Introduction

Congratulations on your purchase of a PowerBass USA Xtreme™ full-range Bluetooth speaker system. You now own a Bluetooth speaker sysytem of uncompromising design and engineering from a factory that truly believes in the relentless pursuit of perfection. Incorporating the highest quality parts and state-of-the-art materials, these bluetooth speakers display the ultimate balance between high fidelity, performance and long-lasting reliability.

Introducing the Powerbass XL-PS200 Amplified Speaker Pods, the perfect addition to your car audio system. These speaker pods are designed to deliver powerful and clear sound, making your music experience on the road more enjoyable. With an estimated price range of $150 to $200, these speaker pods are a great value for the quality they provide.

At PowerBass USA, Inc. we are confident you will have many years of outstanding enjoyment from this great SPEAKER investment. For maximum performance we recommend that you have your new PowerBass Xtreme product installed by an Authorized PowerBass Xtreme Dealer.

Warning

Continuous exposure to sound pressure levels in excess of 100 dB can cause permanent hearing loss. PowerBass Autosound Speakers are capable of producing sound pressure levels well over 170 dB. Please observe all local sound ordinances while listening to your PowerBass Autosound system. PowerBass USA, Inc. accepts no liability for hearing loss, bodily injury, or property damage due to the result of use or misuse of this product.

SPECIFICATIONS

2.75” Powerbass XL-PS200 Amplified Speaker Pods

• Mounting: 1” or 7/8” Handle Bar Mount with adapter included
• Connections: 12V Power, Ground and Ignition Switch
• Compatible with Android, iPhone and most other Bluetooth enabled devices
• Range: 30 Feet
• Adjustments: Power, Track up/down, Volume up/down and Pause
• Voltage: 8.4V-17.4V
• Frequency Response: 120Hz-20kHz

INSTALLATION INSTRUCTIONS

XL-PS200 WIRING DIAGRAM

• YELLOW WIRE - 12V Constant Power Lead
• BLACK WIRE - Ground Lead
• RED WIRE - 12V Ignition Lead

XL-PS200 WIRING INSTRUCTIONS

1. Connect the yellow power wire to the battery positive.
2. Connect the red wire to the ignition switch. This will turn your pods off from the ignition when your motorcycle or vehicle is turned off.
3. Connect the black ground wire to directly to the battery negative.
4. Plug the output connector cable into the input cable of the second speaker pod.

CONTROLLER LAYOUT

CONTROLLER OPERATION

1. POWER BUTTON
   Press the button down to power the controller on/off.  Please note the PS-200 must be powered on from the main pod before each use.  Anytime the PS-200 is powered down the power button must be pressed to power the pod system up for use.
2. VOLUME / TRACK BUTTON -
   Press and HOLD for volume control, Press and Release to change tracks.
3. VOLUME / TRACK BUTTON +
   Press and HOLD for volume control, Press and Release to change tracks.
4. BLUETOOTH BUTTON
   Push the Bluetooth button to pair a new device. The unit will play a tone once connected.
5. PLAY / PAUSE BUTTON
   Press the play / pause button to start or stop music playback.

BLUETOOTH PAIRING AND OPERATION

1. Turn the XL-PS200 on by pressing the power button, there will be an audible beep to confirm the XL-PS200 is on.
2. Press the Bluetooth button momentarily and you will hear an audible sequence of tones to confirm XL-PS200 is now ready to pair with your device.
3. Go into the Bluetooth settings of your device and search for XL-PS200 to pair. Once paired, there will be an audible beep to confirm that the XL-PS200 and your Bluetooth device has paired successfully.
4. Once the pairing process is complete, use either the XL-PS200 or connected device to control volume up and down, track back or forward, and play/pause.

Description of Powerbass XL-PS200 Amplified Speaker Pods

The Powerbass XL-PS200 Amplified Speaker Pods are 6.5-inch component speakers that come with a built-in 200-watt amplifier. They are designed to fit in most car doors and provide excellent sound quality with deep bass and clear highs. The speakers feature a polypropylene cone and a rubber surround for durability and long-lasting performance. The grilles are made of steel and have a sleek black powder-coated finish that adds to the overall look of the speakers.

Troubleshooting

If you experience any issues with your Powerbass XL-PS200 Amplified Speaker Pods, here are some common problems and solutions:

• No sound: Check the wiring and make sure the speakers are properly connected to the amplifier and the audio source.
• Distorted sound: Lower the gain on the amplifier or check the equalization settings on your audio source.
• Rattling noise: Make sure the speakers are securely mounted and the screws are tight.
• Overheating: Make sure the amplifier is properly ventilated and not covered or obstructed.

Due to continuing improvements these specifications are subject to change without any notice. Do not attempt to fix or repair this unit. Unauthorized repairs will void the manufacturer’s warranty..)

POWERBASS XTREME WARRANTY POLICY

PowerBass Xtreme Bluetooth Speaker Pods are to be free of defects in material and workmanship for a period of one (1) year. The warranty is extended to two (2) years for parts and labor, if an Authorized PowerBass Xtreme Dealer completes the installation.

This warranty applies only to PowerBass products sold to consumers by Authorized PowerBass Dealers in the United States of America. Products purchased by consumers from a PowerBass dealer in another country are covered only by that country’s Distributor and not by PowerBass USA.
This warranty covers only the original purchaser of PowerBass product. In order to receive service, the purchaser must provide PowerBass with the receipt stating the consumer name, dealer, product and date of purchase.
Products found to be defective during the warranty period will be repaired or replaced (with a product deemed to be equivalent) at PowerBass’s discretion and will not be liable for incidental or consequential damages. PowerBass will not warranty this product under the following situations:

• Speakers received with bent/cracked frames or significant water damage
• Abuse such as holes in the cone, surround or ripped spider
• Voice coil damage due to amplifier clipping or distortion
• Amplifiers received with apparent rust or corrosion
• Any evidence of liquid damage or exposure to excessive heat
• Attempted repairs or alterations of any nature
• Product that has not been installed according to this owners manual

Pros & Cons

Pros

• Built-in 200-watt amplifier
• 6.5-inch component speakers with polypropylene cone and rubber surround
• Steel grilles with black powder-coated finish
• Clear sound with deep bass and clear highs
• Easy to install

Cons

• May require additional wiring and installation accessories
• May not fit in all car doors
• May produce distorted sound at high volumes
• May require additional amplifier power for optimal performance

Powerbass XL-PS200 Amplified Speaker Pods Customer Reviews

Customers who have purchased the Powerbass XL-PS200 Amplified Speaker Pods have praised their sound quality and ease of installation. However, some have noted that they may require additional amplifier power for optimal performance and that the grilles may be difficult to remove for cleaning.
