Loop Wireless Bluetooth Speaker Introduction

Our main goal is to provide you with a quality product combined with ease of use. Here is a detailed user’s manual that will help you understand the features & functions of the speaker Please read the manual carefully before using the product. The speaker is priced at approximately $39.99, making it an affordable option for music enthusiasts.

Accessories List

1 x TAGG LOOP Bluetooth Speaker
1 x Micro usb Charging Cable
1 x Aux-in Cable
1 x User’s Manual

Detailed Specifications

Bluetooth Specification: Bluetooth Version 4.0
Power Output: 2 x 8W
Line In: 3.5mm
Rechargeable Lion Battery: 7.4V DC/ 2400mAh
Power Input: Micro USB
AC/DC Charger: DC 5V/ 500mAh
Charging Time: 2-3 hrs
Microphone Talking Range: within 3 - 100cm
Play Time: 4 hrs
Talk time: 2 hrs
Stand-by Time: 18 hrs

Panel Function Introduction

FUNCTION	OPERATION
1.	Play/ Pause/ Call
2.	Volume down/ Previous song
3.	Volume increase/ Next song
4.	Mode Function
5.	AUX-in Port
6.	TF Slot
7.	USB Slot
8.	Micro USB Charging Point
9.	Power On/Off Button

Description

The Tagg Loop Wireless Bluetooth Speaker boasts a stylish and compact design that makes it easy to carry around. Its durable build ensures it can withstand the rigors of daily use, while its water-resistant IPX7 rating allows for worry-free use in various environments. The speaker features dual 40mm drivers that deliver clear and balanced sound, making it perfect for listening to music, podcasts, or taking calls.

The intuitive controls on the speaker allow for easy navigation and pairing with your Bluetooth devices. Additionally, the speaker supports hands-free calls and voice assistant integration, adding to its convenience and functionality.

Connecting with your Device

Keep your Bluetooth Device with in 3 Ft. while Pairing.
Press the Power button of TAGG LOOP.
Blue and Red LED will blink and it means that the headset is in the pairing mode.
Now search for Available bluetooth devices in your
Mobile/Laptop/iPad and select TAGG LOOP from the list of available devices.
If prompted, enter password or PIN required “0000”.
If prompted by your mobile phone to connect, click “YES”. After Successfully connecting Blue LED will ﬂash twice after every 4 secs.

How to Charge Loop Wireless Bluetooth Speaker

Connect to power using Micro USB.
To better protect the battery life, kindly use only the charging cable provided with the headset < 5V, 100 mAH - 240 mAH. Allow 2-3 hours to completely charge the headset.

LED Indications

While Charging - Red LED is On.
When completely charged - RED LED is Off.
When battery is low, Red LED blinks every four seconds twice and the voice prompt will let you know that battery status. Pairing Mode- Blue and Red LED starts Flashing.

Reconnect the Speaker

If the connection is lost, TAGG LOOP will try to reconnect automatically.
If it does not reconnect, kindly press the Power button for 3 secs and reconnect manually through your mobile Bluetooth.

Setup Guide

To set up the Tagg Loop Wireless Bluetooth Speaker, follow these steps:

Charge the speaker fully before first use.
Turn on the speaker by pressing the power button until the LED light indicates it is in pairing mode.
On your Bluetooth device, go to settings and select "Tagg Loop" from the list of available devices.
Once paired, you can control playback and adjust settings using the controls on the speaker or through your connected device.

Safety Rules

Avoid Overcharging
Do not keep the speaker in closed and exposing to hot temperature.
Never disassemble or modify your speaker because of any reason.
Make sure the speaker does not get wet.

Troubleshooting

Mobile Can’t Find the Speaker:

Kindly restart your phone and the speaker.
There’s always noise and the Bluetooth keeps disconnecting:
The Speaker needs to be charged.
Make sure you are not beyond the signal distance.

Bluetooth is connected but you are unable to listen to music:

Check your setting to adjust the sound to speaker.
Some mobiles required you to select the device twice. Some mobile devices do not have complete stereo Bluetooth kindly connect the speaker with another device to check if it is functioning properly.
- Bluetooth Password: “0000”
- Maximum Distance: 20 ft.

Red LED is not ON while charging:

This could be due to lack of use of Speaker. It needs to be charged for 30 min before the Red LED occurs.

Restore the Factory Setting:

To restore factory settings, hold the Power Button for about three seconds when charging untill the red and blue LED ﬂashes three times.

Tagg Loop Pros & Cons

Pros

Compact and lightweight design for easy portability
Long-lasting battery life up to 8 hours
Water-resistant IPX7 rating for durability
Clear and balanced sound quality
Easy pairing and intuitive controls

Cons

Limited bass response compared to larger speakers
No built-in microphone for voice assistant
No carrying case included

Customer Reviews

Customers have praised the Tagg Loop for its clear sound, long battery life, and durable build. However, some users have noted that the bass response could be better and that the lack of a built-in microphone for voice assistants is a drawback. Overall, it has received positive reviews for its value and performance.

Common complaints include the need for a carrying case and occasional connectivity issues, but these are generally minor and do not detract from the overall user experience.

EXCEPTIONAL WARRANTY

All our products are completely covered by a 30 day express Exchange Program and 12 Months Warranty on Labor and parts defects. Plus, we offer simply the best, 24 hrs customer support that will never rest until you are absolutely satisﬁed!
