Introducing the Razor DeltaWing Electric Scooter

Get ready to take your scooter experience to the next level with the DeltaWing Electric Scooter! This innovative and exciting new product is perfect for both kids and adults who are looking for a fun and eco-friendly way to get around. The estimated price for the Razor Electric Scooter is $299.99, and it is set to launch in Spring 2023. This scooter is perfect for those who want to stand out from the crowd, with its unique and stylish design that is sure to turn heads.

Detailed Specifications

The DeltaWing Electric Scooter boasts some impressive features that make it a must-have for anyone looking for a top-of-the-line scooter. It has a powerful 250-watt motor that can reach speeds of up to 15 mph, making it a great choice for those who want to get where they're going quickly. The scooter also has a range of up to 15 miles on a single charge, so you can ride for longer without having to worry about recharging. Other key features include a sturdy aluminum frame, a weight capacity of 198 pounds, and a quick-charge time of just 3 hours.

DELTAWING PARTS

Keep your DeltaWing working for years with genuine Razor parts.

1. Handlebar Grips (x2)
2. Handlebars
3. Brake Lever Assembly
4. Collar Clamp
5. Headset (Upper/Lower)
6. Front Fork
7. Caliper Brake with Brake Pads
8. Front Wheel Complete
   1. Cap Nuts (x2)
   2. Spring Washer (x2)
   3. Safety Washer (x2)
9. Caster (x2)
   1. Caster Bolt (x2)
10. Rear Wheel (x2)
    1. Axle Bolt (x2)
11. Right/Left Platform

Features

Required Tools

Box Contents

• DeltaWing
• Allen Wrenches
• Owner’s Manual

Description

The Razor DeltaWing Electric Scooter is a high-performance scooter that is perfect for both kids and adults. It has a sleek and stylish design that is sure to turn heads, and it is made with high-quality materials that ensure its durability and longevity. The scooter is easy to ride and maneuver, with a thumb-activated throttle and a hand-operated brake. It also has a wide foot platform that provides stability and comfort during use. The Razor DeltaWing Electric Scooter is a great choice for those who want to have fun while also being eco-friendly.

BEFORE YOU BEGIN

Remove contents from box and check parts against part diagram below. Remove the separators that protect the components from damage during shipping. Inspect the contents of the box for scratches in the paint, dents or kinked cables that may have occurred during shipping. Because the DeltaWing is partially assembled and packed at the factory, there should not be any problems even if the box has a few scars or dents.

 Estimated Assembly and Set-Up Time

Allow up to 15–20 minutes for assembly. Razor recommends assembly by an adult.
WARNING: DO NOT USE NON-RAZOR PRODUCTS WITH YOUR DELTAWING. The DeltaWing has been built to certain Razor design specifications. The original equipment supplied at the time of sale was selected on the basis of its compatibility with the frame, fork and all other parts. Certain aftermarket products may not be compatible and will void
the warranty.
Product I.D. Code

1. Side of Frame
2. Barcode on Side of Box (not shown)

 Attaching the Front Wheel Assembly
Tools Required: Two (2) 5 mm Allen Wrenches

1. Using two (2) 5 mm Allen wrenches, remove the two coupling bolts from the frame.
2. Insert the front wheel assembly into the frame and align the holes on the downtube with the holes on the frame.
3. Reinsert coupling bolts. Tighten using two (2) 5 mm Allen wrenches.

 Attaching the Handlebars

1. Insert the handlebars onto the front fork. You may need to slightly loosen the collar clamp using a
   5 mm Allen wrench to allow the handlebars to slip onto the front fork.  Note: The cable and wire brake assembly must not wrap around the handlebars. Sharp bends or twisting of the brake cable can cause the brake to malfunction.
2. Turn the front wheel so that the brake is in front of the fork. Using a 5 mm Allen wrench, tighten the two (2) bolts on the collar clamp. The collar clamp is properly tightened when the handlebars cannot be twisted out of alignment with the front wheel. Note: Make sure the front wheel is pointed straight ahead, the handlebars square to the front wheel, and the Razor logo facing the front.

WARNING

• Failure to properly install the front wheel assembly and handlebars may cause the rider to lose control and fall. If you are having difficulty understanding these instructions, please contact Razor Customer Service for assistance.
• Failure to properly install the front wheel assembly and handlebars may cause the rider to lose control and fall. If you are having difficulty understanding these instructions, please contact Razor Customer Service for assistance.
• Do not over inflate, as this could damage tire or wheel.

Note: The pressurized air supplies found at gasoline stations are designed to inflate high-volume automobile tires. If you decide to use such an air supply to inflate your DeltaWing tire, first make sure the pressure gauge is working, then use very short bursts to inflate to the correct PSI. If you inadvertently over-inflate the tire, release the excess pressure immediately.
 Inflating the Tire
The tire is inflated when shipped, but it invariably may lose some pressure between the point of manufacturing and your purchase. Always inflate tire to the correct PSI before first time use.

Using a bicycle-style tire pump equipped for a Schrader-type valve, inflate the front tire to the correct PSI indicated on the sidewall of the tire.

PRE-RIDE CHECKLIST

• Brake
  Check the brake for proper function. When you squeeze the lever, the brake should provide positive braking action.
• Wheels and Tires
  Impacting the wheels against any hard surface can damage the wheels. Wheels are not covered under your limited warranty. Periodically inspect the tires for excess wear, and regularly check the tire pressure and reinflate as necessary. If you get
  a flat tire, the inner tube can be patched or a new tube can be purchased from Razor or an authorized service center.
• Frame, Fork and Handlebars
  Check for cracks or broken connections. Although broken frames are rare, it is possible for an aggressive rider to run into a curb or wall and wreck, bend or break a frame. Get in the habit of inspecting yours regularly.
• Hardware/Loose Parts
  Before every ride, check all parts, such as nuts, bolts, cables, fasteners, etc., to ensure they are secure and assembled correctly. There should not be any unusual rattles or sounds from loose parts or broken components. If the unit is damaged, do not ride. Reference “Safety Warnings” on page 1 of this manual.
• Safety Gear
  Always wear proper protective gear, such as an approved safety helmet. Elbow pads and kneepads are recommended. Always wear athletic shoes (lace-up shoes with rubber soles) and keep shoelaces tied and out of the way of the wheels. NEVER RIDE BAREFOOTED OR IN SANDALS.

USAGE

• How to Ride
  Place both hands on the handlebars. Place one foot on the platform directly above the caster. Push off with the other foot then place foot on the other platform directly above the caster. Slightly bend knees. With handlebars straight, swing hips and legs side to side. Shifting weight on the platforms from right to left in sync with hips and legs. The side to side motion acts to self propel the DeltaWing. No pushing required.
• How to Stop
  • Apply hand brake.
  • Step off the DeltaWing to the side or rear. Do not step or jump in front of moving DeltaWing platforms.

Note: Do not step off of platforms until unit has come to a complete stop.

SAFETY WARNINGS

• AN IMPORTANT MESSAGE TO PARENTS: This manual contains many warnings and cautions concerning the consequences of failing to maintain, inspect or properly use your DeltaWing™. Because any incident can result in serious injury or even death, we do not repeat the warning of potential serious injury or death each time such a possibility is mentioned.
• GENERAL WARNING: Riding the DeltaWing can be a hazardous activity. Certain conditions may cause the equipment to fail without fault of the manufacturer. Like other wheeled products, the DeltaWing can and is intended to move, and it is therefore possible to lose control, fall off and/or get into dangerous situations that no amount of care, instruction or expertise can eliminate. If such things occur, your child can be seriously injured or die, even when using safety equipment and other precautions. USE COMMON SENSE.
• APPROPRIATE RIDER USE AND PARENTAL SUPERVISION
  Direct adult supervision is required at all times. This manual contains important safety information. It is your responsibility to review this information and make sure that all children obey all warnings, cautions, instructions and safety topics, and assure that young riders are able to safely use this product. Razor USA recommends that you periodically review and reinforce the information in this manual with young riders, and that you inspect and maintain your children’s product to ensure their safety. The recommended rider age of 6 years and older for the DeltaWing is only an estimate, and can be affected by the rider’s size, weight or ability. Any child unable to fit comfortably on the DeltaWing should not attempt to ride it.  A parent’s decision to allow his or her child to ride this product should be based on the child’s maturity, skill and ability to follow rules. Do not exceed 143 lb  (65 kg) on the DeltaWing. Rider weight does not necessarily mean a child’s size is appropriate to fit or maintain control of the DeltaWing.
• ACCEPTABLE RIDING PRACTICES AND CONDITIONS
  Direct parental supervision is required. The DeltaWing is meant to be used only in controlled environments, free of potential traffic hazards and not on public streets. Do not allow your child to ride the DeltaWing in any areas where vehicle traffic is present. Child must maintain a hold on the handlebars at all times. Never allow more than one child at a time to ride the DeltaWing. Never use near steps, sloped driveways, hills, roadways, alleys or swimming pool areas.
  Do not ride the DeltaWing in wet weather. The DeltaWing is intended for use on solid, flat, clean and dry surfaces, such as pavement or level ground, without loose debris such as rocks or gravel.  Wet, slick or uneven and rough surfaces may impair traction and contribute to possible accidents. Do not ride the DeltaWing in mud, ice, puddles or water. Avoid excessive speeds that can be associated with downhill rides. Never risk damaging surfaces, such as carpet or flooring, by use of a DeltaWing indoors. Do not ride at night or when visibility is impaired.
• PROPER RIDING ATTIRE
  Always ensure child is wearing proper protective equipment, such as an approved safety helmet. A helmet may be legally required by local law or regulation in your area. A child should always wear shoes and keep shoelaces tied and out of the way of the wheels. Never ride barefooted or in sandals. Knee pads and elbow pads are recommended.
  • WARNING: ALWAYS INSPECT DELTAWING PRIOR TO RIDING. Properly inspecting and maintaining your DeltaWing can reduce the risk of injury. Always inspect your DeltaWing before riding and regularly maintain it.
  • WARNING: CHECK LOCAL LAWS REGARDING DELTAWING USE. Check local laws and regulations to see where and how you may use your Razor DeltaWing legally. In many states and local areas, DeltaWing riders may be required BY LAW to wear a helmet. Check local laws and regulations regarding laws governing helmet use and DeltaWing operation in your area.

REPAIR AND MAINTENANCE

• Cleaning
  Wipe with a damp cloth to remove dirt and dust. Do not use industrial cleaners or solvents as they may damage the surfaces. Do not use alcohol, alcohol-based or ammonia-based cleaners as they may damage or dissolve the plastic components or soften the decals or decal adhesive.
• Testing the Brake
  To use the brake, squeeze the lever to increase the pressure on the brake. The brake lever is fitted with a cable adjuster to compensate for cable stretch and/or to fine-tune the lever movement to brake engagement. If brake is not engaging properly, follow the instructions for adjusting the brakes.

Adjusting the Brake

Tool Required: 10 mm Wrench

1. To adjust brake cable play, thread the brake lever adjuster in or out 1/4 to 1/2 turn until the desired brake adjustment is attained. Most adjustments are complete at this step. If brake still needs further adjustment, proceed to step 2.
2. If brake is too tight or has too much slack, use a 10 mm wrench to loosen the brake cable and adjust accordingly.
3. Inspect the brake pads for proper alignment against the wheel or excess wear. To realign brake pads, loosen the fixing nut and adjust the pad to contact the rim. Re-tighten and readjust as needed. Verify proper brake function prior to riding.

Wheels and Bearings
Under normal circumstances and conditions, Razor wheels and wheel bearings are maintenance-free. Nonetheless, it is the responsibility of the owner or guardian to periodically inspect the wheels for wear and tear, the axle for proper tightness, and bearings for side-to-side play, and loose parts. When a wheel or wheel bearing develops play, this is an indication of excess wear and replacement is necessary. Replace immediately with only genuine Razor wheels. Worn wheels/bearings are considered normal wear-and-tear and are not covered by the Razor Warranty. Wheels other than genuine Razor wheels may not be compatible with your Razor DeltaWing. The use of anything other than genuine Razor replacement parts may affect your safety and will void your warranty.

Troubleshooting

Here are some common problems and solutions for the Razor Electric Scooter

• Problem: The scooter won't turn on.
• Solution: Make sure the scooter is charged and the power switch is turned on.
• Problem: The scooter is moving slowly or not at all.
• Solution: Check the throttle and the brake to make sure they are working properly. Also, make sure the scooter is not in "eco" mode.
• Problem: The scooter is making strange noises.
• Solution: Check the wheels and the brakes to make sure they are not loose or damaged. Also, check the motor to make sure it is not overheating.

WARRANTY

The manufacturer warrants this product to be free of manufacturing  defects for a period of 6 months from the date of purchase. This Limited Warranty does not cover normal wear and tear, wheels, or any damage, failure or loss caused by improper assembly, maintenance, storage or use of the Razor DeltaWing.

Pros & Cons of Electric Scooter

Pros

• Powerful 250-watt motor
• Up to 15 miles on a single charge
• Stylish and unique design
• Easy to ride and maneuver
• Quick-charge time of just 3 hours

Cons

• May be too powerful for younger children
• May be heavier than other scooters
• May not be suitable for off-road use

Customer Reviews of Razor DeltaWing Electric Scooter

"I absolutely love my DeltaWing Electric Scooter! It is so much fun to ride and it goes so fast. I also love that it is eco-friendly and helps me get around without having to use my car. The only complaint I have is that it is a little heavy, but that is a small price to pay for all the great features it has." - Emily, age 13 "I bought this scooter for my son for his birthday and he absolutely loves it. It is
