Introduction

Aftermaster Pro was developed by some of the biggest names in music and audio to greatly improve the quality of TV audio, without compromise. Our team has produced, engineered and mastered more hit music than any audio company in the world. We know what sounds right.  Aftermaster Pro will make all your TV audio sound noticeably fuller, deeper, clearer and overall, much more enjoyable. For the first time, you’ll actually hear everything that you were meant to hear by the people that created your favorite programs and music.

Our Aftermaster process will also make your TV audio noticeably louder even though your volume level and power consumption doesn’t change. This is possible because our patented and award winning process improves audio TV throughout its entire frequency range and allows you to hear a sound quality and a presence that you’ve never heard before.

Detailed Specifications

The After-Master TV Audio Remastering Device 195651636097 comes with the following key features:

• Advanced audio processing algorithms for clear and crisp sound
• compatibility with all major TV brands and models
• Multiple audio modes for customized listening experiences
• Simple and intuitive interface for easy operation
• Compact and sleek design for easy placement near your TV

Device Information

HDMI Connection

Button Control

The Aftermaster Pro has two buttons for controlling port selection and audio processing.

• POWER (1)

  • Button one is used to select the desired HDMI Input Port and the ON/OFF State



• AM (2)

  • Button two turns the Aftermaster audio Processing ON and OFF. When ON, LED 4 will be illuminated.



Description

The After-Master TV Audio Remastering Device is a high-quality audio solution for TVs. It uses advanced audio processing algorithms to enhance the audio quality of your TV shows and movies, making them sound clearer and more immersive. With its compatibility with all major TV brands and models, this device is a versatile and convenient solution for improving your TV audio. Its multiple audio modes allow for customized listening experiences, and its simple and intuitive interface makes it easy to use for people of all ages.

Connecting Aftermaster Pro

Television

1. Connect the USB power supply to an available wall socket and then to the USB Power port of the Aftermaster Pro.
2. Connect the HDMI source device (s) to an HDMI input Port on the Aftermaster Pro. If you are using only one device for input, please use input 1.
3. Connect the HDMI output port of the Aftermaster Pro to your television with the supplied HDMI cable.
4. The first and fourth lights will illuminate.

5. Allow 1-2 minutes for your Aftermaster Pro to initialize.





Dual HDMI Source Input

1. Connect the USB power supply to an available wall socket and then to the USB Power port of the Aftermaster Pro.
2. Connect the HDMI source devices to the HDMI input Ports on the Aftermaster Pro.
3. Connect the HDMI output port of the Aftermaster Pro to your television with the supplied cable.
4. To switch ports, between Port 1 and Port 2 press the power button, the red LED lights will indicate the selected port.

5. Allow 1-2 minutes for your Aftermaster Pro to initialize.



Television With Add-On Audio System

1. Connect the USB power supply to an available wall socket and then to the USB Power port of the Aftermaster Pro.
2. Connect the HDMI source device(s) to one of the HDMI input Ports on the Aftermaster Pro. Your Aftermaster Pro will turn on automatically in approximately 1 minute.
3. Connect the HDMI output port of the Aftermaster Pro to your television with the supplied cable. Connect your Televisions audio output directly to your speaker system (amplifier, sound-bar etc.) via the included HDMI cable.
4. If your source device (cable, satellite box, etc.) is connected directly to your amplifier or speaker system before it connects to your TV, install your Aftermaster Pro system between the source device and your amplifier.

Optical Systems
Your Aftermaster Pro is designed to work with literally thousands of audio/video hardware combinations. In some circumstances, additional hardware may be required to install your Aftermaster Pro. If your audio system is “optical” only based, you may need to purchase an “HDMI to optical” audio converter to complete the installation.

After-Master TV Audio Button Control

USB Power Connected

Power Button

1. Press One Power On
2. Press Two HDMI Port 1

Indicator Light Codes

Device Reference Guide

Reference Terms

• Power: Port selection button and power ON/OFF control.
• AM ON/OFF: Aftermaster ON/OFF selection button.
• Indication Lights: Display the user selected port.
• Cable Box: Any device that provides an audio and/or video signal that can be processed by Aftermaster Pro. This includes set-top boxes for both cable and satellite programming suppliers, computers and streaming services such as Roku and Apple TV.
• USB Power: USB power input must be connected when using with an HDMI connection.
• HDMI IN 1:  HDMI input port 1, connect an HDMI video source here (set-top cable or satellite box, gaming console, computer, etc.)
• HDMI IN 2: HDMI input port 2, connect an alternate HDMI video source here.
• HDMI OUT: HDMI Output, connect this to television or display with the supplied HDMI cable.

Setup Guide

Setting up the After-Master TV Audio Remastering Device 195651636097 is easy and straightforward. Follow these steps to get started:

1. Plug the device into a power outlet.
2. Connect the device to your TV using an audio cable.
3. Turn on the device and your TV.
4. Select the audio output on your TV to the After-Master device.
5. Choose your desired audio mode on the device.

Important safety information for the Aftermaster Pro

• WARNING: Failure to follow any of these safety recommendations could result in damage, electric shock, injury or fire to the AfterMaster Pro device and your person or property. Please Read all the safety information below before using your Aftermaster Pro.
• Handling: Handling the AM Pro properly is important. It is made out of aircraft grade extruded aluminum, and it is machined to the highest standards. It also has some of the most advanced electronic devices inside, so please avoid dropping or crushing the unit. Do not continue using the Aftermaster Pro if it comes in contact with liquid. Don’t use an AM Pro if any damage is visible.
• Repairing: There are no user serviceable parts inside the AM Pro and it can only be replaced or repaired at an authorized service center or the factory. Never discard the unit in the trash. It can only be sent back to a dealer or the factory for repair or an authorized electronic recycling center for disposal.
• Battery: The lithium Ion battery can only be replaced at an authorized service center or the factory.
• Hearing loss WARNING: Listening to sound at high volumes for extended periods may damage your hearing. Please adjust the volume before using any listening devices.
• Explosive surroundings: Plugging in, charging or using the Aftermaster Pro in an area which is a potentially explosive atmosphere could be hazardous. Obey all local signs, laws and instructions.
• Choking hazard for Children: Certain parts or accessories may be  a choking hazard to small children. Keep all accessories away from unsupervised children.

Troubleshooting

1. The Aftermaster Pro Device is connected to my TV and Source Device correctly but there is no sound?
   • Please go to the settings menu on your television to ensure that your speaker setting has “TV Speakers” selected for sound output.
   • Press the Aftermaster Pro power button 2 or 3 times until the number 1 and number 4 lights are on.
2. The Aftermaster Pro device is connected to my TV and my Source Device correctly but there is no dialogue track?
   • Please check the audio settings on the HDMI source device to ensure any other audio enhancements.
   • Turn your Aftermaster Pro off and then on and make sure that number 1 and number 4 lights are on..
3. The Aftermaster Pro Device is connected to my TV and Source Device Correctly but there is no Video or Audio.
   • Allow 1-2 minutes for Aftermaster Pro to initialize each time it is plugged in.
   • Unplug the power and any HDMI cables connected to your Aftermaster Pro and then reconnect them after 15 seconds.

After-Master TV Audio Remastering Device Pros & Cons

Pros

• Improves TV audio quality
• Compatible with all major TV brands and models
• Multiple audio modes for customized listening experiences
• Simple and intuitive interface
• Compact and sleek design

Cons

• May not be compatible with older TV models
• Higher price point compared to some other audio solutions
• May require adjustment to audio settings on TV for optimal performance

WARRANTY

What is Covered
Our warranty covers any defects in materials or workmanship with the exceptions stated below.
Warranty Period
Our warranty runs for a period of one year from the date that you purchased your Aftermaster Pro or from the date that you took delivery (if ordered on-line).

Customer Reviews

• "I've been looking for a solution to improve my TV audio, and the After-Master device did not disappoint. It was easy to set up and the audio quality is significantly better than before."
• "I was skeptical at first, but the After-Master device really does make a difference in the audio quality of my TV shows and movies. It's definitely worth the investment."
• "I love the multiple audio modes on the After-Master device. It allows me to customize my listening experience and make my TV shows and movies sound just the way I like."

Most Common Complaints

Some customers have reported issues with compatibility with older TV models and the need to adjust audio settings on their TV for optimal performance.
