isKn Repaper Graphic Drawing Tablet Slate 2+

Introducing the isKn Repaper Graphic Drawing Tablet Slate 2+ is an innovative tool designed for artists who want to blend traditional drawing with digital technology. Launched in 2018, this tablet is manufactured by iskn, known for its cutting-edge creative solutions. Priced at approximately $199, the Slate 2+ allows users to draw on paper while capturing their work digitally in real-time, featuring 8192 pressure levels and wireless connectivity, making it ideal for both professional and aspiring artists.

Compatibility

iPad iPad 3, iPad 4, iPad Air, iPad Air 2, iPad Mini, iPad Mini 2, iPad Mini 3, iPad Mini 4, iPad Air, iPad Air 2, iPad Pro
iPhone 6, 6 Plus, 6S, and 6S Plus 7 and 7 Plus, 8 and 8 Plus
Mac OSX 10.10 Yosemite and later
PC Windows 7 and later
Android 5.0 and later

ESSENTIAL PACK CONTENTS

the Slate 2
1 iskn black pen
2 clips
1 sketchbook
1 pencil with a universal Ring
1 USB cable

TECHNICAL DIAGRAM

isKn Repaper Graphic Drawing Tablet Slate 2+ Specifications

Compatibility: Works with Mac, PC, and mobile devices.
Resolution: High-resolution capture for precise line work.
Sensitivity: 8192 levels of pressure sensitivity for nuanced strokes.
Paper Size: Supports A5 and A6 paper sizes.
Battery Life: Up to 12 hours of battery life on a single charge.
Connectivity: Bluetooth and USB connectivity options.
Software Compatibility: Compatible with popular art software like Adobe Photoshop and Illustrator.

Features

A pen-and-paper lover at heart, you can now write and draw with real pens and paper while instantly creating a ready-to-use digital file on your device.
With the Slate, keep total control of your work and make your life easier: your creations are instantly digitized.
Use the Imagink app to enhance your creations and share them with a single click.
Use this guide to learn about the Slate and start using its features in just a few minutes.

Description

The isKn Repaper Graphic Drawing Tablet Slate 2+ is designed to mimic the natural drawing experience. It comes with a sleek and compact design, allowing artists to work comfortably in various environments. The device includes a sensor that captures every stroke made on the paper, translating it into digital form in real-time.

The Slate 2+ also features an ergonomic design and a rechargeable battery, making it convenient for extended use. The device supports a variety of paper types and can be used with a range of drawing tools, from pencils to markers.

BEFORE USING THE SLATE

CHARGE

The Slate’s battery may be drained when you receive it. Charge your Slate before using it for the first time.

START CHARGING
Connect the Slate to your computer with the USB cable.
The side LED blinks orange.
FINISH CHARGING
The side LED shines orange continuously.
Disconnect the USB cable.

Do not Plug: Do not try to charge your Slate by plugging it to an AC adapter.

PRECAUTIONS FOR AN OPTIMAL PERFORMANCE
The Slate uses magnetic sensor technology that requires certain conditions for optimal performance. The main elements that can affect the Slate's precision are:

Magnetic objects in the surrounding environment (other iskn pen or ring, magnets, headphones, computers, telephones, metal objects,etc).
WiFi or other Bluetooth radio signals that can interfere with the commu-nication between the Slate and your iPad while using the Slate in Bluetooth mode.

Follow these rules for optimal results when turning on and using your Slate.

Place magnetic objects at least 20 centimeters / 8 inches away (other iskn pen or ring, magnets, headphones, computers, te-lephones, metal objects,etc).
Make also sure that you do not place the iskn pen or the ring you will use near the Slate when you turn it on, in order to not disturb its detection.
Make sure never to place the iskn Pen or Ring near the Slate when turning it on, in order not to disturb its detection.
Do not leave the iskn pen or the ring on top of the Slate for a long time.
We recommend you place your Slate at least 10 centimeters / 4 inches away from your device.

THE SLATE ON TABLET / MOBILE (IPAD / IPHONE)


INSTALLATION

Imagink
Download the Imagink app for iPad/iPhone on the Apple App Store.

CONNECTION

Activate the iPad or iPhone’s Bluetooth.
Launch the Imagink app downloaded from the App Store.
Make sure to respect the precautions described page 5.
Turn on the Slate by ma-king a long push on the power button at the top of the Slate in portrait mode (or at the left side in landscape mode).
Switch to the Bluetooth mode by making a short push on the Power button : a blue LED will shine at the top showing the Slate is ready to be used with your iPad or iPhone.

THE SLATE ON THE DESKTOP (PC / MAC)


INSTALLATION

Imaging
Get the Imagink app for your computer at https://www.iskn.co/download
Download and install the right version for your OS.

CONNECTION

Connect your Slate to your computer thanks to the USB cord included.
Launch the Imagink app downloaded from the iskn website.
Make sure to respect the precautions descri-bed page 5.
Turn on the Slate by ma-king a long push on the power button at the top of the Slate in portrait mode (or at the left side in landscape mode).
The Slate will automatically start in the USB connection mode: a white LED will shine showing you the Slate is ready to be used with your computer and a notification will appear on your screen.

MAGNETIC INDICATOR

The Slate has 32 magnetic sensors in-cluded which track the exact position and the angle of inclination of the iskn Ring.
Other magnetical items can disturb this connection and cause accuracy problems while drawing on your Slate.
This items could be your iPad or your PC (which have to be at least 20 cm | 8 inches away when used along with the Slate), smartphones, speakers, other iskn Rings etc.
The magnetic indicator helps you detecting this disturbing sources to make sure that your digital drawing is as beautyful as your paper version.
If you keep having some trouble using your Slate, feel free to contact us on our customer support.

GRAPHIC TABLET MOD

Graphic Tablet Mode Configurator

Get the Graphic Tablet Mode Configurator for your computer on www.iskn.co/download
Download and install the right version for your OS.

Connect your Slate to your computer thanks to the USB cord included.
Make sure to respect the precautions described page 5.
Turn on the Slate by making a long push on the power button at the top of the Slate.
In the Graphic Tablet Mode Configurator, click on "Activate".

Your Slate is now ready to be used as a graphic tablet with your favorite apps and software.
Enjoy this mode using the Tip on your Slate’s surface for a better experience.

Once you installed the Configurator, it will always run in the background. Be careful to deactivate the Graphic Tablet mode into the Configurator if you want to come back into Imagink app and use the Slate: if not, you will draw with your tool into Imagink as if it were a mouse, so the experience won’t be enjoyable.

ESSENTIAL INFORMATION

With the Slate, you can write on a single sheet of paper or a notebook (up to 7 mm I 0,3 inch thick).

For an optimal experience, make sure that your paper or notebook does not contain metal parts (spiral binding, etc.).
Tilt your pen at an angle greater than 10 degrees to the Slate’s surface.
Place the sheet of paper or notebook on the Slate between the area limit points.
Do not move the sheet of paper or note-book while using the Slate.

HOW TO USE THE CLIPS

Position your sheet, then fasten the Clips to the edge of your Slate.
To remove them, simply press on the back of the Clips.

HOW TO PLACE THE RING

In addition to the iskn pen, the Essential Pack includes a drawing pencil with a ring. This ring is designed to make your drawing tools compa-tible with the Slate: it will fit several kinds of pencils, whether they are cylindri-cal or hexagonal. Use the silicone adapter to place it on your tool.

This Ring fits all pencils up to approximately 8,1 mm (0,31 inch) in diameter.

Place the Ring on your own drawing tool:
1. Squeeze the adapter of your choice (S or M) into a heart shape to insert it into the Ring.
2. Slide the Ring onto a compatible drawing tool1 and adjust it to be around 4 cm from the pen tip, by comparing with the iskn pen.
  List of compatible tools on iskn.co
Calibrate the Ring:
1. You must renew this operation every time you switch tools, and only on a sheet of paper (even if you are going to use it on a notepad).
2. Press and hold the top button, a pink LED breathes.
  Press the tip of your pen at the center of your Slate. Then release the button.
Make sure the Ring is placed correctly:
Press the tip of your pen at the center of your Slate so it is perpendicular to the Slate.
Rotate it around itself in a full circle while keeping the tip in the same place.
If the circle on the screen has a diameter higher than 1.5mm, adjust the Ring so it is perpendicular to your pencil.
Then renew the calibration step and this operation.
If a point or a circle with a diameter below 1.5 mm appears on the screen, you are ready to draw with the Ring!

SCREENLESS MODE

The screenless mode allows you to use the Slate without your iPad, iPhone, Mac, or PC. The Slate contains a battery and a 4 GB memory so that you can take the Slate with you wherever you go.

We advise you to use the ISKN pen in screen-less mode for a better performance. Your strokes are digitized as a black ballpoint pen. Later, you can transfer your drawings to the imaging app via Bluetooth or USB.


Turn on your Slate: by making a long push on the power button at the top of the Slate in portrait mode (or at the left side in lands-cape mode). Your Slate will start in USB mode with the LED white shining.
Turn on the screenless mode by making two short pushes. When the Slate is in Screenless mode, the upper LED shines green and your Slate is ready to be used without your iPad, Mac, or PC.

Setup Guide

To set up the isKn Repaper Graphic Drawing Tablet Slate 2+, follow these steps:

Charge the device using the provided USB cable.
Download and install the isKn app from the official website or app store.
Pair the device with your computer or mobile device via Bluetooth or USB.
Place your paper in the designated drawing area and start creating.
Adjust settings such as sensitivity and line smoothing within the app for optimal performance.

Troubleshooting

If you encounter any issues with your isKn Repaper Graphic Drawing Tablet Slate 2+, here are some common problems and solutions:

Connection Issues: Ensure that Bluetooth is enabled on both devices and that they are within range. Restart the device if necessary.
Line Quality: Adjust the pressure sensitivity settings in the app to improve line quality.
Battery Life: Make sure the device is fully charged before extended use.

Always refer to the user manual for detailed troubleshooting instructions.

Pros & Cons

Pros

Natural Drawing Experience: Mimics traditional drawing on paper with high accuracy.
Portable: Compact design makes it easy to carry around.
Long Battery Life: Up to 12 hours of continuous use.
Software Compatibility: Works seamlessly with popular art software.
Pressure Sensitivity: 8192 levels of pressure sensitivity for detailed artwork.

Cons

Cost: May be slightly expensive for some users.
Learning Curve: Requires some time to get accustomed to the digital capture process.
Limited Paper Size Options: Currently supports only A5 and A6 paper sizes.

Customer Reviews

Customers have praised the isKn Repaper Graphic Drawing Tablet Slate 2+ for its ability to merge traditional and digital art seamlessly. Many artists appreciate the natural feel of drawing on paper while enjoying the benefits of digital editing. However, some users have noted that there is a slight learning curve and that the device may not be as affordable as other graphic tablets on the market.
