How to Use: Medify Air Purifeier MA25 User Manual

cover-image

Content

Introduction of Medify Air Purifier MA-25

Designed to improve the quality of indoor air in medium-sized rooms, the small and powerful Medify MA-25 air purifier is ideal. Its three-stage filtration technology, which consists of an activated carbon filter, an H13 True HEPA filter, and a pre-filter, efficiently eliminates 99.97% of dust, pollen, smoke, and pet dander from the air. It is an excellent option for living rooms, workplaces, and bedrooms because to its energy efficiency, quiet operation, and stylish design. In order to provide ease and best performance for a healthy living environment, the MA-25 also has a sleep mode, a timer function, and an indicator for filter change.

UNIQUE FEATURES & SPECIFICATIONS

GENUINE MEDIFY TRUE HEPA H13 FILTRATION SYSTEM

  • TRUE HEPA H13 FILTRATION
    Removes up to 99.9% of airborne particles as small as 0.1 microns, such as allergens, pollen, dust, germs, pet dander, odor, mold spores, and smoke from air that passes through the filter.

  • CARBON ODOR FILTRATION
    Reduces household odors and VOCs (volatile organic compounds)/gases as shown by independent laboratory testing.

  • PRE-FILTER
    Captures large particles.

3 SPEEDS

Low, medium, and high speeds.

BUILT-IN TIMER

Choose from 1, 2, 4 or 8 hours.

REPLACE FILTER INDICATOR

Illuminates when it is time to replace the filter.

SUGGESTED ROOM SIZE

Up to 250 sf every 15 min and up to 500 sf every 30 min. Portable air purifiers will be more effective in rooms where all the doors and windows are closed.

AIR CHANGES PER HOUR

This air purifier will purify the air up to 250 sf every 15 min and up to 500 sf every 30 min (assuming an 8 FT/2.43 M ceiling) and 4.8 times per hour on high speed in a closed room.


Control Panel


HOW TO USE

BEFORE TURNING THE UNIT ON

  • Take the air purifier out of the box and remove the clear protective plastic bag.

  • Place the air purifier on a firm, leveled surface.

  • Plug the power cord into a standard AC outlet.

POWER BUTTON AND FAN SPEED SETTINGS

  • To turn the air purifier on, press the power  MEDIFY-AIR-MA-25-Air-Purifier-Instruction-Manual_4.jpgbutton.

  • This air purifier has 3 fan speed settings: low (1), medium (2), and high (3). The higher the fan speed setting, the faster the air will be purified. To select or change fan speed, press the fan speed fan_speed_megawise_air_purifier_hg0031.png button
    until the desired setting is reached.

TIMER

Press the timer timer_megawise_air_purifier_hg0031.pngbutton until the desired timer setting is lit on the display. The timer timer_megawise_air_purifier_hg0031.pngbutton will cycle through the following settings: 1 hours, 2 hours, 4 hours, 8 hours and off. To cancel the timer at any time, press the timer timer_megawise_air_purifier_hg0031.pngbutton until all timer LEDs are off. The air purifier will run continuously when the timer function is off.

DIMMER

Press the dimmer image.png button to change the backlight to desired brightness, there are 4 brightness levels to change for all buttons’ backlight LEDs. The green backlight will turn off for 1 second when the dimmer button been pressed.

CHILD-LOCK BUTTON

Press the child-lock button and hold for 3 seconds and all functional buttons will be lockedchild_lock_megawise_air_purifier_hg0031.png. Press and hold again the child-lock button for 3 seconds and all functional buttons will be unlocked.

Description

The Medify Air MA-25 is a powerful and efficient air purifier that can effectively remove pollutants and allergens from the air. Its H13 true HEPA filter is medical-grade, meaning it can capture particles as small as 0.1 microns with 99.97% efficiency. This makes it ideal for people with allergies or respiratory issues. The MA-25 is also Energy Star certified, which means it's energy-efficient and can save you money on your electricity bill in the long run.

One of the standout features of the MA-25 is its touch screen display, which allows you to easily adjust the fan speed, timer, and filter replacement indicator. It also has a child lock feature, which is a great safety feature if you have young children at home. The MA-25 is also easy to move around with its built-in handle and caster wheels.

FILTER REPLACEMENT

REPLACE FILTER LIGHT

The replace filter light illuminates when it is time to replace the True HEPA H13 filter based on the air purifier’s hours of use.

REPLACING THE TRUE HEPA H13 FILTER

For optimal performance, replace every 2500 hours under normal usage conditions. Once the filter has been replaced, press and hold the DIMMER button for 3 seconds to reset the indicator.

  1. Unplug the air purifier. Open the filter grille covers on the left and right of the unit by pushing the lockers on the top of the covers.
  2. Take away the grilles from the unit.
  3. Pull the tabs to remove the old filter.
    To purchase genuine Medify replacement True HEPA H13 filters, for model MA-25, go back to your retailer where you purshased your air purifier, or visit https://www.medifyair.com

  4. Install a new genuine Medify replacement filter with the white side facing out (tabs will be visible).
  5. Align the tabs at the bottom of the grille overs with the unit. Gently push the grille covers until they snap back into place.
  6. Plug the power cord into a standard AC outlet. Press and hold the DIMMER bu tton for 3 seconds to reset the indicator.


Setup Guide

Setting up the Medify Air MA-25 is easy and straightforward. Here are the steps to follow:

  1. Unbox the MA-25 and remove all packing materials.
  2. Place the MA-25 in the desired location and plug it into a power outlet.
  3. Press the power button on the touch screen display to turn on the MA-25.
  4. Adjust the fan speed, timer, and other settings as desired using the touch screen display.

CLEANING & MAINTENANCE

CLEANING THE PRE-FILTER

NOTE: For the best performance, vacuum the pre-filter once a month under normal usage.

  1. Unplug the air purifier.
  2. Remove the True HEPA H13 filter as described in the Replacing the True HEPA H13 Filter section.
  3. Vacuum the white side of the True HEPA H13 filter using the br ush attachment of your vacuum cleaner, cleaning it thoroughly.
  4. Place the True HEPA H13 filter back into the air purifier and close the grille.
  5. Plug the power cord into a standard AC outlet.

FOR THE BEST PERFORMANCE

  • NEVER use water or any household cleaners or detergents to clean the True HEPA H13 filter.
  • Clean off the outside of the unit with a dry cloth as needed.
  • NEVER use water, wax, polish, or any chemical solution to clean the outside of the unit.
  • Clean off the grille cover using a damp cloth or the brush attachment of your vacuum as needed.
  • Vacuum the pre-filter monthly under normal usage conditions.
  • Replace the True HEPA H13 filter every 2500 hours under normal usage conditions.
  • Always use a genuine Medify replacement filter for optimal performance.

This product earned the ENERGY STAR by meeting strict energy efficiency guidelines set by the US EPA. US EPA does not endorse any manufacturer claims of healthier indoor air from the use of this product. The energy efficiency of this ENERGY STAR qualified model is measured based on a ratio between the model’s CADR for dust and the electrical energy it consumes, or CADR/Watt

IMPORTANT SAFETY INSTRUCTIONS

WHEN USING ELECTRICAL PRODUCTS, ESPECIALLY WHEN CHILDREN ARE PRESENT, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING: READ ALL INSTRUCTIONS BEFORE USING

DANGER
TO REDUCE THE RISK OF ELECTRIC SHOCK:

  • Always unplug the air purifier from the electrical outlet immediately after using it and before cleaning or replacing filters.
  • Keep the cord away from heated surfaces.
  • Always place the air purifier on a firm, leveled surface.
  • Always place the air purifier at least 6 inches away from walls and 3 feet from heat sources such as stoves, radiators, or heaters.
  • DO NOT reach for an appliance that has fallen into water. Unplug it immediately.
  • DO NOT place or store appliance where it can fall or be pulled into a tub or sink.
  • DO NOT place in or drop into water or other liquid.
  • Keep dry — DO NOT operate in wet or moist conditions.
  • Check your air purifier cord and plug connections. Faulty wall outlet connections or loose plugs can cause the outlet or plug to overheat. Be sure the plug fits tightly in the outlet.

NOTE: This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of shock, this plug is intended to fit only one way in a polarized outlet. If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician.
DO NOT attempt to defeat this safety feature. To do so could result in an electric shock hazard.

WARNING: TO REDUCE THE RISK OF BURNS, FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS:

  • Always unplug the air purifier when not in use.
  • Do not operate the air purifier with a damaged cord or plug, or after the air purifier malfunctions, or has been dropped or damaged in any manner. Contact to www.medifyair.com for examination, electrical or mechanical adjustment, or repair.
  • This air purifier is not intended for use in bathroom, laundry areas, and similar moist indoor locations.
  • Do not run the cord under carpeting. Do not cover the cord with throw rugs, runners, or similar coverings. Do not route cord under furniture or appliances. Arrange the cord away from traffic areas where it can be tripped over.
  • To disconnect the air purifier, first turn controls to the off position, then remove the plug from outlet.
  • Do not tilt or move the air purifier while it is in operation. Shut it off and remove plug the from the outlet before moving it.
  • Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an  electric shock or fire, or damage the air purifier.
  • Do not block air intakes or exhaust in any manner. Do not use on any soft surface, like a bed, where openings may become blocked.
  • Use this air purifier only for its intended use as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or injury to persons.
  • DO NOT use outdoors.
  • This product is intended for household use only.

SAVE THESE IMPORTANT INSTRUCTIONS FOR EASY REFERENCE.

Troubleshooting

PROBLEMPOSSIBLE CAUSESOLUTION
Unit will not operate• Unit is not plugged in• Plug the unit in
 â€¢ Power button not pressed• Press the power button to turn the power on
 â€¢ No power to unit• Check circuits, fuses, try a different outlet
Reduced airflow• The back grille may be blocked• Make sure side intakes are not blocked or the front outflow area
 â€¢ Pre-filter needs vacuuming• Vacuum the pre-filter with the brush attachment of your vacuum cleaner
 â€¢ The filter needs to be replaced• Replace the filter
Reduced odor removal• The filter needs to be replaced• Replace the filter
Excessive noise• The unit is not leveled• Place the unit on a flat and leveled surface
Replace filter light remains lit after filter replacement• The replace filter indicator needs to be reset• Press and hold the DIMMER button for 3 seconds until the replace filter light turns off

WARRANTY INFORMATION

To register for your lifetime warranty, go to https://www.medifyair.com and go to the warranty section to register your unit. Medify offers a lifetime warranty for parts and service as long as you are on record as having purchased Genuine Medify Replacement Filters as directed every 2500 hours of use.

Medify Air Purifier MA-25 Pros & Cons

  • Pros
    • Medical-grade H13 true HEPA filter
    • Coverage area up to 1,000 square feet
    • Touch screen display
    • Energy Star certified
  • Cons
    • Filter replacements can be expensive
    • Some users may find the noise level to be too loud on higher fan speeds

Customer Reviews

The Medify Air MA-25 has received mostly positive reviews from customers. Many users have praised its efficiency and effectiveness in removing pollutants and allergens from the air. Some users have also commented on its sleek and modern design. However, some users have complained about the high cost of filter replacements and the noise level on higher fan speeds.

PDF

Faqs

What kind of filter does the Medify Air Purifier MA-25 employ?

The three-stage filtration system of the Medify consists of an activated carbon filter, an H13 True HEPA filter, and a pre-filter.

The frequency of filter replacement is a question.

Medify Air Purifier MA-25 expected lifespan is three to four months, depending on usage and the state of the air.

What size room is appropriate for the Medify Air Purifier?

Medify Air Purifier MA-25 efficiently purges spaces up to 250 square feet, making it perfect for medium-sized rooms.

Is there a silent mode on the MA-25?

Indeed, the air purifier is quiet when operating, with noise levels between 35 and 51 dB, making it appropriate for use in living rooms and bedrooms.

Is there an energy-efficient Medify Air Purifier MA-25?

Indeed, the energy-efficient design of the Medify Air Purifier MA-25 allows it to provide effective air filtration with minimal power consumption.

How can I determine when to change the filters?

When it's time to replace the filters, the Medify filter replacement indication lets you know.

What is the Medify MA-25's CADR (Clean Air Delivery Rate)?

With a capacity of 230 cubic meters per hour, the Medify Air Purifier MA-25 provides quick and efficient air filtration.

After using the Medify, what should I do if the air quality does not improve?

Make sure all windows and doors are closed, examine the air intakes and outputs for obstructions, and change the filters if they become unclean.

Is it possible to use the Medify Air Purifier MA-25 in a nursery?

it is appropriate for use in nurseries due to its quiet operation and efficient air filtration.

Does the Medify have a remote control included?

Medify Air Purifier MA-25 does not include a remote control. The device itself has all of the controls.

Does the Air Purifier work well to combat mold spores?

Indeed, the True HEPA filter does indeed collect mold spores, contributing to better air quality and a decrease in mold-related problems.
