Introduction

The Koolatron Corona Bar Fridge COR90 is a stylish and compact refrigerator designed to keep your beverages cool while adding a touch of flair to any space. With a capacity of 90 liters, it features adjustable shelves and a reversible door for convenience. This bar fridge is perfect for game rooms, offices, or small apartments, allowing easy access to your favorite drinks. Priced at approximately $249.99, it combines functionality with a fun aesthetic.

Koolatron Corona Bar Fridge COR90 Parts & Features

Specifications

• Power Requirements: AC 115V 60Hz 60W
• Capacity: 91L / 3.2 cu.ft.
• Setting (7): -2°C (28°F) at 25°C (77°F) ambient air temp.
• Setting (1): 10°C (50°F) at 25°C (77°F) ambient air temp.
• Weight: 22 kg (48.5 lbs)

Description

The Koolatron Corona Bar Fridge COR90 boasts a sleek and modern design that complements any decor. The exterior is made of durable steel with a glossy finish, while the interior features adjustable shelves and a crisper drawer to keep your items organized. The compressor-based cooling system ensures consistent temperatures, keeping your drinks chilled to perfection. The reversible door allows for flexible placement, and the magnetic seal ensures that the cold air stays inside.

This mini fridge is not just limited to beverages; it can also store snacks, fruits, and other small items. Its compact size makes it ideal for small kitchens, offices, or entertainment areas where space is limited.

Installation

1. Unpack your refrigerator by removing all packaging materials like carton, base, foams, adhesive tape, etc.
2. Remove all accessories, internal packaging material used to hold shelves, ice tray, etc. in place.
3. Clean the remains of all adhesive tap used and remove all printed material supplied.
4. Install the refrigerator in a convenient location away from extreme heat and cold. Allow sufficient clearance between the refrigerator and side wall so the door(s) will open without obstruction. Refrigerator is not designed for recessed installation.
5. The floor on which the refrigerator should be placed must be flat, hard, solid, and even. The refrigerator should not be placed on any soft material such as foam, plastic, etc.
6. To level your refrigerator, use the two leveling legs located on the bottom front of your refrigerator. Adjust by turning the legs counter clockwise to raise or clockwise to lower your refrigerator. The door will close easier if the leveling legs are extended.
7. The following are recommended minimum clearances around the refrigerator for proper air circulation:
   • Sides: 3/4” (19mm)
   • Top: 2” (50mm)
   • Back: 2” (50mm)

Proper air circulation will help your refrigerator work at maximum efficiency.

NOTE
The appliance must be correctly connected to the power supply.

CAUTION
Care should be taken during the handling moving and use of the freezer to avoid damaging the refrigerant tubing or increasing the risk of a leak

WARNING
It is important to keep the power cord away from the compressor at the back of the refriger-ator as during operation, the compressor can reach a high temperature and could cause serious damage to the power cord.

PROTECTION FROM HEAT AND MOISTURE

• Do not install your refrigerator in any location where heavy moisture is present or if the location is not properly insulated. This refrigerator is not designed to operate in temperature setting below 55°F.
• Location for the refrigerator should be on a hard surface and away from direct sunlight and heat source, e.g., radiators, baseboard heaters, cooking appliances, etc.

DOOR ALIGNMENT

1. Remove the top hinge cover.
2. Loosen the top hinge screws using a Phillips head screwdriver.

3. Adjust the door or put a spacer in between and then tighten the screws.



STARTING YOUR NEW REFRIGERATOR
After cleaning your refrigerator thoroughly. Wipe the outside with a soft dry cloth, the interior with aclean moist cloth.

1. Insert the power supply cord into the socket.
2. Turn the thermostat dial to an initial setting of “7” for 15-20 minutes.

NOTE
As the door gets pressed in during shipping, the gasket may have to be reset. This is done to prevent the cool refrigerated air from escaping. If there is a gap between the door gasket and the cabinet, set the gasket by gently pulling it out of the seal gap.

REVERSING THE DOOR HINGE

1. Remove the top hinge cover.
2. Using Phillips Head Screwdriver, loosen and remove the screws holding the top hinge in place.
3. Remove top hinge and carefully lift off the door.
4. Remove the screw hole plugs from the opposite side and insert the plugs in the screw hole openings of the just removed screws.
5. Remove any loose items in the refrigerator and carefully turn refrigerator on its back and place in a secure area.
6. Loosen the screws holding the lower hinge bracket to the refrigerator and remove screws and bracket.
7. Remove the screws from the other side and insert in the previously removed screw holes.
8. Remove door pin by turning counter clockwise and reinsert to the underside of the bracket and tighten.
9. Align bracket and insert (2) remaining screws into the holes provided .
10. Align hole in the door with the door pin and washer and gently push down until firm.
11. Align upper hinge bracket with screw holes insert screws and partially secure, check that door and cabinet are properly aligned and then secure tightly.
12. Replace hinge cap.

Operating Instructions

NOTE
If the refrigerator has been placed in a horizontal or tilted position for any period of time wait 24 hours before plugging the unit in.

• The settings of the temperature control are "0, 1, 2, 3, 4, 5, 6, 7." Adjust the temperature control to the setting that best suits your needs. The setting of "4" should be appropriate for home or office use.
• Turning the temperature to “0” position will shut off the cooling cycle, but does not turn off the electrical power to the unit.

NOTE

• Wait 3-5 minutes before restarting if you unplug the refrigerator. The unit may fail to operate properly if restarted too quickly.
• If the ambient temperature is too high, the refrigerator may not reach the desired target temperature.
• Large amounts of foods will lower the cooling efficiency of the appliance.
• Do not place the foods on the air outlet and leave spaces for airflow.
• If you choose to change the thermostat setting, adjust thermostat control one increment at a time.

Allow several hours for temperature to stabilize between adjustments.

REFRIGERATOR INTERIOR SHELF

1. Carefully tilt the shelf up and slide forward until the shelf has been completely removed.
2. Slide the shelf back to replace.

Setup Guide

To set up your Koolatron Corona Bar Fridge COR90, follow these steps:

1. Unpack the fridge carefully and remove all packaging materials.
2. Place the fridge on a level surface away from direct sunlight and heat sources.
3. Allow the fridge to stand upright for at least 24 hours before turning it on to ensure proper oil distribution in the compressor.
4. Plug in the power cord and turn on the fridge. Adjust the temperature settings as needed.
5. Configure the shelves according to your storage needs.

CARE AND CLEANING

CLEANING AND MAINTAINING
The refrigerator should be cleaned and maintained once a month. Before doing so, YOU MUST UNPLUG THE REFRIGERATOR.

• Prepare a cleaning solution of 3-4 tablespoons of baking soda mixed with warm water. Use sponge or soft cloth, dampened with the cleaning solution to wipe down your refrigerator.
• Rinse with clean warm water and dry with a soft cloth,
• Do not use harsh chemicals, abrasives, ammonia, chlorine bleach, concentrated detergents, solvents or metal scouring pads. Some of these chemicals may dissolve, damage and/or discolor your refrigerator.

DOOR GASKET
Clean door gaskets every three months according to general instructions. Gasket must be kept clean and pliable to assure a proper seal.

• Petroleum jelly applied lightly on the hinge sides of gaskets will keep the gasket pliable and ensure a good seal.

CAUTION
To avoid personal injury or product damage always read and follow manufacturer’s instruc-tions and warnings before using any cleaning products.
WARNING
Always unplug your refrigerator before cleaning to avoid electric shock. Ignoring this warning may result in death or injury.

VACATIONS

• Short vacations: Leave the appliance operating during vacations of less than 3 - 4 weeks.
• Long vacations: If the appliance will not be used for over one month, remove all items and unplug the power cord. Clean and dry the interior thoroughly.
  To prevent odor and mold growth, leave the door open slightly: blocking it open if necessary.

MOVING YOUR FRIDGE

1. Remove all contents and store properly.
2. Securely tape down all loose items inside your appliance.
3. Turn the leveling screws up to the base to avoid damage.
4. Tape the door shut.
5. Be sure the unit stays in the upright position during transportation. Protect the outside with a blanket or similar item.

POWER INTERRUPTION
In case of a power interruption/outage, unplug the power cord from the wall outlet. Replug the power cord to the wall outlet once the power has been restored. For long period of power outage, inspect and discard the spoiled or thawed foods from the refrigerator and freezer compartments. Clean the refrigerator thoroughly before using again.

ENERGY SAVING TIPS

• The refrigerator should be located in the coolest area of the room, away from heat-producing appliances or heating ducts, and out of direct sunlight.
• Let hot foods cool to room temperature before placing in the refrigerator. Overloading the refrigerator forces the compressor to run longer and thus increase energy consumption. Foods that refrigerate too slowly may lose quality or spoil.
• Be sure to wrap foods properly, and wipe containers dry before placing in the refrigerator.
• The shelves should not be lined with aluminium foil, wax paper, or paper towels. This will interfere with cold air circulation, making the refrigerator less efficient.
• Organize food to reduce door openings and extended searches. Remove as many items as needed at one time, and close the door as soon as possible.

IMPORTANT SAFETY INSTRUCTIONS

WARNING
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury:

READ ALL INSTRUCTIONS BEFORE USING THE PRODUCT.

NOTE
If the refrigerator/freezer has been placed in a horizontal or tilted position for any period of time, wait 24 hours before plugging the unit in.

1. Use this appliance only for its intended purpose as described in this use and care guide.
2. This refrigerator must be properly installed in accordance with the installation instructions before it is used. See grounding instructions in the INSTALLATION section.
3. Never unplug your refrigerator by pulling on the power cord. Always grasp the plug firmly and pull straight out from the outlet.
4. Do not operate any appliance with a damaged cord or plug. Return appliance to the nearest authorized service facility for examination, repair or adjustment.
5. Unplug your refrigerator before cleaning or before making any repairs. NOTE - If for any reason this product requires service, we strongly recommend that a certified technician performs the service. Component parts shall be replaced with like components and servicing shall be done by factory authorized service personell, so as to minimize the risk of possible ignition due to incorrect parts or improper service.
6. Do not use any electrical device or any sharp instrument in defrosting your refrigerator.
7. DANGER – Risk of child entrapment. Before you throw away your old refrigerator or freezer, take off the doors and leave the shelves in place to that children may not easily climb inside.
8. After your refrigerator is in operation, do not touch the cold surfaces in the freezer compartment, particularly when hands are damp or wet. Skin may adhere to these extremely cold surfaces.
9. Do not refreeze foods that have been thawed completely. The United States Department of Agriculture in Home and Garden Bulletin No. 69 reads: “…You may safely refreeze frozen foods that have thawed if they still contain ice crystals or if they are still cold-below 40°F. “…Thawed ground meats, poultry, or fish that have any off-odor or off-color should not be refrozen and should not be eaten. Thawed ice cream should be discarded. If the odor or color of any food is poor or questionable, discard it. The food may be dangerous to eat … Even partial thawing and re-freezing reduce the eating quality of foods, particularly fruits, vegetables, and prepared foods. The eating quality of red meats is affected less than that of many other foods. Use refrozen foods as soon as possible, to save as much of its eating quality as you can.”
10. This refrigerator should not be recessed or built-in in an enclosed cabinet. It is designed for freestanding installation only.
11. Do not operate your refrigerator in the presence of explosive fumes.

REFRIGERANT GAS WARNINGS

DANGER
RISK OF FIRE OR EXPLOSION. FLAMMABLE REFRIGERANT USED.

• DO NOT use mechanical devices to defrost refrigerator.
• DO NOT puncture refrigerant tubing.
• Consult repair manual/owner’s guide before attempting to service this product. All safety precautions must be followed.
• Dispose of property in accordance with federal or local regulations.

GROUNDING INSTRUCTIONS

ELECTRICAL REQUIREMENTS
The electrical requirements are a 115V 60 Hz, AC only, 15A. It is recommended that a separate circuit serving only the product be provided. The product is equipped with a 3-wire cord having a 3-prong grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded. This appliance must be grounded. In the event of an electrical short circuit, grounding reduces risk of electric shock by providing an escape wire for the electric current.

The cord provided with this appliance is equipped with a grounding wire and a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

Avoid the use of three prong adapters or cutting off the third grounding prong in order to accommo-date a two prong outlet. This is a dangerous practice since it provides no effective grounding for the refrigerator and may result in shock hazard.

WARNING
Improper use of the grounding plug can result in a risk of electric shock.

Consult a qualified electrician or serviceman if:

1. The grounding instructions are not completely understood.
2. You are unsure that the appliance is properly grounded.
3. You have any questions about the grounding or electrical instructions.

POWER SUPPLY CORD

1. Avoid the use of an extension cord because of potential safety hazards under certain conditions. Have a qualified electrician or serviceman to install an outlet near the appliance.
2. If it is absolutely necessary to use longer cord sets or an extension cord, extreme care must be exercised.

• Use only a grounding type 3-wire extension cord that has a 3-blade grounding plug and a 3-slot receptacle that will accept the plug on the appliance.
• The marked electrical rating of the cord set or extension cord must equal to or greater than the electrical rating of the appliance. The longer cord should be arranged so that it will not drape over the counter top or table top where it can be pulled on by children or tripped over unintentionally.

NOTE
Neither Koolatron nor the dealer can accept any liability for damage to the product or personal injury resulting from failure to observe the electrical connection procedures.

Troubleshooting

You can solve many common appliance problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer.

Warranty

This product is warranted to the retail customer for 90 days from the date of retail purchase, against defects in material and workmanship.

IMPLIED WARRANTIES
Any implied warranties, including the implied warranty of merchantability, are also limited to the duration of 90 days from the date of retail purchase.

Koolatron Corona Bar Fridge COR90 Pros & Cons

Pros

• Compact and space-efficient design
• Energy Star certified for energy efficiency
• Adjustable shelves for customizable storage
• Modern and sleek design
• Affordable price point

Cons

• Limited capacity compared to full-size refrigerators
• No ice maker or freezer compartment
• Some users report minor noise during operation

Customer Reviews

Customers have generally praised the Koolatron Corona Bar Fridge COR90 for its performance and aesthetics. Many have noted its ability to keep drinks cold consistently and its ease of setup. However, some users have mentioned minor issues such as slight noise during operation and limited storage space.
