Serenelife Air Conditioner Fan and Dehumidifier SLPAC8

Introducing the SereneLife Air Conditioner Fan and Dehumidifier SLPAC8 is a versatile portable cooling unit designed to enhance comfort in any room. With a powerful 8,000 BTU capacity, it effectively cools spaces up to 215 square feet while also functioning as a dehumidifier to remove excess moisture from the air. Its lightweight design and easy installation make it perfect for home, office, or school use. The SLPAC8 is priced at approximately $495.99, offering a reliable solution for warm weather.

Product Introduction

MAIN PARTS AND COMPONENTS

1. Handle
2. Control panel
3. Louver
4. Caster
5. Air outlet
6. Air inlet
7. Drainage nozzle
8. Remote controller
9. Exhaust duct assembly
10. Window sealing plate assembly

Control Panel and Remote Controller

1. Power key
   Press the key to turn ON/OFF the A/C.
2. Mode key
   Press the key to choose cool, fan and dry.
3. Temperature/ time adjusting key
   Press the key at cooling mode to increase/reduce the setting temperature; press it at timing mode to adjust time; press Up and Down keys simultaneously to switch Fahrenheit and Centigrade degree temperature.
4. Speed key
   Press the key to choose high/ low spee d.
5. Timer key
   Press the key at standby mode to set ON time. Press this key at ON mode to set OFF time.
6. Temperature/ Time
   Display Window Displays the adjusted temperature and time
7. Remote controller receiving window It is used to receive signal of the remote controller.
8. °C/°F switching key
   Press the key to switch °C and °F
9. Sleep key
   In the cooling mode, the sleep mode can be selected by this key

Detailed Specifications

The Serenelife SLPAC8 comes with several key features that make it stand out:

• Cooling Capacity: Up to 3,000 BTUs, suitable for rooms up to 120 sq. ft.
• Dehumidifying Capacity: Up to 30 pints per day.
• Fan Modes: Three fan speeds for customizable airflow.
• Remote Control: Includes a remote control for easy operation from across the room.
• Energy Efficiency: Energy-efficient design with low power consumption.
• Noise Level: Quiet operation with a noise level of around 50 dB.

Description

User ease is a top priority in the engineering of the Serenelife SLPAC8. Its lightweight construction and small size (14.5 x 11.2 x 28.5 inches) make it simple to transport between rooms. Users may easily alter settings with this unit's straightforward control panel, which has clear buttons and an LED display. Furthermore, the remote control gives you the freedom to change settings from any location in the room.

Additionally, the equipment comes with a reusable air filter that traps dust and other allergens to help maintain the purity of the air. In humid locations, the dehumidifying feature is especially helpful in preventing the formation of mold and mildew.

Serenelife Air Conditioner Fan and Dehumidifier SLPAC8 Operation

Placement and Installation

Placement

• Place it at even and dry place, and keep it at least 50cm away from its surrounding object.



Installation

• Screw the exhaust duct assembly in the air outlet behind the panel (counterclockwise).



• Insert the air exhaust hose into the window sealing plate, adjust opening width of window so that the window can match with the sealing plate properly; length of the sealing plate is adjustable.



Incorrect Installation

• It’s important to keep the exhaust duct smooth. Incorrect installation will affect work of the A/C.
• Prevent the exhaust duct from sharp bending.
• Ensure air can flow smoothly in the duct.

Warning: The exhaust duct is designed especially for this model. Don’t replace or lengthen it;  otherwise, it will result in failure.
Notice: Max. developed length of the exhaust duct is 1,500mm. It’s better to shorten it while use and keep it in horizontal position during installation.

OPERATION METHOD

Cooling Mode

• When the A/C enters cooling mode automatically or cooling mode is selected  after power ON, the cooling indicator lamp lights up.
• Press Up/Down key to adjust setting temperature (16°C~30°C)(60°F~86°F).
• Press Speed key to choose High/Mid/Low speed.

Fan Mode

• When pressing mode key or choosing Fan mode by pressing the remote controller, the wind indicator lamp lights up.
• Press Speed key to choose High/Mid/Low speed.
• Temperature can’t be set.

Dehumidification Mode

• When pressing mode key or choosing dehumidification mode by pressing the remote controller, the dehumidification indicator lamp lights up.
• Remove the dehumidification water wedge, insert water manifold, place the other end of the water manifold into the water vessel or drainage passage, as shown in the right figure.
• After entering the dehumidification mode, if room tempearture≥17°C (62°F), the  compressor  is ON. Then control as follows: when room temperature ≤15°C (59°F), the compressor is OFF; when temperature  increases to room temperature≥17°C (62°F), the compressor will start again (in order to protect the compressor,  it will be restarted 3min. later).
• In dehumidification mode, the fan is defaulted  to run at low speed, and wind speed can’t be adjusted.
• Temperature can’t be set.

Note : When use the dehumidify function, should remove exit pipe components, otherwise, it will cause worse dehumidify performance, and appear “FL” water full alarm

Sleep mode (optional function)

• Under cool mode, pressing sleep mode key on the remote controller or pressing time key and down key together on the machine, it will start sleep mode with low wind speed and can’t be adjusted. Pressing the sleep mode key again or pressing time key and down k ey together on the machine to quit the sleep mode.
• If you press the wind speed key under the sleep mode, the screen will display ”SL”

Timer Mode

• In standby state, press the Timer key to set ON time. Press Up and Down keys to set ON time (0~24H), and the timer indicator lamp lights up.
• In ON state, pressure the timer key to set OFF time. Press Up and Down keys to set OFF time (0~24H), and the timer indicator lamp lights up.

Clean and Maintenance

DRAINAGE METHOD

This product is equipped with automatic water vaporization system. The condenser is cooled with the circulating of condensing water, so as to improve cooling efficiency and save energy.

• If the internal vessel is full of water, the display screen will display  “FL”, and the compressor stops working automatically. After power off, unscrew the water cover, pull out the water plug to drain off water, and it will become normal after being restarted.



MAINTENANCE

Notice: In order to avoid electric shock, please turn off the A/C and unplug before maintenance or repair.

CLEANING

• Unplug before cleaning.
• Wipe with soft semi-dry cloth. Don’t use chemical reagent, such as benzene, alcohol and gasoline etc; otherwise surface of the A/C and even the whole A/C will be damaged.
• Prevent water from spattering in the A/C.

FILTER SCREEN

• Wash the filter screen once every two weeks. If it is blocked by dust, efficiency of the A/C will be reduced.
• Take out the air inlet grille and pull out the filter screen at both sides according to the direction shown in the following figures.
• Put the filter screen into the warm water (about 40°C or 104°F) added with neutral detergent, dry it at a shady place after cleaning.

SEASONAL CLEANING

If the A/C will not be used for a long time:

• Pull out the water plug to drain.
• Run the A/C in fan mode for 2H till the inside is dry.
• Turn off the A/C and unplug.
• Wash the filter screen and reassemble it.
• Dismantle the exhaust duct and keep it properly.
• Cover the A/C with a plastic bag and place it at a dry place.

Common Failures and Diagnosis

Intelligent Error Detection

FUSE PARAMETERS

• Voltage: 250VAC
• Current: 3.15A

Setup Guide

Setting up the Serenelife SLPAC8 is straightforward and user-friendly:

1. Position: Ensure adequate ventilation surrounding the device by setting it on a level surface.
2. Turning on the unit: Insert the power cord and use the control panel or remote control to turn it on.
3. Select your desired mode (cooling, fan, or dehumidifying) and make any necessary adjustments to the settings.
4. If you want to use continuous drainage, connect the drainage hose in the drainage setup (for the dehumidifier mode).

Important Safety Tips Serenelife SLPAC8

Precautions
Please read the Manual carefully before operating the machine:

• This machine is for household use only.
• This machine is for indoor use only. Please place it in dry environment.
• Check power cord frequently. When power cord, plug or A/C is damaged, please don’t operate. If the power cord is not long enough, power extension cable can be used. Cable should not scatter at places where power cord may be pulled out or people may be stumbled.
• The A/C should be away from heat source and avoid direct sunlight.
• Turn off the A/C before unplugging.
• Turn off and unplug the A/C before removing or cleaning it, or replacing its parts or when it is not used.
• Clean the A/C according to the Manual.
• Voltage of the A/C should meet requirements. Any damage incurred by incorrect power isn’t included in the warranty.
• Children are not allowed to play with the A/C. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Don’t insert your fingers or any hard object to wind guide bar of the air outlet.
• Don’t place the A/C at any place with water or other liquid. Prevent water or liquid from entering the A/C.
• Don’t repair the A/C by yourself. Any possible hazard incurred by maintenance of laypeople will violate the warranty. If the supply cord is damaged, it must be replaced by professional maintenance personnel.
• Please use the accessories provided by the A/C manufacturer; otherwise, the A/C may be damaged.
• Suggest using environmental temperature for the air conditioner (Cooling): 15°C-35°C or 59°F-95°F.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

Special Warning:

• Place the A/C on even ground and install it vertically, so as to ensure normal operation of the compressor.
• The A/C should be at least 50cm away from surrounding objects. Keep air inlet and outlet smooth.
• Don’t use the A/C beside gasoline or any other inflammable liquid.
• Don’t use spraying agent and other solvent or flammable substances near the A/C; otherwise, its plastic may deform and electric parts may be damaged.

Power

• The plug should be in good condition and can’t be damaged. Don’t replace the plug with power plug.
• In order to run the A/C, plug the power cord first, and then press the power key.

Troubleshooting

In case of any of the following trouble, please contact professional maintenance personnel in time.

Notice: When there is any abnormal to the A/C, turn it off and unplug, and then contact professional maintenance personnel.
The above technical parameters are subject to change without notice.

 Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact you local government for information regarding the collection systems available.If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well   -being. When replacing old appliances with new ones, the retailer is legally obligated to take back your old appliance for disposals at least free of charge.

Pros & Cons

Pros

• Multi-functional: Acts as an air conditioner, fan, and dehumidifier.
• Energy Efficiency: Low power consumption makes it cost-effective.
• Compact Design: Easy to place in small rooms without taking up much space.
• Quiet Operation: Operates at a noise level of around 50 dB.
• Remote Control: Convenient remote control for easy operation.

Cons

• Limited Coverage Area: Suitable for small to medium-sized rooms only.
• No Window Kit Included: Requires separate purchase of a window kit for exhaust.
• Drainage Hose Not Included: Requires separate purchase of a drainage hose for continuous drainage.

Customer Reviews

Customers have generally praised the Serenelife SLPAC8 for its effectiveness in cooling and dehumidifying. Many have noted its ease of use and quiet operation. However, some users have mentioned that it may not be as effective in larger rooms and that additional accessories like window kits and drainage hoses need to be purchased separately.

Common complaints include issues with customer service and occasional noise from the unit when it is in dehumidifier mode.
