Introduction

With UV germicidal protection to reduce germs and permanent HEPA-type filtration to purify the air, the Therapure 240 air purifier will greatly improve the quality of the air in your home, office, or other environments. We want you to be fully satisfied with your Therapure 240. Once you’ve experienced the purity of Therapure 240 air. Launched in 2021, this air purifier is to be priced at $69.99.

Detailed Specifications

The Envion Therapur air purifier TPP240 boasts the following key features:

• Four-stage filtration system: pre-filter, True HEPA filter, activated carbon filter, and patented PlasmaTrue technology.
• Coverage area: up to 500 square feet.
• Clean air delivery rate (CADR): 240 cubic feet per minute (cfm).
• Filter replacement indicator.
• Sleep mode and quiet operation at 35 decibels (dB).
• Energy Star certified.
• Three fan speeds and automatic mode.
• Air quality indicator.
• Child lock feature.
• Remote control included.

Description

A four-stage filtration technology, a stylish design, and cutting-edge technologies come together in the Envion Therapur air purifier TPP240, a high-performance air cleaning solution. By releasing positive and negative ions that attach to pollutants and make them too heavy to stay in the air, its PlasmaTrue technology safely breaks down pollutants into harmless chemicals, so creating a healthy environment. Additionally, the Therapur TPP240 has an air quality meter that constantly modifies the fan speed to maintain the best possible air quality. This air purifier is a practical and efficient way to keep the air inside your home clean and healthy. Its energy-saving design, silent operation, and filter replacement indicator make it an excellent choice.

PRODUCT BENEFITS

• Quadruple action purification:
  1. Permanent HEPA-type filter takes particles out of the air, purifying it.
  2. UV lamp kills germs, such as  viruses and bacteria.
  3. Photo catalyst filter helps remove VOCs  (volatile organic compounds) from the air, including toxic fumes, such as paint  and new carpet fumes.
  4. ION boost refreshes the air.
• 24 hr. Timer to set run time.
• Effectively removes smoke, pollen, dust, animal dander, dust mites, mold and bacteria.
• 3 speed fan setting–lets you select the desired cleaning level.

MAIN PARTS

1. Locking Latch
2. Air Inlet Grill
3. Permanent HEPA-type filter:  the permanent filter removes small visible and non-visible particles down to 0.1  microns in size.
4. UV Lamp Cover
5. UV Lamp
6. Control Panel
7. Speed Button:  there are 3 speed settings: (low, medium and high) for you to  choose from according to the air quality needs in the room.
8. Power Button
9. Timer Button
10. LED Display
11. UV Indicator Light Bar:  Lights up when UV feature is turned ON.
12. Clean Filter Indicator:  Lights up when it’s time to clean the filter. Press Timer + Power Button for 3 seconds to reset filter indicator.
13. ION Button
14. UV/VOC Button:  the germicidal UV/VOC light is used to kill harmful airborne bacteria, germs and viruses and reduce harmful VOC (volatile organic compounds).
15. Air Outlet Grill
16. Base of Unit

OPERATING THE THERAPURE 240

Before using the Therapure 240 air purifier, please  read the following important information.
Electrical Ratings:

• 120V Setting:  120Vac, 60 Hz
• Power consumption: 55 watts at high fan speed, 3 watt UV light bulb
• Net weight: 10.3 lbs.
• Dimension (LxWxH): 9.6” x 7.9” x 26.1”

Replacement Parts:

• Lamp – TPP2400
• Filter – TPP240F

Locate a level surface on which to place the Therapure 240 air purifier near a 120V outlet (follow warnings in the “SAFETY INSTRUCTIONS” and “IMPORTANT WARNINGS” sections of this manual). Position your Therapure® at least one foot (12 inches) from the wall. Plug in the unit.

1. Do not place near fans.
2. Keep both sides of the unit at least 1 foot away from a wall.
3. Do not place the unit near curtains.

4. Placing the unit close to the source of air pollution is an effective way to improve indoor air quality.



Note: DO NOT run the Therapure 240 with a broken filter. Replace the filter if the filter has a tear or a hole in it.

Controls/Settings

• Power Control – To operate the Therapure® 240 air purifier,press the “ON/OFF” button to turn on the air purifier, press the button again to turn off the air purifier.
• Timer Control – The Therapure® 240 air purifier can be programmed to turn off after a preset amount of time. Press the “TIMER” button to program the timer. Each press will add one hour up to a total of 24 hours. Keeping the button pressed will automatically increase to 24 hours, 1 hour at a time, after that it will turn back to off.
• ION Generator – Press the ION Generator button to turn on the ions. Press it again to turn off the ions.
• Speed Control – The Therapure 240 has three different speeds of cleaning, LOW, MED and HI. Press the “SPEED” button to cycle the settings and select the fan speed you desire. The speed state will be shown on the LED display.
• UV Control – Press the UV/VOC control button “UV/VOC” to turn on the UV lamp to kill harmful airborne germs and reduce harmful VOC (volatile organic compounds). Press it again to turn off the UV and VOC.
• Clean Filter Indicator Light – The Therapure Clean Filter Indicator Light will turn on each time the filter needs to be cleaned.
• Reset Filter Control – Press down the “TIMER” and “ON/OFF” button for 3 seconds, the clean filter light will flash 3 times and then the clean filter light will turn off, indicating the unit has been reset.

CLEANING & MAINTENANCE

Keep the Therapure 240 functioning properly by cleaning the permanent HEPA-type filter each time the Clean Filter Indicator Light turns on. More frequent cleaning will be necessary if the unit is located in an area with a high level of airborne contaminants (excessive amounts of smoke, pet dander, etc.).
NOTE: Always make sure the Therapure 240 is turned off and unplugged before cleaning.

1. Vacuuming will restore performance of the permanent HEPA-type filter. However, the filter may appear stained. This is normal and does not affect performance in any way.
2. Do not use water or any household cleaners or detergents to clean the permanent HEPA-type filter.
3. The inlet grill may be cleaned (after unit is turned off and unplugged) with a vacuum or a slightly damp cloth.

Cleaning the permanent HEPA-type filter

1. Release the inlet grill by pressing on the locking latch (see diagram of Main Parts).
2. Remove the inlet grill from the unit as shown below.
3. Grasp the left and right frames of the permanent HEPA-type filter through the indentations on the sides of the filter enclosure and remove the filter.
4. To clean the permanent HEPA-type filter, use the brush or crevice attachment with a vacuum cleaner. Run the attachment along the inlet and outlet side of the filter, cleaning between the crevices as much as possible. Do not use water or any household cleaners or detergents to clean the permanent HEPA-type filter.
5. Once the permanent HEPA-type filter has been cleaned and checked for any possible damage, replace the filter back in the reverse direction described here. Plug in the unit and hold down Timer + Power On button for 3 seconds. The clean filter light will go off and your cleaning maintenance is done.

Exposing the Therapure 240 to candle/oil/fireplace soot and smoke is not recommended and will require more frequent cleaning.

Cleaning External Surfaces

1. Turn off and unplug unit.
2. Use a washcloth slightly dampened with a little water and dishwashing soap to wipe the outer case surfaces.
3. Do not allow water to slip into the internal parts as this could damage your unit and result in electrical shock and injury to you.
4. Allow the unit to thoroughly dry before use.

UV Lamp

The lifetime of the UV lamp is up to 12 months of continuous, effective operation. After this time, the bulb may remain illuminated, but its effectiveness is greatly reduced. Formaximum germicidal protection, please replace the UV bulb annually. If the lamp stops functioning or needs replacement, please visit our web site at www.envionproducts.com to order a replacement lamp. Or call 1.800.875.8577.

Caution:

1. Do not touch the glass part of the lamp. Oil from fingertips will decrease the effectiveness of the lamp.
2. Never operate the unit without a filter or with a damaged filter. UV lamp cover must be installed at all times. The UV light from the UV lamp will result in severe damage to eyes and could cause blindness.

UV Lamp Notice Warning:

UV Light is harmful to bare skin and eyes and can cause temporary or permanent loss of vision. Never look directly at the UV lamp while it is illuminated-doing so could cause loss of vision!

Before replacing the UV lamp, make sure the Therapure air purifier is turned off and unplugged. Let the lamp cool down for 5 minutes before replacing it.
Replacing the UV Lamp:

1. Release the inlet grill by pressing on the locking latch (see diagram of Main Parts).
2. Remove the two bolts used to fix the UV lamp cover and remove the cover out from the unit.
3. Unscrew the old UV lamp from the lamp base of the unit.
4. Install the new UV lamp into the lamp base of the unit.
5. Install the UV lamp cover with the two bolts on the unit.

6. Install the inlet grill on the unit.



Envion Therapur air purifier TPP240 Setup Guide

1. Setting up the Envion Envion Therapur air purifier TPP240 is easy:
2. Remove the air purifier from the box and plug it into a power outlet.
3. Remove the pre-filter and the True HEPA filter from their packaging and place them in the air purifier.
4. Turn on the air purifier and select the desired fan speed and mode.
5. Press the "Filter" button to set the filter replacement reminder to the recommended 6-12 months.
6. Use the remote control to adjust the settings as needed.

Safety Information

SAVE THESE INSTRUCTIONS
WARNING: RISK OF ELECTRICAL SHOCK
Safety precautions should always be used when operating this or any electrical appliance. Decrease the risk of electrocution, electric shock, injury or fire by reading and following all the warnings below.  Use only as described in this Therapure manual. To reduce the risk of electric shock, do   not attempt to service the product in any way other than in the manner described in the   “Cleaning & Maintenance” section of this manual.
READ ALL INSTRUCTIONS BEFORE OPERATING THE AIR PURIFIER.

• This product operates at 120V AC, 60Hz only.
• Do not run power cord under carpets, and do not cover with throw rugs.
• Do not operate the product in any greasy environment, such as in the kitchen. This product is not intended to filter oil or grease from the air.
• Do not use the Therapure 240 air purifier in bathrooms or other humid environments. Do not use near fireplaces or in areas where flammable or combustible vapors or products may exist.
• Always unplug the power cord from the electrical outlet when the purifier is not in use, before cleaning, inserting or removing parts or before moving to another location.
• Never run the air purifier unless it is fully assembled.
• To reduce the risk of electric shock, this product has a polarized plug (one blade is wider than the other). This plug will fit into a polarized outlet only one way. If the plug does not fit into the outlet, contact qualified service personnel to install the proper outlet. Do not alter the plug in any way.
• Always turn off all controls before unplugging the Therapure®240 air purifier from the outlet.
• Attempting to service the Therapure 240 air purifier in any way that is not described in this owner’s manual will cause the warranty to be voided and could cause serious personal injury to the user and/or result in considerable damage to the unit.
• Do not place the cord near a heated surface.
• Never operate the Therapure 240 if the plug or cord is damaged or appears damaged. Only qualified service personnel should replace or attempt to replace a damaged power cord.
• Never use the power cord to pick up, carry, drag, pull, or lift the Therapure 240 air purifier. Do not pull the cord against or around sharp corners and edges. This could result in injury to the user or damage to the cord.
• Always remove the plug from its power outlet by holding onto the plug itself and pulling gently.
• Never pull on the cord itself to unplug it from its power outlet.
• Use care when operating the Therapure 240 air purifier by keeping all foreign objects, fingers, body parts, hair, loose clothing and jewelry away from openings.
• Never touch the Therapure240 air purifier or its plug when your hands are wet.
• The Therapure240 air purifier is an electrical appliance. Adult supervision is required when operating the Therapure 240 in the presence of children.
• To reduce the risk of fire or electric shock, do not use this air purifier with any solid-state speed control devices.

TROUBLESHOOTING

ONE-YEAR LIMITED WARRANTY

Your Therapure 240 air purifier is warranted to be free from defects in materials and workmanship for one year from the original purchase date.

Pros & Cons

Pros

• Four-stage filtration system with PlasmaTrue technology.
• Covers large rooms up to 500 square feet.
• Quiet operation and sleep mode.
• Air quality indicator and filter replacement indicator.
• Energy Star certified and child lock feature.

Cons

• May be too expensive for some budgets.
• Filter replacements can be costly.
• Some users may find the air quality indicator to be overly sensitive.

Customer Reviews

Customers generally have positive things to say about the Envion Therapur air purifier TPP240. They appreciate its powerful filtration system, quiet operation, and easy-to-use features. However, some users have noted that the filter replacements can be expensive and that the air quality indicator may be overly sensitive. Overall, the Envion Therapur air purifier TPP240 is a high-quality air cleaning solution that is well-suited for those who suffer from allergies or asthma and are looking for a powerful and convenient air purifier.
