Introduction

By purchasing the AquaSure Smart Plus RO+ UV+ MTDS water purifier, you have just invested in your family's health by providing them protection against waterborne diseases. The AquaSure Smart Plus RO+ UV+ MTDS has been designed to provide you with safe drinking water, day after day. We recommend you to read the User Manual carefully before commencing to use the product.

TECHNICAL SPECIFICATIONS

Recommended Input Water Quality

Note: The performance data presented in the table is applicable under ‘standard laboratory conditions’. Actual Performance may vary depending on the input water quality, water pressure and condition of filters. Technical Specifications are subject to change without prior notice. Input water quality/pressure and TDS content are important determinants of recovery rate and TDS rejection.

Standard Test Condition

Feed water Quality: TDS Max.: 1000 mg/liters with NaCl,  Pressure: 1.0 kg/cm²,  Turbidity: Max. 1 NTU,  Temperature: 25°C,  Chlorine: below 0.2 mg/liters,  Iron: below 0.3 mg/liters Pressure on Membrane: 75 psi & Product recovery @ 25% Life: 6000' Liters.

Actual performance may vary based on the input water conditions- TDS, Hardness, Pressure, Temperature & pH

Description

The Eureka Forbes AquaSure RO+UV+MTDS is a high-performance water purifier that ensures the delivery of pure and safe drinking water. The RO technology removes dissolved impurities, heavy metals, and salts, while the UV technology kills bacteria, viruses, and other microorganisms. The MTDS system helps to maintain the TDS level of the purified water, ensuring that it is not only safe but also tastes great. The product is designed with a sleek and modern look, and it is easy to install and maintain. The user-friendly interface and digital display make it easy to operate, and the product comes with a one-year warranty from the manufacturer.

MULTI-STAGE PURIFICATION PROCESS

AquaSure Smart Plus RO+UV+MTDS has approx. 6 litres of purified water storage capacity and the rate of recovery for purified water is approx. 25%. It is also equipped with a Microswitch Float Valve Mechanism which automatically shuts off the pump. The sealed lid of the storage tank protects water from dust and other foreign objects.

TDS modulator is located inside the product. As per factory setting, it comes in fully closed mode. TDS level of output water can be increased by slowly loosening (anticlockwise) the spindle of the TDS modulator. Normally a slight quarter turn is enough to increase the TDS of output water. Rotating the spindle in a clockwise direction closes the blending valve and reduces the level of blending. Please note that TDS blending and its adjustment are dependent upon the level of TDS of input water and on the TDS reduction capacity of the RO Membrane. TDS adjustment should be done by the Company authorized personnel.

INSTALLATION

1. Install it in a dry, ventilated place, keeping it away from direct sunlight or below freezing temperatures.
2. Connect it to only cold tap water. Filters can be damaged if connected to hot tap water.
3. Make sure that the tap water pressure is between 4.26 psi to 42.6 psi (0.3 to 3.0 kg/cm²).

Note: In case the water pressure in your area is lower than the minimum specified, we recommend the use of an external booster pump. If the pressure is higher than the maximum specified, use of the pressure reducing valve (PRV) is recommended. (PRV & Booster Pump are available with the company at an extra cost.)

Make sure that the reject water pipe is placed lower than the top of the purifier, if not water might flow back into the purifier. Make sure that the purifier is installed within the distance of 1.0 m from the tap water supply. The purifier is for 230 V only, so make sure that you connect to a 230 V power outlet. Do not install the purifier in a place where water or rain could leak into it (outdoors, etc). Being compact, AquaSure Smart Plus RO + UV+ MTDS is easy to install either on your kitchen counter or on the wall.

Note

1. Flush filters adequately during installation.
2. Drain the first tank fill after installation.

VISUAL INDICATIONS WHEN UNIT IS WORKING

• LED blinking in green color: Smart Plus RO + UV+ MTDS getting ready
• Green color glows solid: Purification Process is ON / Tank is Full
• LED blinking in Amber color: Incoming water pressure is low/ no water supply
• LED blinking in Red color/ red glows solid: Some error in working - Please call service

AQUASURE SMART PLUS RO+UV+MTDS BASED MULTI-STAGE PURIFICATION WATER PURIFIER

CHECK POINTS BEFORE CALLING OUR SERVICE CENTRE

PRECAUTIONS IN USING THE PURIFIER

Setup Guide

To set up the Eureka Forbes AquaSure RO+UV+MTDS, follow these steps:

1. Unpack the product and place it on a flat and stable surface.
2. Connect the inlet pipe to the water source and the outlet pipe to the purifier.
3. Plug in the power cord and turn on the purifier.
4. The purifier will run through an automatic cleaning cycle. Wait for the cycle to complete before using the purifier.
5. Fill a glass with water from the purifier and taste it to ensure that it tastes great.

Maintenance

Replace the filter at following periodicity.

1. i-Filter (Clarity Cartridge) 6000# litres
2. Chemi Block 6000# litres
3. RO Membrane 6000# litres
4. Antiscalant Media 6000# litres or when it gets exhausted (whichever is earlier).
5. Taste Enhancer 6000# litres
6. UV Lamp 5000 glowing hours (as per UV Lamp manufacturer's specifications)

Note

1. Please refer to ‘standard test conditions’ for filter life.
2. Normally approx. 600 ml of water flows per minute from the reject water tube when the unit is working. If the flow reduces, please contact our service centre.
3. 6000 litres is approximately 1000 fillings of storage tank. Even if you fill the storage tank twice a day the filters will last for 1 year.
4. Antiscalant media may get exhausted earlier depending upon the level of hardness in water. Refill whenever the Antiscalant media get exhausted. Please check regularly/at every mandatory service.

Backflushing the i-Filter / Clarity Cartridge

To ensure that the Pre-filter i-Filter works efficiently, it should be thoroughly cleaned by the authorized service technician during every regular service. However, you can yourself carry out the Back-flushing of Clarity Cartridge/i-Filter (preferably every 1-2 months) which will further help in enhancing the performance of your product. Just follow these simple steps:

1. Turn off the diverter valve to stop the water flow. Switch off the power supply to the unit.
2. Disconnect the inlet tube from the inlet port of i-Filter. Also disconnect the output tube of the i-filter. Remove the i-Filter from its clamp.
3. Connect the loose end of the inlet tube (coming from the Diverter Valve) and snug fit it into the outlet port of the i-filter. Keep the open end (i.e. the inlet port) of the i-Filter over the wash basin.
4. Now turn on the diverter valve fully to start water flow through the i-Filter.
5. Allow the water to flow like this for at least five minutes with full pressure. This will dislodge and flush out the accumulated sediments/mud from the filter.
   CAUTION: Do not drink this flushed water.
6. Turn off the diverter valve after the backflushing is over.
7. Remove the inlet tube (coming from the Diverter Valve) from the outlet port of the i-Filter and connect it back to its original place i.e. inlet port of i-Filter. Keep the open end (i.e. the outlet port) of the i-Filter over the wash basin.
8. Now turn on the diverter valve fully to start water flow through the i-Filter. Let it run for 2-3 minutes and then turn off the diverter valve.
9. Put back the i-Filter back to its wall mounting clamp.
10. Reconnect the output tube of the i-filter back in its place i.e. outlet port of the i-Filter. This completes the backflushing process.
11. Now switch on the power supply to the unit and turn on the diverter valve to start water flow. Discard the first tank fill.
12. Now your Smart Plus water purifier is ready for use.

Disinfection & Cleaning of Storage Tank

1. Switch off the power supply to the purifier when the tank is full. Stop the water supply to the unit (by removing the raw water inlet pipe from the Diverter Valve). Remove the top cover of the purifier unit.
2. Disengage the pure water inlet pipe of the storage tank.
3. Drop one disinfection tablet into the opening of the inlet connector of the tank.
   CAUTION: Keep the disinfection tablets out of reach of children. Do not eat/consume this disinfection tablet.
4. Snug fit the pipe for 30 min.
5. After 30 min. open the faucet and discard the purifier tank water completely.
   CAUTION: Do not drink this water. Check if the tablet has completely dissolved. If not, then discard the leftover pcs. of the tablet.
6. Switch on the power to the unit and insert back the raw water inlet pipe into the diverter valve as it was before.
7. Let the purifier tank get completely filled. Discard this fill too.
8. Allow the tank to get filled again. Now your SMART PLUS RO+ UV + MTDS is ready for use. You can start using this water. In case you notice any medicinal taste/smell, then discard the water and let it refill again.

9. Carry out the disinfection process preferably every fortnight.



Troubleshooting

If you encounter any problems with the Eureka Forbes AquaSure RO+UV+MTDS, try these troubleshooting steps:

1. If the purifier is not working, check to make sure that it is properly plugged in and that the power cord is not damaged.
2. If the water flow is low, check to make sure that the inlet pipe is properly connected and that there are no blockages in the pipeline.
3. If the purified water tastes salty, check to make sure that the RO membrane is not damaged and that the TDS level is within the recommended range.
4. If the purifier is making strange noises, check to make sure that all components are properly assembled and that there are no loose parts.

Warranty

Your AquaSure Smart Plus RO+ UV+ MTDS Water Purifier is warranted against defects arising from faulty design, workmanship and materials, for a period of 12 months from the date of invoice, subject to the following conditions:

1. The customer will notify the Company promptly about any defects noticed and give the Company or its Authorised Dealer adequate opportunity to inspect, test and remedy them, for which the customer will deposit the goods if necessary, with the Company's office/service centre along with the original invoice, in the city where they are sold.
2. Inspection and Test Report of the Company's office/service centre will be treated as final and binding under the Warranty for determining defects, repairs/alterations required or carried out, or certifying working of the goods thereafter.
3. The Company or its Authorised Dealer will be entitled to retain any defective part replaced under the Warranty.

CUSTOMER RESPONSE CENTRES

Should you have any future questions/queries, visit us at www.eurekaforbes.com or for any assistance you can be rest assured that we are just a call away.

Pros & Cons

Pros

• Advanced RO+UV+MTDS technology
• High purification capacity and storage capacity
• Digital display and user-friendly interface
• Sleek and modern design
• One-year warranty from the manufacturer

Cons

• Expensive compared to other water purifiers
• Requires regular maintenance and filter replacements
• Not portable and requires a dedicated space
• May not be effective at reducing TDS in areas with high TDS levels
