Introduction of Pentair Filter Housings 3G Slim Line

The Filter Housings 3G Slim Line is a high-performance and space-saving filtration solution for pools and spas. With its streamlined design, this product offers maximum flow while minimizing pressure drop. It is estimated to be priced around $700 to $900 and was launched in 2021.
Pentair 3G Slim Line Housings are the perfect choice for low-flow filtration applications. Their Pentair Filter Housings 3G Slim Line design and high chemical compatibility make them ideal for those challenging applications. Caps are manufactured from reinforced polypropylene in black, blue, and white. Three different style caps add to the flexibility of these housings. The mounting bracket cap allows the housing to be mounted to a single or multiple housing bracket. The bracket is built into the integral bracket cap. The meter mount cap’s gauges indicate when the cartridge is dirty and allow you to get the most out of your cartridges. Housings are available with either clear or opaque sumps with the clear housings being manufactured of Styrene-Acrylonitrile (SAN) and the opaque housings are polypropylene. Clear housings offer on-site examination of the flow, cartridge life, and performance. Opaque housings are molded from reinforced polypropylene and offer outstanding chemical compatibility.

Detailed Specifications

The Filter Housings Slim Line is made of durable materials, designed to withstand harsh chemical environments and extreme temperatures. It has a flow rate of 150 GPM and a filter area of 3 square feet. The product dimensions are 22 x 22 x 66 inches, and it weighs approximately 80 pounds.

• Housing – Polypropylene (opaque) or Styrene Acrylonitrile (clear): O-Ring – #237 EPDM
• Cap – Reinforced polypropylene: 40-125o F (4.4-51.7o C)
• Button Assembly – 300-Series stainless steel, EPDM, and polypropylene: Maximum Pressure125 psi (8.6 bar)

CAUTION: Protect against freezing to prevent cracking of the filter and water leakage.

ACCESSORIES

Description of Pentair Filter Housings Slim Line

The Pentair Filter Housings 3G Slim Line is a reliable and efficient filtration solution for pools and spas. Its slim design makes it easy to install in tight spaces, and its high flow rate ensures clean and clear water. The product is also easy to maintain, with a large opening for easy access to the filter elements. Its durable construction ensures long-lasting performance, even in the harshest environments.

FEATURES/BENEFITS

• 10" housings available with clear or opaque sump
• Buttress threads for additional strength and easier cartridge changes
• John Guest and NPT threaded connections are offered in 1/4", 3/8", and 1/2"
• Cap styles include mounting bracket, integral bracket, meter mount, and optional pressure relief bleed valve
• Housing accepts DOE (double open-end) cartridges
• Leak-proof seal
• The pressure relief button helps reduce pressure in the housing when changing cartridges

Setup Guide of Pentair Slim Line

To set up the Pentair Filter Housings, follow these steps

1. Install the filter housing in a level location, ensuring that it is securely fastened to the ground or a solid surface.
2. Connect the plumbing, using the included adapters and clamps to ensure a watertight seal.
3. Install the filter elements, following the manufacturer's instructions.
4. Fill the filter housing with water, then turn on the pump and check for leaks.
5. Backwash the filter as needed, following the manufacturer's instructions.

PRESSURE DROP VS FLOW RATE

Troubleshooting

If you experience problems with the Filter Housings 3G Slim Line, try these troubleshooting steps

1. Check for leaks in the plumbing connections, and tighten as necessary.
2. Make sure that the filter elements are properly installed and tightly secured.
3. Check the pressure gauge, and adjust the flow rate as needed to maintain optimal pressure.
4. Backwash the filter regularly to remove trapped debris and maintain optimal performance.
5. If the problem persists, consult the manufacturer's troubleshooting guide or contact Pentair customer support for further assistance.

Pros & Cons of Pentair 3G Slim Line

Pros

• Space-saving slim design
• High flow rate and filter area
• Durable construction for long-lasting performance
• Easy to maintain and clean

Cons

• Expensive compared to other filter housings
• May require professional installation

Customer Reviews of Pentair Filter Housings 3G Slim Line

Customers have praised the Filter Housings 3G Slim Line for its high flow rate, durable construction, and easy maintenance. However, some have noted that the product is expensive and may require professional installation. The most common complaint is related to the high price point, but users have noted that the product's performance and durability make it a worthwhile investment.
