Introduction Of Vax Carpet Washer Rapide Ultra series

The Vax Carpet Washer Rapide Ultra series is a powerful and efficient cleaning solution for all your carpet cleaning needs. This series includes various models, each with unique features and specifications, designed to provide deep cleaning and quick drying. The estimated price for this series ranges from $200 to $300, making it an affordable option for those who want a high-quality carpet washer. The Vax Carpet Washer Rapide Ultra series was launched in 2021, and it has since become a popular choice among homeowners and cleaning professionals.

Detailed Specifications

The Carpet Washer Rapide Ultra series features a powerful motor that delivers up to 180 watts of suction power, ensuring that even the toughest dirt and stains are removed. Its SpinScrub technology provides a 360-degree clean, ensuring that every inch of your carpet is cleaned thoroughly. The series also features a large water tank that can hold up to 1.7 liters of water, reducing the need for frequent refills. The washer's lightweight design and easy-to-maneuver handle make it easy to move around, even in tight spaces. Its quick-dry technology ensures that your carpets are dry in just a few hours, preventing the growth of mold and mildew.

Machine Overview

1. Handle
2. Solution trigger
3. Clean water tank release button
4. Clean water tank
5. Recline pedal (hidden)
6. Solution tube port
7. Dirty water tank release lever
8. Dirty water tank carry handle
9. Hose port
10. Rotating brushbar (hidden)
11. On/off pedal
12. Power cord release lock
13. Power cord
14. Hose
15. Wash tool
16. Wash tool solution trigger
17. Handle locking pin
18. Accessory holder
19. Vax pre-treatment carpet cleaning solution (some models only) 20 Pre-treatment wand (some models only) 21 Pre-treatment wand holder (some models only)
20. Vax carpet cleaning solution
21. Vax pet carpet cleaning solution(some models only)
22. Vax Carpet Guard treatment solution (some models only)
23. Float chamber filter

PLEASE NOTE: some parts may vary according to model. Please check inside flap of box for more details.

Accessories

items shown packaged separately

Description of Vax Carpet Washer Rapide Ultra series

The Vax Rapide Ultra series is designed to provide deep cleaning and quick drying, making it an ideal choice for homes with pets and children. Its SpinScrub technology ensures that every inch of your carpet is cleaned thoroughly, removing dirt, stains, and allergens. The washer's powerful motor provides suction that lifts dirt and stains, leaving your carpets looking and feeling clean. Its large water tank reduces the need for frequent refills, saving you time and effort. The quick-dry technology ensures that your carpets are dry in just a few hours, preventing the growth of mold and mildew.

Operation

Assembling your carpet washer handle

• Locate locking pin and press in points shown to remove.
• Insert handle and re-fit locking pin.
• Locking pin will ‘click’ when in place.

Assembling your tool caddy and hose

• Ensure locking tabs are horizontal. Attach caddy to unit top first.
• Rotate tabs 90˚ clockwise to lock caddy onto unit.
• Fit hose connector end in first.
• Wrap hose around caddy tightly anti-clockwise. Clip in the last wrap of the hose and wash tool as shown.

Assembling your pre-treatment kit (some models only)

Wrap solution tube around holder for storage.

Before you begin cleaning

NOTE: Do not over saturate your carpet.

• Vacuum your carpets thoroughly.
• Test for colourfastness - Wet a white absorbent cloth with the solution. In a small, hidden area of your carpet, gently rub the surface with the dampened cloth. Wait ten minutes and check for colour removal or bleed with white paper towel or cloth. If your carpet has more than one colour, check all colours.
• When cleaning an entire room, move furniture out of the area to be cleaned. If the furniture is too heavy to move, place aluminium foil or wax paper under legs. This will prevent wood finishes from staining your carpet. Pin up furniture skirts and curtains.

IMPORTANT: Only use Vax carpet cleaning solution. Using other solutions may cause excess foaming. Excessive foam will prevent the machine from working effectively. Using other solutions will invalidate the guarantee.
Operating your pre-treatment wand (some models only )
NOTE: Pre-treating your carpet before washing will help to remove stubborn stains.
NOTE: Do not over saturate your carpet.

• Pour required dose of pre-treatment solution (approx. 40ml per 1L of water).
• Mix solution with warm water. (max 40˚ C)

• Remove clean water tank.



• Fill clean water tank with solution mix.
• Tighten cap before returning tank to unit.

• Unwrap power cord and plug unit in.



• Spray evenly onto desired areas.

NOTE: Leave pre-treatment solution to work for 10-15 minutes then wash carpets as described on page 6 of Operation.
IMPORTANT: Before setting the machine up to wash, ensure the clean water tank is rinsed thoroughly of a pre-treatment solution.

Operating your carpet washer
NOTE: Your dirty water tank is fitted with a float. When the dirty water tank is full or the floor head is not in contact with the carpet the float will shut off the suction at the floor nozzle. You will be able to hear if this has happened as the motor noise on the unit will increase. Once the float is activated, empty the dirty water tank if full. If the dirty water tank is not full then turn off your machine at the power switch and wait for the float to settle before re-starting.

• Pour required dose of cleaning solution (approx. 40ml per 1L of water).
• Mix solution with warm water. (max. 40˚C)

• Remove clean water tank.



• Fill clean water tank with solution mix.
• Tighten cap before returning tank to unit.

• Unwrap power cord and plug unit in.



• Recline the machine. NOTE: When machine is reclined brushbar will rotate. Upright position brushbar will not rotate.
• Press trigger to release solution.
• For best results apply solution on the forward stroke and and release the trigger to recover solution on the backward stroke.

Picking up spills

Using the wash tool
NOTE: Do not over saturate your upholstery.
NOTE: The clean water tank will need to be filled with solution and water before use.

Protecting your carpets
NOTE: Using Vax Carpet Guard solution will protect your carpets from future stains. NOTE: Do not over saturate your carpets.

• Hold the Vax Guard solution approximately 1 metre away from the desired area and spray evenly.
• Leave to dry for 30 minutes.

General Safety Information

FOR HOUSEHOLD USE ONLY.
When using the carpet washer, basic safety precautions should always be observed, including the following

1. Do not leave the carpet washer unattended when plugged in. Unplug it from socket when not in use.
2. To prevent electric shock do not use outdoors.
3. Not to be used as a toy. Children should be supervised to ensure that they do not play with the appliance.
4. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge,unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.
5. Use only as described in this manual.
6. Do not use the carpet washer if it has been dropped, damaged, left outdoors or dropped into water. Do not use the carpet washer with a damaged cord or plug. If the supply cord is damaged, it must be replaced by the manufacturer or a recommended Service Agent to avoid hazard and invalidating the guarantee.
7. Do not pull or carry by cord/hose. Do not use the cord/hose as a handle, close a door on the cord/hose or pull cord/hose around sharp edges or corners. Do not run the carpet washer over the cord/hose. Keep the cord away from heated surfaces.
8. Do not unplug by pulling on the cord.
9. Do not handle the plug or carpet washer with wet hands.
10. Do not put any objects into openings or operate with openings blocked, keep them free of anything that may reduce airflow.
11. Keep hair, loose clothing, fingers and all parts of the body away from openings and moving parts.
12. Do not use the carpet washer on any glowing, burning or smoking particles.
13. Do not use without the solution tank and dirty water tank in place.
14. Turn off all controls before unplugging.
15. Do not use to pick up flammable or combustible liquids such as petrol, or use in areas where they may be present.
16. Keep the unit on the floor.
17. Do not use an extension cord.
18. Do not attempt to remove blockages with sharp objects as they may cause damage.
19. Store indoors put away after use to prevent tripping accidents.
20. Using improper voltage may result in damage to the motor and possible injury to the user. The correct voltage is listed on the rating label.
21. A hazard may occur if the carpet washer runs over the power supply cord.
22. To prevent dirty water from running into the motor, do not hold the appliance upside-down or lay on its side. Use the appliance in normal cleaning position.
23. Use extra care when cleaning on stairs.
24. Do not carry appliance while motor is running.

IMPORTANT: Cleaning filters maintain cleaning ! performance. Vax recommends that your filters should be checked and cleaned periodically. If your filters are washable make sure they are completely dry before inserting back into the machine.
This machine is intended for household use only, and NOT for commercial or industrial use.
PLEASE KEEP THESE INSTRUCTIONS FOR FURTHER USE.

Maintenance

(Keep your Vax as good as new)
WARNING: To reduce the risk of electric shock, turn the machine off and unplug from electrical outlet before performing maintenance/troubleshooting checks.
Emptying the dirty water tank
NOTE: Rinse out tank with clean water and leave to air dry before storing your machine.

Cleaning the float chamber filter

Rinse under water to remove debris (max 40ºC). Allow to dry completely before replacing or storing away your machine.
Removing blockages from the brushbar
WARNING: To reduce the risk of electric shock, turn the machine off and unplug from electrical outlet before performing maintenance/troubleshooting checks.

Threads caught in the brushbar can be cut.
Replacing the belt

• Use a crosshead screwdriver to remove two (2) screws.
• Remove damaged/broken belt off the spindles.
• Replace new belt on to spindles and secure the belt cover.

Storage

• Empty and rinse out clean and dirty water tanks and leave to air dry before replacing.
• You can remove the handle and tool caddy for convenient storage.

Troubleshooting

If your Vax Carpet Washer Rapide Ultra series is not working correctly, there are a few things you can check. First, ensure that the washer is properly plugged in and that the power cord is not damaged. Check the water tank to ensure that it is properly filled and that there are no blockages in the hose. If the washer is still not working, refer to the user manual for troubleshooting instructions. It is important to note that the washer should not be used on wet or damp carpets, as this can cause damage to the machine. Always follow the manufacturer's instructions for use and maintenance.

Pros & Cons of Carpet Washer

Pros

• Powerful motor that delivers up to 180 watts of suction power
• SpinScrub technology that provides a 360-degree clean
• Large water tank that reduces the need for frequent refills
• Quick-dry technology that ensures carpets are dry in just a few hours
• Lightweight design and easy-to-maneuver handle

Cons

• May be too loud for some users
• May not be suitable for deep pile carpets
• The hose may be too short for some users
• May not remove all stains, especially old or set-in stains

Customer Reviews of Vax Carpet Washer Rapide

Customers have praised the Vax Carpet Washer Rapide for its powerful suction, easy-to-use design, and quick-drying technology. Many have noted that the washer is lightweight and easy to maneuver, making it an excellent option for those who have a lot of carpet to clean. However, some have reported issues with the hose length and the machine's ability to remove old or set-in stains. Overall, the Vax Carpet Washer Rapide Ultra series has received positive reviews from customers who appreciate its powerful cleaning capabilities and quick-drying technology.
