Introduction

Please read all directions before using the product and retain this guide for reference. This product is intended for household use only. It is not intended for commercial use. This product is covered by a limited one-year warranty. Coverage is subject to limits and exclusions. See warranty for details.
This product is the next best thing to having a real wine cooler in your home. It protects your favorite bottles and stores them at the precise recommended temperatures for red and/or white wines. The advanced compressor cooling system delivers the optimal environment for those special vintages, preserving their unique flavor and delicacy.

The Schmecke wine cooler is priced at approximately $200.

PRODUCT OVERVIEW

1. Exterior
2. Shelves
3. Retainer bar
4. Feet
5. Upper door hinge with cover
6. Control panel
7. Glass door
8. Door gasket
9. Security lock
10. Bottom hinge

RECOMMENDED TEMPERATURE

TECHNICAL SPECIFICATIONS

SHMFWCC121LB

• Power Supply: 115V 60Hz Rated Power: 95W
• Unit Dimensions (W x D x H):  9.9 x 17.7 x 31.2 in. (252 x 450 x 792 mm)
• Net Weight: 37.5 lbs. (17 kg)

SHMFWCC121LB FEATURES

• Keeps red and/or white wines at their proper temperature
• One-touch controls and LCD display
• Interior lighting with independent on/off control
• Celsius or Fahrenheit, adjustable by one-degree increments
• Chrome shelves are easy to pull out
• Automatic panel lock
• Tempered smoked glass door protects wines from UV rays
• Black metal exterior
• CFC-free solid polyurethane foam insulation
• Lockable door for added security and peace of mind

Description

The Schmecke Wine Coolers Compressor SHMFWCC121LB features a compact design with a door seal that ensures minimal temperature fluctuations. The cooler is equipped with adjustable shelves, allowing users to customize the storage space according to different bottle sizes. The digital temperature control ranges from 39°F to 64°F, providing precise temperature management. Additionally, the unit includes a soft interior light for easy viewing and a lock to secure the contents.

The exterior is crafted from durable stainless steel, enhancing its aesthetic appeal and longevity. The compressor is designed for quiet operation, making it suitable for placement in living areas or commercial spaces without disrupting the environment.

CONTROL PANEL

Single zone models:
SHMFWCC121LB / SHMFWCC125LB / SHMFWCC181LB / SHMFWCC241LB / SHMFWCC281LB / SHMFWCC341LB / SHMFWCC511LB

Dual zone models:
SHMFWCC331DLB / SHMFWCC431DLB

1. Unlock the control panel by pressing the button for 2 seconds. A beep will alert you that the panel has been unlocked. (For Dual Zone model, press once more to select either the upper or lower zone.)
2. Adjust the temperature in 1 degree increments by pressing buttons until desired temperature is reached.
3. To switch between Fahrenheit and Celsius, press the for 2 seconds.
4. You can also turn the interior light on or off by pressing the button. The light will turn off automatically after 10 minutes.

DE-ICING THE WINE COOLER

The unit’s Auto Defrost feature should prevent ice accumulation from occurring.

• However, should ice accumulation occur, you can do the following:
  • Unplug the Wine Cooler
  • Wait for all ice to melt
  • Once melting is complete, remove water from the unit
  • Plug in and restart the unit

Setup Guide

To set up your Schmecke Wine Coolers Compressor SHMFWCC121LB, follow these steps:

1. Place the unit on a level surface to ensure proper operation.
2. Plug in the cooler and turn it on.
3. Allow the unit to cool down to the desired temperature before loading it with wine bottles.
4. Adjust the shelves according to the size of your bottles.
5. Use the digital control panel to set your preferred temperature.
6. Secure the door with the provided lock if necessary.

CLEANING THE WINE COOLER

TO CLEAN THE EXTERIOR

• Unplug before cleaning.
• Do not use abrasive cleaning products.
• Wash the cabinet exterior only with mild soap and water and rinse thoroughly.
• Clean the glass door with glass cleaner or mild soap and water and a soft cloth.
• Wipe the control panel with a damp cloth and dry thoroughly. To avoid damaging the panel, do not use cleaning sprays or over-saturated.

TO CLEAN THE INTERIOR

• Unplug before cleaning.
• Do not use abrasive cleaning products.
• Cleaning the door gasket:
  • Use mild soap or baking soda solution
  • Rinse well
  • Apply a thin layer of petroleum jelly to the gasket at the hinge side to prevent sticking
• Use a warm water and baking soda solution inside the unit (about one tablespoon of baking soda to one quart of water) to clean and neutralize odors.

SAFETY PRECAUTIONS

1. WARNING: CHOKING HAZARD – Small parts. This product contains small parts and is not suitable for children under 3 years old.
2. Remove all packaging before using this device. Please keep all packaging materials out of reach of children and pets.
3. Properly dispose of all packing materials immediately after unpacking product, as the bags used for packaging could present a suffocation or choking hazard.
4. Read all instructions carefully before attempting to operate this device. Improper usage could result in injury or a reduction in efficacy.
5. Never allow children to operate, play with, or crawl inside the appliance.
6. Keep all flammable liquids or materials away from this unit. Failure to do so may result in a fire or explosion.
7. Keep out of direct sunlight and away from heat sources.
8. Do not attempt to repair or replace any parts or service this unit unless specifically recommended in this User Guide.
9. Use only with a properly grounded, standard 115V 60Hz electrical outlet to avoid the risk of electrical shock.
10. Do not use with an extension cord.

IMPORTANT SETUP NOTES

• Before plugging in your Wine Cooler, allow to stand upright for 3 hours.
• Place only on a level surface that will support the full weight once Wine Cooler has been fully loaded. You can ensure the unit is level by placing a small ball on top and checking to make sure it does not roll in any direction.
• Position in a dry, well-ventilated space with temperatures between 41°F – 90°F (5°C – 32°C).
• Leave a space of at least 6" in the back of the unit and 10" on both sides. Do not place any objects on top of the unit.
• Do not use without feet: the unit requires 2" of ground clearance.
• If you are discarding an old unit, remove its door and leave shelves in place to avoid an entrapment hazard.

Please note: it is normal for your Wine Cooler to make a whirring sound that will cycle up when the compressor is working harder to chill your wine, and cycle down as the temperature levels off.

TROUBLESHOOTING

If the unit doesn’t work:

• Check to make sure the power supply has the correct voltage. Also check to make sure there isn't a circuit breaker that has been tripped or a blown fuse.

If the unit isn’t getting cold enough:

• Make sure the temperature settings are adjusted correctly. If so, the room in which the unit is operating might be too hot. Also check whether the door has been opened too frequently or has not been completely closed. Check the deal on the door to make sure it is intact. Make sure the unit has sufficient clearance on all sides.

If the unit vibrates or makes excessive noise:

• Make sure the unit has been placed on a level, stable surface. Also check to make sure the fan is working properly.
• If the LED display is not working or shows an error message:
• Check to see if the unit is plugged in properly. If so, there may be a problem with the main circuit board that requires professional servicing.

If the buttons don’t work:

• The Control Panel may be damaged.

Schmecke Wine Coolers Compressor SHMFWCC121LB WARRANTY

WHAT IS THE PERIOD OF COVERAGE?
This limited warranty starts on the date of your purchase and lasts for one year (the “Warranty Period”). The Warranty Period is not extended if we repair or replace the product. We may change the availability of this limited warranty at our discretion, but any changes will not be retroactive

LIMITATION OF LIABILITY

TO THE EXTENT NOT PROHIBITED BY LAW, THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES, ORAL, WRITTEN, STATUTORY, EXPRESS OR IMPLIED. EXCEPT FOR THE EXPRESS WARRANTIES CONTAINED IN THIS LIMITED WARRANTY STATEMENT AND TO THE EXTENT NOT PROHIBITED BY LAW, WE DISCLAIM ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, STATUTORY OR OTHERWISE, INCLUDING WITHOUT LIMITATION, THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. SOME STATES DO NOT ALLOW DISCLAIMERS OF IMPLIED WARRANTIES, SO THIS DISCLAIMER MAY NOT APPLY TO YOU. TO THE EXTENT SUCH WARRANTIES CANNOT BE DISCLAIMED UNDER THE LAWS OF YOUR JURISDICTION, WE LIMIT THE DURATION AND REMEDIES OF SUCH WARRANTIES TO THE DURATION OF THIS EXPRESS LIMITED WARRANTY.

Pros & Cons

Pros:

• Compact Design: Ideal for small spaces without compromising on storage capacity.
• Precise Temperature Control: Maintains optimal temperatures for various types of wine.
• Suitable for placement in living areas or commercial spaces.
• Built with high-quality materials for long-lasting performance.
• Accommodates different bottle sizes for flexible storage.

Cons:

• May be more expensive than some other wine coolers on the market.
• Holds up to 12 bottles, which may not be sufficient for larger collections.
• Some users report minor noise during the automatic defrost cycle.
• Some users find the initial setup process slightly challenging.

Customer Reviews

Customers have praised the Schmecke Wine Coolers Compressor SHMFWCC121LB for its reliable performance and sleek design. Many appreciate the precise temperature control and quiet operation, making it a favorite among both home users and commercial establishments. However, some users have noted that the initial setup can be a bit complex and that the unit's limited capacity may not meet the needs of larger wine collections.

Common complaints include minor noise during the defrost cycle and the higher price point compared to other models on the market.
