Hp FHD Gaming Monitor Card X27c User Manual

cover-image

Content


Introduction of HP FHD Gaming Monitor Card X27c

The HP FHD Gaming Monitor Card X27c is a high-performance gaming monitor that offers stunning visuals and a smooth gaming experience. With a Full HD (1920 x 1080) resolution and a rapid 144Hz refresh rate, this monitor is perfect for fast-paced games that require quick reflexes and smooth movement. The monitor also features AMD FreeSync technology, which synchronizes the monitor's refresh rate with the graphics card's output for even smoother gameplay. The estimated price of the HP FHD Gaming Monitor Card X27c is around $300, and it is set to launch in the second quarter of 2023.

HP Specifications

Panel specifications

Display Size27 inch diagonally measured
Panel TechnologyVA
Curved Panel1500R
Maximum Refresh Rate1920 x 1080 @ 165Hz (DP/HDMI)
Panel Bit Depth8-bit
Aspect Ratio16:9
Brightness350 nits
Resolution1920 x 1080 (FHD)
Contrast RatioStatic: 3000:1, Dynamic: 10M:1
Low Blue LightEyesafe and TÜV certified
Flicker-FreeYes
Scan RateHorizontal: DP/HDMI: 30 KHz - 210 KHz, Vertical: 60 Hz - 165 Hz
BacklightLamp life: 30K, Type: Edge-lit
Screen TreatmentAnti-glare, 3H hardness, 25% haze
Response Time1ms MPRT (with overdrive)
Viewing AngleHorizontal: 178°, Vertical: 178°
Synchronization TechnologyAMD FreeSync Premium
Color97% sRGB

Monitor specifications

Bezel3-sided Micro-edge
Exterior Color

Bezel: Black

Stand: Black

Connectivity/Ports

1 DisplayPort™ 1.4

1 HDMI 2.0

HDCP support: DP and HDMI

1 3.5 mm Audio Jack (out)

Power- Power supply: Internal <br> - Power source: 100 - 240 VAC 50/60 Hz
VESA Mounting100 mm x 100 mm (bracket not included)
Height Adjustable Stand Range100mm
Tilt Range-5 to +20 degrees
PivotNo
SwivelNo
Security Lock ReadyStandard Security Lock Slot
Detachable StandYes
Languages10 (English, Spanish, German, French, Italian, Netherlands, Portuguese, Japanese, T-Chinese, S-Chinese)
On-screen Display

User-programmable modes: 20

 User assignable function buttons: 3 (7 options)

Categories: Gaming, Color, Image, Input, Power, Menu, Management, Information, Exit

SoftwareOmen Gaming Hub

Accessories & warranty

What's in the Box

Power cord

DisplayPort cable

Quick Setup poster

Document kit

WarrantyProtected by a one-year HP limited warranty. Certain restrictions and exclusions apply.

Approvals & certifications

Agency Approvals

Microsoft WHQL Certification:

Windows 10

CE, CB, KC/KCC, NOM, PSB, ICE, TUV-S, ISO 9241-307, EAC, TUV us, PSB, ISC, CCC, CEL, ISC, VCCI, FCC, BSMI, Vietnam MEPS, RCM, Australian-New Zealand MEPS, WEEE, S. Africa NRCS, Ukraine, TUV-GS, UAE, Mexico energy, Belarus Energy, Eye safe certificate, BIS

Product/package specifications

Base Area Footprint8.44 in x 8.33 in
Unpackaged Dimensions24.07 in x 8.33 in x 20.12 in
Unpackaged Weight14.6 lb
Packaged Dimensions27.2 in x 9.84 in x 17.32 in
Packaged Weight23.1 lb

Additional information

Product Number32G11AA#ABA
UPC Code195697574337
Ad Embargo Date10/03/2021
Internet Embargo Date9/20/2021
Country of OriginChina
Pallet Information

Dimensions:

45.04 in x 31.06 in x 75.75 in

Total weight: 588.63 lb

Layers: 4

Products per layer: 6

Total products per pallet: 24

Immersive all play, every play
Plug and play on this sweet curved monitor. We've redefined high definition gaming with 165Hz, 1ms response and AMD FreeSync Premium.


HP FHD Gaming Monitor Card X27c Overview

  • Game in Comfort
    Play the long game comfortably on this amazing 1500R curved panel. Reduce eye strain and protect your eyes with HP Eye Ease with Eye safe certification.(10) Yup, filters harmful blue light out and the color accuracy in. Now sit back, sink into your seat and find your perfect angle with the adjustable stand.
  • Built for Gaming
    Find more room to play in FHD (1920x1080).(1) Eliminates blurring and ghosting while gaming thanks to the super fast 165Hz refresh rate and 1ms response time(3) with MPRT. Plus, gameplay free of stuttering and tearing with AMD Free Sync Premium.(2)(11)
  • Game Your Way
    Your gaming experience just got better with a monitor that is plug and play ready as soon as you take it out of the box. Compatible with the latest generation consoles.(12) Game on your PC. Game on your console. We've got you covered.
  • Control Your Game
    Customize your monitor and your game with OMEN Gaming Hub. From software enhancements to hardware control, OGH offers more to gamers in an easy and simple way. Plus, live services to make your gaming experience even better.

Features

  • Eyesafe Certified Display
    Eyesafe certified displays meet TÜV low blue light requirements and Eyesafe standards for protecting your eyes from harmful blue light without distorting colors. Monitors with integrated Eyesafe displays help reduce eyestrain and improve eye comfort when gaming for long periods of time.(10)
  • Adjust your view
    Adjust your screen for comfortable viewing with height adjust and tilt capabilities.
  • OMEN Gaming Hub
    OMEN Gaming Hub is your one place for everything to make your gaming experience better. From software enhancements to hardware control, and live services, OGH elevates play in easy and simple way.
  • VA panel
    With a wide, 178-degree viewing angle and better black levels, VA panels elevate your favorite content with a superb contrast ratio for colors that pop.
  • 1500R Curved Display
    By bringing the sides of the display even closer, the dramatically curved screen provides an incredibly realistic and immersive gaming experience.
  • 165Hz refresh rate
    This lightning-fast refresh rate practically removes all artifacting and motion blurring for action that looks crisp and gameplay that feels incredibly responsive.(3)
  • FHD Display
    Be prepared for brilliant visuals and crisp images with the unforgettable quality of this stunning FHD display.(1)
  • Console compatible
    Easily connects with your favorite current and next gen gaming consoles – just plug and play.
  • 1 millisecond MPRT
    How fast your pixels can react to changing frames is critical for fast-paced gaming, and a 1ms response time ensures even the most action-packed moments are fluid, crisp, and free of motion blur.(3)
  • Moving Picture Response Time
    Greatly reduces motion blur for a more fluid visual experience.
  • Off the desk and on the wall
    The display is equipped with standard VESA mounting for showcasing on a wall or swivel arm.(7)
  • Three-sided micro-edge display
    See more of your screen with a three-sided micro-edge display that maximizes your viewing area.
  • Sustainably sourced packaging
    HP is innovating new ways to reduce the amount of materials in our packaging and to use more recycled materials in the design.(6)
  • AMD FreeSync Premium technology
    Game confidently with a high refresh rate, low framerate compensation, and low latency with AMD FreeSync™ Premium Technology.(2)

Description of FHD Gaming Monitor

The HP FHD Gaming Monitor Card X27c features a 27-inch TN panel with a 1ms response time, which ensures that fast-moving images appear sharp and clear without any ghosting or blurring. The monitor also has a wide viewing angle of 170/160 degrees, which means that the picture quality remains consistent even when viewed from the side. The monitor has a sleek and modern design with thin bezels and a sturdy stand that allows for tilt, swivel, and height adjustments. The monitor also features built-in speakers and a headphone jack for added convenience.

Key Descriptions

  • Viewable image area: 27 inch diagonally measured
  • Panel type: VA / Curved
  • Aspect ratio: 16:9
  • Resolution: 1920 x 1080 (FHD) (1)
  • Connectivity:
    • 1 DisplayPort™ 1.4
    • 1 HDMI 2.0
    • 1 3.5 mm Audio Jack (out)

HP FHD Gaming Monitor Card X27c Setup Guide

Setting up the HP FHD Gaming Monitor Card X27c is a simple process that can be completed in a few easy steps. First, unpack the monitor and attach the stand to the base. Next, connect the monitor to a power source and plug in the HDMI or DisplayPort cable to your computer. Once connected, the monitor will automatically detect the signal and display the image. Use the on-screen display (OSD) controls to adjust the monitor's settings, such as brightness, contrast, and color temperature, to your liking.

Troubleshooting

If you encounter any issues with the HP FHD Gaming Monitor Card X27c, there are a few troubleshooting steps you can take. First, ensure that the monitor is properly connected to a power source and your computer. If the monitor is still not displaying an image, try using a different cable or port. If the monitor is displaying an image but the colors appear washed out or distorted, adjust the monitor's settings using the OSD controls. If the monitor is flickering or displaying horizontal lines, try adjusting the refresh rate or enabling AMD FreeSync technology.

Pros & Cons of Monitor Card X27c

Pros

  • Full HD resolution and 144Hz refresh rate for smooth gameplay
  • AMD FreeSync technology for reduced screen tearing and stuttering
  • 1ms response time for sharp and clear images
  • Sleek and modern design with adjustable stand
  • Built-in speakers and headphone jack

Cons

  • TN panel may not have as wide a color gamut as IPS or VA panels
  • May not be as bright as some other gaming monitors
  • May not support HDR

Customer Reviews about HP FHD Gaming Monitor Card X27c

Customers have praised the HP FHD Gaming Monitor Card X27c for its smooth gameplay and sharp image quality. Many have also appreciated the monitor's sleek design and adjustable stand. However, some have noted that the TN panel may not have as wide a color gamut as other types of panels. Others have mentioned that the monitor may not be as bright as some other gaming monitors, and may not support HDR.

Faqs

What sets apart other gaming displays from the HP FHD Gaming Monitor Card X27c?

The immersive 27-inch curved display of the HP FHD Gaming Monitor Card X27c, which offers Full HD quality for clear, colourful images, makes it stand out. Its low response time, fast refresh rate, and adaptive sync technology minimise screen tearing and stuttering, making it ideal for games.

How significant is the refresh rate of the HP FHD Gaming Monitor Card X27c for gaming, and what is it?

With a refresh rate of up to 144 Hz, the HP FHD Gaming Monitor Card X27c is ideal for gamers as it guarantees smoother frame rendering, lowers motion blur, and enhances overall visual clarity, making competitive gaming more accurate and fast-paced games more pleasurable.

Is adaptive sync technology compatible with the HP X27c?

Adaptive sync technology, which enables the monitor to dynamically alter its refresh rate to match the output of a compatible graphics card, is supported by the HP FHD Gaming Monitor Card X27c. This feature reduces screen tearing and ensures a smoother gaming experience.

What is the HP FHD Gaming Monitor Card X27c's response time, and how does it impact gaming?

Its low response time (usually about 1 ms) reduces ghosting and motion blur in fast-moving scenes, which is important for games that need to load rapidly. It also gives you a competitive edge by rendering frames more quickly and correctly.

Is it possible to utilise the HP FHD Gaming Monitor Card X27c for duties other than gaming for work purposes?

Absolutely. HP FHD Gaming Monitor Card X27c resolution and color accuracy make it suitable for a wide range of professional applications, including graphic design, video editing, and any task requiring precise color reproduction.

Can the monitor be tilted or swivelled, and is its height adjustable?

The HP FHD Gaming Monitor Card X27 boasts an adjustable stand that enables users to change the height, tilt, and swivel to attain the ideal viewing angle. This feature improves ergonomic comfort for extended gaming or work sessions.

Which connectivity choices does the HP FHD Gaming Monitor Card X27c offer?

With its many connectivity options, such as HDMI and DisplayPort ports, the HP FHD Gaming Monitor Card X27c usually makes it simple to connect to PCs, gaming consoles, and other media devices. Additionally, some versions could have USB connections for extra accessories.

How is the gaming experience improved by the HP FHD Gaming Monitor Card X27c's curved screen?

The goal of the curved design of the HP FHD Gaming Monitor Card X27c is to offer a more immersive viewing experience by engulfing the field of vision and imitating the natural curvature of the human eye to alleviate eye strain and create a panoramic perspective that is unmatched by flat panels.

How could I get the HP FHD Gaming Monitor Card X27c to support HDR content?

If the monitor has HDR support, you can turn on HDR content by going into your operating system's display settings and making sure your graphics card and content source are compatible with HDR.

What kind of guarantee is there for the HP FHD Gaming Monitor Card X27c from HP?

A one-year standard warranty is typically offered for the HP FHD Gaming Monitor Card X27c. Extended warranty options are available for additional coverage.
