Introducing the Dyson DC 40 Upright Vacuum Cleaner

THANK YOU FOR CHOOSING TO BUY A DYSON APPLIANCE
If you have a question about your Dyson appliance, call the Dyson Helpline with your serial number and details of where and when you bought the appliance Most questions can be solved over the phone by one of our Dyson Helpline staff.

The Dyson DC 40 Upright Vacuum Cleaner is a powerful and versatile cleaning machine that is designed to tackle all kinds of flooring surfaces. Launched in 2011, this vacuum cleaner has become a popular choice among homeowners and cleaning professionals due to its advanced technology and user-friendly features. The estimated price of the Dyson DC 40 ranges from $300 to $400, making it a mid-range vacuum cleaner in terms of pricing.

Detailed Specifications

The Dyson DC 40 Upright Vacuum Cleaner is equipped with a range of features that make it a high-performing cleaning machine. Here are some of its key specifications:

• Weight: 15.6 pounds
• Cleaner head width: 13.4 inches
• Hose length: 6.6 feet
• Cord length: 30 feet
• Filtration: HEPA
• Dust cup capacity: 0.55 gallons
• Suction power: 245 Air Watts
• Motor: Dyson digital
• Warranty: 5 years

ASSEMBLY

IMPORTANT SAFETY INSTRUCTIONS

BEFORE USING THIS APPLIANCE READ ALL INSTRUCTIONS AND CAUTIONARY MARKINGS IN THIS MANUAL AND ON THE APPLIANCE
When using an electrical appliance, basic precautions should always be followed to reduce the risk of fire, electric shock, and injury to persons, including the following:
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY:

1. This Dyson appliance is not intended for use by young children or infirm persons with reduced physical, sensory or reasoning capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction by a responsible person concerning use of the appliance to ensure that they can use it safely.
2. Do not allow to be used as a toy. Close attention is necessary when used by or near children. Children should be supervised to ensure that they do not play with the appliance.
3. Use only as described in this Dyson Operating Manual. Do not carry out any maintenance other than that shown in this manual, or advised by the Dyson Helpline.
4. Suitable for dry locations only. Do not use outdoors or on wet surfaces.
5. Do not use to pick up water.
6. Do not handle any part of the plug or appliance with wet hands.
7. Do not use with a damaged cord or plug. If the supply cord is damaged it must be replaced by Dyson, its service agent or similarly qualified persons in order to avoid a hazard.
8. If the appliance is not working as it should, has received a sharp blow, has been dropped, damaged, left outdoors, or dropped into water, do not use and contact the Dyson Helpline.
9. Contact the Dyson Helpline when service or repair is required. Do not disassemble the appliance as incorrect reassembly may result in an electric shock or fire.
10. Do not stretch the cord or place the cord under strain. Keep the cord away from heated surfaces. Do not close a door on the cord, or pull the cord around sharp edges or corners. Arrange the cord away from traffic areas and where it will not be stepped on or tripped over. Do not run the appliance over the cable.
11. Do not unplug by pulling on the cord. To unplug, grasp the plug, not the cord. The use of an extension cord is not recommended.
12. Do not use to pick up flammable or combustible liquids, such as gasoline, or use in areas where they or their vapors may be present.
13. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
14. Keep hair, loose clothing, fingers, and all parts of the body away from openings and moving parts. Do not point the hose, wand or tools at your eyes or ears or put them in your mouth.
15. Do not put any object into openings. Do not use with any opening blocked; keep free of dust, lint, hair, and anything that may reduce airflow.
16. Use only Dyson recommended accessories and replacement parts.
17. To avoid a tripping hazard rewind the cord when not in use.
18. Do not use without the clear bin and filters in place.
19. Do not leave the appliance when plugged in. Unplug when not in use and before servicing.
20. Do not pull or carry by cord or use cord as a handle.
21. Use extra care when cleaning on stairs. Do not work with the appliance above you on the stairs.
22. Turn off all controls before unplugging. Unplug before connecting any tool or accessory.

READ AND SAVE THESE INSTRUCTIONS
THIS DYSON APPLIANCE IS INTENDED FOR HOUSEHOLD USE ONLY
POLARIZATION INSTRUCTIONS
To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not attempt to defeat this safety feature and do not change the plug in any way.

USING YOUR DYSON APPLIANCE

IMPORTANT!  WASH FILTERS

Wash filters with cold water at least every month. The filters may require more frequent washing if vacuuming fine dust.

ASSEMBLY

• Lie the appliance on its back.
• Attach the cleaner head by sliding it on to the connections on the lower front part of the ball. Ensure the electrical plug on the cleaner head fits into the twin-block connection on the body of the appliance, which is directly above the airway. Push firmly: the cleaner head will click into place.
• Stand the appliance up straight.
• Attach the wand handle by sliding it on to the top of the appliance. The spring clip in the handle will click into place.
• Ensure the hose is straight. Press the button on the hose. Slide the wand into the hose.
• Ensure the hose and wand sit in the recess of the handle. Slide the end of the wand down into the handle to secure it
• Close the wand cap.
• Slide the tool holder onto the side of the duct as shown.
• Ensure the cyclone and clear bin unit is secured to the main body of the appliance.
• Attach the tools as shown. In use, the tools can be attached to either the hose or the wand.
• Wind the cord counter-clockwise around the cord hooks. Secure with the clip.
• To watch a short online video visit:  www.dyson.com/DC40gettingstarted

Dyson DC40 Upright Vacuum Cleaner Operation

• Unwind the cord.
• Plug the appliance into the main electricity supply.
• To switch ‘ON’ or ‘OFF’ press the power button, located as shown.
• To use, recline the handle. The stabilizer stand will automatically lift up.
• After use, return the appliance to the upright position, pushing it firmly into place. The stabilizer wheels will automatically lower.
• Then unplug the appliance, coil the cable safely and put the appliance away.
• Switch ‘OFF’ the appliance, unplug and ensure it is upright before:
  • changing or using tools
  • removing the hose or airway inspection parts.
• Use the cyclone carry handle to carry the appliance.

Attachments with Dyson DC 40 Upright Vacuum Cleaner

• To release the wand, open the wand cap and pull the red tube up and away from the handle until it clicks into place.
• Should you wish to use the hose without the wand, follow the above instruction and press the red button to release the wand from the hose.

CARPETS OR HARD FLOORS

• The brush bar will always default to ‘ON’ (spinning) each time you switch the appliance ‘ON’ and recline it for cleaning.
• The brush bar will not rotate when the appliance is upright.
• To switch the brush bar ‘OFF’ (e.g. for delicate rugs and hard floors):
  • switch the appliance ‘ON’
  • recline the appliance
  • press the brush bar ‘ON/OFF’ button – the brush bar will stop spinning.
• The brush bar will automatically stop if it becomes obstructed. See ‘Brush bar – clearing obstructions’.
• Before vacuuming your flooring, rugs and carpets, check the manufacturer’s recommended cleaning instructions.
• Some carpets may fuzz if a rotating brush bar is used when vacuuming. If this happens, we recommend vacuuming in ‘hard floor’ mode and consulting with the flooring manufacturer.
• The brush bar on the appliance may damage some carpet types. If you are unsure, turn ‘OFF’ the brush bar.

LOOKING AFTER YOUR DYSON APPLIANCE

• Do not carry out any maintenance or repair work other than that shown in this Dyson Operating Manual, or advised by the Dyson Helpline.
• Only use parts recommended by Dyson. If you do not this could invalidate your warranty.
• Store the appliance indoors. Do not use or store it below 32°F (0°C). Ensure the appliance is at room temperature before operating.
• Clean the appliance only with a dry cloth. Do not use any lubricants, cleaning agents, polishes or air fresheners on any part of the appliance.
• If used in a garage, always wipe the base plate, ball and stabilizer wheels with a dry cloth after vacuuming to clean off any sand, dirt or pebbles that could damage delicate floors.

Dyson DC 40 Upright Vacuuming Cleaner

• Do not use without the clear bin and filters in place.
• Fine dust such as plaster dust or flour should only be vacuumed in very small  amounts.
• Do not use the appliance to pick up sharp hard objects, small toys, pins, paper clips, etc. They may damage the appliance.
• When vacuuming, certain carpets may generate small static charges in the clear bin or wand. These are harmless and are not associated with the main electricity supply. To minimize any effect from this, do not put your hand or insert any object into the clear bin unless you have first emptied it and rinsed it out with cold water (see ‘Cleaning the clear bin’).
• Powerful suction can cause the hose to ‘pull back’ – please take care.
• Do not work with the appliance above you on the stairs.
• Do not put the appliance on chairs, tables, etc.
• Before vacuuming highly polished floors, such as wood or linoleum, first check that the underside of the floor tool and its brushes are free from foreign objects that could cause marking.
• Do not leave the cleaner head in one place on delicate floors.
• Do not use this vacuum cleaner outdoors. The Dyson Car Cleaning Kit  (Model 08909) is intended for use only inside a garage.

EMPTYING THE CLEAR BIN

• Switch ‘OFF’ and unplug before emptying the clear bin.
• Empty as soon as the dirt reaches the level of the MAX mark – do not overfill.
• To remove the cyclone and clear bin unit, press down on the red button at the rear of the carrying handle on the cyclone.
• To release the dirt, press all the way down on the red button at the rear of the carrying handle on the cyclone.
• To minimize dust/allergen contact when emptying, encase the clear bin tightly in a plastic bag and empty.
• Remove the clear bin carefully.
• Seal the bag tightly, dispose as normal.
• To refit
  • close the clear bin base so it clicks into place
  • push the cyclone and clear bin unit into the main body of the appliance; it will click into place
  • ensure the cyclone and clear bin unit is secure.

CLEANING THE CLEAR BIN

• Remove the cyclone and clear bin (instructions above).
• To separate the cyclone unit from the clear bin press the red button to open the clear bin base. This exposes a small silver button behind the red opening mechanism. Press the silver button and separate the cyclone unit from the clear bin.
• Clean the clear bin with cold water only.
• Ensure the clear bin is completely dry before replacing.
• Do not use detergents, polishes or air fresheners to clean the clear bin.
• Do not put the clear bin in a dishwasher.
• Do not immerse the whole cyclone unit in water or pour water into the cyclones.
• Clean the cyclone shroud with a dry cloth or dry brush to remove lint and dust.
• To refit:
  • fit the cyclone shroud into the clear bin so that the silver button clicks and engages
  • close the clear bin base so it clicks into place
  • push the cyclone and clear bin unit into the main body of the appliance;  it will click into place
  • ensure the cyclone and clear bin unit is secure.

WASHING YOUR FILTERS

• Your appliance has two washable filters, located as shown.
• Check and wash the filters regularly according to instructions to maintain performance.
• Switch ‘OFF’ and unplug before checking or removing the filters.
• The filters may require more frequent washing if vacuuming fine dust.
• Wash with cold water only. Do not use detergents.
• Do not put the filters in a dishwasher, washing machine, tumble dryer, oven, microwave or near an open flame.
• To remove filter A see the ‘Wash filters’ section in this Dyson Operating Manual.
• After washing lay filter A on its side and leave at least 24 hours to dry completely before refitting.

• To remove filter A



  • turn the central locking dial on the outer cover of the ball counter-clockwise until the cover is released
  • lift off the cover

  • turn the filter one-quarter counter-clockwise to release.



• Filter B should be rinsed and tapped out until the water runs clean, then tapped out again to ensure all excess water is removed. Leave to dry completely for 24 hours.
• It is normal for the filter in the ball to turn grey in color.

• To refit filter B



  • refit the filter on to the ball
  • secure the filter by turning it one-quarter turn clockwise.
• When refitting the outer cover of the ball, keep turning the central locking dial clockwise. When it starts to click it is locked.

• To watch a short online video visit:  www.dyson.com/DC40filterwash



LOOKING FOR BLOCKAGES

• Switch ‘OFF’ and unplug before looking for blockages. Failure to do so could result in personal injury.
• Look for blockages in the wand, airways and cleaner head.
• To remove the base plate to access an obstruction, see ‘Base plate – disassembly/reassembly’.
• To look for blockages in the airway between the ball and the cleaner head  you will need to remove the cleaner head: see ‘Base plate – disassembly/reassembly’ below on how to do this.
• Beware of sharp objects when checking for blockages.
• Refit all parts securely before using.
• Clearing blockages is not covered by your warranty.

DYSON CLEARING BLOCKAGES

THERMAL CUT-OUT

• This appliance is fitted with an automatically resetting thermal cut-out.
• Large items may block the tools or wand inlet. If any part becomes blocked the appliance may overheat and automatically cut-out.
• Switch ‘OFF’ and unplug. Leave to cool down for 1-2 hours before checking the filters or for blockages.
• Clear any blockage before restarting.
• Clearing blockages is not covered by your warranty.

BRUSH BAR CLEARING OBSTRUCTIONS

• If your brush bar is obstructed, it may shut off. If this happens, you will need to remove the blockage.
• Switch ‘OFF’ and unplug before proceeding. Failure to do so could result in personal injury.
• Beware of sharp objects when clearing obstructions.
• If you still cannot clear the obstruction, please follow the instructions below to remove the base plate. This gives more access to the obstruction. Alternatively, contact a Dyson expert on the Dyson Helpline or visit the website. Clearing brushbar obstructions is not covered by your warranty.

BASE PLATE

DISASSEMBLY/REASSEMBLY

• Switch ‘OFF’ and unplug before proceeding. Failure to do so could result in personal injury.
• Lie the appliance on its front.
• Detach the red ‘C’ clip, which is on the connection between the cleaner head and the appliance. It is quite firm, but do not pull it off roughly. Use a constant, firm pressure.
• Pull the cleaner head away from the  appliance. Use a constant, firm pressure.
• At each end of the cleaner head are two levers:
  • swing them out at right angles
  • the base plate will disengage
  • lift up the top edge (of the base plate), so it rotates to the upright position
  • lift out.
• Beware of sharp objects when clearing obstructions.
• To refit the base plate:
  • fit the 3 lugs on the lower edge of the base plate into the 3 slots in the base of the cleaner head
  • swing the upper edge of the base plate down; it will click into place.
• To secure the base plate push both levers back into position so they are flush with the surface of the cleaner head.
• Refit the red ‘C ‘clip onto the cleaner head. The flatter edge of the clip fits against the cleaner head. It is easier to slide one lug into its slot before the other.
• Lie the appliance on its back.
• Attach the cleaner head by sliding it on to the connections on the lower front part of the ball. Ensure the electrical plug on the cleaner head fits into the twin-block connection on the body of the appliance, which is directly above the airway.
• Push firmly: the cleaner head will click into place.

Description

The Dyson DC 40 Upright Vacuum Cleaner is a powerful and versatile cleaning machine that is designed to tackle all kinds of flooring surfaces. Its lightweight design and maneuverable ball technology make it easy to move around furniture and obstacles, while its self-adjusting cleaner head automatically adapts to different floor types. The vacuum cleaner is also equipped with Dyson's Root Cyclone technology, which provides constant suction power and captures microscopic dust and allergens. The DC 40 also features a washable HEPA filter, which captures 99.97% of particles as small as 0.3 microns, making it an ideal choice for people with allergies.

Setup Guide

Setting up the Dyson DC 40 Upright Vacuum Cleaner is a simple and straightforward process. Here are the steps to follow:

1. Remove the vacuum cleaner from its box and attach the handle to the main body.
2. Attach the hose and wand to the handle, making sure they are securely in place.
3. Plug in the vacuum cleaner and turn it on to ensure that it is working properly.
4. Adjust the suction control to your desired level.
5. Choose the appropriate floor tool for your cleaning needs and attach it to the wand.

Troubleshooting of Dyson DC 40 Upright Vacuum Cleaner

Here are some common problems and solutions for the Dyson DC 40 Upright Vacuum Cleaner:

• Problem: The vacuum cleaner is not picking up dirt and debris.
  Solution: Check the suction control and make sure it is set to the appropriate level. Also, check the dust cup and empty it if it is full.
• Problem: The vacuum cleaner is overheating.
  Solution: Check the air filter and clean or replace it if necessary. Also, make sure the vacuum cleaner is not overloaded with debris and dirt.

5 year warranty

Your Dyson DC 40 Upright Vacuum Cleaner appliance is warranted against original defects in material and work man ship for a period of 5 years from the date of purchase, when used for private household purposes in accordance with the Dyson Operating Manual. This warranty provides, at no extra cost to you, all labor and parts necessary to ensure your appliance is in proper operating condition during the warranty period.

Pros & Cons

Pros

• Powerful suction
• Lightweight and maneuverable
• HEPA filtration
• Self-adjusting cleaner head
• Washable filter

Cons

• Expensive
• Short cord length
• Small dust cup capacity

Dyson DC 40 Customer Reviews

Customers have praised the Dyson DC 40 Upright Vacuum Cleaner for its powerful suction and maneuverability. However, some have criticized it for its high price point and short cord length. Many users have also commented on the vacuum cleaner's excellent filtration capabilities, noting that it has greatly reduced their allergy symptoms. The vacuum cleaner's self-adjusting cleaner head has also been a popular feature, with many users noting that it makes transitioning between different floor types a breeze.

Most Common Complaints about Vacuum Cleaner

The most common complaints about the Dyson DC 40 Upright Vacuum Cleaner include its high price point and short cord length. Some users have also noted that the vacuum cleaner's hose is relatively short, which can make reaching certain areas difficult. Additionally, some users have reported issues with the vacuum cleaner's brush roll, noting that it can become tangled with hair and debris.
