Introduction

A powerful and effective cleaning option, the Eureka Forbes Trendy Wet & Dry DX Vacuum Cleaner is designed to easily tackle both wet and dry problems. It is designed to be used in both dry and wet environments. Because of its adaptable design and powerful suction, it is an excellent option for use in both residential and commercial settings.

CARTON CONTENTS LIST

Detailed Specifications

GETTING STARTED WITH THE Trendy Wet & Dry DX

Description

The Eureka Forbes Trendy Wet & Dry DX Vacuum Cleaner is a vacuum cleaner that is both versatile and powerful, making it ideal for individuals who are looking to achieve a thorough cleaning of both commercial and residential spaces. It is a breeze to clean with this vacuum cleaner because of its high suction and innovative features. As a result of its lightweight and maneuverable design, the vacuum cleaner makes it simple to clean corners and regions that are sometimes difficult to access. The High Efficiency Particulate Air (HEPA) filter guarantees that the air in your home or business is germ- and allergen-free. The wet and dry capability is an additional advantage that makes it simple and hassle-free to clean surfaces that are damp. Additionally, the vacuum cleaner comes with a number of attachments, which ensures that it is a versatile cleaning equipment that can meet all of your requirements.

DRUM ASSEMBLY

ATTENTION! If any part is missing or damaged, please do not assemble until you have all the parts.

1. Invert the drum to install the wheel.

2. Insert the four wheels (part G) into the socket of the wheel base. Be sure that the wheels spin freely. (picture I)



ASSEMBLING THE DEVICE

Fitting the HEPA filter. Put the HEPA filter( part J) into the float holder, then lid the HEPA filter cover(part K), and fasten it clockwise. On the contrary, remove the HEPA filter anticlockwise. (picture2)

NOTE: HEPA filter---High Efficiency Particulate Air Filter

1. When picking up small amounts of liquid the HEPA filter may be left in place.
2. When picking up large amounts of liquid we recommend that the HEPA filter be removed If the HEPA filter is not removed, it will become saturated and misting may appear in the exhaust.

3. Fitting the dust bag. Put the dustbag board (part) into the inlet base. (Dustbag board should aim at the slot of the inlet base). Rotate the board clockwise 90 degrees to fasten the dustbag according to the arrow direction(LOCK side) (picture 3) .



4. To remove the dustbag from the inlet base, just rotate the dustbag board anticlockwise 90 degrees (OPEN side), then take out the dustbag.
   NOTE: The dust bag use only for dry-vacuum cleaner can not be used for wet suction
5. Install the power head assembly onto the drum assembly as shown. (picture 4)
6. Rotate both latches down and press until you hear them snap over the flanges on the drum. (picture5)

7. Insert the flexile hose connector into the inlet base of the vacuum cleaner. (Picture6)



OPERATION

Accessories use instructions:
The vacuum cleaner is equipped with three nozzles for different applications. Each individual nozzle can either be fitted onto the connecting tube or directly onto the handle of the flexible hose.

1. Floor brush
   This is suitable for cleaning wide areas. The floor brush is fitted with a practical 360° tie-in, this ensures that you can reach easily into any corner. (Picture7)
2. Sofa brush
   You can use this to clean the dust from books or sensitive objects such as picture frames etc. This nozzle is suitable for the careful cleaning of upholstered furniture, mattresses, cushions, curtains etc. (Picture8)
3. Crevice nozzle
   This nozzle is suitable for sucking and cleaning the corners or niches that cannot be reached with the floor brush. Besides, it can be used as blowing tool. (picture9)

ATTENTION!

1. Make sure all the assembly is according to the instructions. Connect the hose to the unit, then install the specific accessories for the intended cleaning purpose.
2. Pull the cable to suitable length, insert the plug into the socket. Press the ON/OFF switch button, start the using.

3. After using, press the ON/OFF switch button to stop. Unplug the cable from the socket. Then press the cord rewind button to roll back the cable steadily (picture 10)



NOTE: If the cable can not rewind completely, please pull out the cable a little bit and press the rewind button again. You can repeat the rewind steps until the cable is rewind completely.

Wet Vacuuming

CAUTION: Always remove the dust bag when you commencing wet vacuuming.

1. When picking up small amounts of liquid the HEPA filter may be left in place.
2. When picking up large amounts of liquid we recommend that the HEPA filter be removed. If the HEPA filter is not removed, it will become saturated and misting may appear in the exhaust.
3. When the liquid in the drum reaches a predetermined level, the float mechanism will rise automatically to cut off air- flow, the indicator light turn on at the same time. When this happens, turn off the vac, unplug the power cord, and empty the drum.
4. After using the vac to pick up liquids, the HEPA filter must be dried to reduce the risk of possible mildew and damage to the filter.

Dry Vacuuming
CAUTION: Never dry-vacuum cleaner without the filter assembly installed.

1. For dry -vacuum cleaner using, there are two filtting methods:
   1. dust bag
   2. HEPA filter. For mass dust cleanning, we advise to use dust bag. For a bit but tiny dust cleanning, we advise to use HEPA filter. Since the HEPA fliter have better filtting performace but will low down the air flow.
2. The device has dirt full and block indication function, the light turns on that means the air routeway is blocked. In this case,user should switch off the device and check:
   1. Is the hose or accessories blocked by large dirt?
   2. Is the filter blocked by dirt?

User should take action:

1. Clean the dirt in the hose or other accessories.
2. Change or clean the dustbag (the HEPA filter).

Blowing Function
The device has a blow function, if necessary, fix the hose connector to the exhaust of the device (the same method with inlet connection), then fix the accessories to use. (picture 11)

CARE AND MAINTENANCE

ATTENTION! Before storing the vacuum cleaner, the dust drum and filter should be emptied and cleaned.

• The accessories should be stored in the storage base (Picture 12). The vac should be stored indoors.



• To clean the device casing switch off and disconnect the plug from the mains socket.
• Never expose the vacuum cleaner cleaner to the effects of the weather (rain, etc.). No parts may be washed in a dish washer.
• The casing, dust collecting chamber and filter chambers of the vacuum cleaner cleaner can be wiped with a damp cloth if required. No liquid must enter the vacuum cleaner in the process. Never use strong cleaning substance(scouring liquids, thinners), since these will corrode the plastic surface. Only place the plug back in the mains socket when you have made sure that all the parts are thoroughly dry.
• Hair and fluff may gather on the running wheels and on the floor nozzle of the vacuum cleaner in time. You should remove these to ensure that handling of the vacuum cleaner is always easy.
• Lubricating or oiling of the roller bearing is not recommended, because this will cause dirt and fluff to stick even better.

Setup Guide

Setting up the Eureka Forbes Trendy Wet & Dry DX Vacuum Cleaner is easy.

• First, remove all packaging materials and ensure that the vacuum cleaner is unplugged.
• Next, attach the handle to the vacuum cleaner body and ensure that it is securely fastened.
• Insert the HEPA filter into the vacuum cleaner and make sure that it is properly positioned.
• Plug in the vacuum cleaner and turn it on. The vacuum cleaner is now ready to use.
• To use the wet and dry feature, simply fill the vacuum cleaner with water and attach the appropriate attachment. The vacuum cleaner will automatically adjust to the wet setting.

SAFETY INFORMATION

ATTENTION! Read all safety rules carefully before attempting to operate.
DANGER! Never operate this unit when flammable materials or vapors are present because electrical devices produce arcs or sparks that can cause a fire or explosion.
WARNING!

1. Do not leave vacuum cleaner when plugged in. Unplug from outlet when not in use and before servicing.
2. To reduce the risk of electric shock, do not expose to rain- store indoors.
3. Use only as described in this manual. Use only Manufacturer's recommended attachments.
4. Do not use with damaged cord or plug. If vacuum cleaner is not working as it should, has been dropped, damaged, or dropped into water, return it to a service center.
5. Do not pull or carry by cord, use cord as a handle, close a door on cord or pull cord around sharp edges or corners.
6. Do not run vacuum cleaner over cord. Keep cord away from heated surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
8. Do not handle plug or vacuum cleaner with wet hands.
9. Do not put any object into openings. Do not use with any openings blocked.
10. Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.
11. Turn off all controls before unplugging.
12. Do not use to pick up flammable or combustible liquids such as gasoline or use in areas where they may be present.
13. To avoid spontaneous combustion, empty tank after each use.
14. Do not pick up anything that is burning or smoking, such as cigarettes, matches, or hot ashes.
15. Do not use without dust bag and/or filter in place.
16. To reduce the risk of the electric shock. Make sure the plug is dry and do not operate with wet hands.
17. Do not run vacuum cleaner unattended.
18. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a similarly qualified person in order to avoid a hazard.
19. This appliance is not intended for use by persons including children with reduced physical,sensory or mental capabilities,or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

Troubleshooting

1. If you encounter any problems with your Eureka Forbes Trendy Wet & Dry DX Vacuum Cleaner, here are some common solutions.
2. If the vacuum cleaner is not turning on, ensure that it is properly plugged in and that the power switch is in the ON position.
3. If the vacuum cleaner is not picking up dirt or dust, ensure that the filter is not clogged and that the dust container is not full.
4. If the vacuum cleaner is making strange noises, ensure that all attachments are properly secured and that there are no blockages in the vacuum cleaner.

WARRANTY

Forbes Trendy Wet and Dry DX Vacuum Cleaners are warranted against defects arising out of faulty design, workmanship and materials, for a period of 12 months from the date of the Invoice,

Pros & Cons

• Pros:
  • Powerful suction
  • Large dust capacity
  • HEPA filter
  • Wet and dry feature
  • Several attachments
• Cons:
  • May be expensive for some
  • May be heavy for some users

Customer Reviews

Customers have praised the Eureka Forbes Trendy Wet & Dry DX Vacuum Cleaner for its powerful suction and advanced features. Many have commented on the vacuum cleaner's ease of use and versatility, with several noting that it is an ideal choice for those who suffer from allergies. However, some have noted that the vacuum cleaner may be expensive for some and that it may be heavy for some users. Overall, customers have given the vacuum cleaner positive reviews, with many noting that it is a worthwhile investment for a high-quality vacuum cleaner.
