Chekoh Hercules B1 Security Camera Introduction

Reliable and advanced home security solution designed to keep your property safe. With features like high-definition video recording, motion detection, and night vision, the Hercules B1 provides comprehensive surveillance around the clock. Its user-friendly app integration allows for remote monitoring, making it easy to keep an eye on your home from anywhere. Whether for home or office use, this security camera offers peace of mind with its robust performance and ease of use.

Specification

Product Details

Notice Before Using The Camera

NOTICE
Before Starting Using Chekoh Hercules!

• When start to add the camera to the Wi-Fi network, please make sure it’s under a full  Wi-Fi signal (You can test with your smartphone)
• Make sure connect the device to your smartphone (successfully monitored on app) before installing on the wall.
• This camera only supports 2.4GHz Wi-Fi router. Please make sure you are using 2.4GHz Wi-Fi router (the same as the smartphone).
• Wi-Fi password does not support special characters (Eg. * / @ $). Please reset the Wi-Fi password only with English letters and numbers if the original password has special characters.
• Please install the camera under a stable Wi-Fi coverage area. If the Wi-Fi signal is unstable in the place where you install it, we suggest purchasing an additional Wi-Fi amplifier. Contact us at [email protected] for more advises if necessary.

If you need any help when installing or using the camera, here are the ways to follow:

1. Read this quick guide or our manual.

2. View the installing video guide at



3. Consult our customer service by starting a live chat at https://chekoh.net  (Mon-Fri 8:00 am - 5:00 pm PST)

4. Download the Full User Manual at



5. Consult our customer service by emailing us. (reply in 12 working hours).

Description

The chekoh Hercules B1 Security Camera is a high-performance home security solution that offers peace of mind for homeowners and business owners alike. Its 1080p HD resolution ensures clear and detailed video footage, while its night vision capability allows for round-the-clock monitoring. The camera's motion detection feature sends push notifications to your smartphone, so you can stay informed of any activity on your property. With two-way audio, you can communicate with anyone on your property, whether it's to warn off intruders or greet visitors. The weather-resistant design of the chekoh Hercules B1 Security Camera makes it suitable for both indoor and outdoor use, and its rechargeable battery provides up to 3 months of standby time. The camera can be easily installed with no wiring required, and it can be controlled and monitored via the chekoh app.

Starting Using The Camera

Now Let's Start Using the Chekoh Hercules!

Connect The Power

1. It takes 30 seconds to get ready after connecting the power. The camera will stay silent during this 30 seconds.
2. When the camera is starting, it will turn up and down, right and left for 3-5 seconds. We suggest holding the camera when it's starting.

3. When the camera turns to silent again, a voice will remind us start to connect the smartphone!



Download The "Chekoh" App

1. Search "Chekoh" on Apple Store (iOS)  or Google Play (Android) to download the app.



2. Use the phone camera to scan the following QR code to download the "Chekoh" app.*



3. For New user, Please Select 'Agree' To The Tips Pop-Up
   1. Allow Chekoh to access mobile cellular data and wireless LAN, otherwise you cannot add camera.
   2. Allow Chekoh to receive pushed messages, otherwise the phone will not receive an alarm push message.
   3. Allow Chekoh to use the microphone when you want to use 2 way audio function.

Account Sign Up (On Chekoh App)

1. Open the app and click Sign up.
2. Enter your email or phone number, click send verification code.
3. Get the verification code from your email or message, input it and set up the password
4. Sign in with the account and password.

Add Device

Before Adding the Device:

1. Connect your phone to 2. 4G Wi-Fi (5G is not supported)
2. Wi-Fi passwords do not support special characters (Eg. * / @ $). Please reset the Wi-Fi password only with English letters and numbers.
3. Make sure the Wi-Fi signal is full .

Adding the Device

1. Tap 'Add Device' or '+.
2. Connect the power and the camera is boosting, Please wait for 30 seconds, the  camera will start to move around. Follow the prompts on the screen. Click here to confirm the camera status, click 'Next'.
3. Enter the Wi-Fi password, and click 'Next'. Confirm the Wi-Fi Information.
4. A QR code will show up on the smartphone, Use the camera to scan the QR code.
   Please follow the advice in the app.
5. A voice will sound after the QR code is scanned successfully. And then the camera will start the auto binding and configuration.
6. Wait for 10-120 seconds during the configuration. If the binding is successful, you will hear 'binding successful'. Then the app will automatically jump to the camera list page.

Tip: If you do not hear a voice saying "binding successful", it means the binding is failed. Please try to reset the camera and bind again.

• Use the reset needle (can be found in the package) to hold the reset button for several seconds, until you hear deng~deng~deng~ prompt voice means the camera has been reset successfully.

• If you still can’t bind the camera, please contact us for more advises.



How To Use The App

Press anywhere on the camera screen to enter the Live View.

• Tap this icon to enter the full-screen mode.
• Tap this icon to enable or disable audio.
• SD Tap this icon to modify the image quality.
• Tap this icon to adjust the monitoring area.
• Tap this icon to enter the 1/4windows division menu.
• Tap this icon to record live video.
• Long press this icon to start a conversation.
• Tap this icon to take a photo of the live view.

Insert Micro SD Card (not included)
Tip: The video playback function requires a micro SD card inserted.

Open the bottom micro SD Card slot cover. Insert a micro SD card 8G, 16G and 32G micro SD cards, the format must be FAT32.
64G, 128G micro SD cards, the format must be exFAT format.
Note: Please power off the camera when inserting the micro SD card.

Install The Camera On The Wall

Paste the drilling location mark on the wall, then drill the hole according to the mark and Insert the anchors, pass the screws through the back of the bracket, and fix the top of the bracket on the wall.

1. Mark Position
   Place the mounting template where you want the camera. For wall mounting, drill four holes through four circles.
2. Mount Camera
   Affix the camera base using the screws. For wall mounting, insert four anchors into the holes and use the screws to affix the camera base over

Camera Placement Do's & Don'ts
To reduce false alarms, please note that:

1. Do not install the camera facing any objects with bright lights, including sunshine, bright lamp lights, etc.
2. Do not place the camera too close to a place where many vehicles move frequently; 15 meters (55ft) away from the vehicle is the recommended distance based on our numerous tests.
3. Stay away from the outlets, including the air conditioner vents, humidifier outlets, the heat transfer vent of projectors, etc.
4. Do not install the camera facing the mirror.
5. Keep the camera at least 1 meter away from any wireless devices, including Wi-Fi routers and phones in order to avoid wireless interference.

V

Playback

This part will cover how to play back the videos recorded to your Micro SD card. Playback is only available when the SD card is inserted and recognized by the camera.

How To View Video Playback

1. Tap to enter the playback page.
2. Scroll to select the start time of the video and click 'OK' to confirm.
3. Tap this icon  to enter the full-screen mode.
4. Drag this icon to quickly select the start time of the video.
5. Click this icon   , when the icon turn into this , indicating that it is recording, click again, the recording ends.  The recording time is displayed on the screen, and the video is stored in your phone.
6. Click this icon to play, click again to pause.
7. Tap this icon to take a live view photo. The photos are stored in your phone.
8. When the SD card space is almost full, the oldest videos will be deleted automatically, freeing up some space to store new videos.

Set Recording Video Quality

You can set the quality of the recorded video in the APP. Please follow the steps below
Steps: Go to 'Settings' > 'Video storage' > Choose the picture quality you need.

Note: You can set the recording video quality and real-time image quality separately, they are different functions. HD quality occupies the highest memory, Smooth occupies the lowest memory.

Troubleshooting

If you experience any issues with the chekoh Hercules B1 Security Camera, try the following troubleshooting steps:

1. Check that the camera is charged and turned on.
2. Make sure the camera is connected to your Wi-Fi network.
3. Restart the camera and try the setup process again.
4. Check that the camera's lens is clean and free of obstructions.
5. Move the camera closer to your Wi-Fi router if the signal is weak.

Chekoh Hercules B1 Security Camera Pros & Cons

Pros

• 1080p HD resolution
• Night vision up to 30 feet
• Motion detection with push notifications
• Weather-resistant design
• Easy installation with no wiring required

Cons

• May be more expensive than some competing cameras
• Cloud storage fees may apply

Customer Reviews

Customers are raving about the Chekoh Hercules B1 Security Camera, with many praising its high-quality video footage and easy installation. Some common complaints include the high cost of cloud storage and the short battery life when the camera is in active use.
