Introducing the Reliance Controls CSR202 Easy-Tran Transfer Switch

The Reliance Controls CSR202 Easy-Tran Transfer Switch is a versatile and reliable automatic transfer switch that ensures uninterrupted power supply to your critical loads during power outages. This product is designed for use with portable generators and is ideal for home, office, and job site use. With an estimated price range of $300 to $400 and a launching date of January 2021, this transfer switch is a worthwhile investment for anyone seeking a dependable power backup solution.

Reliance Detailed Specifications

• 2000 watts rated capacity
• NEMA 3R rated enclosure for indoor or outdoor use
• Automatic transfer switch with manual override
• 50 Amp circuit breaker and 30 Amp plug
• Volts: 120V
• Weight: 35 lbs
• Dimensions: 14 x 12 x 8 inches

KEY COMPONENTS OF THE TRANSFER SWITCH

• SELECTOR SWITCH:  Selects either "LINE" (utility) or "GEN" (generator) as the source feeding the circuit load(s).
• POWER INLET: EMA L14-20 configuration.  Inputs power from the portable generator.

WIRING

IMPORTANT:  DISCONNECT ALL ELECTRICAL SUPPLY SOURCES BEFORE INSTALLATION AND WHEN SERVICING CONNECTED EQUIPMENT OR CIRCUITS.
Remove the wiring compartment cover by loosening the two screws that hold it in place, and lift out. Six color-coded wire leads are provided.

They are to be connected as follows:

• RED (2):  To incoming utility line, 250 VAC.
• WHITE:  To neutral.
• BLACK (2): To load, 250 VAC
• GREEN:  To ground bar or terminal.

Replace wiring compartment cover when wiring is completed.

USING THE RELIANCE TRANSFER SWITCH  WITH A GENERATOR

THIS RELIANCE TRANSFER SWITCH IS NOT FOR "DO-IT-YOURSELF" INSTALLATION.

 Installer must be thoroughly familiar with electrical wiring systems.  This Reliance Transfer Switch is designed to provide, in the event of a utility power outage, a safe and simple method of powering a single 250 volt circuit, or two 125 volt circuits simultaneously, from a portable generator with a combination 125/250 VAC output.  The DPDT selector switch will feed the circuit load(s) from either the utility or the generator, and prevent backfeeding of one source from another.

TRANSFERRING FROM UTILITY POWER TO GENERATOR POWER

1. Move the selector switch handle to the "OFF" or “LINE” position.
2. Insert the male power cord plug into the appropriate outlet on the generator.  If locking receptacle is used, rotate to lock.
3. Insert the female power cord connector into the power inlet located on the lower face of the transfer switch. Rotate to lock.
4. Start the generator, following the procedures described in the generator owner's manual furnished by the generator manufacturer.
5. Move the selector switch knob to the "GEN" position to energize load from generator.

TRANSFERRING FROM GENERATOR POWER BACK TO UTILITY POWER

1. Move the selector switch handle to the "LINE" position to energize load from utility.
2. Follow the procedures in the generator owner's manual to turn off the generator.
3. Disconnect the power cord.

Easy-Tran Transfer Switch Description

The Reliance Controls CSR202 Easy-Tran Transfer Switch is a high-quality automatic transfer switch designed for use with portable generators. It is easy to install and use, and it features a NEMA 3R rated enclosure that allows for indoor or outdoor use. The transfer switch has a 2000 watt rated capacity and is equipped with a 50 Amp circuit breaker and 30 Amp plug. It is compatible with most portable generators and ensures that your critical loads are powered during an outage, making it an essential purchase for anyone seeking a reliable power backup solution.

Setup Guide of Reliance Controls CSR202

1. Choose a location for the transfer switch that is within reach of the main electrical panel and generator.
2. Mount the transfer switch using the included hardware, ensuring that it is secure and level.
3. Connect the transfer switch to the main electrical panel using the appropriate wiring and following all local and national electrical codes.
4. Connect the transfer switch to the generator using the included 30 Amp plug.
5. Turn on the main electrical panel and the generator, and test the transfer switch to ensure that it is functioning properly.

Troubleshooting

If the transfer switch is not functioning properly, check the following:

• Ensure that the transfer switch is properly connected to the main electrical panel and generator.
• Check for any blown fuses or tripped circuit breakers.
• Make sure that the generator is producing the correct voltage and frequency.
• Check for any loose or damaged wiring.
• If the problem persists, consult the user manual or contact Reliance Controls for further assistance.

Reliance Controls Pros & Cons

Pros

• Reliable power backup solution
• Easy to install and use
• NEMA 3R rated enclosure for indoor or outdoor use
• Automatic transfer switch with manual override
• Compatible with most portable generators

Cons

• May be expensive for some users
• May require professional installation depending on local codes

Customer Reviews about Easy-Tran Transfer Switch

Customers have praised the Reliance Controls CSR202 Easy-Tran Transfer Switch for its ease of use, reliability, and durability. Many have noted that it provides a convenient and dependable power backup solution during outages. However, some have expressed concern about the high cost and the need for professional installation in some areas. Overall, the transfer switch has received positive reviews and is highly recommended for anyone seeking a reliable power backup solution.

Most Common Complaints

The most common complaints about the Reliance Controls CSR202 Easy-Tran Transfer Switch are its high cost and the need for professional installation in some areas. Some users have also reported issues with the transfer switch not functioning properly, but these issues have been resolved with the help of Reliance Controls' customer support team.
