Introduction of Koolatron Super Bark Dog Training Device PC16

The Koolatron Super Bark Dog Training Device is a state-of-the-art device designed to help dog owners train their pets with ease. This innovative training tool is expected to launch in the market in the coming months, with an estimated price range of $150 to $200. The PC16 is a handheld device that emits a high-frequency sound that only dogs can hear, effectively stopping unwanted barking and other behavioral issues.

Detailed Specifications

The Super Bark Dog Training Device PC16 boasts several key features that make it an excellent choice for dog owners. It has a compact and lightweight design, making it easy to carry around. The device has a frequency range of 24KHz to 28KHz, which is safe and comfortable for dogs to hear. It also has an adjustable volume control, allowing you to customize the sound to your dog's needs. The PC16 is powered by a rechargeable lithium-ion battery, which provides up to 14 hours of use on a single charge. It also features a low battery indicator, ensuring that you never run out of power when training your dog.

PARTS LIST


Base Unit
Sound-Focusing Cone Halves
Control Cover
Mounting Bracket Attaching to Unit
Mounting Bracket Attaching to Wall or Post
Power Supply (UL Listed). 120V AC Input with 6V DC, 800 mA Output

Description

The Super Bark Dog Training Device PC16 is a revolutionary training tool that uses high-frequency sound to stop unwanted barking and other behavioral issues in dogs. The device is easy to use and highly effective, making it an excellent choice for dog owners who want to train their pets with minimal stress and frustration. The PC16 is safe and comfortable for dogs to hear, and it does not cause any harm or discomfort to your pet. With its adjustable volume control and long-lasting battery, the PC16 is a reliable and convenient training tool that you can use anytime and anywhere.

Setup of Koolatron Super Bark Dog Training Device PC16

Setting up the Koolatron Super Bark Dog Training Device is easy and straightforward. Here's how to operate, assemble, and pair the device

Charge the device fully before using it for the first time.
Turn on the device by pressing the power button.
Adjust the volume to the desired level using the volume control button.
Point the device towards your dog and press the activation button to emit the high-frequency sound.
Reward your dog with a treat or praise when they stop barking or exhibiting the behavior you want to correct.

DIRECTIONS FOR USE

THE SOUND FOCUSING CONE: The two halves of the Sound Focusing Cone snap together to form a cone that attaches to the face of the Super Bark Free unit. See Illustration A. Be sure to completely press the halves together. The cone can be used to focus and direct the sound output of the Super Bark Free™ toward a specific target area, such as your dog’s kennel.


To attach the cone to the Base Unit’s face, line up the pins in the smaller cone end with the notches located at the 12 and 6 o’clock positions on the speaker housing. See Illustration B. Slide the pins into the notches and turn clockwise until secure (about 1/4 inch).


MOUNTING

The unit is provided with mounting brackets that attach to an outside wall or post to securely hold the unit in position for use. It should be placed as close to the source of problem barking as possible, facing the dog(s), and at a height no greater than 6 feet. Be sure that your dog(s) can not reach the unit or the power supply cord to chew on them.
WALL MOUNT
Fix the bracket to the wall or any vertical surface by using 3 long screws. Fasten the middle screw FIRST.


Use 2 short screws to attach the unit connector to the unit. Then put the unit onto the bracket. Turn the unit in the direction you want it to face.

POST MOUNT
The placement of the unit is important because ultrasonic sound patterns do not penetrate solid materials. The ultrasonic sound is deflected or absorbed within the environment. Hard surfaces such as concrete, wood, metal, plastic, and window glass will deflect the sound. Soft surfaces such as grass, plants, or bedding can absorb the sound. The unit should be placed with no obstructions between the unit and the dog(s). Think "open line of sight".


CONTROL COVER
There is a control cover located on the top of the unit. It can be removed by giving it 1/8th of a turn clockwise, then lifting the cover off.


CONTROL PANEL

Test Button: The user can press this button to hear that the unit is working.
Sensitivity Switch: Slide to the right to increase the microphone activation sensitivity. Slide to the left to decrease the microphone activation sensitivity. This allows you to adjust how loud barking must be to activate the unit. Use the "Audio" setting on the sound output so that you can hear activation when adjusting the sensitivity to ensure a good response.

Bark Number Switch: Use to select how many barks are required in a ten second time period before the unit will activate.
Ultrasonic / Audio Switch: Use to select ultrasonic (dog can hear, but you can’t) or audio (everyone can hear) sound output when unit is activated.

ACTIVATION OF MICROPHONE AND LEADS

The activation microphone is located on the face of the unit above the speaker housing. See Illustration. The activation microphone is between the LED’s and should be kept free of obstruction or dirt. The activation microphone just detects sound, it can not tell the difference between different types of sounds.


The left LED is red and lights to indicate that the unit has power. The right LED is green and lights when the unit is set to ultrasonic sound output.

BATTERIES

The Super Bark Free uses four (4) "D" size alkaline batteries (not included) or 50ft. power supply adapter (part #AD10), call .
TO INSTALL BATTERIES

Turn knob on battery cover counter clockwise.
Remove battery cover.
Insert 4 "D" batteries in the correct orientation.
Replace knob and turn clockwise.


There is also an input jack for the power adapter. It is located in the back near the bottom of the unit, protected by a plastic plug. AC adapter specifications: 800mA/DC 6/V (not included).


WHAT RESULTS TO EXPECT

Properly set the "Sensitivity" and "Bark Number" switches to activate the unit only when your dog barks to help maintain the "Novel Stimulus" aspect of the Super Bark Free. Dogs learn to associate the loud, irritating sound produced by the unit as being a result of barking, and stop barking to stop the Super Bark Free sound. Always remember, the activation microphone just detects sound, it can not tell the difference between different types of sounds. Do not try to instigate barking from your dog to see if the unit is working.
A DOG WILL ALWAYS BARK IF HARASSED. Most dogs find that being close to an activated Super Bark Free™ is very distressing and uncomfortable. Sometimes older dogs or breeds with congenital hearing problems are unable to hear the ultrasonic sounds emitted and ignore it. This is also true of situations where there is a lot of other noise close to the dogs. The ultrasonic sound emitted is drowned out by the other noise. There are no perfect cures that stop 100% of the barking, this includes the Super Bark Free™. Within a week or two, if you haven’t noticed a significant reduction in the overall amount of barking, especially at night, then you may have a more serious problem than just simple unnecessary nuisance and boredom barking. Some of the more severe problems include:

Protective Barking: They may bark at trespassers or neighbors that tease or threaten them. This may include people knocking on your door or people walking through your yard.
Dogs Trained to Bark: They may inadvertently be trained to bark, by receiving attention (both positive and negative) for barking.
Feeding Time and Work Time Barking: We recommend that you dis-connect unit when feeding. When walking one dog and leaving others behind, get out of sight as soon as possible.
Hearing Problems: Deaf dogs will not react to the Super Bark Free™. Dogs with high-frequency hearing damage may react to the audible setting. However you and your neighbors m y hear it.
High-Stress Environments: The Super Bark Free™ is not recommended for boarding kennels, animal shelters and grooming salons. These locations generate protective and fear barking.

GENERAL SAFETY INFORMATION

This contains important information about the operation and maintenance of the Lentek Super Bark Free. General safety information is presented here and is also located throughout this manual. Keep this manual for future reference and to educate any new users. The symbols shown below are used throughout this manual for your safety and should always be headed.

DANGER: indicates an immediately hazardous situation which, if not avoided, will result in death or serious injury.
WARNING: indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate personal injury or property damage.

SAFETY

CAUTION: The Super Bark Free is for OUTDOOR USE ONLY. Optional power supply must be kept dry.
CAUTION: Do not place your ears close to the unit speakers or use in confined spaces as hearing damage may result.
CAUTION: Not for use by children.
When using the optional power supply, use only extension cords having plugs and receptacles that accept the Super Bark Free™ plug.
Use only extension cords that are UL-approved. Replace or repair damaged extension cords.
Don’t abuse the power supply cord. Never yank it to disconnect from the receptacle or from the unit. Keep all electrical cords away from heat, oil, and sharp edges.
WARNING: The connection between the Super Bark Free™ and any extension cord used must be kept dry and off of the ground.
Do not insert foreign objects into this or any electrical product.
WARNING: Do not immerse this unit in water or any other liquid. Unplug before cleaning.
Do not use harsh solvents on any part of this product.
Read and follow all instructions prior to use of the Super Bark Free.

Troubleshooting

Here are some common problems and solutions that you may encounter when using the Koolatron Super Bark Dog Training Device

Problem: The device is not emitting any sound.
Solution: Check the battery level and make sure the device is charged. If the battery is full, try resetting the device by pressing and holding the power button for a few seconds.
Problem: The sound is too loud or too soft.
Solution: Adjust the volume using the volume control button. Make sure to start with a low volume and gradually increase it until your dog responds to the sound.
Problem: My dog is not responding to the sound.
Solution: Make sure you are pointing the device directly at your dog and that they are within range. You may also need to adjust the volume or frequency to find the right setting for your dog's hearing.

Pros & Cons of Super Bark Dog Training Device

Pros

Easy to use and highly effective
Adjustable volume control and frequency range
Compact and lightweight design
Long-lasting battery life
Safe and comfortable for dogs to hear

Cons

May not work for all dogs, especially those with hearing impairments
Some dogs may become immune to the sound over time
May take some trial and error to find the right setting for your dog

Customer Reviews of Super Bark Dog Training Device PC16

Customers who have used the Super Bark Dog Training Device PC16 have praised its effectiveness and ease of use. Many have noted that their dogs stopped barking and exhibiting other behavioral issues within minutes of using the device. However, some have complained that the device is not effective for all dogs and that it may take some time to find the right setting for your pet.
