Introduction

The Yaberauto YA70 Car Jump Starter is a powerful and portable device designed to jump-start your vehicle's dead battery quickly and easily. With a capacity of 20000mAh, it can jump-start most 12V vehicles up to 30 times on a single charge. The YA70 also features a built-in LED flashlight, compass, and USB charging ports, making it a versatile tool for both emergency situations and everyday use. The estimated price of the Yaberauto YA70 Car Jump Starter is around $100, and it is now available for purchase.

Package Content

O Jump Starter with Air Compressor

• 1 Gas Nozzles *3
• Air Pump Hose *1
• Smart Jumper Clamps *1
• USB-C Charging Cable *1
• DC Cigarette Lighter *1
• User Manual *1
• Portable Storage Bag *1

Specifications

• Model: YA70
• USB1 Output:  5V/2.4A
• USB2 Output:  5V/2.4A, 9V/2A, 12V/1.5A
• USB-C Input:  5V/2A, 9V/2A
• DC Output:  12V-16.8V 1 0A
• Size:  220 • 97 • 47mm

Know Your Product

1. LED Screen
2. Lighting Button
3. Power Button
4. Switch Button (Inflation Mode Switch/LI nit Switch)
5. Air Pressure Increase Button
6. Air Pressure Reduction Button
7. USB-C Input
8. DC Output
9. Output 1
10. Output2
11. Jump-Start Port
12. LED Light
13. Air Hose Interface
14. "Smart Clamp" plug
15. Red Jumper Cable(+)
16. Black Jumper Cable(-)
17. Indicator Light
18. Force Start Button

Charging Your Jump Starter

1. Please use the included USB-C charging cable and adapter (5V/2A and above) to charge the product. (adapter is not included)
2. It will take about 5 hours to fully charge the unit when using a 5V/2A adapter. In order to extend the battery life, please fully charge the unit every 3 months.
3. When using the product for the first time, please make sure the product is fully charged.

Powering Your Devices

This portable jump starter is equipped with dual USB outputs.
(Output 1: 5V/2.4A Output 2: 5V/2.4A, 9V/2A, 12V/1.5A) that can quickly charge your portable electronic devices such as phones, tablets, etc.

LED Light

• Short press power button to turn on the device, then long press the lighting button more than 3 seconds to turn on the light mode, then short press lighting button to change the light modes in lighting, SOS, Strobe.
• Long press the lighting button more than 3 seconds to turn off the LED light.

Air Compressor Yaberauto YA70 Car Jump Starter

Built-in 150 PSI air pump, it supports 5 inflation modes:car inflation mode, motorcycle inflation mode , bicycle inflation mode, basketball inflation mode, custom inflation mode; 3 kinds of unit switching, BAR, KPA, PSI.

Description

The Yaberauto YA70 Car Jump Starter is a compact and lightweight device, measuring only 7.3 x 3.1 x 1.5 inches and weighing 1.1 pounds. It is made of high-quality materials and has a durable design, making it ideal for use in various environments. The device has a built-in LED flashlight with three modes: flashlight, SOS, and strobe. It also has a compass that can help you navigate in emergency situations. The YA70 has two USB charging ports that can charge your smartphones, tablets, and other devices. It also has a 12V output that can power your car accessories. The device has a built-in safety feature that protects against reverse polarity, short circuits, over-current, overload, and over-voltage.

Setup Guide

To use the Yaberauto YA70 Car Jump Starter, follow these steps:

1. Charge the device fully before using it for the first time.
2. Connect the jumper cables to the YA70's jump-starting terminals.
3. Attach the other end of the jumper cables to your car's battery terminals, making sure to connect the positive (red) cable to the positive terminal and the negative (black) cable to the negative terminal.
4. Turn on the YA70 and wait for the indicator to show that the device is ready to jump-start the car.
5. Start your car's engine. If the engine does not start, wait for a few minutes and try again.
6. Disconnect the jumper cables in the reverse order that you connected them.

How to Inflate Car Tires

1. Take out the device and connect the air hose and tighten it, short press the power button to start the device, short press the power button again to enter the inflation mode,
2. Short press the switch button to select the inflation mode, long press the switch button to switch 3 kinds of unit, press the "+" button / "- " button to adjust the air pressure value,
3. Long press the power button to start inflation
4. Short press the power button or switch button , it will automatically stop inflating.

Yaberauto YA70 Car Jump Starter Your Car

1. Insert the plug of the smart clamp into the jump starter, the indicator light of the smart clamp will flash red and green alternately

2. Correctly clip the red and black clamps to the electrodes of the car battery (red to positive and black to negative), the indicator light of the smart clamp is always green.



3. Start the vehicle.

4. When the vehicle is started, remove the jumper cable from the car battery immediately.



Note:

1. If it does not start successfully, please wait for 60 seconds and then repeat the above steps.
2. When using this product, please do not connect two clips together. Otherwise, this product will be damaged.

Maintenance

1. Do not use the product to start an already expanded car battery.
2. Inflate continuously for more than 1 O minutes. It is recommended to stop for 1 O minutes and continue to use after the temperature of the machine drops!
3. When using this product, keep the surroundings well ventilated, do not block the cooling holes, and do not use it in the following environments:
   1. Damp places and places easily splashed by water.
   2. A place where it is easy to drop.
   3. A place subject to vibration, corrosion, dust, and chemical gas hazards.
   4. A place where flammable and explosive materials are stored, and near a high-temperature heat source.
4. Check the battery level at least once every 3 months and recharge it in time.
5. Keep away from children and pets.

Troubleshooting

If the Yaberauto YA70 Car Jump Starter does not work, try these troubleshooting steps:

1. Make sure that the device is fully charged.
2. Check the jumper cables for any damage or wear and tear.
3. Make sure that you have connected the jumper cables to the correct terminals.
4. Check the battery voltage of your car. The YA70 can only jump-start batteries with a voltage between 12V and 12.6V.
5. If the device still does not work, contact Yaberauto's customer support for further assistance.

Indicator Light Troubleshooting Guide

Error Message on Screen/ Cause/ Solution

• "E1 "- Low temperature charging protection: Stop charging, it will automatically release protection when the temperature rises above 2°C
• "E2" - High temperature charging protection: Stop charging, it will automatically release protection when the temperature is lower than 45°C
• "E3" - High temperature discharge protection: Stop charging, it will automatically release protection when the temperature is lower than 65°C
• "E?'' - Cylinder over temperature protection: Automatically release the protection when the temperature is lower than 70° C, After the protection is released, please wait for 10 minutes before continuing to operate.

Warranty

Yaberauto YA70 Car Jump Starter If there is any problem or failure during use, please send your question and order number to our email. We will provide you with good after-sales service within 24 hours [email protected]

Pros & Cons

• Pros:
  • Compact and lightweight design
  • High capacity jump-starter
  • Built-in LED flashlight and compass
  • Dual USB charging ports
  • Multiple safety features
• Cons:
  • May not work with larger vehicles or batteries with a voltage higher than 12.6V
  • The LED flashlight may not be bright enough for some users
