Introduction

Introducing the JBL On Stage III Portable Loudspeaker, the perfect companion for all your audio needs. This versatile speaker boasts a sleek and compact design, making it ideal for both indoor and outdoor use. With an estimated price range of $100 to $150 and a launch date set for early 2023, the JBL On Stage III is poised to become the go-to choice for music lovers everywhere.

JBL 10-Button Remote Technical Specifications

Transmission: IR
Frequency: 38kHz
Operating Range: 20 feet
Battery Type: CR2025 3V
Dimensions
- Width: 1.29|| (33mm)
- Height: 3.38|| (86mm)
- Depth: 0.23|| (6mm)
- Weight (including battery): 1.2 oz.

Unpacking

Carefully unpack your JBL On Stage and identify all its components:

JBL On Stage III
Power adapter
IR remote
Dock adapter for iPod
3.5mm Audio cable
Carry Case

Getting to Know your JBL On Stage III

Syncing and Transferring Files with Your Computer

Make sure your iPod is securely docked into the JBL On Stage III, using the correct adapter.
Connect a USB cable (sold separately) into the USB jack on the back of the unit, connect the other end of the USB cable directly to your computer’s USB port.

Adapters for iPod
For detailed information regarding selection, installation and removal of the dock adapters, visit www.jbl.com. To remove an adapter, insert a flat-head screwdriver (sold separately) into the slot on the back of the adapter and lift up.


JBL On Stage III easy setup guide

Step 1. Unpack the JBL On Stage III, adapter, remote control, pow-er adapter and input cable. Read these instructions completely.
Step 2. Rotate the battery door to the unlocked position to open the battery compartment.
Step 3. Place 6 AA batteries in the battery compartment.
Step 4. Connect the power adapter into the input marked on the rear of the JBL On Stage III; plug the power adapter into a wall outlet or power strip.
Step 5. Place the appropriate iPod adapter onto JBL On Stage III. Place your iPod on the docking connector or connect the audio input cable to the rear of the JBL On Stage III. Connect the audio cable to the audio source.
Step 6. Press the Power button on the back of the JBL On Stage III. A green LED will light when the JBL On Stage III system is on.
Step 7. Adjust the volume using (+) to increase and (–) to decrease. Press both to mute the JBL On Stage III. Press either button to unmute.

JBL On Stage Important Safety Instructions

Please read the following precautions before use:

Read these instructions, heed all warnings, and keep for future reference.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings; a minimum distance of 10mm around the entire apparatus is required for sufficient ventilation.
No naked flame sources such as lighted candles should be placed on or near apparatus.
Attention should be drawn to the environmental aspects of battery disposal.
Apparatus is to be used in moderate climates only.
Do not install near any heat sources such as radiators, heat registers, stoves or other apparatuses (including amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarizing plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or third prong is provided for safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched, particularly at the plugs and convenience receptacles, and at the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Unplug this apparatus during lightning storms or when unused for long periods of time.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, or the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
To be completely disconnected from the power input, the main plug of AC/DC adaptor shall be disconnected from the main.
The main plug of AC/DC adaptor should not be obstructed OR should be easily accessed during intended use.
The marking information is located at the bottom of apparatus.
Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
The apparatus and AC/DC adaptor shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on apparatus and AC/DC adaptor.
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER (OR BACK). THERE ARE NO USER-SERVICEABLE PARTS INSIDE THIS UNIT. PLEASE REFER SERVICING TO QUALI-FIED HARMAN CONSUMER GROUP, INC.SERVICE PERSONNEL.
Never remove grille covers in order to service the speaker system. The speaker system does not contain any user-serviceable parts.

Description JBL On Stage III Portable Loudspeaker

The JBL On Stage III Portable Loudspeaker delivers powerful, crystal-clear sound in a compact package. Its rechargeable battery provides up to 12 hours of playtime, while its Bluetooth connectivity allows for easy pairing with smartphones, tablets, and other devices. The speaker also features a built-in microphone for hands-free calling and voice assistant integration, making it a truly versatile audio solution.

Setup Guide

Setting up the JBL On Stage III Portable Loudspeaker is a breeze. Simply charge the battery using the included USB cable, then turn on the speaker and put it into pairing mode. From there, simply select the speaker on your Bluetooth device and you're ready to start playing your favorite tunes. The speaker also features physical buttons for controlling volume, playback, and call functions, making it easy to use even without the need for a smartphone or tablet.

IMPORTANT: The appropriate adaptor must be installed before inserting your iPod into the JBL On stage III. Make sure that the iPod’s connector is properly aligned with the JBL On stage III’s connector when installing your iPod. Failure to do so may cause permanent damage to the iPod’s connector, rendering the iPod inoperable.

Important Note for All Electronic Products:
Before inserting or unplugging audio cables from the source device’s headphones or line-level output jacks, it is good practice to turn off the device first. This will prolong the life of your unit, help protect your device from static electricity and prevent potential damage.

WARNING: TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING: THE APPARATUS SHOULD NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO OBJECTS FILLED WITH LIQUID, SUCH AS VASES, SHOULD BE PLACED ON THE APPARATUS.

DANGER: THE LIGHTNING FLASH AND ARROWHEAD WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU TO DANGEROUS VOLTAGE INSIDE THE PRODUCT.

CAUTION: RISK OF ELECTRIC SHOCK DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

WARNING: THE EXCLAMATION POINT WITHIN THE TRIANGLE IS A WARNING SIGN ALERTING YOU TO IMPORTANT INSTRUCTIONS ACCOMPANYING THE PRODUCT.

Battery Disposal
Alkaline batteries are considered nonhazardous and can be disposed of with your regular household trash. Rechargeable batteries (i.e., nickel cadmium, nickel metal-hydride, lithium and lithium-ion) are considered hazardous household materials and may pose an unnecessary health and safety risk. Unwanted materials should be disposed of in an environmentally sound manner. Contact your local waste management officials for other information regarding the environmentally sound collection, recycling and disposal of used batteries.

DO NOT MIX BATTERY TYPES
DO NOT MIX CHARGED AND PARTIALLY CHARGED BATTERIES
BATTERIES WILL NOT RECHARGE WHILE IN JBL On STAGE III

JBL On Stage III remote easy setup guide


In the battery-only mode, the JBL On Stage III loudspeaker dock will In the battery-only mode, the JBL On Stage III loudspeaker dock will turn off to save battery power when muted or paused for longer than 10 minutes.

Navigation Control Mode

Turn iPod on: Press any button on the remote control to wake the iPod.2
Turn iPod off: Press and hold the Play/Pause button for two seconds.2
Bring up iPod menu: Press the Menu button.
Scroll up: Press the Scroll Up button.
Scroll down: Press the Scroll Down button.
Go to previous menu: Press the Menu button.
Select menu/track/feature: Press the Select button.

Music Control Mode

Play a track: Press the Play/Pause button.
Note: If the iPod is at the Main Menu, pressing Play/Pause will cause the iPod to start playing all of its music.
Pause a track: Press the Play/Pause button while a song is playing.
Skip to next track: Press the Next/Fast Forward button.
Skip to previous track: Press the Previous/Rewind button.
Fast-advance track: Press and hold the Next/Fast Forward button.
Fast-reverse track: Press and hold the Previous/Rewind button.
Increase volume: Press the Volume Up button.
Decrease volume: Press the Volume Down button.
Mute: Press the Mute/Unmute button.
Go to previous menu: Press the Menu button.
Select menu/track/feature: Press the Select/Enter button.

In the battery-only mode and after 10 minutes of mute or paused play, You will need to power on the JBL On Stage III unit using the power button located on the back of the unit,

Troubleshooting your JBL On Stage III

Symptom	Possible Problem	Solution
Sound Quality
No sound from the JBL On Stage III speaker system (continued)	The JBL On Stage III has been muted for more than 10 minutes in the battery-only mode	Press the JBL On Stage III’s Power button to turn the unit back on. Press either (+) or (–) to unmute.
No power; green LED is not on	Wall adapter is not plugged into the JBL On Stage III correctly. Wall adapter is not receiving AC power	Check the connection of the wall adapter. Place the wall adapter in a known powered outlet. Test the outlet with a lamp or other device. Connect the JBL On Stage III to a known audio source. Test the audio source with headphones.
Charging/Syncing
iPod will not charge	No power to input Wrong adapter is used	Check input cable connection Replace adapter
iPod is not recognized by the computer or an error message appears	Third-party accessories may be conflicting with the USB signal USB port is not supplying enough power	Make sure you do not have the JBL On Stage III connected to a USB hub or USB device. Connect the JBL On Stage III directly to the computer's USB port. Try connecting the USB cable to another port on the back of the computer.

If you have any questions or need further assistance, please visit https://www.jbl.com/country-selector?geoip=false. These specifications are subject to change without notice.

Symptom	Possible Problem	Solution
No sound from the JBL	No power to the system	Ensure that the power supply is connected to a live power source and properly connected to the JBL On Stage III. Note: When the JBL On Stage III is powered, a green power LED on the JBL On Stage III should light up.
On Stage III speaker system	Power adapter plug is not inserted correctly	---

No volume or low volume	Touch the volume “Up” (+) pad on the volume control to unmute and/or increase the system volume level. Note: Touching the volume “Down” (–) pad lowers the system volume. Touching both the (+) and (–) volume control pads at the same time will mute the system.
Input source volume is low	Increase the volume level on the audio source device.
Low or drained batteries	Replace the batteries.
iPod is paused	Press the Play button on the iPod or remote control.
iPod is paused (battery-only mode)	If the iPod is paused more than 10 minutes, press the JBL On Stage III’s Power button to turn the unit back on.

Technical Specifications

Frequency Response: 70Hz – 20kHz
Power Consumption: 20W Maximum
Power Input: 12V/1.5A
JBL On Stage III Transducer: (4) 1 Full range per channel
Dimensions
- Diameter: 7 1/2||(190mm)
- Height: 2|| (51mm)
System Weight: 1.12 lb (0.51kg)
Battery
- Size: AA
- Type: Alkaline, Ni Mh

DO NOT MIX BATTERY TYPES. DO NOT MIX CHARGED AND PARTIALLY CHARGED BATTERIES. BATTERIES WILL NOT RECHARGE WHILE IN JBL On Stage III.

JBL On Stage III Portable Loudspeaker Pros & Cons

Pros

Powerful, clear sound
Compact and portable design
Long battery life
Bluetooth connectivity
Built-in microphone and voice assistant integration

Cons

May not be loud enough for large gatherings
No wired connectivity options
May experience connectivity issues with some devices

Customer Reviews

Customers have praised the JBL On Stage III Portable Loudspeaker for its excellent sound quality, long battery life, and easy-to-use design. However, some have noted issues with connectivity and the lack of wired connectivity options. Overall, the speaker has received positive reviews and is a great choice for those looking for a versatile and portable audio solution.
