LED Medicine Cabinet BLMC Introduction

The Queen Fun Bathroom LED Medicine Cabinet BLMC is a stylish and functional addition to any bathroom, designed to enhance both storage and lighting. Featuring a sleek mirror with adjustable LED lighting, it allows users to customize the brightness and color temperature for optimal visibility. The cabinet can be installed either recessed or surface-mounted, making it versatile for various spaces. Priced at $249, it combines modern design with practical features for everyday use.

PACKING LIST

• The quantity of A/B screws varies according to the size of the product.
• BLMD3032 needs 5 screws,BLMD3630 needs 6 screws.
• We offer additional 2 screws to prevent screw missing in case.

USE TIPS

1. Please use in safe voltage range. (100V-120V)
2. Do not strike the mirror with hard or pointed items.

DANGER: Before installation, make sure the main power has already cut off.

WARNING: The installation must be performed by a qualified licensed electrician.

PRODUCT SPECIFICATION

Note: Sockets and USB output voltage is 5V, current is 3.6A, power is 18W,not suitable for high power appliances.

BEFORE INSTALLATION

1. Important Safety Instructions:
   • Please read all instructions carefully before assembling the item.
   • Assembly by two or more adults is highly recommended.
   • To connect the wires to electrical junction box, a qualified technician or electrician is highly recommended.
   • Before installation, component addition or replacement, please make sure the main power has already cut off.
   • Ensure the assembly location(solid stone / brick walls) can bear the weight of the complete fitting.
   • To prevent injury, the mirror must be installed according to this instruction.
2. Pre-assembly:
   • After opening the package, please inspect the accessories according to the packing list in order to ensure the received accessories are complete.
   • Ensure the assembled voltage is between 100V and 120V.
     If the voltage exceeds 120V, please use a transformer.
   • You can connect the wires directly to your junction box or a plug.

   • Before assemble the medicine cabinet on wall, please try to plug and power the product at first, to make sure that the lighting effects and the functions mentioned in section 3 work.
     If so, you can start to install it.



3. Before installation, please check to make sure the mirror is working properly :



   1. Left button: Color temperature adjustment.
      Press and hold the touch to make the color temperature stepless adjustment(6000K to 3000K).
      Memory function: The color temperature will keep the last choice.
   2. Middle button: Light Brightness adjustment.
      Press and hold the button to make the brightness stepless adjustment(100% to 20%).
      Memory function: The light brightness will keep the last choice.
   3. Right button: Anti-fog function.
      Note: The anti-fog film will automatically turned off one hour. Remember to turn off the switch to prevent the energy waste when you don't use it.
   4. Left/Right button: Time function.
      In standby state, long press the color temperature button for 5S to wake up the clock adjustment function. At this time, the hour can be adjusted. After 5 seconds, the minutes can be adjusted.
      The color temperature key is -, and the light Brightness key is +.
   5. Induction Led Strip.
      The top light bar will automatically on and off as the door open and close.
      Note: The color temperature key and the light Brightness key can turn the light on or off.

Description

The Queen Fun Bathroom LED Medicine Cabinet BLMC boasts a contemporary design that fits seamlessly into any bathroom setting. The cabinet features a large, anti-fog and anti-moisture treated glass mirror that ensures a clear view even in humid conditions. The interior is well-organized with multiple shelves and compartments, allowing you to store a variety of items from medications to skincare products. The adjustable LED lighting provides the perfect amount of illumination, making it easy to see what you're doing without harsh shadows.

The exterior is made from high-quality materials such as stainless steel and glass, ensuring durability and a sleek appearance. The wall-mounted design makes it easy to install and keeps the floor clear, adding to the overall sense of space in your bathroom.

INSTALLATION

Advised Installation Tools (Not offered)

HYDRAULIC HINGE ADJUSTMENT METHOD

Open the "DTC" cover in the direction of the arrow.

1. Adjust the door counterclockwise to move to the right,
   Turn clockwise to adjust the door to move to the left.

2. Twist counterclockwise to loosen it,You can adjust the front and rear direction of the door.
   Tighten clockwise after adjustment.



METHOD 1: FOR HANGING WALLS

1. Before installation, place the medicine cabinet against the wall, keep an appropriate safety distance from faucets and lights, at least 3 inches, confirm the installation height and bracket installation position, use a level to level the bracket, and mark the hole position on the wall.



   Note: Two-person installation.

2. Use a 1/4” (6mm) drill to drill holes at the marked points to a depth of 13/4” (45mm), then apply the wall anchors with a hammer. Mount the lower bracket to the wall with screws.



   Note: Please wear goggles and pay attention to safety.

3. Lift the medicine cabinet and place it securely in the upper bracket. Holding the cabinet in an upright position, secure the lower bracket in the grooves on the bottom of the cabinet.



   Note: Gently shake the mirror to ensure that the mirror is securely installed.

4. Install side mirrors.



   Note: No need to install side mirror if recessed.

5. Plug the medicine cabinet. You can use the plug directly or connect the wire to a standard switch lighting circuit.
   Use the plug
   After hanging the mirror, plug it directly.



   Hardwire Installation
   Cut the plug and connect the mirror's wire to the power by the wire connectors.
   DANGER: Before installation, make sure the main power is cut off.
   BLACK WIRE --- POWER SUPPLY L (LIVE)
   WHITE WIRE --- POWER SUPPLY N (NEUTRAL)
   GREEN WIRE --- POWER SUPPLY E (EARTH)
   WARNING: This mirror must be earthed.



   METHOD 2: FOR RECESSED

6. The wall space is set aside in advance based on the size of the recessed led medicine cabinet.
   Single door



   Double door



7. Plug the recessed led medicine cabinet.
   Hardwire Installation
   Cut the plug and connect the mirror's wire to the power by the wire connectors.
   DANGER: Before installation, make sure the main power is cut off.
   BLACK WIRE --- POWER SUPPLY L (LIVE)
   WHITE WIRE --- POWER SUPPLY N (NEUTRAL)
   GREEN WIRE --- POWER SUPPLY E (EARTH)
   WARNING: This mirror must be earthed.



8. Install the recessed led medicine cabinet.
   Note: Gently shake the mirror to ensure that the mirror is securely installed.

9. Insert the glass shelves.
   Note: The glass shelves varies according to the height of the product. BLMC3630 has only two glass shelves.



10. The installation has completed!



Setup Guide

To set up your Cabinet BLMC, follow these steps:

1. Unbox the cabinet and all included hardware.
2. Locate the wall studs in your bathroom to ensure secure mounting.
3. Mark the wall where you will drill the holes for the mounting screws.
4. Drill the holes and insert the wall anchors.
5. Hang the cabinet on the wall, ensuring it is level and secure.
6. Plug in the power cord and turn on the LED lights to test them.
7. Organize your bathroom essentials inside the cabinet.

Troubleshooting

If you encounter any issues with your Queen Fun Bathroom BLMC, here are some common problems and solutions:

• LED Lights Not Turning On: Check if the power cord is properly plugged in. Ensure that the on/off switch is in the correct position.
• Foggy Mirror: Use a cloth and mild soap solution to clean the mirror. Ensure that the anti-fog coating has not been damaged during cleaning.
• Loose Mounting: Check if all screws are tightened securely. If necessary, re-drill holes or use additional wall anchors for extra support.

Instructions and Warnings: Always follow the manufacturer's instructions for installation and maintenance. Avoid using abrasive cleaners or harsh chemicals on the mirror or LED lights.

Pros & Cons

Pros:

• Energy-Efficient LED Lighting: Provides bright illumination while saving energy.
• Ample Storage: Multiple shelves and compartments keep your bathroom essentials organized.
• Durable Construction: Made from high-quality materials such as glass and stainless steel.
• Easy Installation: Wall-mounted design with clear installation instructions.
• Aesthetic Appeal: Sleek and modern design that fits well with any bathroom decor.

Cons:

• Higher Cost: Compared to basic medicine cabinets, this model is more expensive due to its advanced features.
• Dependence on Electricity: Requires a power source, which may be a drawback for some users.
• Complex Cleaning: The LED lights and mirror require careful cleaning to maintain their condition.

Customer Reviews

Customers have praised the Queen Fun Bathroom LED Medicine Cabinet BLMC for its bright LED lighting and ample storage space. Many have noted that the anti-fog mirror is particularly useful in humid bathroom environments. However, some users have mentioned that the installation process can be a bit challenging without additional help.

Common complaints include the higher price point compared to other medicine cabinets and the need for careful cleaning of the LED lights and mirror to prevent damage.
