SPT BM-1107 Breakfast Maker Machine 3-in-1

Introducing the SPT BM-1107, a 3-in-1 breakfast maker designed to simplify your morning routine. This versatile appliance combines a non-stick griddle, a coffeemaker, and a toaster oven, all in one sleek and compact design. The estimated price range is $60 - $80, making it an affordable addition to any kitchen. The BM-1107 is now available for purchase, bringing convenience and efficiency to your daily breakfasts.

PART IDENTIFICATION

3-IN-1 Breakfast Machine

1. Coffee Maker,

2. Toaster Oven, and

3. Frying Pan



SPECIFICATIONS

• Model: BM-1107

• Input voltage: 120V / 60Hz

• Power consumption: 1150W

  • Coffee Maker Power: 650W

  • Toaster Oven Power: 500W

  • Upper Pan Power: 300W

• Coffee Maker Capacity: 4 cups

• Toaster Oven Capacity: 5 L

• Timer: 15 min

• Unit dimension (L x W x H): 16 x 9.5 x 9.75 in.

• Net weight: 7.5 lbs

Description

The SPT BM-1107 features a 1500-watt power capacity, providing fast and even cooking on its spacious 19.5 x 9.5-inch non-stick griddle. The 4-cup coffeemaker ensures a fresh brew every morning, while the 6-slice toaster oven accommodates various bread types and sizes, with temperature control ranging from 150°F to 450°F. The BM-1107's removable and dishwasher-safe parts, along with its cord storage, make cleanup and storage a breeze.

OPERATING INSTRUCTIONS

COFFEE MAKER

Note: Before initial use, clean glass carafe, filter cone, and reusable filter thoroughly with lukewarm water and mild detergent. Clean the water tank by wiping the interior with a clean cloth. Then fill 1 ~ 2 cups of clean water and with the glass carafe in place, turn on the Coffee switch and allow water to cycle through. Discard water.

• Open the water tank lid and fill with clean water to the required level.

• Add ground coffee or tea into the reusable filter.

• Place the reusable filter into filter cone and insert cone in place.

• Place coffee carafe on the hot plate.

• Switch on the coffee maker switch, the indicator light should light up.

Note

• To close the filter cone, swing the cone clockwise, lift up a little, and gently push inward. This will lock the cone in place. To open, lift up and pull counter-clockwise.

• To keep coffee/tea warm, keep the glass carafe on the hot plate.

• Scalding may occur if the lid is removed during the brewing process.

• If ground coffee or tea leaves are to be added during operation, first switch off the power and switch back on after adding.

• If there is no water in the water tank, switch off the power before adding water.

FUNCTION SELECTOR

• OFF – Oven and Frying Pan switched off

• UP – operates only the upper element (Frying Pan)

• DOWN – operates the lower element (toaster oven)

• COMBO – operates both upper and lower elements

TOASTER OVEN

• Turn Selector Dial to DOWN position and turn Timer Dial to the desired cooking time (maximum 15 minutes).

• It is suggested to preheat the toaster oven for 2 minutes, especially when using the baking tray.

• When toasting, place food directly on the Baking Rack.

• Keep the door closed while the oven is in use, to prevent heat loss.

• The oven may be used to defrost frozen food. If possible, freeze food in smaller pieces wrapped in aluminum foil. This will ensure uniform defrosting. Defrost time depends on the size and amount of food.

FRYING PAN

• Turn Selector Dial to UP position and turn Timer Dial to the desired cooking time (maximum 15 minutes).

• It is suggested to preheat the frying pan for 2 minutes.

COMBO

To use both the toaster oven and top cooking element, turn Selector Dial to COMBO position and turn Timer Dial to the desired cooking time.

Note

• Once the cooking time has elapsed, the unit will emit an audible signal and the heating will stop.

• Turning the Timer Dial counter-clockwise to the “0” position or turning the Selector Dial to OFF will interrupt the cooking process.

• Turn both dials to the off position when done.

Setup Guide

1. Assemble the toaster oven by attaching the crumb tray and baking pan.
2. Plug in the BM-1107 and ensure the power switch is in the "Off" position.
3. Fill the water reservoir in the coffeemaker and add desired ground coffee to the filter basket.
4. Preheat the toaster oven or griddle as needed.
5. Place bread, food, or cookware on the griddle or in the toaster oven.
6. Select the appropriate setting and timer for the coffeemaker, toaster oven, or griddle.
7. Monitor the cooking process and adjust settings as needed.

CLEANING

• Turn all switches to OFF position.

• Unplug the appliance from the main power source.

• Remove coffee pot, filter, and filter cone – clean with lukewarm water.

• Remove baking rack, baking tray, frying pan – clean with lukewarm water with mild detergent, or in a dishwasher.

• The crumb collecting tray can be removed for cleaning.

• Use a damp cloth to clean the outer surfaces.

• Use a dry cloth to clean the interior.

• Never use abrasive detergents or products that cause scratching.

• Take special care not to touch the resistances when cleaning the inside of the oven.

Note: Do not clean immediately after use, as the appliance is hot. Wait until the appliance has cooled down before cleaning.

To remove backing rack and crumb collecting tray

IMPORTANT SAFEGUARDS

1. Read all instructions carefully.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against electrical shock, do not immerse cord, plugs, or oven in water.

4. Close supervision is necessary when any appliance is used by or near children.

5. Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts.

6. Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner. Contact the manufacturer.

7. The use of accessory attachments not recommended by the manufacturer may cause injuries.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch hot surfaces.

10. Do not place on or near a hot gas or electric burner, or in a heated oven.

11. Use extreme caution when moving an appliance containing hot oil or other hot liquids.

12. Always attach plug to appliance first, then connect cord to wall outlet. To disconnect, turn all controls to OFF position then remove plug from wall outlet.

13. Do not use appliance for other than intended use.

14. Before plugging the appliance into the main supply, make sure the voltage corresponds to that indicated on the nameplate.

15. Place the appliance on a dry, flat surface.

16. Oversized foods or metal utensils must not be inserted in the toaster oven, as they may create fire or the risk of electrical shock.

17. A fire may occur if the toaster oven is in operation while covered or touching flammable material, including curtains, draperies, walls, and the like. Do not store any item on top of the appliance when in operation.

18. Do not clean with metal scouring pads. Pieces breaking off the pad and touching electrical parts could present a risk of electrical shock.

19. Exercise extreme caution when using containers constructed of other than metal or glass.

20. Do not store any of the following materials in the oven: paper, cardboard, plastic, etc.

21. A short power cord (or detachable power cord) is provided to reduce the risk of becoming entangled or tripping.

22. This appliance is equipped with a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

23. If an extension cord is to be used: · Ensure the electrical rating of the extension cord meets the requirements of the unit’s rating label. · The extension cord is grounded. · Ensure the extension cord is not draped over the countertop or tabletop where it can be pulled on or tripped over.

24. Do not cover the crumb tray or any part of the oven with metal foil. This will cause overheating of the oven.

25. To reduce the risk of fire, do not place any heating or cooking appliances beneath the Breakfast Maker.

26. To reduce the risk of fire, do not store anything directly on top of the appliance surface when in operation.

27. Do not immerse the appliance in water or any liquid.

28. Never leave the appliance unsupervised when in operation.

29. Use only clean water when filling the water tank.

30. Do not touch the hot plate while the appliance is in operation or immediately after switching off, as it will be very hot.

31. After several uses, clean the filter cone, reusable filter, glass carafe, and water tank thoroughly with warm water and non-abrasive detergent.

32. The manufacturer is not responsible for damages caused by improper use or non-observance of this instruction. SAVE THESE INSTRUCTIONS

SPT BM-1107 Breakfast Maker Machine 3-in-1 Troubleshooting

1. Problem: Coffee is too weak or strong.
   Solution: Adjust the amount of coffee grounds or water used.
2. Problem: Food is not cooking evenly on the griddle.
   Solution: Preheat the griddle and distribute food or oil evenly.
3. Problem: The toaster oven is not heating.
   Solution: Ensure the BM-1107 is properly plugged in and reset the circuit breaker if necessary.
4. Problem: Crumbs remain in the toaster oven.
   Solution: Regularly clean the crumb tray and oven interior.

Guarantee

If this product is found to be faulty as a result of faulty materials or workmanship within one year from the date of purchase, it will be repaired free of charge. The warranty after repair will not be extended beyond the original one-year period.

What is NOT COVERED

• Warranty does not include freight charges.

• Incidental or consequential damage caused by possible defects with this product.

• Damage to product caused by improper power supply voltage, accident, fire, floods or acts of nature

Pros & Cons

• Pro: Space-saving 3-in-1 design
• Pro: Non-stick griddle for easy cooking and cleanup
• Pro: Dishwasher-safe removable parts
• Pro: Temperature control for toaster oven
• Con: Limited coffee maker capacity (4 cups)
• Con: Griddle may require frequent cleaning due to oil splatter

Customer Reviews

Customers appreciate the BM-1107's versatility and convenience, with most praising its ability to simplify their morning routines. Common complaints include the small coffee maker capacity and the griddle's tendency to splatter oil during use.
