Introduction of Omron Bronze Blood Pressure Monitor BP5100

The Omron Bronze Blood Pressure Monitor BP5100 is a reliable and accurate home monitoring device that allows users to keep track of their blood pressure and heart rate. This monitor features advanced technology, including Omron's IntelliSense technology, which inflates the cuff to the ideal level for each individual, ensuring accurate and consistent readings. The estimated price of the BP5100 is around $60, making it an affordable option for those looking for a high-quality home blood pressure monitor. The monitor was launched in 2019 and has since become a popular choice among healthcare professionals and consumers alike.

This blood pressure monitor uses the oscillometric method of blood pressure measurement. This means this monitor detects your blood movement through your brachial artery and converts the movements into a digital reading.

Specifications

1. Model
   BP5100 HEM-7122-Z
2. Display
   LCD digital display
3. Cuff Pressure Range
   Pressure: 0 to 299 mmHg
4. Measurement Range
   Pressure: 20 to 280 mmHg
   Pulse: 40 to 180 beats/min
5. Accuracy
   Pressure: ±3 mmHg
   Pulse: ± 5% of display reading
6. Inflation
   Fuzzy-logic controlled by electric pump
7. Deflation
   Automatic pressure release valve
8. Measurement Method
   Oscillometric method
9. IP Classification
   IP 20
10. Rating
    DC6 V 4 W
11. Power Source
    4 “AA” batteries 1.5 V
12. Battery Life
    Approximately 1000 measurements (using new alkaline batteries)
13. Durable Period (Service Life)
    Monitor: 5 years
    Cuff: 5 years
14. Operating Conditions
    +50 °F to +104 °F (+10 °C to +40 °C) / 15 to 90% RH (non-condensing) / 800 to 1060 hPa
15. Storage / Transport Conditions
    -4 °F to +140 °F (-20 °C to +60 °C) / 10 to 90% RH (non-condensing)
16. Weight
    Monitor: Approximately 8.8 oz (250 g) not including batteries
    Arm cuff: Approximately 6 oz (170 g)
17. Dimensions
    Monitor: Approximately 4.0" (w) × 3.1" (h) × 5.1" (l) (103 mm × 80 mm × 129 mm)
    Arm cuff: Approximately 5.7" × 23.4" (air tube: 29.5") (145 mm × 594 mm (air tube: 750 mm))
18. Cuff Circumference Applicable to the Monitor
    7" to 17" (170 to 420 mm) (included arm cuff 9” to 17” (220 to 420 mm))
19. Memory
    Up to 14 Readings
20. Contents
    Monitor, arm cuff, instruction manual, quick start guide, 4 “AA” batteries
21. Applied Part
    Type BF (arm cuff)
22. Protection Against Electric Shock
    Internally powered ME equipment

Know Your Monitor

Contents

Monitor, arm cuff, instruction manual, quick start guide, 4 “AA” batteries.

Monitor

• A Display
• B START/STOP button

• C Memory button



• D Battery compartment

• E Air jack

  Arm cuff

• F Arm cuff (Arm circumference 9" - 17" (22 - 42 cm))
• G Air plug

• H Air tube



Display and Symbols

I		Memory symbol Appears when viewing readings stored in the memory.
J	Systolic blood pressure reading
K	Diastolic blood pressure reading
L		Low battery symbol Flashes when batteries are low.
		Depleted battery symbol Appears when batteries are depleted.
M		Heartbeat symbol Flashes while taking a measurement.
N		Irregular heartbeat symbol Appears along with readings when an irregular rhythm is detected 2 or more times during a measurement. An irregular heartbeat rhythm is defined as a rhythm that is 25% less or 25% more than the average rhythm detected while your monitor is measuring blood pressure. Irregular heartbeat symbol may be displayed when the monitor detects arm movements. Refer to section 4 for more information. If it continues to appear, we recommend you to consult with and follow the directions of your physician.
O		Movement error symbol Appears with your reading when your body is moving during a measurement. If it appears, remove the arm cuff and wait for 2 to 3 minutes. Then, reapply the cuff, remain still and take another measurement.
P	Pulse display / Memory number Pulse rate appears after the measurement.
Q		Deflation symbol Appears during cuff deflation.

Classification of BP (Blood Pressure)

ACC/AHA 2017 Hypertension guidelines define categories of BP in adults as below.

Categories of BP in Adults*

Individuals with Systolic BP and Diastolic BP in 2 categories should be designated to the higher BP category. BP indicates blood pressure (based on an average of ≥ 2 careful readings obtained on ≥ 2 occasions).

Source: ACC/AHA 2017 High Blood Pressure Clinical Practice Guideline

Warning NEVER diagnose or treat yourself based on your readings. ALWAYS consult with your physician.

Blood Pressure Measurement

Tips: To help ensure an accurate reading, follow these directions:

• Stress raises blood pressure. Avoid taking measurements during stressful times.
• Measurements should be taken in a quiet place.
• It is important to take measurements at the same times each day. Taking measurements in the morning and in the evening is recommended.
• Remember to have a record of your blood pressure and pulse readings for your physician. A single measurement does not provide an accurate indication of your true blood pressure. You need to take and record several readings over a period of time.

Caution

• Avoid bathing, drinking alcohol or caffeine, smoking, exercising and eating for at least 30 minutes before taking a measurement.
• Rest for at least 5 minutes before taking a measurement.

Preparation

Battery Installation

1. Remove the battery cover.

2. Insert 4 “AA” batteries as indicated in the battery compartment.



3. Replace the battery cover.

Notes

• When the low battery symbol ( ) appears on the display, turn the monitor off, then replace all batteries at the same time. Long life alkaline batteries are recommended.
• The measurement values continue to be stored in memory even after the batteries are replaced.
• Disposal of used batteries should be carried out in accordance with local regulations.

Description

The Omron Bronze Blood Pressure Monitor BP5100 is a compact and portable device that is easy to use and store. The monitor has a large, easy-to-read LCD screen that displays systolic and diastolic blood pressure readings, as well as pulse rate. The device can store up to 60 readings, with the ability to recall the average of the last 3 readings with the touch of a button. The BP5100 is equipped with irregular heartbeat detection, which alerts users to any potential heart rhythm abnormalities. The monitor also features a multi-color indicator system, which uses green, orange, and red lights to signify normal, pre-hypertension, and hypertension readings, respectively.

Using The Monitor

Applying the Arm Cuff

Caution Remove tight-fitting, thick clothing from your arm while taking a measurement.

1. Insert the air plug into the air jack securely.



2. Place your hand through the cuff loop, then pull the cuff until it reaches your upper left arm.



   • The bottom edge of the arm cuff should be 0.5 inch (1 to 2 cm) above the elbow. Air tube is on the inside of your arm and aligned with your middle finger.



3. Secure closed with the fabric fastener.



Notes

• When you take a measurement on the right arm, the air tube will be at the side of your elbow. Be careful not to rest your arm on the air tube.

• The blood pressure can differ between the right arm and the left arm, and the measured blood pressure values can be different. OMRON recommends to always use the same arm for measurement. If the values between both arms differ substantially, please check with your physician which arm to use for your measurements.



How to Sit Correctly

To take a measurement, you need to be relaxed and comfortably seated with a comfortable room temperature. Place your arm on the table.

• Sit in a comfortable chair with your back and arm supported.
• Keep your feet and your legs uncrossed.

• The arm cuff should be placed on your arm at the same level as your heart, with the arm resting comfortably on a table.



Taking a Measurement

Notes: To stop the measurement, press the START/STOP button once to deflate the arm cuff. Remain still and quiet while taking a measurement.

1. Press the START/STOP button. The arm cuff will start to inflate automatically.



2. Remove the arm cuff.
3. Press the START/STOP button to turn the monitor off. The monitor automatically stores the measurement result in its memory. It will automatically turn off after 2 minutes.
   Note: Wait 2-3 minutes before taking another measurement. Waiting between measurements allows the arteries to return to the condition prior to taking a measurement.

Using the Memory Function

The monitor automatically stores the results up to 14 sets.

Note: If the memory is full, the monitor will delete the oldest value.

To View the Measurement Values Stored in Memory

1. Press the button. The Memory number appears for a second before the pulse rate is displayed. The newest set is numbered “1”.



2. Press the button repeatedly to view the values stored in memory.

To Delete All the Values Stored in Memory

1. Press the button, while the memory symbol appears.

2. While holding the button down, press the START/STOP button for more than 3 seconds.



Note: You cannot partially delete the values stored in memory.

Omron Bronze Blood Pressure Monitor BP5100 Setup Guide

Setting up the Omron Blood is a simple process that can be completed in just a few easy steps:

1. Insert the batteries: Open the battery compartment on the back of the monitor and insert 2 AA batteries.
2. Connect the cuff: Attach the blood pressure cuff to the monitor and ensure that it is properly connected.
3. Wrap the cuff: Wrap the cuff around your upper arm, making sure that the bottom edge of the cuff is about 1 inch above the bend of your elbow.
4. Turn on the monitor: Press the power button on the front of the monitor to turn it on.
5. Begin measurement: Press the "Start" button to begin taking your blood pressure.

Maintenance

To protect your monitor from damage, please follow the directions below:

• Changes or modifications not approved by the manufacturer will void the user warranty.

Caution DO NOT disassemble or attempt to repair this monitor or other components. This may cause an inaccurate reading.

Storage

Store your monitor and other components in a clean, safe location.

1. Remove the arm cuff from the monitor.
   Caution: To unplug the air plug, pull on the plastic air plug at the base of the tube, not the tube itself.

2. Gently fold the air tube into the arm cuff.



Note

• Do not bend or crease the air tube excessively.

Do not store your monitor and other components:

• If your monitor and other components are wet.
• In locations exposed to extreme temperatures, humidity, direct sunlight, dust or corrosive vapors such as bleach.
• In locations exposed to vibrations or shocks.

Cleaning

• Do not use any abrasive or volatile cleaners.
• Use a soft dry cloth or a soft cloth moistened with neutral soap to clean your monitor and arm cuff, and then wipe them with a dry cloth.
• Do not wash or immerse your monitor and arm cuff or other components in water.
• Do not use gasoline, thinners or similar solvents to clean your monitor and arm cuff or other components.

Disposal

• Dispose of your monitor, other components and optional accessories according to applicable local regulations.
• Unlawful disposal may cause environmental pollution.

Optional Medical Accessories Arm cuff

• Arm circumference 7" - 9" (17 - 22 cm)



  CD-CS9 (Model: HEM-CS24)

• Arm circumference 9" - 17" (22 - 42 cm)



  CD-WR17 (Model: HEM-RML31)

Notes

• These specifications are subject to change without notice.
• This monitor complies with the requirements of ISO 81060-2:2013. In the clinical validation study, K5 was used on 85 subjects for determination of diastolic blood pressure.
• This monitor has not been validated for use on pregnant patients.
• IP classification is degrees of protection provided by enclosures in accordance with IEC 60529. This monitor is protected against solid foreign objects of 12.5 mm diameter and greater such as a finger.

Pictogram on the Product

• Type of marks used to indicate the correct positioning of the artery for the upper arm
• Identifies the type of cuff that is compatible with the blood Pressure Monitor.

Safety Instructions

This instruction manual provides you with important information about the OMRON BP5100 Blood Pressure Monitor. To ensure the safe and proper use of this monitor, READ and UNDERSTAND all of these instructions. If you do not understand these instructions or have any questions, contact 1-800-634-4350 before attempting to use this monitor. For specific information about your own blood pressure, consult with your physician.

Intended Use This device is a digital monitor intended for use in measuring blood pressure and pulse rate in adult patient population. The device detects the appearance of irregular heartbeats during measurement and gives a warning signal with readings. Environments of Use: Home Patient Population: Adult

Important Safety Information

Read the Important Safety Information in this instruction manual before using this monitor. Follow this instruction manual thoroughly for your safety. Keep for future reference. For specific information about your own blood pressure, CONSULT WITH YOUR PHYSICIAN.

Warning Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

• DO NOT use this monitor on infants, toddlers, children or persons who cannot express themselves.
• DO NOT adjust medication based on readings from this blood pressure monitor. Take medication as prescribed by your physician. ONLY a physician is qualified to diagnose and treat high blood pressure.
• DO NOT use this monitor on an injured arm or an arm under medical treatment.
• DO NOT apply the arm cuff on your arm while on an intravenous drip or blood transfusion.
• DO NOT use this monitor in areas containing high frequency (HF) surgical equipment, magnetic resonance imaging (MRI) equipment, computerized tomography (CT) scanners or in oxygen rich environments. This may result in incorrect operation of the monitor and/or cause an inaccurate reading.
• DO NOT use this monitor in oxygen rich environments or near flammable gas.
• Consult with your physician before using this monitor if you have common arrhythmias such as atrial or ventricular premature beats or atrial fibrillation; arterial sclerosis; poor perfusion; diabetes; pregnancy; pre-eclampsia or renal disease. NOTE that any of these conditions in addition to patient motion, trembling, or shivering may affect the measurement reading.
• NEVER diagnose or treat yourself based on your readings. ALWAYS consult with your physician.
• To help avoid strangulation, keep the air tube away from infants, toddlers and children.
• This product contains small parts that may cause a choking hazard if swallowed by infants, toddlers and children.

Battery Handling and Usage

• Keep batteries out of the reach of infants, toddlers and children.

Caution Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury to the user or patient, or cause damage to the equipment or other property.

• Stop using this monitor and consult with your physician if you experience skin irritation or discomfort.
• Consult with your physician before using this monitor on an arm where intravascular access or therapy, or an arteriovenous (A-V) shunt, is present because of temporary interference to blood flow which could result in injury.
• Consult with your physician before using this monitor if you have had a mastectomy.
• Consult with your physician before using this monitor if you have severe blood flow problems or blood disorders as cuff inflation can cause bruising.
• DO NOT take measurements more often than necessary because bruising, due to blood flow interference, may occur.
• ONLY inflate the arm cuff when it is applied on your upper arm.
• Remove the arm cuff if it does not start deflating during a measurement.
• DO NOT use this monitor for any purpose other than measuring blood pressure.
• During measurement, make sure that no mobile device or any other electrical device that emits electromagnetic fields is within 12 inches (30 cm) of this monitor. This may result in incorrect operation of the monitor and/or cause an inaccurate reading.
• DO NOT disassemble or attempt to repair this monitor or other components. This may cause an inaccurate reading.
• DO NOT use in a location where there is moisture or a risk of water splashing this monitor. This may damage this monitor.
• DO NOT use this monitor in a moving vehicle such as in a car.
• DO NOT drop or subject this monitor to strong shocks or vibrations.
• DO NOT use this monitor in places with high or low humidity or high or low temperatures. Refer to section 5.
• During measurement, observe the arm to ensure that the monitor is not causing prolonged impairment to blood circulation.
• DO NOT use this monitor in high-use environments such as medical clinics or physician offices.
• DO NOT use this monitor with other medical electrical (ME) equipment simultaneously. This may result in incorrect operation of the monitor and/or cause an inaccurate reading.
• Avoid bathing, drinking alcohol or caffeine, smoking, exercising and eating for at least 30 minutes before taking a measurement.
• Rest for at least 5 minutes before taking a measurement.
• Remove tight-fitting or thick clothing from your arm while taking a measurement.
• Remain still and DO NOT talk while taking a measurement.
• ONLY use the arm cuff on persons whose arm circumference is within the specified range of the cuff.
• Ensure that this monitor has acclimated to room temperature before taking a measurement. Taking a measurement after an extreme temperature change could lead to an inaccurate reading. OMRON recommends waiting for approximately 2 hours for the monitor to warm up or cool down when the monitor is used in an environment within the temperature specified as operating conditions after it is stored either at the maximum or at the minimum storage temperature. For additional information on operating and storage/transport temperature, refer to section 5.
• DO NOT use this monitor after the durable period has ended. Refer to section 6.
• DO NOT crease the arm cuff or the air tube excessively.
• DO NOT fold or kink the air tube while taking a measurement. This may cause an injury by interrupting air flow.
• To unplug the air plug, pull on the plastic air plug at the base of the tube, not the tube itself.
• ONLY use the arm cuff, batteries and accessories specified for this monitor. Use of unsupported arm cuffs and batteries may damage and/or may be hazardous to this monitor.
• ONLY use the approved arm cuff for this monitor. Use of other arm cuffs may result in incorrect readings.
• Inflating to a higher pressure than necessary may result in bruising of the arm where the cuff is applied. NOTE: please refer to “If your systolic pressure is more than 210 mmHg” in section 3 of this instruction manual for additional information.

Battery Handling and Usage

• DO NOT insert batteries with their polarities incorrectly aligned.
• ONLY use 4 “AA” alkaline or manganese batteries with this monitor. DO NOT use other types of batteries. DO NOT use new and used batteries together. DO NOT use different brands of batteries together.
• Remove batteries if this monitor will not be used for a long period of time.
• If battery fluid should get in your eyes, immediately rinse with plenty of clean water. Consult with your physician immediately.
• If battery fluid should get on your skin, wash your skin immediately with plenty of clean, lukewarm water. If irritation, injury or pain persists, consult with your physician.
• DO NOT use batteries after their expiration date.
• Periodically check batteries to ensure they are in good working condition.

Error Messages and Troubleshooting

If any of the below problems occur during measurement, check to make sure that no other electrical device is within 12 inches (30 cm). If the problem persists, refer to the table below. Error Messages

Error Display	Cause	Solution
	Irregular heartbeats are detected.	Remove the arm cuff. Wait 2 - 3 minutes and then take another measurement. Repeat the steps in section 3.3. If this error continues to appear, contact your physician.
	Movement during measurement.	Carefully read and repeat the steps in section 3.3.
	The batteries are low.	You should replace the batteries with new ones ahead of time. Refer to section 2.1.
	The batteries are depleted.	You should replace the batteries with new ones at once. Refer to section 2.1.
	Air plug disconnected.	Insert the plug securely. Refer to section 3.1.
	Arm cuff is applied too loosely.	Apply the arm cuff tighter. Refer to section 3.1.
	Air is leaking from the arm cuff.	Replace the arm cuff with a new one. Refer to section 5.5.
	Movement during measurement and the arm cuff has not been inflated sufficiently.	Repeat measurement. Remain still and do not talk during measurement. Refer to section 3.3.
		If “E2” appears repeatedly, inflate the arm cuff manually until it is 30 to 40 mmHg above your previous measurement result. Refer to section 3.3.
	The arm cuff was inflated exceeding the maximum allowable pressure, and then deflated automatically when inflating the arm cuff manually.	Do not touch the arm cuff and/or bend the air tube while taking a measurement. Do not inflate the arm cuff more than necessary. Refer to section 3.3.
	Movement during measurement.	Repeat measurement. Remain still and do not talk during measurement. Refer to section 3.3.
	Clothing is interfering with the arm cuff.	Remove any clothing interfering with the arm cuff. Refer to section 3.1.
	Device error.	Contact Customer Service.

Troubleshooting

Warranty

Your BP5100 Automatic Blood Pressure Monitor, excluding the arm cuff and batteries is warranted to be free from defects in materials and workmanship appearing within 2 years from the date of purchase, when used in accordance with the instructions provided with the monitor. The arm cuff is warranted to be free from defects in materials and workmanship appearing within 1 year from the date of purchase when the monitor is used in accordance with the instructions provided with the monitor.

Pros & Cons

Pros

• Accurate and consistent readings
• Easy to use
• Compact and portable design
• Large, easy-to-read LCD screen
• Multi-color indicator system
• Irregular heartbeat detection

Cons

• Some users may find the cuff to be uncomfortable
• May not be as accurate for users with very large or very small arms

Customer Reviews about Omron Bronze Blood Pressure Monitor BP5100

Customers have praised the Omron Bronze Blood Pressure Monitor BP5100 for its accuracy and ease of use. Many users have also appreciated the compact and portable design, which makes it easy to take the monitor on the go. However, some users have reported that the cuff can be uncomfortable and that the monitor may not be as accurate for users with very large or very small arms.
