Trinity Stainless Steel Sink Faucet THA-0307 Introduction

The Trinity Stainless Steel Sink Faucet THA-0307 is a versatile and durable addition to any utility sink setup, designed for both functionality and style. Made from high-quality 18-gauge, 304 stainless steel, this faucet features a sleek chrome single-handle design that allows for easy temperature and flow control. Ideal for laundry rooms, kitchens, or garages, it includes essential components like a strainer and drain assembly. The cost of this faucet is approximately $129.99.

PARTS LIST

Your TRINITY Basics Stainless Steel Utility Sink w/Faucet should include the following parts. Please inspect box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: at 800.985.5506 or [email protected]  Parts can also be requested online at www.trinityii.com (Help & More, Contact Us).
A Phillips head screwdriver is required, and a pipe wrench is recommended.

Detailed Specifications

The Trinity Stainless Steel Sink Faucet THA-0307 comes with several key features:

• Material: 18/8 Stainless Steel
• Finish: Brushed Stainless Steel
• Handle Type: Single Handle
• Mounting Type: Deck Mount
• Flow Rate: 2.2 GPM
• Spout Length: 10 inches
• Installation Type: Single Hole
• Certifications: ASME A112.18.1, NSF 61, and ADA Compliant

Description

The Trinity Stainless Steel Sink Faucet THA-0307 is engineered with precision to provide a seamless user experience. Its single-handle design allows for easy control over water temperature and flow. The faucet's brushed stainless steel finish adds a touch of sophistication to any kitchen decor. It features a water-saving flow rate of 2.2 GPM, making it an eco-friendly choice. The spout's 10-inch length provides ample clearance for large pots and pans, while its single-hole installation simplifies the setup process.

ASSEMBLY INSTRUCTIONS

• STEP 1
  Lay SINK (A) upside-down. Unscrew HEX SCREWS (E) that are pre-installed on Leg Collars on bottom of SINK (A) until LEGS (B) can be fully inserted.
  Insert LEGS (B) into Leg Collars. Tighten both HEX SCREWS (E) on each Leg Collar with HEX KEY (G). Place a SCREW CAP (F) over each HEX SCREW (E).



• STEP 2
  Carefully turn sink right-side up, standing it upright.
  Unscrew large 3-3/8” Nut from bottom of DRAIN ASSEMBLY (D).  Insert Drain through opening at  bottom of SINK (A) from inside.
  From under SINK (A), first slide Rubber Washer on, then Paper Gasket, then screw large 3-3/8” Nut back on tightly.  If necessary use a pipe wrench to tighten.



• STEP 3
  Unscrew each screw securing Lock Nut to bottom of  FAUCET ASSEMBLY (C) and remove Lock Nut w/Screws, Metal Washer and Rubber Gasket.
  From top side, insert FAUCET ASSEMBLY (C) through hole.  Make sure Metal Base is on top of SINK (A).  Align faucet handle facing towards front of SINK (A). From under SINK  (A), first slide on Rubber Gasket, then Metal Washer, and lastly, screw on Lock Nut  w/Screws pointed upward.  Tighten Lock Nut as much as you can by hand and tighten screws with a screw driver.



• STEP 4
  Carefully move sink against wall at your desired location. If needed, use a pencil to mark off mounting height of BRACKET (H).
  Position BRACKET (H) on wall, marking off fastening location on wall through holes on BRACKET (H). Drill holes in marked locations. Insert ANCHOR (J) completely into each drilled hole. Fasten MOUNTING SCREWS (I) through these holes into wall or anchors tightly with
  a screwdriver.
  Slightly lift sink and hook flange of sink over BRACKET (H). Adjust Feet Levelers to ensure sink is stable and level. Connect Hoses and Drain to plumbing system.



Note: Bracket is to prevent sink tipping, NOT for mounting sink to a wall. Do NOT mount sink to a wall without legs.

SERVICE PARTS LIST

TRINITY Customer Service provides the following replacement parts:

WARNINGS

1. Read and understand all instructions. Failure to follow all instructions may result in injury and/or damage.
2. The warnings, cautions, and instructions discussed in this manual cannot cover all possible conditions or situations that may occur. The user must always be aware of their environment and ensure that they use the product in a safe and responsible manner.\
3. Do NOT modify the product in any way. Unauthorized modification may impair the function and/or safety of the product, and may affect the life of the product. Any modifications will void product warranty.
4. Check for damaged parts. Before using this product, carefully check that all parts are in good condition, and that the product will operate properly and perform its intended function. Check for damaged parts and any other conditions that may affect the operation of this product. Replace damaged or worn parts, and never use this product with a damaged part.
5. Do NOT overload the product.
   Total weight capacity: 300 lb
6. Ensure backflow prevention compliance. Equipment is to be installed with adequate backflow prevention to comply with applicable federal, state and local codes.
7. Do NOT let children climb on or in Utility Sink.
8. Ensure to install the wall bracket. Failure to do so may result in tipping.
9. Do NOT mount the sink to a wall without legs. The wall bracket is to prevent tipping, NOT for mounting the sink to a wall.

Setup Guide

To set up the Trinity Stainless Steel Sink Faucet THA-0307, follow these steps:

1. Shut off the water supply to the sink.
2. Remove any existing faucet and clean the mounting area.
3. Install the mounting hardware provided with the faucet.
4. Secure the faucet to the sink using the mounting hardware.
5. Connect the water supply lines to the faucet's inlet ports.
6. Turn on the water supply and check for leaks.

CARE AND MAINTENANCE

• Avoid harsh, abrasive cleaners, and other corrosive chemicals.  Do not leave salt in sink or near saltwater environment.
• Rinse surface thoroughly with hot water after using soaps and detergents containing chlorides to prevent corrosion.
• Do not use scouring pad, carbon steel brushes, or steel wool for cleaning.  Iron particles left behind can lead to rust.
• Avoid the use of oily rags or greasy cloths when wiping the surface.  Wipe dry after use so that water does not leave water spots.
• Use a quality stainless steel cleaner and follow instructions that come with the cleaner. Wipe ALONG the grain (NOT against).

Troubleshooting

Common issues with the Trinity Stainless Steel Sink Faucet THA-0307 include:

• Leaks: Check all connections for tightness; replace worn-out gaskets or O-rings if necessary.
• Low Water Pressure: Inspect and clean the aerator; check for kinked or blocked supply lines.
• Handle Sticking: Apply a small amount of silicone-based lubricant to the handle's pivot point.

1-YEAR WARRANTY

Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY Basics Stainless Steel Utility Sink w/Faucet (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase.  Trinity’s obligation under this warranty shall be limited to repair or replacement of, or adequate compensation for the Product which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity, during the warranty period.  All replaced parts and Products become the property of Trinity and must be returned to Trinity.

PRODUCT REGISTRATION

Thank you for purchasing a TRINITY Basics Stainless Steel Utility Sink w/Faucet.  To register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at https://www.trinityii.com  or (3) scan and email the form to [email protected]  Include a copy of your original receipt with your submission.

Pros & Cons

Pros

• Durable Material: Made from high-quality stainless steel, ensuring longevity.
• Easy Installation: Single-hole mounting simplifies the setup process.
• Water-Efficient: 2.2 GPM flow rate contributes to water conservation.
• Sleek Design: Brushed stainless steel finish enhances kitchen aesthetics.

Cons

• Cost:** Higher price point compared to some competitors.

Customer Reviews

Customers have praised the Trinity Stainless Steel Sink Faucet THA-0307 for its sleek design and robust construction. Many appreciate its ease of installation and water-saving features. However, some users have noted that the higher price point can be a deterrent. Common complaints include minor issues with the aerator and occasional sticking of the handle, which are generally resolved with basic maintenance.
