How to Pair: Earfun Free Pro2 ANC Wireless Earbuds User Manual

cover-image

Content

Introduction

The Earfun Free Pro 2 ANC Wireless Earbuds are a compact and affordable audio solution designed for users seeking high-quality sound and effective noise cancellation. These earbuds feature hybrid Active Noise Cancellation (ANC), capable of reducing ambient noise by up to 40dB, making them ideal for commuting or working in noisy environments.

What’s in the Box


Product Diagram

  1. Touch control zone

  2. Microphone

  3. Earbuds LED indicator

  4. Charging contactor

  5. USB – c charging port

  6. Charging case

  7. Charging dock

  8. Charging case indicator

Specifications

Bluetooth versionV5.2
Bluetooth frequency2.402GHz-2.48GHz
Bluetooth transmitted power<7dBm
Bluetooth profileA2DP, AVRCP, HFP, HSP
Maximum working range15m(without obstacle)
Battery capacity35mAh x 2(earbuds); 420mAh(charging case)
Charging time‘Thour(for earbuds ) ;  2 hours(for charging case via USB-C); 3.5 hours(for charging case via wireless charger)
Play timeANC OFF–Up t o  6 hours, Totally 30 hours with the charging case; (varies by volume level  and audio content) ANC ON-Upto4 hours, Totally 20 hours with the charging case;(varies by volume level  and audio content)
InputDC5V/1A
Dimentions6.6mm x 25mm x 28.5mm
Weight38g

Charging

  1. Remove the insulating film on the charging case for the first time.

  2. Fully charge both the earbuds and the charging case before the first-time usage.

  3.  Place earbuds back into the charging case and the earbuds will start charging .

  4. Open or close the charging case te activate the LED battery level indicator.

  5. Fully dry off the earbuds and the USB port before charging .


Connect USB-C cable for charging Wireless charging(not included)


Description

Earfun Free Pro2 ANC Wireless Earbuds come with three sizes of silicone ear tips so you may customize them to fit your needs comfortably and securely. The earbuds include a glossy finish, a small charging case, and a sleek and fashionable design. You can easily take calls and control your music with the touch controls because they are intuitive and responsive. With crisp, precise music and a powerful, deep bass, the sound quality is superb. Outstandingly, the noise cancellation feature helps you concentrate on your music or phone calls by successfully cutting out background noise.

How to Fit

Note: If the earbuds are not worn correctly, they may affect the noise cancelling effect.

  1. Choose the ear tips and ear hooks that fit your ears the best. If you couldn’t use the ear hook, please choose the one without the wing.

  2. Identify the left and right earbuds .

  3. Insert the earbuds into the canal of your ears, the ear hook should also be inserted into the upper canal of your ears.

  4. Turn and find the most comfortable position .

Pairing Your Earbuds

  1. First-time Pairing with Device

    1. Open the chargi the ilie power on and enter ito pairing mode.

    2. Activate Bluetooth on your Bluetooth-enabled device and search for other Bluetooth devices .

    3. Select “EarFun Free Pro 2” from the list of Bluetooth devices shawn (if a password is needed, type ‘0000’.


    Notes: The earbuds will automatically connect with the device they were last paired with when the case is open. Each earbud could be used independently.

  2. Connect to a New Device
    Option A

    Unpair the earbuds from the Bluetooth-enabled device that’s connected. The earbuds will disconnect from the current device and enter into pairing mode for another pair.

    Search on the new device and connect .


    Option B

    Place both earbuds b a c k into the charging case and ensure they are being charged, keep the cover open, then press and hold the two earbuds for 3 seconds until the LED lights on both earbuds flash in blue rapidly, when the earbuds will enter the pairing mode.

    Search on the new device and connect.


Setup Guide

To set up the Earfun Free Pro2 ANC Wireless Earbuds, follow these simple steps:

  1. Remove the earbuds from the charging case.
  2. Turn on Bluetooth on your phone or device.
  3. Search for available devices and select "Earfun Air Pro 2" from the list.
  4. Wait for the earbuds to connect.
  5. Once connected, you can use the touch controls to play, pause, skip tracks, and adjust the volume.

Functions

  • Open the charging case, the earbuds will automatically power on.

  • Place the earbuds back into the charging case. Close the case and the earbuds will automatically power off.


Note: If the earbuds are not connected to any device, they will automatically power off after 30 minutes to save the battery life.

earfun-icon Playing music
Play/Pause
Next  track
Volume up
Volume down
earfun-icon4 Hands free conversation
Answer/End a call
Reject a call
Answer and transfer two calls
earfun-icon8 Activate the voice assistant
Voice assistant

earfun-icon10 Noise cancelling control
Noise Cancelling/
Ambient sound/Normal
earfun-icon12 Game mode control
Game mode ON/OFF

Notes

  • Turn on the game mode can drop latency to as low as 80ms and improve the playing game and video experience, but it will shorten the connection distance. We suggest you tum off the game mode when you use the earbuds for music.

  • The normal mode provide latency about 200ms.

  • Bluetooth technology can’t eliminate latency.

Earbuds LED Indicator

Power onBlue indicator flashes 1 second
Power offWhite indicator flashes 1 second
Pairing modeIndicator flashes blue
Successfully connectedIndicator goes out
Factory resetIndicator flashes alternately i n  blue and white

Reset and Reconnecting

If you fail to build connection between two earbuds, or between earbuds and Bluetooth device, please try the following steps :

  1. Place both earbuds into the charging case.

  2. Keep the charging case open, then touch and hold the button on each earbud at the same time for at least 10s until they flash alternately in blue and white then  arbuds have been reset successfully.

  3. Delete the old connection from the Bluetooth device and reconnect “EarFun Free Pro 2″.


Pros & Cons

  • Pros
    • Advanced noise-cancelling technology
    • Excellent sound quality
    • Affordable price
    • Touch controls
    • Wireless charging case
  • Cons
    • No customizable EQ settings
    • No multipoint connectivity

Customer Reviews

Customers have praised the Earfun Free Pro2 ANC Wireless Earbuds for their excellent sound quality, noise cancellation, and affordable price. Some have noted that the touch controls can be a bit sensitive, but overall, the earbuds have received positive reviews.

The most common complaint is that the earbuds can sometimes disconnect unexpectedly, but this can usually be resolved by restarting the earbuds or resetting them to their factory settings. Some users have also noted that the charging case can be a bit difficult to open, but this is a minor issue that doesn't affect the overall performance of the earbuds.

PDF

Faqs

What is the price of the Earfun Air Pro 2 earbuds?

The estimated price of the Earfun Free Pro2 ANC Wireless Earbuds is $89.99.

Will the earbuds shut off automatically?

The earbuds will remain on as long as they are connected to a device. If no audio is in use, they will enter power-saving mode and wake up once audio is played. If the earbuds are not connected with any devices, they will automatically shut off In 30 minutes.

What Is the range of Bluetooth earphones?

Bluetooth earphones have maximum range of 49 feet (15m, no obstacle). However, the actual range will depend on usage and environment.

Why the connection is not stable and cuts out intermittently?

Please make sure there are no objects between the earphones and your Bluetecth device, and make sure there i s no radio or WIFI interference nearby.

Are the Earfun earphones resistant to water?

Earfun Free Pro2 ANC Wireless Earbuds are water-resistant, with an IPX5 rating, so you may use them in mild rain or while exercise.

The earphones are turning on, but it doesn’t connect to my device?

To connect the earbuds to your device, please check if the Bluetooth of the device is on at first, then select ‘EarFun Free Pro 2′ on the Bluetooth list to get paired. If the earbuds still can’t connect to your device, please try to reset it, or contact our customer support.

What is the name of this earbuds' Bluetooth version?

Utilizing Bluetooth 5.2, the Earfun Free Pro2 ANC Wireless Earbudsguarantees a dependable and effective connection with your gadgets.

Are the earbuds independent to use?

Please recharge it and make sure it has enough battery power. If it i s fully charged and still nothing happens or if you are not able to charge the unlit, please contact our customer support for warranty cover.

My earphones will not switch on.

You can use the touch controls on the Earfun Free Pro2 ANC Wireless Earbuds to activate voice assistants like Siri and Google Assistant with the Earfun Free Pro2.

For the Free Pro2 earbuds, what warranty does Earfun offer?

Earfun Free Pro2 ANC Wireless Earbuds normally provides an 18-month guarantee that covers manufacturing and material flaws, giving you piece of mind after your purchase.
