Olight Magicshine Bicycle Light RN 800 User Manual | Specifications

cover-image

Content


Introduction of Olight Magicshine Bicycle Light RN 800

The Olight Magicshine Bicycle Light RN 800 is a high-performance, versatile, and durable bicycle light designed to provide riders with superior visibility and safety on the road. This powerful light boasts an impressive maximum output of 800 lumens, making it ideal for both urban and off-road biking environments. With an estimated price range of $60 to $80 and a planned launch date in late Q2 2023, the RN 800 is perfect for cycling enthusiasts and commuters alike.

 Detailed Specifications

  • Max output: 800 lumens
  • LED Type: CREE XP-L2
  • Power source: Rechargeable 2600mAh Li-ion battery
  • Burn time: 1.5 hours on max output, up to 40 hours on lowest setting
  • Waterproof rating: IPX6 (protected against high-pressure water jets from any direction)
  • Mount: Adjustable quick-release mount for handlebars 22mm - 35mm diameter
  • Weight: 120g (light and battery)
  • Dimensions: 104mm (length) x 28mm (head diameter) x 30mm (body diameter)

LUMENS / RUNTIME


All performance measurements in accordance with ANSI/NEMA FL1-2009 Standard. The tests are performed indoors under a room temperature of 25 degrees celsius with windless conditions. The runtime may vary depending on the external temperature and ventilation conditions, and these biases may affect the results of testing.
Note: The maximum output brightness will decrease as the battery voltage decreases.

Description of Magicshine Bicycle Light RN 800

The Olight Magicshine Bicycle Light RN 800 offers a robust set of features to enhance your biking experience. Its CREE XP-L2 LED provides a bright, wide beam that effectively illuminates your path, while the Olight's patented cooling system ensures consistent performance and longevity. The quick-release mount allows for easy attachment and removal, and the rechargeable 2600mAh Li-ion battery ensures you're never left in the dark. With multiple brightness levels and a convenient USB-C charging port, the RN 800 is an indispensable companion for any cyclist.

IN THE BOX


HOW TO INSTALL


BEFORE FIRST USE

  • The bike light arrives in lockout mode.
  • Before first use, please unlock the light.
  • If the light is left unused, carried, or transported, please lock out the power button to prevent potential damage from the heat built up due to accidental activation.
  • Lock: When the light is off, press and hold the power button about 3 seconds until the indicator flashes red.
  • Unlock: When the light is locked, press and hold the power button about 3 seconds until the indicator turns constant red.

HOW TO RECHARGE


Standard Charging Time: Approx.2.5hrs (5V 3A)

BATTERY INDICATOR

  • When the device is powered on, the indicator on the power button will indicate the battery level.
  • When the device is powered off, short press the power button to activate the indicator light (light will shut down automatically after 2 seconds).

PHONE CHARGING INSTRUCTION


Note: Charging cables need to be purchased separately.
DANGER

  • DO NOT shine the light directly into human eyes. This may cause temporary blindness, or permanent damage to the eyes.
  • DO NOT cover the light head when the bicycle light is on, or place the bicycle light head on the ground. The radiation energy of the bicycle light may cause damage to the bicycle light itself, or even result in burning to flammable objects.

WARNING

  • Keep out of reach of children.
  • The light contains a lithium-ion battery. Certain restrictions may apply to this product when traveling, especially when traveling by air. Always check with your carrier for specific restrictions prior to traveling with this product.
  • DO NOT clean the lens with alcohol or any other chemicals.

NOTICE


  • Store the light at room temperature in a dry place. Avoid moisture, or extreme hot or cold.
  • Store the light in the charged condition. Avoid “deep discharge". Battery life will decrease if the light is stored in a fully discharged condition.
  • Over time, the run time of the battery will diminish. Expect about 500 full charges, depending on care. After a full life, the battery will continue to charge but with a lower run time.
  • When the run time is unsatisfactory, please recycle. DO NOT open the case of the light or incinerate.

EXCLUSION CLAUSE
Olight is not liable for damages or injuries sustained resulting from the usage of the product inconsistent with the warnings in the manual, including but not limited to using the product inconsistent with the recommended lockout mode.

Customer Reviews about Olight RN 800

  1. "The Olight Magicshine RN 800 is hands down the best bike light I've ever owned. The brightness and beam pattern are fantastic, and the build quality is top-notch."
  2. "I love how easy it is to charge the RN 800 with the included USB-C cable. No more fussing with proprietary chargers!"
  3. "The adjustable mount is a game-changer. I can quickly switch the light between my different bikes without any hassle."
  4. "This light is bright enough to light up the entire trail, making off-road biking much safer and more enjoyable."
  5. "The only complaint I have is that the battery life could be a bit longer on the lower settings."

Faqs

On my bike, how can I install the Olight Magicshine RN 800?

Using the included straps or mount, firmly fasten the light mount onto the handlebars of your bicycle to complete the installation. Make sure it is securely fastened to avoid any movement. Before you leave on your ride, fasten the RN 800 to the mount.

What is the lifespan of the RN 800 battery and how can I recharge it?

Which lighting mode the RN 800 is in will determine how long its battery lasts. The highest setting lasts 1.5 hours, while the lowest lasts 12 hours. Use the USB-C cord that comes with it to recharge it; a full charge takes about 3.5 hours.

How can I fix my RN 800 if it won't turn on?

First, make sure the light is fully charged. If it still won't power on, make sure the cable is in good working order and look for any debris in the USB-C port. If issues continue, see your warranty or get in touch with Olight customer support.

Is it possible to use the Olight Magicshine RN 800 in wet weather?

Yes, the RN 800 is waterproof, having an IPX6 rating that allows it to survive strong rain and splashing. It isn't intended to be submerged underwater, though.

How can I go through the various modes on the RN 800?

The power button can be pressed to switch between modes. Long presses turn on and off the light; short presses cycle between the modes. There are multiple brightness settings and a flashing option among the modes.

What is the RN 800's maximum illumination distance?

To ensure that you can see the road clearly and that oncoming vehicles can see you, the RN 800 can illuminate the route ahead for up to 125 metres.

How can I determine when I need to charge my RN 800?

The RN 800 features an integrated battery indicator. The indicator will turn red when the battery is low, telling you that it's time to recharge your light.

Is it easy to remove the light from its mount for security reasons?

Yes, when the bicycle is left unattended, the RN 800 can be easily removed from its mount to deter theft. It is made to be removed and reattached with ease.

What should I do if the light gradually gets dimmer?

The RN 800 may be indicating that its battery is not keeping a charge as well if it starts to get dimmer over time. If a complete charge cycle is unsuccessful, the battery might need to be replaced.

How long is the Olight Magicshine RN 800 warranty?

In most cases, Olight provides a 2-year guarantee that covers manufacturing defects for their lights. To activate the warranty, make sure you register your product with Olight.
