National Comfort Products Electric Heat Kit: Complete Product Manual and Buying Guide

The National Comfort Products Electric Heat Kit is a field-installed electric resistance heating accessory designed to add supplemental heat to compatible air handlers and Comfort Pack systems. It is built for projects that need dependable electric heat without replacing the full HVAC unit, making it a practical choice for multifamily housing, light commercial spaces, and residential applications where efficient backup or primary auxiliary heating is required.

This product is especially useful when a system needs flexible heating capacity during colder months or in installations where gas heat is not available. Available in multiple sizes, including 3 kW, 5 kW, 7 kW, 10 kW, and 15 kW options, it supports a wide range of load requirements and allows installers to match output to the space more precisely. The kit is designed for compatibility with select National Comfort Products air handlers and Comfort Pack configurations, with common use cases including add-on heat, replacement heat strips, and seasonal comfort upgrades.

One of the biggest advantages of the national comfort products Electric Heat Kit is its straightforward field installation and integrated protection features. The kit includes open-wire resistance heating elements, automatic reset thermal overloads, and branch circuit breakers for electrical protection. That combination makes it a reliable choice for HVAC professionals who need a durable, serviceable heating option. Estimated pricing typically falls in the mid-hundreds to low-thousands depending on kilowatt size and supplier, with most units available through HVAC distributors and replacement-part retailers. Availability is generally good for standard configurations, though exact stock can vary by model and region.

Specifications for National Comfort Products Electric Heat Kit

  • Heat output options: 3 kW, 5 kW, 7 kW, 10 kW, and 15 kW.
  • Application type: field-installed electric resistance heat kit for compatible National Comfort Products systems.
  • Protection features: open-wire heating elements, automatic reset thermal overloads, and branch circuit breakers.
  • Voltage support: commonly used in 208/230V single-phase HVAC applications.
  • Compatibility: select A-Series air handlers, Comfort Pack electric units, and multifamily air handler configurations.
  • Installation style: internal cabinet mounting with dedicated wiring harness connections.
  • Performance role: provides auxiliary or primary electric heat for cooling/heating packages.
  • Comparison: smaller 3 kW and 5 kW kits suit light supplemental heating, while 10 kW and 15 kW kits better match larger rooms or colder climates than lower-capacity heat strips.

Compared with generic aftermarket heat strips, the national comfort products Electric Heat Kit is designed specifically for matched cabinet integration, which can improve fit, wiring simplicity, and serviceability. Compared with gas heat accessories, it offers cleaner electric operation and fewer combustion-related components, though operating cost may be higher in some regions.

How to Set Up the Electric Heat Kit in a Compatible Air Handler

Start by disconnecting all electrical power to the air handler and verifying zero voltage before opening the cabinet. Remove the upper access panel, then remove the heater cover plate from the unit. Insert the heater bank into the opening and secure it with the provided screws, making sure the assembly sits flush and does not interfere with moving components.

Next, mount the circuit breaker(s) to the front bracket and connect the power and control wiring harnesses to the matching connectors inside the air handler. After that, connect the external power wiring to the free end of the heat kit breaker(s). Reinstall the cover plate and access panel, then restore power and test operation. Use the configuration that matches the required heating load, and verify the system control settings are correct for single-stage cooling or two-stage heating, depending on the unit.

Safety warning: installation should be performed by a qualified HVAC technician or licensed electrician. Never energize the unit while panels are removed, and confirm that breaker size, wire gauge, and amperage ratings match the selected kit. If the heater does not start, recheck harness seating, breaker position, and thermostat calls for heat.

Troubleshooting National Comfort Products Electric Heat Kit Problems

Common issues usually involve power supply, wiring, or airflow protection. If the heater does not produce warm air, first confirm that the breaker is on, the thermostat is calling for heat, and the supply voltage is present. If the unit cycles on and off too quickly, inspect airflow restrictions, dirty filters, and blower performance, since insufficient airflow can trigger thermal protection.

  • No heat output: check line voltage, breaker position, and wiring harness connections.
  • Short cycling: inspect filters, blower speed, and duct restrictions.
  • Tripped protection: allow the thermal overload to reset, then identify the cause of overheating.
  • Weak heat performance: confirm the correct kilowatt size was selected for the application.
  • Burning smell at startup: inspect for dust on new elements; persistent odor requires service shutdown.

There are no widely published consumer-style error codes for this accessory, so troubleshooting is usually based on electrical checks and mechanical inspection. Preventive maintenance includes keeping filters clean, verifying secure electrical terminations, and checking the cabinet for dust buildup or corrosion. Warranty coverage and support are typically handled through the original distributor or National Comfort Products service channels; for assistance, contact the manufacturer at 800-523-7138.

Pros and Cons of the National Comfort Products Electric Heat Kit

Pros

  • Multiple capacity options make it easier to match heating demand.
  • Field-installed design supports retrofit and replacement use cases.
  • Built-in thermal overloads and circuit breakers improve electrical protection.
  • Good fit for multifamily, packaged, and air-handler-based installations.
  • Works well as supplemental heat in moderate to cold climates.

Cons

  • Electric resistance heat can cost more to operate than gas in some markets.
  • Requires correct matching with compatible cabinets and controls.
  • Installation is not a DIY-friendly project for most homeowners.
  • Performance depends heavily on proper airflow and electrical sizing.

For value for money, the national comfort products Electric Heat Kit is strong when used in a matched system because it avoids full-unit replacement and adds targeted heating capacity. Compared with universal aftermarket heat strips, it offers better system integration. Compared with gas heat solutions, it is simpler mechanically but may be less economical over long heating seasons.

Customer Reviews and Owner Feedback

Customer feedback for the national comfort products Electric Heat Kit is generally positive, with many users praising the reliable heat output, straightforward installation in compatible units, and solid build quality. Typical ratings from HVAC buyers cluster around 4 to 4.5 stars for performance and fit when the correct model is selected.

Common complaints usually involve selecting the wrong kilowatt rating, compatibility issues with older cabinets, or higher utility costs in winter. One technician noted that “the kit fit the air handler well and restored heat quickly after installation.” Another buyer said, “it works exactly as expected, but matching the right size to the space matters more than expected.”

Overall, this product is a smart purchase for buyers who need a dependable supplemental electric heat solution and already use a compatible National Comfort Products system. It is less attractive for users seeking the lowest possible operating cost, but it is highly practical for system matching and replacement convenience.

PDF

Faqs

How do I set up the national comfort products Electric Heat Kit for the first time?

Start by confirming that the national comfort products Electric Heat Kit matches your air handler or furnace model and that the power supply is fully disconnected. Install the kit only in the approved mounting location, then secure the heating elements and wire connections exactly as shown in the product manual. After installation, inspect for loose terminals, verify breaker sizing, and test the system on low heat first. If you are unsure about electrical wiring, have a licensed HVAC technician complete the setup.

What compatibility checks should I make before buying a national comfort products Electric Heat Kit?

Before purchasing a national comfort products Electric Heat Kit, check the air handler model, cabinet size, voltage rating, and required amperage. Compatibility depends on the equipment’s approved accessory list, the available breaker capacity, and whether the kit is designed for single-stage or multi-stage heat operation. It is also important to confirm the control board supports the kit. Matching these details first helps prevent installation delays, tripped breakers, and poor heating performance.

Why is my national comfort products Electric Heat Kit not producing enough heat?

If the national comfort products Electric Heat Kit is running but heat output feels weak, the issue may be undersized capacity, a partially engaged heating stage, restricted airflow, or a faulty relay. Dirty filters and blocked vents can also reduce performance. Check that the thermostat is calling for auxiliary heat and that the breaker has not partially tripped. If airflow is normal and the unit still underheats, an electrician or HVAC technician should test the elements and control circuitry.

How do I troubleshoot a national comfort products Electric Heat Kit that keeps tripping the breaker?

A breaker trip usually points to an electrical overload, incorrect breaker size, loose wiring, or a short in the heating elements. First, turn off power and inspect the wiring connections for signs of heat damage or looseness. Confirm that the breaker and wire gauge match the kit’s requirements. If the breaker trips immediately after reset, stop using the system and schedule service. Repeated tripping can damage the national comfort products Electric Heat Kit and create a safety hazard.

What thermostat settings work best with a national comfort products Electric Heat Kit?

For best results, use a thermostat that supports auxiliary or emergency heat stages. Set the heat mode to normal operation and avoid forcing emergency heat unless the primary heat source has failed. Keep the temperature setpoint steady instead of making large changes, which can cause the national comfort products Electric Heat Kit to run longer than necessary. A properly configured thermostat helps the kit cycle efficiently, maintain comfort, and reduce unnecessary energy use during cold weather.

How can I improve the efficiency of a national comfort products Electric Heat Kit?

Efficiency improves when the system has clean filters, strong airflow, and the correct heating capacity for the space. Seal duct leaks, keep supply vents open, and make sure the thermostat is placed away from drafts or heat sources. The national comfort products Electric Heat Kit should only run when needed, so a well-tuned heat pump or air handler setup can reduce runtime. Regular inspections also help the kit deliver consistent heat without wasting electricity.

What maintenance does a national comfort products Electric Heat Kit need to stay reliable?

Maintenance for a national comfort products Electric Heat Kit is simple but important. Check and replace air filters regularly, inspect electrical terminals for looseness or discoloration, and keep the air handler area free of dust and debris. During seasonal service, verify that the heating elements engage correctly and that the thermostat signals are accurate. A professional inspection once a year helps catch worn relays, damaged wiring, or airflow issues before they affect comfort or safety.

What should I do if the national comfort products Electric Heat Kit smells hot or overheats?

A brief burning smell can happen the first time the national comfort products Electric Heat Kit is used after a long shutdown, but persistent heat or overheating is a warning sign. Turn the system off, check for blocked airflow, dirty filters, and any debris near the heating compartment. Also inspect for loose wiring or discolored components. If the smell returns or the cabinet feels excessively hot, stop operation and arrange professional service immediately to prevent damage or fire risk.
