parents a reliable and user-friendly solution to keep an eye on their little ones. With an estimated price range of $80 to $100 and a planned launch date in mid-2023, this baby monitor aims to make a splash in the market with its impressive features and affordable price point.

Detailed Specifications

The bonoch Baby Monitor boasts the following key features

• 1080P full HD resolution for clear and sharp video
• Night vision for monitoring in low-light conditions
• Two-way audio for communicating with your baby
• Room temperature monitoring for ensuring a comfortable environment
• Lullabies and white noise options for soothing your baby
• Secure, encrypted connection for added peace of mind
• Long battery life and rechargeable battery
• Expandable up to four cameras for monitoring multiple rooms

Description Of bonoch Baby Monitor 1080P

Designed with parents in mind, the bonoch Baby Monitor 1080P delivers crisp, high-definition video and a range of convenient features to make monitoring your baby a breeze. The monitor's camera can be easily mounted on a wall or placed on a tabletop, and the parent unit features a user-friendly interface for quick access to all functions. Whether you need to check in on your baby during the day or monitor them in the dark, the bonoch Baby Monitor 1080P has you covered.

Product Overview

Baby Unit

1. Light Sensor
2. Standard Camera
3. Microphone
4. Pairing Button
5. TF Slot
6. Reset Hole
7. USB-C Charging Port
8. Antenna
9. Temperature Sensor
10. Power Switch

BParent Unit

1. Display
2. Power Button
3. Volume Button
4. Volume Level Indicator
5. Status Indicator Light
6. Power Indicator
7. Menu/Back/Camera/ Video Recording
8. Zoom
9. Up Arrow Key
10. Left Arrow Key
11. OK Button
12. Right Arrow Key
13. Down Arrow Key
14. Play Music
15. Intercom
16. Microphone
17.  Antenna
18. Speaker
19. USB-C Charging Port )
20. Reset Hole

Keyboard & Indicator Light Instructions

Menu Options Overview

Status Indication Overview

Setup Guide of Baby Monitor

To get started with your bonoch Baby Monitor 1080P, follow these simple steps

1. Charge the parent unit and camera unit fully.
2. Mount the camera unit on the wall or place it on a tabletop.
3. Connect the camera unit to a power source.
4. Turn on both the camera unit and parent unit.
5. Pair the parent unit with the camera unit using the provided instructions.
6. Adjust the settings and position the camera unit for optimal viewing.

Setting Up

1. Connect the power adapter with camera. Plug the power adapter into power socket (refer to the illustration). Turn the on/ off button on the camera to the ON position.
2. Press the POWER BUTTON for 2 seconds to turn on the parent unit.
3. The factory default camera and the parent unit are paried, If no pairing occurs, or you need to add a new camera, please follow the steps below to add.

Quick Operation

Quick Actions to Record

Quick Actions To Record

• Double-tap the menu button, camera icon shows with sound, photo taken.
• Hold the menu button, video icon shows with sound, start manual recording.
• Then hold the menu button again to stop manual recording.

Switching Camera

Switch cameras manually

When two or more cameras are connected, press the “OK” button to enter the split screen mode. You can now use the arrow keys to select a screen you want to zoom in, and press the "OK" button again to switch to the new camera screen.
Turn on multiple cameras' scan mode

When two or more cameras are connected and the screen displays a single camera, press the "OK" button for 3 seconds. "Scan mode on" will then be displayed at the bottom left of the screen, and the loop logo of the camera will appear at the top of the screen. The baby monitor will automatically loop real-time video from up to 4 cameras in single-screen mode every 15 seconds.
Turn off multiple cameras' scan mode

To turn off multiple cameras scan mode, press the"OK" button for 3 seconds, the loop logo of the camera at the top of the screen will disappear.

TF card installation

1. Insert the TF card according to the direction as shown.
2. It is recommended to use a Class 10 or higher speed and a capacity of 32GB or above for the TF card.
3. For detailed instructions and operation videos, please visit the official website or contact customer support for assistance.

Replacing the Camera Len

Rotate to remove the decorative ring of the original lens (please keep the removed decorative ring properly, it needs to be reinstalled later when using the standard lens) Take out the additional wide-angle lens align it and screw it in, pay attention to make sure it is installed in place
Note: After installation, remove the lens protection cover for normal use

WARNING
STRANGULATION HAZARD

Noise or Signal Interference
Avoid placing the two cameras too close together.
Please keep a distance of at least 3 feet or more to prevent noise or signal interference. To ensure safety, please use the adapter and charging cable included in our package to charge the bonoch Baby Monitor. Please don't use the charging devices we provide to charge other electronic devices, such as cell phones, laptops, etc.

Troubleshooting

If you encounter any issues with your Baby Monitor, try the following troubleshooting steps

1. Ensure both the camera unit and parent unit are charged and turned on.
2. Check that the camera unit is connected to a power source.
3. Confirm that the parent unit is properly paired with the camera unit.
4. Make sure the camera unit is within range of the parent unit.
5. If the issue persists, reset the parent unit and camera unit to their factory settings and pair them again.

Pros & Cons of bonoch Baby Monitor 1080P

Pros

• High-definition video for clear monitoring
• Secure, encrypted connection for added safety
• Long battery life and rechargeable battery
• Expandable up to four cameras
• Affordable price point

Cons

• No mobile app support (reliant on parent unit)
• Limited range compared to some competitors

Customer Reviews of Baby Monitor 1080P

The Baby Monitor 1080P has received positive reviews from parents, with many praising its clear video, user-friendly interface, and affordable price. Some common complaints include limited range and no mobile app support.
