Introduction

The Lanbo Appliances Wine Cooler LW28D is an ideal choice for wine enthusiasts, featuring a dual-zone design that accommodates both red and white wines at their optimal temperatures. With a capacity to hold up to 28 standard Bordeaux bottles, this compact cooler fits seamlessly into cabinetry or can be used freestanding. Its advanced compressor cooling system ensures consistent temperatures without hot spots, making it a reliable option for preserving wine quality. The cost of the LW28D is approximately $599.99.

Product Specifications

MODEL NO.: LW28D
VOLUME: 2.83 CF ( 80 Liter )
TYPE OF COOLING: compressor with air-circulated fan cooling
CLIMATE TYPE: N
ELECTRICITY PROTECTION GRADE: I
NOMINAL VOLTAGE/FREQUENCY: 110-120V/60HZ
RATED POWER(W): 90W /1.3A
AMBIENT TEMPERATURE: 32 - 100 °F
TEMPERATURE RANGE
- 5°C~12°C or 41°F ~54°F
- 12°C~18°C or 54°F ~64°F
NET WEIGHT: 86 lbs (39 KGS)
PRODUCT DIMENSION: 14.96 "W x 23.62"D × 34.45*H

Diagram of Product

Control Panel
Carbon Filter
Evaporator Fan
Upper Sensor
Full Wooden Shelf
Baffle Plate
Heating Fan
Lower Sensor
Small Wooden Shelf
Door Support Bracket
Adjustable Feet
Upper Door Hinge
Glass Door With Lock
Door Seal
Handle (16) Lock Hook
Lower Door Hinge
Front Vent

Installation Instructions

Before Using Your Wine Cooler / Beverage Cooler 26 Remove the exterior and interior packing.
Before connecting the wine cooler / beverage cooler to the power source, let it stand upright for approximately 24 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation.
Clean the interior surface with lukewarm water with a soft cloth.
The cooler is specially designed for wine storage, please do not put in other goods.

Installation:

The cooler should be placed independently so as to make sure good heat dissipation. The back of the cooler should be away from the wall 10cm at minimum.
Place your wine cooler / beverage cooler on a floor that is strong enough to support it when it is fully loaded. To level your wine cooler, adjust the front leveling leg at the bottom of the wine cooler.
Locate the wine cooler / beverage cooler away from direct sunlight and sources of heat (stove, heater, radiator, etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption. Extreme cold ambient temperatures may also cause the unit not to perform properly.
Avoid locating the unit in moist areas.
Plug in the proper power socket. Make sure that the shape and voltage of the socket is consistent with the nameplate on the back of the cooler.

Description

With its elegant and small form, the Lanbo Appliances Wine Cooler LW28D is ideal for home offices, bars, and kitchen worktops. Your wines will be stored in a stable atmosphere thanks to the double-layer glass door's superior insulation and UV protection. Bottles of different sizes can be stored in a variety of ways thanks to the wooden shelves that can be removed and adjusted. The compressor cooling system maintains the desired temperature while using the least amount of energy possible, ensuring silent and effective operation.

Operation Instruction

Control Panel

Display Windows

RUN light: Indicator light of compressor working. While the compressor operating, the red light is on. While it stops operating, the red light is off.
UPPER CHAMBER: Display of the actual temperature of the upper chamber. The range is 0°C~37°C or 32ºF ~99°F .
LOWER CHAMBER: Display of the actual temperature of the lower chamber; The range is 0°C~37°C or 32°F ~99°F.
C/F light: When the °C light is on, it indicates Celsius temperature; When the °F light is on, it indicates Fahrenheit temperature.

Button Operation

SET Button: Temperature setting button; Once you press the button, the temperature increased 1°C or 1ºF . Detail temperature setting range as following:
For LW28D/LW46D/LW72D/LW142D/LW165D/LW306Dis between: 5°C~12°C or 41F ~54 F for upper zone, 12°C~18°C or 54F ~64°F for lower zone;
LIGHT Button: Cabinet light control button;
Note: Once the light is turned on, it will automatically shut off after 10 minutes in order to protect the wines inside.
C/'F Button: Celsius and Fahrenheit conversion button;
ON/OFF button: Power on and off button; Press the button for 3 seconds, to start; press it 3 seconds again, to stop.

Note: This series of wine coolers has its delay protection function. The compressor will start to work about 3 to 5 minutes after it is power has been connected or powered on. Please use the wine cooler under the T type of climate. The temperature inside the cabinet will fluctuate and influence the refrigerating effect if the surrounding temperature is too high or too cold.

Shelf Change LW28D, LW46D,LW72D,LW142D,LW165D,LW306D, LW133DD,LW162DD,LW33S,LW52S,LW155S,LW177S,LW321S, LW144T

Follow the diagram below to remove or change the adjustable shelves

First, remove all wines from the shelves and pull shelf out to the limit. Then press up the left plastic bracket of sliding rail while pressing down on the the right one, pull the shelves out at this time. It could be easily pulled out if doing the three steps (Press up left bracket, press down on the right one and pull out) all at the same time.

Placement and storage of wines Several common layouts of wines:

Your cabinet was designed to store a maximum number of bottles adequately. The shelves are designed to accommodate wines uniformly.

The best temperature for red wines is 52-64°F;
For white wines is 43-54°F ;
The temperature range of our wine coolers can be set between 41-64°F.

Reversing the door swing of your appliance
(only suitable for model LW46D,LB148BC,LW72D,LW142D,LW165D,LW52S,LW155S, LW177S, LW144T)

The unit is delivered to you with the door opening from the left side (hinge on right side). The door of this appliance is capable of opening from either the left or right side. To reverse the door swing of your cooler and open from the right side, please follow the instructions and diagram as follows.

NOTE: All parts removed must be saved to allow the door swing to be reversed

Use the sharp tools to pry the decoration nail on the top of the cabinet and the cap of door spindle carefully. (Fig 1)
Open the door to an angle, unscrew the screw of the door hinges cover, remove the cover of the upper door hinge; then unscrew all the screws on the upper door hinge. Be careful to hold the glass door firmly after removing screw and take off the door. (Fig 2)
Remove the screw of lower door hinge and the left side screw of the front vent (Fig 3); and then install the lower door hinge at the designated position on the opposite side.(Fig 4)
Remove the screw of door handle, then remove the bottom screw of left side of the door and remove the lower supporter of the door(Fig 5); Install the lower support of the door to the opposite side.(Fig 6)
Pull open middle section of the door gasket, then it will come out the handle screw hole(Fig 7); remove the handle and install it on the opposite side. (Fig 8)
Install the upper door hinge to the opposite side and tighten the screws. (Fig 9)
Set glass door shaft to aim the shaft of lower door hinge (Fig 10);and then aim the upper door hinge (Fig 11); adjust the door and the cabinet is aligned and leveled, then tighten all the lock screws.

You also can call customer service for reversal instructions if it is necessary.

Setup Guide

Use these procedures to configure your Lanbo Appliances Wine Cooler LW28D:

To provide uniform chilling, position the cooler on a level surface.
Turn the device on after plugging it in. Before adding your wine bottles, let it cool to the appropriate temperature.
Adapt the racks to your wine bottles' dimensions.
Use the digital control panel to adjust the temperature. The default temperature is often about 55°F (13°C), but you can change it to suit the demands of your wine collection
To keep the cooler operating at its best, clean its outside and interior on a regular basis.

Care and Maintenance

Cleaning Your Wine Cooler

Wash the inside surfaces with warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda with a quart of water.
Wash the shelves with a mild detergent solution.
Turn off the power, unplug the appliance, and remove all items including shelves and rack.
Wring excess water out of the sponge or cloth when cleaning area of the controls, or any electrical parts.
Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with a clean soft cloth.

Power Failure
Most power failures are corrected within a few hours and will not affect the temperature of your appliance if you minimize the number of times the door is opened. If the power is going to be off for a longer period of time, you need to take the proper steps to protect your contents.

Vacancy time

Short vacancy: Leave the Wine Cooler off for around three weeks.
Long vacancy: If the appliance will not be used for several months, remove all items and turn off the appliance. Clean and dry the interior thoroughly so as to restraint odors and mold. Leave the door open slightly all the time if necessary.

Moving Your Wine Cooler

Remove all items.
Securely tape down all loose items (shelves) inside your appliance.
Turn the adjustable leg up to the base to avoid damage. Shut door/s.
Be sure the appliance stays secure in the upright position during transportation.
Also protect outside of appliance with a blanket, or similar item.

Energy saving Tips
The Wine Cooler should be located in the coolest area of the room, away from heat producing appliances, out of the direct sunlight

Important Notes

Warnings
To reduce the risk of fire, electrical shock, or injury when using your appliance, follow these basic precautions:

Carefully read all instructions before operating appliance.
Keep children away from the wine cooler. Never allow children to operate, play with, or crawl inside the appliance.
Never clean appliance parts with flammable liquids. Fumes can create a fire hazard or explosion.
If wine cooler stops working, please contact LANBO customer service department or certified repair technician to inspect the appliance. Avoid injury or accident, and never attempt to repair yourself.
If power cord becomes worn or damaged, contact a certified repair technician to replace the faulty power cord. Avoid injury, Do Not attempt to replace power cord by yourself.
Make sure to unplug cord before cleaning, moving or repairing. Never unplug the cooler by pulling the electrical cord as this may damage it. Grip the plug firmly and pull straight out.
Keep ventilation openings in the appliance enclosure clear of obstruction.
Do not use mechanical devices or other means to accelerate the defrosting process other than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartments of the appliance unless they are of the type recommended by the manufacturer.

Notes

In order to avoid damage to door seal, make sure the door is completely opened when removina the adiustable shelves.
Place the cooler close to a direct power source or outlet.
Once wines have been stored inside the cooler, avoid moving.
Choose a location for your cooler that isn't too cold. The ambient room temperature should be above 50°F. Stand your cooler in a dry place - avoid areas of high moisture or humidity. Don't put the cooler in frosty or unprotected areas like a garage or patio. Keep the cooler out of direct sunlight. Have adequate space at the back and sides for air circulation.
Do not power on the wine cooler repeatedly. Power on in 5 minute intervals.
DANGER or WARNING: Risk of child entrapment and suffocation. Before disposing your old wine cooler: Remove the door/s, Leave the shelves in original place so children may not easily climb inside. This appliance uses R600a refrigerant. Keep all flammable and explosive articles away from appliance to avoid fire or explosion.
Under supervision or guidance, this appliance may be operated by children ages 8 years and above, or any persons with reduced physical, sensory or mental capabilities, provided proper operating and safety instructions have been administered.
Do not allow children to play with appliance. Cleaning and maintenance shall not be performed by children without adult supervision.
If supply cord is damaged, it must be replaced by the manufacturer, its service agent or certified repair technician, in order to avoid a hazard.
Please keep this user manual for future reference, if you misplace or lose the user manual.
This appliance is intended to be used in household and similar applications such as:
- Residential: houses, apartments, townhomes, condos
- Work Environment: kitchen areas, lunch rooms, cafeterias, offices and other working environments;
- Hospitality: hotels. motels. bed and breakfast

Lanbo Appliances Wine Cooler LW280 Troubleshooting

PROBLEM	POSSIBLE CAUSE	SOLUTION
Refrigerator does not operate	Not plugged in Theappliance is turnedOFF at the control panel Thecircuit breaker hastripped or a fusehas blown out	Press ON/OFF Check and make surethe power plug is well connected Ask an engineer for help
Refrigerator is not cold enough; can not cool down to the presettemp.	Compressor does not start	Askan engineer for help/ check the connection of the compressor
	Compressor self-protected and has stopped operating	The ambient temperature is too high ( over 38Cdegree Celsius) The air venting is not smooth, check that the air duct isnot blocked Fan operates slowly or is faulty and has stopped operating. Thedoor is not closed completely, or the dooropened too long The compressor, or its components are faulty
	Fans stop working or operate at low speed	Ask an engineer for help. Power the refrigerator ON and OFF. Check the fan and whether the voltage is normal. If the voltage is normal, thenthe fan should be damaged
	Evaporator ices up	Turn OFF therefrigerator for one hour and open the door. The iceon the evaporator will melt.Check the door seal for any air gaps.
	Door is not closed properly	Check the doorlock, shelves, or other objects, make sure door is well closed. Check the rubber seal for any air gaps. Check the door hinges, make sure they are not loose
	Condenser is dusty	Wash and clean thecondenser
	Cooling systemfaulty (Gas leakage or blockage)	Ask an engineer for help
Compressor starts and stops frequently	The doorgasket does not seal properly.	Use low heaton a hair dryer to make the door seal take shape.
	The sensor connection is wrong.	Read the wiring diagram to make the correct connection of sensor
	The sensoris faulty.	Replace with a new sensor
	The door is opened too often.	Reduce the times/ frequency of door openings.
The light does not work.	Not plugged in, or the light buttonis "OFF'. Light itself faulty.	Check and make sure the lightbutton is ON, or ask an engineer for help.
The Refrigerator seems to make too much noise.	Thestand feet is not leveling, vibrations lead to noise	Adjust thestand feet and ensure they are level.
	Copper pipe hits otherobjects and makes noise	Gently adjustthe position of the pipe.
	When the compressor shutsdown or starts, it is normal for noise from the vibrations generated by the internal moving parts due to inertia.	Take no action

	A liquid plumbing noise may come from the flow of the refrigerators gases, whichis normal. As each cycle ends, you may hear gurgling sounds	Take no action
The door will not close properly.	Door is blockedby the door lock, shelves, or other objects.	Remove the barrier
	Door sealing rubber is deformed	Repair or replace the rubber seal
	Door hinges are notloose.	Adjust and fasten the hinges.
Iceup	Outlet / suction outlet blockage	Remove the barrier
	Fans stop working or operate at low speed.	Ask an engineer for help. Power the refrigerator ON and OFF.Check the fan and the voltage. If the voltage is normal, the fanmay be damaged.
	The door gasketdoes not seal properly; or door is opened too often	Use low heat on a hair dryer to make the door seal take shape.
	Gas leakage or cooling systemblockage	Askan engineer for help
External cabinet seems too hot	Ambient temperature is too high,or direct sunshine	Operating conditions need to be improved
	Front grill outlet/ suctionoutlet blockage	Remove the barrier
	Fans stop working orlow speed operating	Ask engineer for help, poweron the refrigerator, check the fan whether the voltage is normal or not. If the voltage is normal, the fan should be damage
Water drop on glass door	Ambient humidity is high	Use a softcloth to clean the water
	Door is opened toooften	Reduce the times I frequency of door opening.
	Thedoor gasket does notseal properly	Use low heat on a hair dryer to make the door seal take shape.

You can solve many common wine cooler problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the service.

Pros & Cons

Pros:

Sleek and compact design suitable for small spaces.
Energy-efficient compressor cooling system.
Double-layer glass door for excellent insulation and UV protection.
Adjustable and removable wooden shelves for flexible storage.
Quiet operation and low energy consumption.

Cons:

Limited capacity compared to larger wine coolers.
No built-in humidity control feature.
May not be suitable for very large or irregularly shaped wine bottles.
Slightly higher price point compared to some other compact coolers on the market.

Customer Reviews

The Lanbo Appliances Wine Cooler LW28D has received accolades from customers for its sophisticated appearance, effective cooling capabilities, and silent operation. The shelves' ability to be adjusted and the setup's simplicity are praised by several reviews. Some have pointed out that it lacks an integrated humidity control feature and that the capacity might be increased.
The inability to accommodate larger bottles and the somewhat greater cost in comparison to comparable small coolers are frequent concerns.
