Segway-Ninebot KickScooter Max G2 051501U User Guide

cover-image

Content

Introduction

The Segway-Ninebot KickScooter Max G2 051501U is an advanced electric scooter designed for urban commuting, featuring a powerful 900W motor and a maximum speed of 25 km/h. With its innovative RideyLONG technology, it offers an impressive range of up to 70 km on a single charge, making it ideal for longer journeys. The scooter is equipped with double suspension for a smooth ride and self-sealing tires for added durability. The Segway-Ninebot KickScooter Max G2 is priced at approximately $799.99.

Specifications

 ItemParameter
    ProductNameNinebot KickScooter Max G2
Model051501U
Length × Width × HeightApprox. 47.6 × 22.4 × 49.8 in (1210 × 570 × 1264 mm)
Folded: Length × Width × HeightApprox. 47.6 × 22.4 × 23.8 in (1210 × 570 × 605 mm)
Net WeightApprox. 53.5 lbs (24.25 kg)
  RiderMax. Payload265 lbs (120 kg)
Recommended Age16+ years old
Required Height3'11"–6'6" (120-200 cm)
              Machine  Max. Speed [1]Approx. 20 mph (32 km/h) (Factory default condition) Approx. 22 mph (35 km/h) (Enable Higher speed via the Segway-Ninebot APP.)
Theoretical Range [2]Approx. 43 miles (70 km)
Range at Max. Speed [3]Approx. 28 miles (45 km) at speed of 20 mph (32 km/h) Approx. 25 miles (40 km) at speed of 22 mph (35 km/h)
Max. SlopeApprox. 22%
Traversable TerrainMost of the flat road conditions and Cobblestone road.
Operating Temperature14–104°F (-10–40°C)
Storage Temperature14–122°F (-10–50°C); recommended: 50–86°F (10~30°C)
IP RatingIPX5
Duration of ChargingApprox. 5 h
      BatteryNominal Voltage36 V
Max. Charging Voltage42 V
Charging Ambient Temperature32–104°F (0–40°C)
Nominal Capacity15.3 Ah
Nominal Energy551 Wh
Battery Management SystemOver-heating, short circuit, over-current, over-discharge and over-charge protection
MotorNominal Power0.45 kW, 450 W
Max. Power1 kW, 1000 W
    ChargerModelNB-42D0-02D9
TypeBuilt-in
Output Power0.1218 kW, 121.8 W
Input Voltage100–240 V ~ 50–60 Hz, 2.0 A MAX.
Max. Output Voltage42 V
Output Current2.9 A
TireTire Pressure42-48 psi
Tires10-inch Tubeless Self-sealing Tire
  1. Max. Speed: tested while riding with a full battery, 75 kg (165 lbs) load on pavement. * Some of the factors that may affect the maximum speed include the rider's weight, remaining battery power, wind resistance, etc. Warning: it is your legal duty to comply with your local traffic law and regulations when using this product. In the Unites States, in certain States, an electric kickscooter is not allowed to be used on public road (i.e., “on-road” ), if its maximum speed capacity, weight and/or other features do not comply with the mandatory requirements imposed by law. With respect to maximum speed capacity restriction, certain States require that an electric kickscooters’ maximum speed capacity shall be capped at / limited to a specific miles per hour if it is for on-road use, and the cap / limit varies in different States. By way of examples, the States that impose such maximum speed capacity restriction include New York, Florida, Arizona, New Jersey etc. In the event you intend to use this product on-road in a State that imposes such maximum speed capacity restriction, you MUST select a proper lower speed mode of this Product to assure that the product’ s maximum speed capacity under such speed mode complies with the law. In the event the maximum speed capacity of the lowest speed mode of this product nevertheless exceeds the maximum speed capacity restriction imposed by a State for on-road use, you shall not use this product on-road in that State. Furthermore, a State may have other law regulating on-road use of this product, such as maximum speed requirement and/or helmet requirement. In addition to State law, there may be further restrictions or prohibition on use of electric kickscooters by local law and/or regulations. For off-road use of this product, there may be other restrictions and/or limitations imposed by the property owner or others. The App of the product may provide additional useful information related to this matter. Disclaimer: this is not a legal opinion or legal advice. The information provided herein (including in the app) is for your convenience and information purpose only. It is not intended to cover every piece of law and/or regulation that may be applicable to this product. Segway and Ninebot explicitly hereby disclaim any and all warranty and/or representation, express or implied, related to completeness, accuracy, up-to-date of such information. Segway and/or Ninebot reserves the right but not obligation to correct, implement and/or update the information. You shall use the information at your own risk. It is your sole responsibility to learn and understand any and all the law and/or regulation, requirements, prohibition, restriction and/or limitation imposed by either law, government authority, court, private party or the others that may apply to your use of this product.
  2. Theoretical Range: Tested while riding with a full battery, 165 lbs (75 kg) load, 77°F (25°C), at the speed of 9.9 mph (16 km/h) on average on pavement.
  3. Range at Max. Speed: Tested while riding with a full battery, 165 lbs (75 kg) load, 77°F (25°C), at the max. speed on average on pavement.

Product Diagram

ninebot MAX G2 KickScooter 1

Dashboard & Power Button

ninebot MAX G2 KickScooter 2
  • Power Button: Press the button to power on; press and hold the button for 3 seconds to power off. When the KickScooter is on, press the button to turn on/off the headlight and the tail light; and press twice to switch between the speed modes.
  • Speedometer: It displays the current speed of the scooter, as well as error codes. *After setting the starting speed to <1.86 mph (3 km/h), the KickScooter will automatically enter Parking mode (P) upon powered on, and the KickScooter is unable to accelerate with "P" displayed on the speedometer. Rider has to exit Parking mode (P) by squeezing the brake lever once or accelerating the KickScooter to over 1.86 mph (3 km/h) before riding.
  • Direction Indicator: When turning left or right, press the “←” (left) or “→” (right) switch on the direction indicator switch. Then the direction indicator will flash regularly which can be turned off by pressing the corresponding switch again.
  • Walk Mode: Max. speed is 3.1 mph (5 km/h). The headlight and rear light are always on and can't be turned off. * How to enable in the Segway-Ninebot app: Settings > Walk Mode.
  • Speed Mode: There are three modes available. The top speed is as follows: * The top speed and the accelerated speed of Sport mode (S) can be adjusted in Segway-Ninebot APP. (Current battery level will influence the maximum speed.)
Mode                         Item SpeedRange*
ECO (Energy-saving mode)9 mph (15 km/h)43 miles (70 km)
D (Standard mode)16 mph (25 km/h)31 miles (50 km)
S (Sport mode)20 mph (32 km/h) (Factory default condition)28 miles (45 km)
22 mph (35 km/h) (Enable Higher speed via the Segway-Ninebot APP.)25 miles (40 km)
  • Ranges of Speed Modes: Tested while riding with a full battery, 165 lbs (75 kg) load, 77 °F (25 °C), at the max. speed of each speed mode on average on pavement.
  • Cruise mode: The symbol indicates that the cruise mode is activated. *Enable Cruise mode via Segway-Ninebot APP, and it will function when rider presses and holds the throttle for more than 5 seconds, with the buzzer ringing a long beep. (KickScooter can not enter Cruise mode when its speed is slower than 3.1 mph (5 km/h).
  • Bluetooth: It indicates that the scooter has been successfully connected to the mobile device.
  • Battery Level: The total battery level equals 5 bars. * The battery power is very low when the first battery bar is red. Please charge your KickScooter immediately.

Description

The Segway-Ninebot is built with premium materials and a sturdy frame, ensuring longevity and reliability. The scooter features a sleek and ergonomic design, making it comfortable to ride for extended periods. The large 10-inch pneumatic tires provide excellent traction and stability, while the advanced braking system ensures safe stops.

The scooter also comes with a user-friendly interface, including an LCD display that shows vital information such as speed, battery level, and mode. It supports multiple riding modes to cater to different riding styles and preferences.

Setup Guide

To set up your Segway-Ninebot KickScooter Max G2 051501U, follow these steps:

  1. Unbox the scooter and all included accessories.
  2. Charge the battery fully before the first use.
  3. Assemble the scooter by attaching the handlebars and tightening all screws securely.
  4. Turn on the scooter and check all functions, including lights and brakes.
  5. Download and pair the Segway app to access additional features and customization options.

Recommended Maintenance Schedule

To ensure safe riding, day to day care and regular maintenance are essential. You, the owner, have control and knowledge of how often you use your scooter, how hard you use it and where you use it. It is the owner's responsibility to perform regular checks and bring your scooter to authorized service center for inspection and service. Please refer to the maintenance schedule below. Note: This maintenance schedule charges a service fee.

    Item    Component    Maintenance Method    Every 3 monthsEvery 6 months or every 310 miles (500 km)  Every 1 year or every 621 miles (1,000 km)  Every 3 years or every 6,214 miles (10,000 km)
                    Mainframe maintenanceMainframe partsUse a soft, wet cloth to wipe the mainframe clean.
Tire pressureInflate tires to 42-48 psi
Tire wearCheck if the tires are cracked, deformed, or significantly worn.
        Screws on the stem topTighten the screws fixed with the handlebar and the stem. The suggested torque is 5.5±0.5 N·m.  √  √  √  √
Tighten the screw on the throttle. The suggested torque is 0.9±0.06 N·m. Tighten the screws on the brake lever. The suggested torque is 6±1 N·m. Tighten the screws on the stem top. The suggested torque is 8.5±0.5 N·m.     √    √    √
      Screws on the folding mechanismTighten the fixing screws of the folding handle and the front fork, Two lateral screws at the side, the recommended torque is 15 ± 1N · m Fold and unfold, the upper vertical screw, the recommended torque is 15 ± 1N · m Fold the connecting rod, and fasten the connecting rod screws when rocking on the bike. The folding is smooth without shaking.         √        √        √
      Item      Component      Maintenance Method    Every 3 months  Every 6 months or every 310 miles (500 km)  Every 1 year or every 621 miles (1,000 km)  Every 3 years or every 6,214 miles (10,000 km)
                                  Function inspection  Hub motorTo accelerate and decelerate, check if the hub motor is stalled or has abnormal sounds.    √  √
Front wheel maintenanceCheck if the front wheel is stalled or gets shaky, or the axis shaft is unbalanced.
      Brake adjustmentIf the brake is too tight/loose, use the 4 mm Allen key to loosen the screw on the caliper. Then slightly adjust the brake line (decrease/increase the exposed length), and tighten the screw again. Test standard: the riding speed is 12.4 mph (20 km/h), and the braking distance is within 6m       √      √      √
  Drum brakeFront wheel can rotate normally without abnormal sound. Front wheel can be braked after squeezing the brake lever.   √  √  √
  TaillightSqueeze the brake lever, the tail light works normally.   √  √  √
  HeadlightCheck the headlight and see if it lights brightly.   √  √  √
  Direction indicatorsToggle the direction indicator button to the left/right respectively, check if the direction indicators on the left/right side flash normally.   √  √  √
  DashboardPower on the scooter, the dashboard works properly.   √  √  √
  HornPress the horn button and the sound is loud.
    ThrottlePress and hold the throttle then release it, checking for acceleration and deceleration. Note: Release it, check if the throttle will back to the position.     √    √    √
      Item      Component      Maintenance Method    Every 3 monthsEvery 6 months or every 310 miles (500 km)  Every 1 year or every 621 miles (1,000 km)Every 3 years or every 6,214 miles (10,000 km)
                  Function inspection      Fault detectionAfter connecting with the Segway-Ninebot app: 1) Update the firmware to the latest version. 2)  Check if the notification of the corresponding error code and possible causes will prompt when the scooter detects an error       √      √      √
      ChargingCharge the scooter: 1) Check if the current battery power displays on the dashboard. 2)  Check the LED indicator on the battery charger. Charging: red, Fully charged: green.       √      √      √
Control buttonsPress or toggle the button 3 times without failure.
  TurningTest with left turns and right turns (the steering angle is 60). No resistance or lag when turning.    √  √
      Important parts    Battery assemblyThe battery need to be replaced when it is charged and discharged for 500 times or the total mileage is more than 6,214 miles (10,000 km). Note: It is recommended to charge once every 60 days for long-term storage.                         √
Controller            After 3 years' or 6,214 miles' (10,000 km's) riding, the abnormal parts of the kickscooter have to be repleced immediately.
Hub motor
          Functional partsRear wheel assembly
Throttle & Brake lever
Front fork assembly
Folding mechanism
Drumbrake
Dashboard Cover

Troubleshooting

If you encounter any issues with your Segway-Ninebot, here are some common problems and their solutions:

  • Issue: Scooter not turning on. Check if the battery is fully charged or if there is a loose connection.
  • Issue: Brakes not functioning properly. Ensure the brake pads are not worn out and that the brakes are adjusted correctly.
  • Issue: Tire deflation. Regularly check tire pressure and inflate as necessary.

Always refer to the user manual for detailed troubleshooting guides and follow safety instructions to avoid any potential hazards.

Segway-Ninebot KickScooter Max G2 051501U Pros & Cons

Pros:

  • 900W motor with speeds up to 25 km/h
  • Up to 70 km on a single charge

Cons:

  • Some users find turn signals less visible while riding
  • Speed adjustments via the app may not be intuitive for all users

Customer Reviews

Customers have praised the Segway-Ninebot KickScooter Max G2 051501U for its reliability, performance, and comfort. Many have noted its ability to handle long commutes effortlessly and its robust build quality. However, some users have mentioned that the scooter is heavier than expected and that the price could be more competitive.

Common complaints include issues with the app connectivity and some users finding the scooter too large for easy storage.

Faqs

What is the maximum range of the Segway-Ninebot KickScooter Max G2 051501U?

The Segway-Ninebot KickScooter Max G2 051501U has a maximum range of up to 43 miles on a single charge, depending on riding conditions and user weight.

How long does it take to fully charge the battery?

The battery of the Segway-Ninebot KickScooter Max G2 051501U typically takes around 6 hours to fully charge from empty.

Is the Segway-Ninebot KickScooter water-resistant?

Scooter has an IP67 water resistance rating, making it suitable for use in various weather conditions, including light rain and snow.

What is the top speed of the G2 051501U?

The top speed of the Segway-Ninebot is approximately 18.6 mph.

How do I pair my scooter with the Segway app?

To pair your scooter with the Segway app, download and install the app on your smartphone, turn on your scooter, and follow the in-app instructions to connect via Bluetooth.

What is the weight capacity of the Segway-Ninebot?

The maximum weight capacity of the KickScooter Max G2 051501U is 220 lbs.

Can I customize the riding modes on my G2 051501U?

You can customize the riding modes using the Segway app. The app allows you to adjust settings such as speed limits and acceleration to suit your riding style.

How often should I maintain my Segway-Ninebot?

Regular maintenance is crucial. Check tire pressure monthly, clean the scooter regularly, and perform routine checks on brakes and other components as recommended in the user manual.

Is the Max G2 051501U suitable for off-road use?

While the scooter can handle some off-road terrain due to its pneumatic tires, it is primarily designed for urban use. Extreme off-road riding may void the warranty and could potentially damage the scooter.

What safety features does the Segway-Ninebot KickScooter have?

The scooter comes equipped with an advanced braking system including both front and rear brakes, as well as bright LED lights for enhanced visibility during night rides.
