EdgeStar CRF150SS-1 Refrigerator-Freezer

Introduction Of EdgeStar CRF150SS-1 Refrigerator-Freezer

Thank you for purchasing this EdgeStar refrigerator/freezer. We hope that this purchase will be the beginning of a lasting and rewarding relationship between you and EdgeStar. We will provide the customer support and exemplary products necessary to nurture that relationship.  This manual contains important information regarding the proper installation, use, and maintenance of your dual-function refrigerator/freezer. Following this manual will ensure that your product will work at its peak performance and efficiency.
Please save the original product packaging in case you need to safely transport your dual-function refrigerator/freezer.

Detailed Specifications

The EdgeStar CRF150SS-1 Refrigerator-Freezer is a compact refrigerator-freezer with a total capacity of 4.4 cubic feet. The refrigerator section has a capacity of 2.6 cubic feet and features adjustable glass shelves, a crisper drawer, and door storage. The EdgeStar CRF150SS-1 Refrigerator-Freezersection has a capacity of 1.8 cubic feet and features a slide-out wire basket. The unit operates on a standard household current of 115V and has a noise level of less than 45 decibels. It also has a temperature range of 34°F to 50°F for the refrigerator and -11°F to 5°F for the freezer. The exterior dimensions of the unit are 23.5" x 22.6" x 33.75" (H x W x D) and it has a stainless steel door finish.
Note: Technical data and performance information are provided for reference only. Specifications are subject to change. Check the rating label on the freezer for the most accurate information.

• Description of product : Convertible Refrigerator or Freezer
• Model : CRF150SS-
• Voltage / Frequency : AC 115V ~ 60Hz
• Amperage :1.1 A
• Color Black: Cabinet; Stainless Steel Door
• Storage Capacity: 1.1 Cu. Ft.
• Refrigerant R600a: 0.92 oz.
• Freezer Temperature Range: 5° F ~ -11.2° F
• Refrigerator Temperature Range: 32° F ~ 50° F
• Dimensions: (Height x Width x Depth ) 19 5/16” x 18 11/16” x 17 1/8”
• Net Weight: 37 lbs.

Description of EdgeStar CRF150SS-1 Refrigerator-Freezer

The EdgeStar CRF150SS-1 is the perfect solution for those who need a small refrigerator-freezer in their office, dorm room, or other small space. The unit has a sleek and modern design with a stainless steel door finish. The interior is spacious and well-organized, with adjustable glass shelves, a crisper drawer, and door storage in the refrigerator section, and a slide-out wire basket in the freezer section. The unit is energy efficient and operates quietly, making it a great choice for any setting. Additionally, the temperature range is adjustable, allowing for maximum flexibility in storing different types of food and drink.

Parts Identification

Installing the Refrigerator / Freezer

Place the appliance in a location with a firm base. In order to prevent vibration and noise, the freezer must be leveled by adjusting the front foot. Choose a well-ventilated location with no less than five (5) inches of clearance around the unit in all directions. Place the refrigerator / freezer away from direct sunlight and heat sources such as an oven or boiler.
Warning: This appliance must be grounded. Do not use an adapter to circumvent the ground prong.

First-Time Operating Instructions

Before use, make sure all packaging labels and materials are removed from the unit. Be sure to keep track of all included parts and pieces before discarding the packaging materials. It is advised that you keep the original box and packaging materials in case you ever need to move or ship the appliance in the future.
Let the unit stand for at least 24 hours before you use it; this allows the cooling components time to settle from transit. The instruction manual should be read before use.

Operation

Before plugging in your refrigerator / freezer for the first time, remove all packaging materials and clean the refrigerator / freezer with lukewarm water and baking soda. Wipe the unit dry with a soft cloth.

• Temperature Control
  The temperature in the refrigerator / freezer is controlled by the thermostat control knob located inside the unit. Turn the thermostat control knob clockwise or counterclockwise to regulate the temperature inside the refrigerator / freezer. The markings on the control knob indicate the “MIN, MAX, and OFF” positions for the different temperature grades. The temperature decreases from high to low, with the MIN position being the warmest and the MAX position being the coldest.
• Storing Frozen Food
  When using the refrigerator / freezer for the first time or after defrosting, turn the temperature control to the MAX setting for at least two (2) hours before introducing the food to be stored. All frozen food products you purchase should be placed in the unit as soon as possible to prevent the frozen food from defrosting. You should always follow any storage recommendation printed on food packaging.
• Freezing Fresh Food
  Ensure that your freezing operations are carried out under the most hygienic conditions as freezing alone does not sterilize the food. It is advisable to freeze large amounts of food by packing it into separate meal portions and not in bulk form. Never put hot or even warm food into the unit. Prior to storing frozen food, pack it in plastic bags, aluminum sheets, or freezing containers and then put it in the freezer. Never freeze more than the maximum permissible amount of food.
• Defrosting
  Remove the power plug from the wall socket, open the door, and move all of the appliance’s contents to a cool place.
  Defrost the unit using a plastic scraper, or let the temperature rise naturally until the frost melts. Then wipe away the remaining ice and water. When you are finished defrosting the unit, plug the freezer back into the power supply.

Cleaning and Maintenance

Before you start to clean your refrigerator/freezer remove the power plug from the electrical outlet. Clean the unit with a cloth soaked in a solution of lukewarm water and baking soda. Dry the refrigerator/freezer with a soft cloth.

Important Safety Information about CRF150SS-1

Improper handling can cause serious damage to the EdgeStar refrigerator/freezer or injury to the user. This refrigerator/freezer is designed for domestic indoor use only. Do not use the unit for industrial or commercial use. Any other use may invalidate the warranty. Please review the ratings label located on the rear panel of the unit for electrical and other technical data related to this unit. The unit must be used in a properly grounded wall outlet.
Please read and follow the safety information listed below to reduce the risk of fire, electric shock, or injury.

Electrical Safety

• Do not exceed the power outlet ratings.
• It is recommended the refrigerator / freezer be connected on its own circuit.
• The unit must be installed in accordance with state and local electrical codes.
• A standard electrical supply (115 V, 60 Hz), that is properly grounded in accordance with the National Electrical Code and local codes and ordinances is required.
• Use outlets that cannot be turned off by a switch or pull chain.
• Always turn the unit off and unplug it from the outlet when cleaning.
• Unplug the unit if it is not going to be used for an extended period of time.
• Do not operate the unit with a power plug missing the ground plug, a damaged cord, or a loose socket.
• Be sure the refrigerator / freezer is properly grounded.
• Never plug or unplug the unit with wet hands.
• Do not bypass, cut, or remove the grounding plug.
• Do not use extension cords or power strips with this unit. You may need to contact your electrcian if it is necessary to use a longer cord or if you do not have a grounded outlet. Do not modify the power cord’s length or share the outlet with other appliances.
• Do not start or stop the unit by switching the circuit’s power on and off.
• If the power cord is damaged, it must be replaced by the manufacturer or a qualified technician.
• Never repair the unit while it is plugged in.
• Immediately unplug the unit if it makes strange sounds, emits smells, or smoke comes out of it, and contact customer service.
• Do not remove any part of the casing unless you are instructed to do so by an authorized technician.
• You should never attempt to repair the unit yourself.
• Contact customer service for service options if the unit needs service.

   General Safety

• To prevent back and other types of injuries, use at least two people to move and install the refrigerator / freezer.
• This appliance is not intended for use by persons, including children, with reduced physical, sensory or mental capabilities, unless they have been given supervision or instruction concerning the use of the appliance by the person(s) responsible for their safety.
• Install the refrigerator/freezer in a well-ventilated area where the ambient temperature is above 50°F and below 90°F.
• Do not place hot or warm items into the freezer before they cool down to room temperature.
• This unit is designed to be installed indoors, and protected from rain, sleet, snow, and / or moisture.
• This unit is not intended to be used by children
• Children should be supervised to ensure that they do not play with this product.
• Never allow children to crawl inside the refrigerator / freezer. If you are disposing of the unit, remove the door.
• Do not use this cooler near flammable gas or combustibles, such as gasoline, benzene, thinner, etc.
• Do not place the unit near heat sources such as ovens, grills, or direct sunlight.
• Only use in an upright position on a flat, level surface and provide proper ventilation.
• Do not pinch or kink the power supply line between the unit and cabinet.
• Do not leave any cleaning solutions in the unit.
• Do not use solvent-based cleaning agents or abrasive solutions to clean the unit as they may damage the interior and exterior.
• Do not place any other appliances on top of the unit.
• Do not turn the unit upside down, on its side, or at an angle off level.
• If your model of refrigerator/freezer is equipped with a lock, take care to keep the keys away from children.
• Do not move the unit without emptying the contents and securing the door in a closed position.

Caution: Flammable Refrigerant Used! When handling, moving, and using the refrigerator / freezer, make sure to avoid either damaging the refrigerant tubing, or increasing the risk of a leak.
Note: This owner’s manual is provided for reference use only. Specifications may change without prior notice. Refer to the product label on the back of your refrigerator / freezer for the latest technical information.

Normal Attributes

The following characteristics are part of normal operation and should not be viewed as malfunctions:

• A gentle trickling sound caused by coolant flowing into the pipe.
• The compressor operating at a high temperature.

Preparing the Refrigerator / Freezer for Storage

If the refrigerator / freezer will not be used for a long period of time, proceed as follows:

• Disconnect the unit from the power supply by removing the plug from the wall socket.
• Clean and dry the inside of the unit as instructed in the “Cleaning and Maintenance” section.
• Leave the door open to prevent any unpleasant smells from building up while the refrigerator/freezer is not in use.

Energy Saving Guide

• Do not open the door too often, especially when the weather is wet and hot. Once you open the door, close it as soon as possible.
• Every now and then check if the appliance is sufficiently ventilated. Make sure there is adequate air circulation behind the refrigerator / freezer.
• For household refrigerating appliances, in normal temperature conditions, leave the thermostat at the middle setting.
• Before loading the appliance with fresh food, make sure the food is cooled to the ambient room temperature.
• The ice and frost layer increases energy consumption. Be sure to clean the appliance once this layer reaches a thickness of 1/8”.

Troubleshooting

Before calling for service please check for the following possible causes.

• The refrigerator / freezer is not working
  • Check that the plug is inserted correctly into the wall socket.
  • Check whether there is power to the wall socket by plugging in another appliance.
  • Check the fuse in the refrigerator / freezer’s plug.
• The refrigerator / freezer is noisy when running
  • Check that the refrigerator / freezer is level and is not in contact with another appliance or piece of furniture.
• The refrigerator / freezer does not cool sufficiently
  • If the door is opened too often, or if it is left open for a long time, it will take longer for the refrigerator / freezer to reach its set temperature.
  • Make sure that the airflow to the rear of the unit hasn’t been reduced due to insufficient clearance around the refrigerator / freezer.

EdgeStar Warranty

LABOR: For a period of NINETY (90) DAYS from the date of original purchase, labor will be performed free of charge at an authorized EdgeStar repair facility. At its option, EdgeStar will repair the product with new or remanufactured parts, or exchange the defective product with a new, refurbished, or remanufactured product. If a product is replaced, it will carry the remaining warranty of the original product. After the ninety (90) day period, EdgeStar will no longer be responsible for labor charges incurred. All defective products and parts covered by this warranty will be repaired or replaced on a mail-in basis to an EdgeStar-authorized repair facility.

Pros & Cons of EdgeStar Refrigerator-Freezer

Pros

• The compact size is perfect for small spaces
• Adjustable temperature range for flexibility
• Quiet operation
• Well-organized interior with adjustable shelves and door storage
• Sleek and modern design

Cons

• May be too small for some users
• Stainless steel finish may show fingerprints
• Limited freezer space
• May not be as energy-efficient as some other models

Customer Reviews

Customers love the EdgeStar CRF150SS-1 Refrigerator-Freezer for its compact size, adjustable temperature range, and well-organized interior. Many note that it is perfect for small spaces and that it operates quietly. However, some customers note that the freezer space is limited and that the stainless steel finish may show fingerprints. Additionally, some customers mention that it may not be as energy efficient as some other models.
