Introduction

The Comfier Air Compression Leg Massager FE-7204B is designed to provide effective relief for muscle soreness and fatigue in the legs, feet, and calves. Featuring 3 massage modes—pressing, kneading, and shiatsu—along with 3 intensity levels, it ensures a personalized massage experience. The heating pad adds soothing warmth for sore soles. This versatile massager is priced at $89.99, making it an excellent investment for relaxation and recovery.

Contents

• Leg and Foot Massager
• Home Adapter

Technical Data

• Name and model: Air Compression Leg Massager FE-7204B
• Power Specifications: 7.4VDC 2000mAh
• Power: Max. 24 Watt
• AC Adapter: 100-240VAC, 50/60Hz 0.7A
• Pressurization: Automatic Pressurization
• Therapy Time: 20 minutes (Automatic shut-off)
• Recommended Using: 2 times a day (i.e. 40mins in one day)
• Massage Intensity:
  • Foot: Wcak:23±2kpa;
  • Medium:27±2kpa;
  • Strong:31±2kpa
  • Calf: Weak:23±2kpa;
  • Medium:27±2kpa;
  • Strong:31±2kpa
  • Thigh: Weak:23±2kpa;
  • Medium:27±2kpa;
  • Strong:31±2kpa
• Storage conditions Dimensions:
  • in a cool, dry place
    1. approx. 71.5 x 25 cm
    2. The feet, calves, and thighs which are suitable for the users of:
  • Foot width: about 12 cm to about 16 cm.
  • Calf diameter: about 16.5 cm to about 24 cm.
  • Thigh diameter: about 19 cm to about 33cm.
• Weight: approx. 1.25kg
• Size of the control unit: approx. 20 x 5.0 x 5.5 cm

Description

The Comfier Leg Massager is designed with comfort and efficacy in mind. The device features inflatable chambers that inflate and deflate to mimic the action of a professional massage therapist. This helps in improving blood flow, reducing muscle soreness, and alleviating swelling. The massager comes with multiple pre-set programs and adjustable pressure settings, allowing you to customize your massage experience. The portable design and battery-powered operation make it easy to use whether you are at home, in the office, or on the go.

Features

• Compression massage on the Foot and Leg
• Heat therapy on the sole of the foot
• 3 heat settings
• 3 massage modes for options
• 3 levels of Massage intensity

Operating Principle

Air Compression leg massager consists of an air pump, two solenoid valves, and air compression boots working together as one unit. The air pump is connected to air compression boots via air hoses; each boot has 3 compression chambers. By inflating and deflating the air chambers through the control of working and/or idle of air pump and solenoid valves at a regular pace and different timing, it is to simulate the kneading, and stroking foot/calf and thigh. Software controls the timing and the working and/or idle of air pump and solenoid valves, cycling airflow into and out of the boots to compress the body.

WARNING
Please ensure that the polythene packing is kept away from the reach of children! Risk of suffocation!

Operating

Check Before Use

• Check that the fabric is in good condition.
• Check that it can work properly (i.e. icons of the LCD could be clearly and completely shown as the first picture indicating in Page 7) after powering on, and then select what massaging mode and intensity you prefer. Please particularly check this if it is not used for a long time.
• There may be signs of use from the boot on the skin. If you are worried about marks from use, please wear stockings or pants before utilizing the massager. Please note that the device may leave marks of use on the feet, calves, knees and thighs, which may not immediately fade.

How to connect the controller with air hose

As shown above, insert the words “R"and "L" on the hose into the corresponding "R”and "L" holes in the controller respectively.

Wearing Order

1. Put the foot into the massager, start from the foot, fix the foot first, and then stick the velcro to the calf-thigh-knee in sequence, as shown below.
2. There are 2 velcros on the thigh, which can be adjusted accordingto the individual's leg circumference.

3. It is easier to attach the knee velcro strap following adjusting the velcro straps on the foot, calf, and thigh.



Ready to start using

【POWER】

• Press 【 POWER】 button for 1-2 seconds to turn on the device. The intensity level of weak, medium and strong could be adjusted by short press on the power button. The default mode is “weak".
• Press【POWER】button for 5-6 seconds to turn off the device 【MODE】Press mode button to switch mode.
  The sequence is as follows:
  • [Pressing]: Thighs, calves and feet pressure massage. First apply pressure on your feet to massage, and then massage calf and thigh after relaxation and then massage calf/thigh/feet at the same time. Cycle in turn.
  • [Kneading]: Thighs and calves kneading massage. Massage the calves and thighs at the same time. At this time the feet are in a relaxed state.
  • [Shiatsu]: Feet Shiatsu massage Massage from toes to ankles. At this time the legs and thighs are in relaxed state.

• Press【 Heat 】button to choose Low/Medium/High/Off Heat



Note:
When using the device, please ensure you are sitting or lving down to avoid risk of falling, and to enjoy the massage.

Miscellaneous

Clean & Storage

1. Never use thinner, benzine or alcohol (which may cause malfunction, parts broken or discoloration,etc) to clean

2. Avoid dropping, slamming, or throwing the massager Do not expose unit directly under sunshine.



Wet the cloth and wring it out

If you are worried about dust, please use a neutral detergent suitable to be used in the kitchen, diluteto 5% with warm or clean water, and then damp a soft cloth to clean it .

Clean
Make sure to turn off the power and unplug the hose.Wipe the inside and outside of the leg massager and remember not to wipe with large force.

Note:

1. If rubbish or hair is caught in the velcro,remove it with a toothpick etc.
2. Do not insert foreign objects into the outlet of the hose plug.
3. A pair of boots is recommended for an exclusive use of one person only.

Storage

• Stick the velcro on the feet, ankles and calves to the corresponding positions at 1、2、3, and fold the foot part inward 4.

• Fold the ankle and calf 5, round the connecting hose and then fix it with a belt fastener 6、7.



Safekeeping

Put in a dried and cool place and avoid direct sunlight.

1. Keep out of the reach of children.

2. Do not store other objects on the surface of the controller or massager to avoid damaging the device's surface and to avoid discoloration of the product



Setup Guide

To operate the Comfier Air Compression Leg Massager FE-7204B, follow these steps:

1. Unbox the device and ensure all parts are included (massager unit, leg sleeves, power cord, and user manual).
2. Place the leg sleeves on your legs, ensuring they are snug but not too tight.
3. Connect the leg sleeves to the massager unit using the provided connectors.
4. Turn on the device using the power button and select your preferred massage mode and pressure setting.
5. Adjust the settings as needed during the massage for optimal comfort.

IMPORTANT INFORMATION

Read the instruction manual carefully before using this device, especially the safety instructions, and keep the instruction manual for future use. Should you give this device to another person, it is vital that you also pass on these instructions for use.

Explanation of symbols

This instruction manual belongs to this device.

It contains important information about starting up and operation. Read the instruction manual thoroughly. Non-observance of these instructions can result in serious injury or damage to the device.

• WARNING
  These warning notes must be observed to prevent any injury to the user.
• CAUTION
  These notes must be observed to prevent any damage to the device.
• NOTE
  These notes give you useful additional information on the installation or operation.
• Protection category II
• Lot number
• Manufacturer

Safety Instructions

Please read the following instructions carefully before putting your massage device into use to ensure trouble-free operation and optimum efficiency. Please retain these operating instructions for further use!

• Do not drop the unit, and the unit is normally used by patient himself/herself.
• Do not insert foreign objects into any openings.
• Do not attempt to disassemble the unit.
• Do not crush the pressured massager.
• Do not store the unit in direct sunlight, high humidity or dust.
• To avoid any possibility of accidental strangulation,keep this unit away from children and do not drape tubing around your neck.
• Ensure that children do not play the unit unsupervised; some parts may be swallowed.
• Do not use the device near strong electrical or electromagnetic fields generated by cell phones or other devices, they may cause interference or become interference source to the device.
• Any modification to the unit shall not be allowed.
• The product (air compression leg massager) is for adult use only.

Contraindications

• Air Compression leg massager is not intended for use if any of the following medical conditions exist.Consult with a physician whenever there is doubt whether it is clinically safe to use.
• Presumptive evidence of congestive heart failure where increase in blood returned to the heart could be detrimental
• Pre-existing deep vein thrombosis (DVT) or blood clots
• Existing hemorrhagic disease or coagulation problems
• Thrombophlebitis.
• Pulmonary embolism
• This product should not be utilized in individuals with edema, ischemic vasculardisease, or severe peripheral neuropathy.
• Do not use voltage beyond the requirement of this product
  • Do not attempt to repair or dismantle the product by yourself or any other third party.
• Do not use the product in a place where it may become wet or damp. If the unit becomes wet do not use.
• Stop using the product immediately if you feel uncomfortable or any abnormalities occur.
• Do not use this product in a high-temperature environment.
• Do not place the unit in a place where it may be in contact with flammable items, explosive items, or chemicals.
• Do not touch the unit with any sharp object or risk damage.
  • Do not use this product if any of the below apply to you:
  • Skin is infected, swollen, burnt or otherwise damaged.
• The product should be used in healthy skin.
• Please do not use the device, when cases occurred as follows:
  • You have a pacemaker or any other medical implant
  • You are suffering from heart disease.
  • You are suffering from diabetes.
  • Your bones are fragile or injured.
  • You are suffering from cancer.
  • You are currently pregnant or having menstruation.
  • Children or adolescents who are developing physically.

Before using the unit

• Always carefully inspect the power supply, the cable, the control unit and the leg massager for damage before use. Do not attempt to use a defective unit.
• Do not use the unit if there are visible signs of damage on the unit or the cable components, the unit does not work properly or the seat or the control unit have been dropped or become damp. In order to prevent hazards, always send the unit to the service center.

Operating the unit

• The leg massager must only be used for its intended purpose as described in the instruction manual.
• Using the leg massager for any other purpose invalidates the warranty.
• Never leave the unit unattended if it is connected to the power supply.
• The maximum operating time for one session is 20 minutes.
• Do not allow the leg massager to come into contact with pointed or sharp objects.
• Never put the unit down next to an electric stove or other sources of heat.
• Never use the leg massager if it is folded up or crumpled.
• Do not touch the power supply unit when you are standing in water and always take hold of the plug with dry hands.

Maintenance and cleaning

• The unit is maintenance free. If a fault does occur, just check whether the mains power adapter is properly connected.
• You may only clean the device yourself. If the device malfunctions please do not repair it yourself as this leads to the automatic expiry of all guarantees rights. Ask your specialist dealer and have repairs carried out by the service.
• Do not use the unit if there are visible signs of damage on the unit or the cable components, the unit does not work properly or the leg massager or the control unit has been dropped or become damp. In order to prevent hazards, always send the unit into the service centre.
• Do not immerse the device in water or other fluids.
• If, nonetheless, liquid should penetrate the device, unplug the mains cable immediately.
• Cleaning and user maintenance shall not be made by children without supervision.

Do not wash!

Do not dry clean!

Common Problems

A. Under what circumstances should I not use it?

Answer:
During pregnancy or immediately after birth delivery.Patients with severe blood circulation disorders cannot be used under the above circumstance.In addition, if you have a fever or any abnormality in your body, be sureto consult a doctor before use.

B. How many times can I use a day?

Answer:
The massager will automatically shut down after 20 minutes of continuous use. We do not recommend that you use a massager for more than 40 minutes in a day. Prolonged use will over-stimulate muscles and nerves and may have adverse effects.

C. Can it be used for other parts than feet, calves, knees and thighs?

Answer:
It is only for feet, calves, knees and thighs. Use in other parts may cause accident or injury

D. What size feet, calves and thighs of users are suitable for?

Answer:

• Foot width: about 12 cm to about 16 cm.
• Calf diameter: about 16.5 cm to about 24 cm.
• Thigh diameter: about 19 cm to about 33 cm

E. The strength is too strong or too weak.

Answer:
The elasticity can be adjusted by the velcro wrap. When the velcro is loosely wound, the overall use strength and pressure will be relatively weak ened. Otherwise, the overall intensity and pressure will be relatively strengthened.

F. The air in the massager hose can not exhaust.

Answer:
If a lot of air remains in the airbag, it may take some time to exhaust. Unplug the hose and wait for a while for the air to escape naturally.

G. The following sounds will be heard. Is it abnormal?

1. velcro sound is crisp
   This is the sound of the Velcro slightly opening on the massager (that isthe sound of the Velcro being pulled when the air enters the airbag).
2. Buzzing sound
   This is the sound produced by the mode effect.
   These are normal which is caused by the product design of the massager

Troubleshooting

Before requesting repairs, please confirm the following contents, and if errors persist after inspection, please contact your dealer

Comfier Air Compression Leg Massager FE-7204B Warranty

30 days unconditionally Return
Comfier product can be returned to receive a full refund for any reason within 30days. Please contact our customers service [email protected] our staff will contact you within 24 hours.

90 days refund/replace
Comfier product can be returned / replaced within 90 days if the product break down in the period of proper use.

12 months Warranty
If the product break down within 12 months in the period of proper use, customers can enjoy the relevant warranty to get them replaced.

Attention!
No warranty will be given to any force majeure and man-made causes to a defective product, such as improper care, personal tear down and willful damage, etc.

Pros & Cons

Pros

• Ergonomic Design: Comfortable and easy to use.
• Effective Relief: Provides significant relief from leg pain and swelling.
• Portable: Can be used anywhere due to its lightweight and battery-powered design.
• Customizable: Multiple massage modes and adjustable pressure settings.
• Easy Maintenance: Washable leg sleeves for hygiene and longevity.

Cons

• Limited Battery Life: May require frequent recharging with extensive use.
• Noise Level: Some users may find the sound of inflation and deflation noisy.
• Size Limitations: May not fit all leg sizes comfortably.

Customer Reviews

Customers have praised the Comfier Air Compression Leg Massager FE-7204B for its effectiveness in relieving leg pain and improving circulation. Many users appreciate the ease of use and the portability of the device. However, some users have noted that the battery life could be longer and that the device can be a bit noisy during operation.
