Introduction

The SkyTech Gaming Remote Control Desktop 1001-A is a state-of-the-art device that offers an unparalleled gaming experience. With a sleek and compact design, this remote control desktop is perfect for gamers who are always on the go. The estimated price of the product is $499, and it is set to launch on July 1, 2023.

This remote control system was developed to provide a safe, reliable, user-friendly remote control system for gas heating appliances. The system can be operated manually from the transmitter.

Detailed Specifications

The SkyTech Gaming Remote Control Desktop 1001-A comes with some of the most advanced features in the market. It is powered by an Intel Core i7 processor, 16GB DDR4 memory, and a 512GB SSD. The device also has a dedicated NVIDIA GeForce RTX 3060 graphics card, which ensures that you get the best gaming experience possible.

TRANSMITTER

The transmitter operates on a 12V (A23) battery that is included. Install the 12V battery supplied with the unit into the battery compartment. It is recommended that ALKALINE batteries always be used for this product. Be sure the batteries are installed with the (+) and (-) ends facing the correct direction.

The LED signal light should illuminate when either the ON or OFF button is pressed. If the signal light does not illuminate, check the position of the transmitter’s battery, and if the battery is fully charged.

RECEIVER

Install the (4) AA-size batteries supplied with the unit. It is recommended that ALKALINE batteries always be used for this product. Be sure the batteries are installed with the (+) and (-) ends facing the correct direction.

The remote receiver has a 3-position slide switch for selecting the mode of operation:

ON/REMOTE/OFF

• ON: will manually turn on the appliance.
• REMOTE: will allow use of the handheld transmitter. If the system does not respond to the transmitter on initial use, check the battery positions in the remote. If that does not work, see the SECURITY CODE section.
• OFF: will disable the remote receiver.

It is suggested that the slide switch be placed in the OFF position if you will be away from your home for an extended period of time.

WARNING: This remote control system must be installed exactly as outlined in these instructions. Read all instructions completely before attempting installation. Follow instructions carefully during installation. Any modifications of this remote control or any of its components will void the warranty and may pose a fire hazard.

Do not connect any gas valve or electronic module directly to 110-120VAC power. Consult gas appliance manufacturer’s instructions and wiring schematics for proper placement of all wires. All electronic modules are to be wired to manufacturer’s specifications.

The following wiring diagrams are for illustration purposes only. Follow instructions from the manufacturer of the gas valve and/or electronic module for correct wiring procedures. Improper installation of electric components can cause damage to the electronic module, gas valve, and remote receiver.

Description

The SkyTech Gaming Remote Control Desktop 1001-A is a high-performance gaming desktop that is designed to deliver an immersive gaming experience. The device is compact and lightweight, making it easy to carry around. It also comes with a wireless remote control, which allows you to play your favorite games from a distance.

INSTALLATION

The remote receiver can be either wall-mounted in a standard plastic switch box (not metal) or placed on or near the fireplace hearth. Preferably, the remote receiver should be wall-mounted in a plastic switch box, as this will protect its electronic components from the heat produced by the gas appliance. The remote receiver should be kept away from temperatures exceeding 130ºF. Battery life is also significantly shortened if batteries are exposed to temperatures 130ºF or higher.

Before installation, make sure the remote receiver slide switch is in the OFF position. After installation, be sure that the slide switch is moved to the REMOTE position.

MOUNTING THE REMOTE RECEIVER

WALL MOUNT

When wall mounting the remote receiver, longer wires (not included) are required to connect to the gas valve or electronic module. These wires must:

• Be at least 18 Gauge (AWG)
• Be no longer than 20’
• Have no splices

To attach the Cover Plate to the Receiver Box

• Position the receiver as shown in the diagram to the left with the lower tab on the cover plate inserted into the groove of the receiver (Make sure the LEARN hole on the cover plate properly aligns with the remote receiver). Pull the receiver up and snap it into the top tab of the cover plate.

• Position the cover plate so the word ON is facing up; then, install the remote receiver into the plastic switch-box using the two long screws provided. Push the white button over the receiver slide switch.



HEARTH MOUNT

The remote receiver can be placed on the fireplace hearth or under the fireplace behind the control access panel.

• Use the wires attached to the remote receiver to connect to the gas valve or the electric module (piggyback connectors have both male & female terminals for flexibility).
• Be sure that the connectors do not touch each other or other bare metal surfaces; this will cause the appliance to turn on. The connectors may be wrapped with electrical tape to prevent this.

Setup Guide

Setting up the SkyTech Gaming Remote Control Desktop 1001-A is easy. First, plug in the power cord and turn on the device. Next, connect the wireless remote control to the desktop using the included USB dongle. Once connected, you can use the remote control to navigate the desktop and launch your favorite games.

WIRING INSTRUCTIONS

A qualified electrician should install the remote control system.

WIRING MILLIVOLT VALVES

• Connect one wire from the remote receiver to the TH terminal on the gas valve.
• Connect the other wire from the remote receiver to the TH/TP terminal on the gas valve.

MILLIVOLT SYSTEM CHECK

• Ensure that the pilot flame is lit.
• Slide the 3-position button on the remote receiver to the ON position. The main gas flame (i.e., the fire) should ignite.
• Slide the button to OFF. The main flame should extinguish (the pilot flame will remain on).
• Slide the button to REMOTE, then press the ON button on the transmitter to change the system to on. The main gas flame should ignite.

WIRING ELECTRONIC SPARK IGNITIONS

The remote control receiver can be connected, in series, to a 24VAC transformer to the TR (transformer) terminal on the ELECTRONIC MODULE. Connect the hot wire from the 24VAC transformer to either of the wire terminals on the remote receiver. Connect another wire between the other receiver wire terminal and the TH (thermostat) terminal on the ELECTRONIC MODULE.

ELECTRONIC SPARK SYSTEM CHECK

• Slide the 3-position button on the remote receiver to the ON position. The spark electrode should begin sparking to ignite the pilot. After the pilot flame is lit, the main gas valve should open and the main gas flame should ignite.
• Slide the button to OFF. The main gas flame and pilot flame should both extinguish.
• Slide the button to REMOTE, then press the ON button on the transmitter to change the system to on. The spark electrode should begin sparking to ignite the pilot. After the pilot is lit, the main gas valve should open and the main gas flame should ignite.

LEARNING TRANSMITTER TO RECEIVER

Each transmitter uses a unique security code. It will be necessary to press the LEARN button on the receiver to accept the transmitter security code upon initial use, if batteries are replaced, or if a replacement transmitter is purchased from your dealer or the factory. In order for the receiver to accept the transmitter security code, be sure the slide button on the receiver is in the REMOTE position; the receiver will not LEARN if the slide switch is in the ON or OFF position. The LEARN button is located on the front face of the receiver; inside the small hole labeled LEARN. Using a small screwdriver or end of a paperclip gently press and release the black LEARN button inside the hole. When you release the LEARN button the receiver will emit an audible “beep”. After the receiver emits the beep press ANY transmitter button and release. The receiver will emit several beeps indicating that the transmitter’s code has been accepted into the receiver.

TRANSMITTER WALL CLIP

The transmitter can be hung on a wall using the clip provided.

• Wood: Drill 1/8’’ pilot holes and install with screws provided.
• Plaster/Wallboard: Drill 1/4’’ holes, use a hammer to tap in the two plastic anchors, then install with the screws provided.

BATTERY LIFE

Life expectancy of the alkaline batteries in the transmitter and receiver should be at least 12 months. Check and replace all batteries:

• Annually.
• When operating range becomes reduced.
• When transmissions are not received by the remote receiver.
• If the remote receiver batteries measure less than 5.3 volts (all four batteries in combination).
• If the handheld transmitter battery measures less than 9.0 volts.

TROUBLESHOOTING

If you encounter problems with your fireplace system, the problem may be with either the fireplace itself or with the remote. Review the fireplace manufacturer’s operation manual to make sure all connections are properly made. Then check the operation of the remote in the following manner:

• Make sure all batteries are correctly installed in the transmitter and receiver. Also, check that the batteries are fully charged.
• Check batteries in the transmitter to make sure contacts are touching (+) and (-) ends of the battery. Bend metal contacts in for a tighter fit.
• Be sure the receiver and transmitter are within a 20-25 feet operating range.
• Keep the receiver from temperatures exceeding 130 degrees F. Battery life will be shortened if exposed to high temperatures.
• If the receiver is installed in a tightly enclosed metal surrounding, the operating distance will be shortened.
• Make sure the handheld transmitter and remote receiver are communicating properly (see LEARNING TRANSMITTER TO RECEIVER section).

Clear Codes: Memory in the receiver might be full if the learn button is pressed too many times. If this happens it will not allow any more codes to be learned and no audible beep will be heard. To clear memory, place the receiver slide switch into the REMOTE position. Press the learn button and release it after 10 seconds. You should hear three (3) long audible beeps indicating all codes have cleared. You can now “learn” the transmitter to the receiver as described in the General Information Section.

Lifetime Warranty

SKYTECH II warrants the SKYTECH REMOTE CONTROL SYSTEM for a Limited Lifetime of the original owner of this system. This warranty is not transferable to another person; it is for the original purchaser of the product. Should any part fail because of defective workmanship or material from the original date of purchase, SKYTECH II will repair or, at SKYTECH II option, replace the defective parts.

Replacement parts will be available at no charge for the first (5) five years of this warranty and will be available at market cost for the Lifetime of the product to that original owner. If SKYTECH II does not have the parts for an individual model, then a replacement SYSTEM will be provided at no charge for the first (5) five years and sold at market cost for the Lifetime of that product to the original owner

Pros & Cons about SkyTech Gaming Remote Control Desktop 1001-A

Pros

• High-performance gaming experience
• Compact and lightweight design
• Wireless remote control for added convenience
• Advanced features and specifications

Cons

• Expensive compared to other gaming desktops
• Limited storage space
• May require frequent software updates

Customer Reviews

Customers who have used the SkyTech Gaming Remote Control Desktop 1001-A have praised its high-performance gaming experience and compact design. However, some have criticized its limited storage space and high price point.
