Introduction of Impex Fitness Fan Bike AIR-1

Introducing the impex Fitness Fan Bike AIR-1, the ultimate fitness equipment for all your cardio needs. This fan bike is designed to provide you with a challenging and effective workout, no matter your fitness level. With a sturdy steel frame and adjustable seat, the AIR-1 is built to last and accommodate users of all sizes. The bike features a smooth and quiet fan wheel, providing a refreshing breeze during your workout. The LCD display helps you track your progress and stay motivated, while the pulse sensors monitor your heart rate. The estimated price of the impex Fitness Fan Bike AIR-1 is around $300 to $400, and it is now available for purchase.

Detailed Specifications

The impex Fitness Fan Bike AIR-1 boasts several key features that make it stand out from other fan bikes on the market. These include:

• Durable steel frame with a powder-coated finish
• Adjustable seat with a comfortable padded seat and backrest
• Smooth and quiet fan wheel with adjustable resistance
• LCD display that tracks time, distance, speed, calories, and pulse
• Pulse sensors built into the handlebars
• Sturdy transport wheels for easy mobility
• Maximum user weight capacity of 300 lbs
• Dimensions: 48" L x 22" W x 51" H

Assembly Instructions

Tools Required For Assembling the Machine: One Crossing Wrench and Allen Wrench, provided by manufacturer.

NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injury.

1. Do not tighten Bolts until instructed to do so.

   • Attach the Front Stabilizer (#39) to the Main Frame (#35). Secure it with four M8 x 5/8” Allen Bolts (#5) and four ∅ 5/8” Washers (#6).

   • Attach the Rear Stabilizer (#55) to the Main Frame. Secure it with four M8 x 5/8” Allen Bolts (#5), and four Ø 5/8” Washers (#6).

   • Securely tighten all Bolts.

   • Use the four Floor Level Adjustment Knobs (#38) to stabilize the Bike on floor.



2. Connect the Upper Computer Wire (#2) from the Front Post to the Computer Wire from the Computer (#1).

   • Attach the Computer to the Front Post (#4). Secure it with four Computer Philips Screws (#3).



3. Connect the Lower Computer Wire (#37) from Main Frame (#35) to the Upper Computer Wire (#2) from Front Post (#4).

   • Attach the Front Post to the Main Frame. Secure it with four M8 x 5/8” Allen Bolts (#5).



4. Attach the pivot on the Left Swing Handle (#30L) to the pivot on the Main Frame (#35).

   • Thread the Swing Handle Shaft – L (#75) through the Left Swing Handle into Main Frame, and firmly secure them together.



5. Attach the Swing Handle Connecting Rod (#48) to the open bracket on the bottom of the Left Swing Handle (#30L).

   • Secure them together with one M8 x 1 ¾” Allen Bolt (#49) and one M8 Aircraft Nut (#50).



6. Attach the pivot on Right Swing Handle (#30R) to the pivot on Main Frame (#35).

   • Thread the Swing Handle Shaft – R (#28) through Right Swing Handle into Main Frame, and firmly secure them together.



7. Attach the Swing Handle Connecting Rod (#48) to the open bracket on the bottom of the Right Swing Handle (#30R).

   • Secure them together with one M8 x 1 ¾” Allen Bolt (#49) and one M8 Aircraft Nut (#50).



8. Thread the Left Pedal (#41L) counterclockwise into Left Crank (#44L).

   • Thread the Right Pedal (41R) clockwise into the Right Crank (#44R).



9. Remove the three Ø 5/8” Seat Flat Washers (#32) and M8 Seat Aircraft Nut (#33) from the Seat Pad (#31).

   • Attach the Seat Pad to the Seat Post (#34). Secure it with the three Ø 5/8” Seat Flat Washers (#32) and M8 Seat Aircraft Nut (#33) from the Seat Pad (#31).



10. Insert the Seat Post (#34) into the opening one Main Frame (#35).

    • Thread the Lock Knob (#63) through the hole on Seat Post to securely hold it at desired height.



Impex Fitness Fan Bike AIR-1 Exploded Diagram

Parts List

Description of Impex Fitness Fan Bike AIR-1

The impex Fitness Fan Bike AIR-1 is a versatile piece of fitness equipment that can provide a challenging workout for both beginners and experienced athletes. The fan wheel provides a cooling breeze during your workout, while the adjustable resistance allows you to customize your workout to your fitness level. The LCD display helps you track your progress and stay motivated, while the pulse sensors monitor your heart rate to ensure you are working out safely. The bike is easy to assemble and move, thanks to the sturdy transport wheels. With its durable construction and adjustable features, the impex Fitness Fan Bike AIR-1 is a great investment for anyone looking to improve their cardio fitness.

CARE, MAINTENANCE AND STORAGE

1. Inspect and tighten all parts each time you use the machine. Replace any worn parts immediately.

2. The bike can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use solvents.

3. Store the bike IN-DOOR. Excess moisture and water would cause rust on the frame.

4. The Bike shall be placed at least 24 inches away from the wall or/and any other object such as furniture to provide safe access to and passage around the machine.

5. To avoid possible injury, the help of two or more people is needed when moving the machine around.

6. Disposal Instructions – The equipment can be safely disassembled and disposed of without unreasonable hazards. Call your local recycling agency regarding details of recycling.

7. The maximum user weight is 300 lbs.

8. Assembled Dimension: 45” x 25” x 47.5″

OPERATING NOTES

SEAT ADJUSTMENT

• The seat height ranges from 29” to 41”.

• Loosen and pull out the Lock Knob. Slide the Seat Post to the selected scale marked on the Seat Post, then release the Lock Knob and securely fasten the Knob to lock the Seat Post.

• The seat height adjustment is in approximately 1 ½” increments.

TRANSPORT

• The Bike has a pair of transport Roller Wheels on the Front Stabilizer. To move, carefully tilt and roll.

Impex Fitness Fan Bike AIR-1 Computer

• MODE: Press the “MODE” button, will automatically scan Time, Speed, RPM, Distance, and Calories, every 6 seconds.

• Time: Display the elapsed time. The max value is up to 99:59.

• Speed: Display the current speed in miles per hour.

• RPM: Display repetition/min, Speed, and RPM display will switch to each other every 6 seconds.

• Distance: Display the distance traveled in Miles. The max value is 99.99 miles.

• Calories: Display the calorie consumption in cal. Increment by 10 cal. The max value is 999 calories.

• SET

  • To set up the hour, minute, year, month, and date.

  • To set up the target value of Time, Distance, and Calories.

• RESET

  • Press the button to reset the function value from the previous setting.

  • Press the button and hold for 2 seconds to reset all values to zero.

  • When the computer is in idle mode, the screen will display Calendar, Clock, and Temperature.

• CALENDAR Display date, month, and year.

• CLOCK Display current clock time.

• TEMPERATURE

  • Displays current room temperature from 50°F to 140°F.

  • To set up time and date; remove the batteries for a few seconds, and then place the batteries back.

  • The computer will beep and display “8888” and display the Time/Date field.

  • Press the “SET” key to enter the Time or Date field. Press the “MODE” key to enter time/Date data.

REPLACE BATTERY

• Remove the battery cover on the back of the computer.

• Replace two 1.5V (AA) batteries.

• Make sure the batteries are installed correctly and the polarities are correct.

• If the display is not clear or only partial segments appear, remove the batteries and wait for 15 seconds before re-install them.

• The battery life is approx. 3 months under normal usage.

• When the batteries are removed, all the functional values will reset to zero.

Note: Please note all values on this computer are approximate and they are for comparison purposes only. Do not use these values for any medical or rehabilitation purpose.

Setup Guide

Setting up the impex Fitness Fan Bike AIR-1 is easy and straightforward. Here are the steps to follow:

1. Unbox the bike and remove all packaging materials.
2. Assemble the base tubes and connect them to the main frame.
3. Install the seat post and adjust the seat height to your desired level.
4. Install the handlebars and adjust the resistance level to your preference.
5. Plug in the bike and turn on the LCD display.
6. Adjust the pedal straps to fit your feet securely.
7. Start pedaling and begin your workout!

IMPORTANT SAFETY NOTICE

PRECAUTIONS

This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions:

1. Keep children and pets away from the machine at all times. DO NOT leave children unattended in the same room with the machine.

2. Only one person at a time should use the machine.

3. If the user experiences dizziness, nausea, chest pain, or any other abnormal symptoms, STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.

4. Position the machine on a clear, leveled surface. DO NOT use the machine near water or outdoors.

5. Keep hands away from all moving parts.

6. Always wear appropriate workout clothing when exercising. DO NOT wear robes or other clothing that could become caught in the machine. Running or aerobic shoes are also required when using the machine.

7. Use the machine only for its intended use as described in this manual. DO NOT use attachments not recommended by the manufacturer.

8. Do not place any sharp object around the machine.

9. Disabled persons should not use the machine without a qualified person or physician in attendance.

10. Before using the machine to exercise, always do stretching exercises to properly warm up.

11. Never operate the machine if the machine is not functioning properly.

12. Read all warnings posted on the exercise bike.

13. Inspect the exercise bike for worn or loose components before use. Tighten/replace any loose or worn components before use.

14. Care should be taken in mounting or dismounting the exercise bike.

15. This exercise bike is for consumer and home use only.

WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.

WARNING LABEL PLACEMENT

WARNING

• DO NOT MISUSE THIS EQUIPMENT

• The possibility of serious injuries or death or both, (if applicable) may occur if caution is not used.

• Before beginning any exercise program, consult your physician.

• Read the user’s manual. All warnings and instructions must be read and followed and proper instructions be obtained before use.

• Replace this label if damaged, illegible, or removed.

• Keep children and pets away from this equipment.

CAUTION AVOID SHEER AND PINCH POINTS

Keep fingers and body parts clear and away from all sheer and pinch points. Injury may occur if fingers become entangled in moving parts. The Warning Labels and Caution Label shown here have been placed on the Rear Stabilizer, Main Frame.

NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

Troubleshooting of Impex Fitness Fan Bike AIR-1

Here are some common issues that may arise with the impex Fitness Fan Bike AIR-1 and how to resolve them:

• LCD display is not working: Check that the bike is properly plugged in and that the power switch is turned on.
• Resistance is too hard/easy to turn: Adjust the resistance level using the knob on the bike. If the resistance is still too hard or easy to turn, contact impex Fitness for assistance.
• Pedals are hard to turn: Make sure the pedal straps are properly adjusted and that you are pedaling with proper form. If the pedals continue to be hard to turn, contact impex Fitness for assistance.
• Bike is making strange noises: Check that all bolts and screws are tightened securely and that the bike is properly assembled. If the bike continues to make strange noises, contact impex Fitness for assistance.

Impex Warranty

IMPEX Inc. (“IMPEX”) warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser. IMPEX’s obligation under this Warranty is limited to replacing or repairing, at IMPEX’s option.

Pros & Cons

Pros

• Adjustable resistance for customized workouts
• LCD display for tracking progress
• Pulse sensors for monitoring heart rate
• Sturdy construction and durable design
• Transport wheels for easy mobility

Cons

• May be too large for small workout spaces
• Resistance may not be challenging enough for experienced athletes
• LCD display may be difficult to read in bright lighting

Customer Reviews about Impex Fitness Fan Bike AIR-1

Customers who have purchased the impex Fitness Fan Bike AIR-1 have praised its sturdy construction, adjustable features, and quiet operation. Many have noted that the bike is easy to assemble and move, and that it provides a challenging workout. However, some have noted that the resistance does not increase significantly, and that the bike may be too large for small workout spaces.
