Introduction of Razor Electric Scooter E300

The Razor Electric Scooter E300 is a powerful and stylish mode of transportation for both kids and adults. This scooter boasts a high-torque, chain-driven motor that delivers a top speed of 15 mph, providing an exhilarating ride. With its extra-wide 10-inch pneumatic tires, the E300 offers a smooth and comfortable ride, even on rough surfaces. The scooter can run for up to 40 minutes of continuous use on a single charge, making it an excellent choice for short commutes or recreational rides. The estimated price of the Razor E300 is around $299.99, and it was launched in 2012.

Required Tools

Product ID Locations: See locations to the left

Handlebar Stem
Underneath battery tray
Charger
UPC side of box (not shown)

Plastic Bag Contents

Charger
Tools
Owner’s Manual

Razor Electric Scooter E300 Specifications

Top speed: 15 mph
Run time: Up to 40 minutes of continuous use
Motor: High-torque, chain-driven motor
Throttle: Twist-grip throttle control
Brake: Hand-operated rear brake
Tires: Extra-wide 10-inch pneumatic tires
Frame: All-steel frame and fork
Product dimensions: 41 x 17 x 42 inches
Product weight: 52 lbs.
Recommended age: 13 and up

BEFORE YOU BEGIN

Remove contents from box. Remove the separators that protect the components from damage during shipping. Inspect the contents of the box for scratches in the paint, dents or kinked cables that may have occurred during shipping. Because the scooter was 95 percent assembled and packed at the factory, there should not be any problems, even if the box has a few scars or dents.
MAKE SURE POWER SWITCH IS TURNED “OFF” BEFORE CONDUCTING ANY ASSEMBLY OR MAINTENANCE PROCEDURES.

Estimated Assembly and Set-Up Time

Razor recommends assembly by an adult. Allow up to 10 minutes for assembly, not including initial charge time.

WARNING: DO NOT USE NON-RAZOR PRODUCTS WITH YOUR RAZOR ELECTRIC SCOOTER. The scooter has been built to certain Razor design specifications. The original equipment supplied at the time of sale was selected on the basis of its compatibility with the frame, fork and all other parts. Certain aftermarket products may not be compatible and will void the warranty.

Assembly & Setup

Attaching the Handlebars

Tools Required: 5 mm Allen wrench

Loosen the collar clamp. With a twisting motion, push and twist to slide the handlebar onto the fork.
With the front wheel pointed straight ahead and the handlebars square to the front wheel, tighten both bolts on the clamp as shown with a 5 mm Allen wrench. Tighten securely.

Note: Make sure any cables/wires are out of the way before inserting the stem into the fork.
WARNING: Failure to properly tighten the collar clamp may allow the handlebars to dislodge while riding and may cause you to lose control and fall. When correctly tightened, the handlebars will not rotate out of alignment with the front wheel under normal circumstances.
Note: The cable and wire assembly from the handlebar must not wrap around the steering tube or handlebar. Sharp bends or twisting of the brake cable can cause the brakes to malfunction.

Inflating the Tires

Tires are inflated when shipped, but they invariably lose some pressure between the point of manufacturing and your purchase. Always inflate tires to the correct PSI before first time use.
Rear Tire

Use the valve extender located in the end of the right handlebar grip.
Open the round cover located on the chain guard by sliding the cover downward. Align the opening in the sprocket with the valve stem. Thread the valve extender completely onto the valve stem and attach the pump. Inflate to the PSI indicated on the tire sidewall.
Remove valve extender immediately after inflating and close the round cover.
Front Tire
Using a bicycle style tire pump equipped for a Schrader-type valve, inflate the front tire to the PSI indicated on the sidewall of the tire.

WARNING: Failure to remove the valve extender after inflating will cause the inner tube and/or adapter to be severed by the rear sprocket.
Note: If you lose the valve extender, contact customer service or one can be purchased at most auto parts stores.
WARNING: Do not over inflate, as this could damage tire or wheel.
Note: The pressurized air supplies found at gasoline stations are designed to inflate high-volume automobile tires. If you decide to use such an air supply to inflate your electric scooter tires, first make sure the pressure gauge is working, then use very short bursts to inflate to the correct PSI. If you inadvertently over-inflate the tire, release the excess pressure immediately.

Attaching the Seat

Tools required: Two (2) 4 mm Allen wrenches and Phillips screwdriver.

Attach the seat to the seat post with two (2) 4mm Allen wrenches. See note below.
Remove the four screws on the middle of the deck with the 4 mm Allen wrench and the Phillips screwdriver.
Place the seat post on the deck and secure using the same 4 screws.

Note: Do not completely tighten at this time. Adjust the seat tilt approximately level to the ground, or slightly tilted depending on your personal preference. Tighten securely. The seat tilt adjustment should not move when riding.

Charging The Battery

Your electric scooter may not have a fully charged battery; therefore you must charge the battery prior to use.

Initial charge time: 12 hours.
Recharge time: up to 12 hours, even if the light turns green. Recommended maximum charging time is 24 hours.
Always charge the battery immediately after riding.
Fully charge battery before storing for extended periods of time.
Unplug charger from the wall outlet when not in use.
Failure to recharge battery periodically may result in a battery that will not accept a charge.
Make sure the power switch is turned OFF when unit is not in use. If the power switch is left on for an extended period of time, the battery may reach a stage at which it will no longer hold a charge.
To ensure long battery life, never store the product in freezing or below freezing temperatures! Freezing will permanently damage the battery.
Run time: Up to 40 minutes of continuous ride time. Run time may vary depending on riding conditions, rider weight, climate, and/or proper maintenance.
Constant starting and stopping may shorten ride time.
Battery life can vary depending on proper maintenance and usage of the unit.

Note: Make sure power is turned OFF when unit is not in use. If the power switch is left on for an extended period of time, the battery may reach a stage at which it will no longer hold a charge.

Plug the charger plug into wall outlet. The light on the charger should be green.
Note: If green light (LED) does not turn on, try a different outlet.
Plug the charger into the charger port on the product. Make sure the power switch is in the OFF position. The light on the charger should turn red during charging. The light will turn green again when charging is complete.

WARNING: Use ONLY with the recommended charger. Batteries are only to be charged under adult supervision. The charger is not a toy. Always disconnect the charger before wiping down and/or cleaning the electric scooter with a damp cloth. The charger supplied with the electric scooter should be regularly examined for damage to the cord, plug, enclosure and other parts. In the event of such damage, the electric scooter must not be charged until it has been repaired or replaced. Chargers have built-in overcharge protection to prevent battery from being overcharged.
Note: If the charger gets warm during regular use, this is a normal response and is no cause for concern. If your charger does not get warm during use, it does not mean that it is not working properly.

Wall outlet Green (stand by) Wall outlet and unit
Red (charging) Wall outlet and unit
Green (charged)

Note: Continue charging unit even if light turns green prior to 12 hours.
WARNING: Battery charge can deplete over time. Failure to recharge the battery at least once a month may result in a battery that will no longer accept a charge.

Razor Electric Scooter E300 Description

The Razor E300 Electric Scooter is a high-performance scooter that is both durable and stylish. The all-steel frame and fork provide a sturdy base for the scooter, while the extra-wide tires ensure a smooth and comfortable ride. The scooter's high-torque motor delivers impressive speed, making it a fun and exciting way to get around. The twist-grip throttle control and hand-operated rear brake make it easy to control the scooter, even for beginners. Overall, the Razor E300 is an excellent choice for anyone looking for a reliable and enjoyable electric scooter.

E300/E300S SERIES ELECTRIC SCOOTER PARTS

Handlebar Grip (right/left)
- Handlebar End Cap
- Valve Extender
Single Speed Twist Grip Throttle
- 1 Sleeve
Handlebar Stem
Brake Lever Assembly
Collar Clamp
Headset (upper/lower)
Limiter and Cover
Front Fork
Front Wheel Complete
Control Module
Battery Tray
Reset Button
On/ Off Switch
Charger Port
Motor (24V/250W)
Kickstand
Rear Wheel Complete
Chain Tensioner
Chain
Chain Guard
Battery (2x 12V/7Ah)
Battery Bracket
Deck Plate with Grip Tape
Seat Post with Seat (E300S only)

PRE-RIDE CHECKLISPRE-RIDE CHECKLISTT

Brake
Check the brakes for proper function. When you squeeze the lever, the brake should provide positive braking action. Make sure brake is not rubbing when the lever is released.
Tires
Periodically inspect the tires for excess wear and regularly check the tire pressure. Reinflate as necessary.
Frame, Fork and Handlebars
Check for cracks or broken connections. Although broken frames are rare, it is possible for an aggressive rider to run into a curb or object, and wreck and bend or break a frame. Get in the habit of inspecting your scooter on a regular basis.
Hardware/Loose Parts
Before every ride, check all parts, such as nuts, bolts, cables, fasteners, etc., to ensure they are secure and assembled correctly. There should not be any unusual rattles or sounds from loose parts or broken components. If the unit is damaged, do not ride. Reference “Safety Warnings” on page 1 of this manual.
Safety Gear
Always wear proper protective gear, such as an approved safety helmet. Elbow pads and kneepads are recommended. Always wear athletic shoes (lace-up shoes with rubber soles) and keep shoelaces tied and out of the way of the wheels, motor and drive system. NEVER RIDE BAREFOOTED OR IN SANDALS.
Laws and Regulations
Always check and obey any local laws or regulations.
Insurance
Do not assume that your existing insurance policies necessarily provide coverage for scooter use. Check with your insurance company for information regarding insurance.

Setup Guide

Charge the scooter's battery fully before using it for the first time.
Assemble the scooter by attaching the handlebars to the base.
Turn on the scooter by twisting the throttle grip.
Adjust the seat height to your preference.
Test the scooter's brakes to ensure they are working correctly.
To pair a Bluetooth device with the scooter's built-in speaker, turn on the scooter and press the "pairing" button on the speaker.
To charge the scooter, plug the charger into a standard electrical outlet and connect it to the scooter's charging port.

Usage

Starting the Scooter
To start unit, turn on power switch; place both hands on handlebars and use one foot to push scooter forward while applying the throttle with right hand.
Stopping the Scooter
To stop unit, release the throttle and apply the brake until the unit comes to a complete stop.

WARNING: The brake is capable of skidding the rear tire and throwing an unsuspecting rider. Practice in an open area free from obstacles until you are familiar with the brake function. Avoid skidding to a stop as this can cause you to lose control and/or damage the rear tire.
Note: As an additional safety feature, the scooter is designed to cut power to the motor when the hand brake is applied.

Repair & Maintenance

Turn power switch “OFF” before beginning repair or maintenance:

Read the instructions
Remove charger plug
Turn the power switch off
Secure the unit under repair
Exercise caution around exposed parts
Contact Razor customer service if unsure about any repair or maintenance

Razor Electric Scooter E300 Adjusting the Brakes

Tools required: 10 mm wrench

To adjust the brake cable tension, thread the brake lever adjuster in or out 1/4 to 1/2 turn until the desired brake adjustment is attained. Most adjustments are complete at this step. If brake still needs further adjustment, proceed to step 2.
If the brake is too tight or too loose, use a 10 mm wrench to loosen the nut for additional adjustment on the brake cable. Securely tighten the nut when finished.

WARNING: The brake is capable of skidding the rear tire and throwing an unsuspecting rider. Practice in an open area free from obstacles until you are familiar with the brake function. Avoid skidding to a stop as this can cause you to lose control and/or damage the rear tire.

Chain and Rear Tire Replacement

Tools required: Phillips screwdriver, 10 mm wrench, two (2) 8 mm wrenches and two (2) 16 mm wrenches.

Disassembly

With a Phillips screwdriver, loosen the three (3) screws on the chain guard and remove.
With a 10 mm wrench, loosen the brake cable anchor bolt and disconnect the cable.
With two (2) 8 mm wrenches, remove the cable guide bracket from the frame and brake plate. Keep the bolt, washer, spacer, and nuts together.
With two (2) 16 mm wrenches, loosen the axle locknuts. Push down and remove wheel from the frame. Remove chain from rear sprocket.
Note: Rear wheel hardware sequence.
1. Left Side (Brake)
  17-1 Locknut
  17-2 Spring Washer
  17-3 Washer (thick)
  Frame
  17-4 Washer (thin)
  17-5 Brake Plate
  17-6 Spacer
2. Middle
  17-9 Rear Axle Bolt
  Right Side (Throttle)
  17-7 Spacer
  17-8 Washer (plate cut)
  Frame
  17-3 Washer (thick)
  17-2 Spring Washer
  17-1 Locknut
3. Right Side (Throttle)
  17-7 Spacer
  17-8 Washer (plate cut)
  Frame
  17-3 Washer (thick)
  17-2 Spring Washer
  17-1 Locknut
Install the chain onto the rear wheel sprocket. Slip wheel axle into the frame slots. See rear wheel hardware sequence on prior page. Push the chain tensioner down to create slack in chain. Hand tighten rear axle locknuts.
Verify chain is properly installed on each sprocket and tensioner is correctly positioned at the bottom of the chain.
Install the cable guide bracket to the frame and brake plate using bolt, washers, and nut. Do not tighten.
Thread the brake cable through the brake adjuster barrel, through the large spring, and into the small hole in the side of the anchor bolt. Position the cable to the original location (as indicated by the slight cable kink) and tighten securely.
Tighten the cable guide bracket bolt. Tighten the locknuts on the rear axle. Test the brake to verify proper function before riding. Readjust as needed.
Replace the chain guard.

Front Tire Replacement
Tools required: Two (2) 16 mm wrenches.

1 Using two (2) 16 mm wrenches, loosen the front axle bolts by turning the wrenches counter clockwise. Remove wheel and install replacement wheel. Note the sequence of the hardware.

Note: Front wheel hardware sequence.

Right Side (Throttle)
9-5 - Spacer
9-4 - Washer
Fork
9-3 - Washer
9-2 - Spring Washer
9-1 - 16 mm Locknut
Middle
9-6 - Front Axle Bolt
Left Side (Brake)
9-5 - Spacer
9-4 - Washer
Fork
9-3 - Washer
9-2 - Spring Washer
9-1 - 16 mm Locknut

Razor Electric Scooter E300 Troubleshooting

Does not work out of the box

Possible Cause: Loose connection(s)
Solution: Check for loose connections/wires.

No longer works

Possible Causes
- Loose connection(s)
- Charger not working
- Tripped reset button
- Battery will not hold a charge
Solutions
- Check for loose connections/wires.
- Check power to wall outlet and/or try a different outlet.
- Check lights on charger:
  - Plugged into wall - Green
  - Plugged into wall & unit - Red (charging)
  - Plugged into wall & unit - Green (charging complete)
  - No lights/Blinking lights - Replace Charger
- Secure unit; turn the power switch on and with no weight on the unit, lift up back end and apply the throttle. If motor engages - Replace Battery.
- The reset button will trip if the motor is overloaded. Wait a few seconds then press reset button.
- If motor does not engage but makes a clicking sound - Replace battery.
- If motor does not engage and there's no clicking sound - Replace Control Module.

Short ride time/runs slow

Possible Causes
- Rider weight
- Low tire pressure
- Riding conditions
- Battery not fully charged
- Old/damaged battery
- Improper battery maintenance
- Brake is dragging
Solutions
- Do not exceed 220 lb (100 kg) maximum weight limit.
- Verify correct tire pressure.
- Use only on flat, dry surfaces. Avoid inclines and areas with heavy debris.
- Charge unit for a minimum of 12 hours.
- Charge battery periodically when not in use.
- Do not store unit in freezing or below freezing temperatures.
- Check the brake cable has 2-3 mm of slack at lever. Adjust brake cable slack according to instructions.

Runs intermittently

Possible Cause: Loose connection(s)
Solution
- Check the wires around the throttle and connectors underneath the deck plate for other possible loose connections.
- Replace - twist grip throttle.

Razor Warranty

The manufacturer warranties this product to be free of manufacturing defects for a period of 90 days from date of purchase. This Limited Warranty does not cover normal wear and tear, tires, tubes or cables, or any damage, failure or loss caused by improper assembly, maintenance, storage or use of the Razor electric scooter.

Pros & Cons

Pros

High-performance motor
Extra-wide tires offer a smooth ride
Sturdy all-steel frame and fork
Twist-grip throttle control and hand-operated rear brake
Reasonable price point

Cons

Heavier than some other electric scooters
Battery life could be longer
No LED lights
No suspension system

Customer Reviews about Razor Electric Scooter E300

Customers who have purchased the Razor E300 Electric Scooter have praised its high-performance motor and sturdy construction. Many have noted that the scooter is easy to assemble and operate, making it an excellent choice for beginners. However, some customers have complained that the battery life could be longer, and that the scooter is heavier than some other electric scooters. Overall, the Razor E300 has received positive reviews from customers, with many praising its value for the price.
