Introduction

The Miufly Indoor & Outdoor Body Camera EH15 is a versatile surveillance device designed for both indoor and outdoor use, ensuring comprehensive security coverage. Manufactured by Miufly, this body camera features 1080p HD video recording, night vision capabilities, and a wide-angle lens for enhanced monitoring. Launched in 2023, it is priced at approximately $89. With its durable design and user-friendly interface, the EH15 is ideal for personal safety and professional security applications.

Product Overview

MIUFLY EH15 Body Camera is ruggedly designed to provides law enforcement, security and emergency personnel with super Full HD 1296p video recording capabilities, and one-button recording and activation. When worn on the front of clothing, an ultra-wide 140° field-of-view lens captures what happens in the field as accurate information for further analysis. Featuring a 32GB (64GB) internal memory, pre-record buffering, importance tagging, and integrated Infrared LEDS for night vision, EH15 is equipped to perform in any conditions.

With full featured and adaptable operation, EH15 can record video and audio simultaneously, or audio only for suspect interrogations and victim/witness statements. EH15 is fully configurable and offers multiple recording qualities, super full HD 1296p video down to 720x480 resolution, giving users the options to adjust the recording quality according to their storage capabilities.

EH15 can also take up to 20 high-resolution snapshots, which, together with video, can be viewed on backlit, 2 inch LCD color screen or on an HDTV screen using a HDMI connector. Security protocols of the device are secure to prevent accidental deletion of evidence or modification of system settings. Video footage is also digitally watermarked with the user ID, time and date, ensuring the authenticity of collected video of the event. The internal GPS receiver provides automatic location tagging of video- and still-captures, offering irrefutable substantiation of where and when the audio and video were recorded..

Box contents

• MIUFLY Body Camera
• Charging Dock
• USB Cable
• USB Adaptor
• 360 Degree Rotatable Clip
• User Manual
• Should Clip
• Car Charger

Technical Specifications

Features

Description

The miufly Indoor & Outdoor Body Camera EH15 is built with a rugged and ergonomic design, ensuring it is comfortable to wear for extended periods. The camera features a wide-angle lens that captures a broad field of view, making it ideal for surveillance and evidence collection. The device also includes a built-in microphone that records clear and audible audio.

The EH15 is designed with user convenience in mind. It has a simple one-button operation for quick start and stop of recordings, and it comes with a clip and magnetic mount for easy attachment to clothing or other surfaces.

Main Menu Optional Detail

To enter the setting menu:

1. Press Menu () button and then enter a password.
2. Enter the password by using the following commands:
   • Press Scroll Up () button to change the character to the previous letter or number.
   • Press Menu () button to change the character to the next letter or number.
   • Press OK () button to move to the next character PS: The default password is 000000.
3. After selecting the last character, press OK () button to enter the setting menu.

To navigate the settings menu:

• Press Menu () button to select next setting or option.
• Press Scroll Up () button to select the previous setting or option.
• Press OK () button to move to confirm your selection or enter the submenu.
• Press Power () button to return to the previous menu without changing anything.

Following is a list of the available settings and options. The bold items are the default options.

1. Power on/off
   1. Power on: when camera is off, press and hold power () button for 3 seconds, camera will power up and enter standby mode;
      • Boot up image shows up;
      • Working status LED indicator turns green;
      • Boot up music;
      • Camera vibrates;
      • Camera voice “beeps” when [Record Warning] is ON.
   2. Power off: press and hold power () button for 3 seconds to turn off working-status camera:
      • Save video/audio files before power-off;
      • Working status indicator turns off;
      • Power off image;
      • Power off music;
      • Camera vibrates.
2. Resetting
   Press reset button (inside HDMI port) to have camera resetting when camera works abnormally. Please note: DO NOT PRESS this button except for maloperation.
3. Infrared Night Vision
   While under dark circumstances, infrared LED will help to record clear image or video in HD.
   In standby mode, PRESS Menu () button to navigate. Find option 【Infrared】, PRESS OK () button to enter sub-menu: Manual & Auto, press OK () button to select.
   1. Auto infrared mode:
      In low light situations (3 Lux), IR LEDs will be turned on automatically, camera switches on infrared filter lens, video image turn black and white.
      Otherwise, when circumstance brightness grew up, IR LED turns off, and image becomes colorful again.
   2. Manual infrared mode:
      When night vision is needed, PRESS IR light button to switch to Infrared mode, IR LEDs will be turned on, black and white image. PRESS this button again to turn off IR LEDs, image becomes colorful.
4. Take Photos
   In standby, PRESS snapshot () button to take a snapshot, with a sound “Click”, LED working status indicator will flash green once, and the photo stored. The photo resolution and quality can be set in the settings.
5. Snapshot
   While camera is recording video, PRESS snapshot () to take a snapshot.
   On the LCD display, there will be a flashing green square, which refers to that a photo has been taken while video is recording.
6. Video Recording
   In standby mode, PRESS record () button, indicator LED flashes Alternate Red and Green, then camera “beep” and vibrates, starts video recording. If the voice is on, camera will start video recording with indication voice. PRESS record () button again, video recording stops and camera switches to standby mode, working status indicator changes to green.
7. Motion Detection
   In settings, please find [Motion Detect] option. PRESS OK () button to select.
   Sub options: ON/OFF
   PRESS record () button to activate motion detection, any moments are detected, camera will start recording. If there are no movements for 10 seconds, camera will stop recording. Once any movements detected, camera will start video recording again.
8. Audio Recording
   In standby mode, PRESS Audio () button, with a beep and camera vibration, LED indicator turn yellow and flashes, audio recording started. PRESS Audio () button again to stop audio recording.
9. One Button recording
   When camera is powered off, HOLD Record () button, camera will initiate and start video recording immediately.
10. Tag Important file
    In audio or video recording, PRESS importance tag () button, camera vibrates, the audio or video file will be tagged important, with a yellow icon () showing on the top right of the LCD screen.
11. Device ID/ User ID
    In standby mode, PRESS Menu () button to enter settings. Find [ID setting], PRESS OK () button to select. Enter the password, the default password is: 00000. After right password entered, the Device & Person SN interface show up, 5 characters for device and 6 characters for Person. PRESS scroll-Up () button or Scroll-down () button to highlight a character, then PRESS OK () button to select.
12. Time Setting
    In standby mode, PRESS Menu () button to enter settings. Find Time bar, for example, 2008/02/02 07:40. PRESS OK () button and enter the password, then users can change the date and time.
    Press Scroll-Up () button or Scroll-down () button to highlight a character, the PRESS OK () button to select.
13. USB Driver
    After being connected to PC, password interface shows up, please enter the password (default password is 000000), the camera will be recognized by the computer.
14. Playback
    1. In playback mode, PRESS OK () to pause/resume playback; PRESS Scroll-Up () button to rewind, PRESS Scroll-down () button to fast forward, then PRESS OK () to play normally. You can fast forward or rewind 2x, 4x, 8x, 16x, 32x, 64x, 128x.
    2. Exit the Playback mode: In Playback mode, PRESS Record () button to get back to standby mode step by step.
15. External Mini Camera (optional)
    Connect the external camera to USB port, the audio and video signal input will be switched to external camera automatically. Meanwhile, the external camera can be controlled by the main body camera.
    Drive-by-wire button operating instructions: When the camera is in standby mode: A, HOLD the button for 3 seconds to have the external camera start/stop video recording; B, PRESS the button to take a picture through external camera.
16. Charging
    When camera batter is low, the battery icon will flash in the display, and you will hear a alert tone. When this happens, charge the camera.
    While camera is charging, indicator lights blue and will turn off after camera is fully charged. It will take approximately 4 hours to fully charge the camera.
    Charging methods:
    1. Use a USB cable to connect camera’s USB port to one of the following:
       • A USB port on your computer (powered on)
       • The included USB power adapter (connect to a power outlet)
       • The included car charger.
    2. Attach camera to the docking bay. Use a USB cable to connect the docking bay to one of the following:
       • A USB port on your computer (powered on)
       • The included USB power adapter (connect to a power outlet)
       • The included car charger.

17. GPS tag
    When GPS turns on, camera will record specific location information along with body camera footage, and the tags are stored in the video metadata, pinpointing the location when the footage is reviewed.
    There will be GPS coordinate (longitude and latitude) showing up in the upper right corner of LCD screen when GPS signal is received.



    To view GPS tags, User will need to use GPS player (stored in camera and Google Earth (go to https://www.google.com/earth/desktop/ to download Google Earth to your PC)
    GPS Player



    Run GPS player and Google Earth. Open the video (with GPS tags ) footages by the GPS player.
    PS: you could choose related maps in your region.



    Click Google Earth icon to review GPS route on Google Earth program.
    (PS: make sure Google Earth program is working in your PC.)



    GPS tags on Google Earth.



Setup Guide

To operate the miufly Indoor & Outdoor Body Camera EH15,

• Start by charging the device using the provided USB-C cable.
• Once charged, insert a microSD card into the slot located on the side of the camera.
• Attach the camera to your clothing using the clip or magnetic mount.
• Press the single button to start recording; the LED indicator will flash to indicate that the camera is active.

To stop recording

• Press the button again.

For configuration

• Connect the camera to your computer via the USB-C cable and use the provided software to adjust settings such as date and time, resolution, and more.

Miufly Indoor & Outdoor Body Camera EH15 Troubleshooting

Cannot enter Menu of Body Camera

• A. Stop Recording prior to entering Body Camera’s menu by pressing Record button.
• A. Body Camera supports a six character alphanumerical password format. Prior to entering menu of Body Camera, ensure that correct password is entered.

IR are not turning on

• A. IR turn on automatically only if they’re set to Auto in the Infrared menu. Otherwise the Infrared will remain disabled.

Indicator LEDs are not lit

• A. If the camera is powered up and Status LEDs are not lit go to Body Camera’s menu and select LED Light menu option. Ensure that it is set to ON. 6.4 Body Camera only records for short periods of time
• A. In event of Body Camera recording for brief moments then shutting off, please ensure that menu option Auto Power OFF is set to OFF.

How do I delete videos on the body camera?

Considering the needs of law enforcement, all recorded videos, pictures and sound recording ONLY can be deleted on the computer via USB cable.

The GPS map does not work.

You can open the GPS track through Google earth. Please make sure Google Earth program is working in the computer. If you don’t know how to use please contact us.

Pros & Cons

Pros

• High-quality video and audio recording
• Infrared night vision for low-light conditions
• Long-lasting battery life up to 8 hours
• Compact and lightweight design
• Easily attachable with clip and magnetic mount
• Supports large storage capacity with microSD cards

Cons

• Limited storage without microSD card
• No Wi-Fi or Bluetooth connectivity for real-time streaming
• May require periodic software updates

Customer Reviews

Customers have praised the miufly Indoor & Outdoor Body Camera EH15 for its robust build and excellent video quality. Many users appreciate its ease of use and the long battery life, making it a reliable tool for their daily needs.

Some common complaints include the lack of Wi-Fi or Bluetooth connectivity, which limits real-time streaming capabilities. However, overall feedback indicates high satisfaction with the product's performance and durability.
