EcoFlow RIVER 2 Pro Power Station

Introducing the EcoFlow is a versatile and portable energy solution designed for outdoor adventures and emergency backup. With a substantial capacity of 768Wh and an output of 800W, it can power most small appliances and devices, making it ideal for camping or home use. The unit features rapid charging capabilities, reaching full capacity in just 70 minutes. Priced at approximately $599, it offers a reliable and eco-friendly power source wherever you go.

What's in the Box

Detailed Specifications

General Information
Model	EFR620
Weight	Approximately 7.8kg(17.2lbs)
Dimension	270 x 260 x 226mm(10.6 x 10.2 x 8.9inches)
Capacity	768Wh (40Ah 19.2V )
Wi-Fi(2.4G)	Frequency range : 20M: 2412-2472MHz/40M: 2422-2462MHz Maximum output power : 14.82dBm
Bluetooth	Frequency range : 2402-2480MHz Maximum output power : 4.27dBm
Input Specifications
AC Input	220V-240V~50Hz/60Hz, 8A Max
Car Charging Input	12V/24V 8A, 100W Max
Solar Charging Input	11-50V 13A, 220W Max
USB-C Input	5/9/12/15/20V 5A, 100W Max
Output Specifications
USB-C Output	5/9/12/15/20V 5A, 100W Max
USB-A Output	5V 2.4A 12W Max per port
DC Output	12.6V 10A/3A/3A, 126W Max
AC Output	Pure sine wave,800W total (1600WPeak) 230V~50Hz/60Hz*
Battery Specifications
Cell Material	LFP battery
Cycle Life	80%+ capacity after 3000 cycles
Operating Temperature
Optimal Ambient Temperature for Operation	20°C~30°C(68°F to 86°F)
Ambient Temperature for Discharging	-10°C~45°C(14°F to 113°F)
Ambient Temperature for Charging	0°C~45°C(32°F to 113°F)
Ambient Temperature for Storage	-10°C~45°C (optimal: 20°C~30°C) 14°F to 113°F (optimal: 68°F to 86°F)

Product Details

Overview

AC output switch
Main power switch
Power indicator
USB-A port
USB-C port
LCD
Car charger outlet
DC5521 output port (x2)
DC output switch
AC output socket
X-Stream AC charging input port
Solar/Car charging input port
Fan (do not block)

LCD Screen

Remaining battery
Remaining charge/discharge time
AC output
USB-A output
High temperature warning
Fan indicator
Bluetooth connection status
Wi-Fi status
Discharge/Recharge level limitation
Input power
Output power
Car output
USB-C output
Low Temperature warning
Overload Warning

Description

The EcoFlow RIVER 2 Pro Power Station boasts a robust design with a durable outer casing, ensuring it withstands various environmental conditions. It features an intuitive LCD display that provides real-time information on battery level, output power, and charging status. The unit also includes multiple safety features such as overcharge protection, short-circuit protection, and thermal management to ensure safe operation.

The RIVER 2 Pro is highly portable due to its compact size and carry handle, making it easy to transport to camping sites or other off-grid locations. Its expandable capacity allows users to add an additional battery pack for extended power needs.

Power On/Off

Press the main power button once to turn on the product, then the LCD screen lights up and the main power indicator becomes breathing white; press and hold the main power button (for about 3 seconds) to turn off the product, meanwhile, the LCD screen also goes off.

After the product is turned on, press the main power button once to turn off the LCD screen.
If the product is not used for 5 minutes, it will enter hibernation state with the LCD screen gone off.
When RIVER 2 Pro is charging, it can't be turned off by pressing and holding the main power button unless the charging cable is unplugged first.

Charge Your Devices

The USB-A and USB-C output ports are automatically turned on once the product is turned on. Press the "DC output switch" or "AC output switch" once to turn on their corresponding DC/AC output sockets; press again to turn them off.

When using the AC output socket, make sure that the sum power of all loaded devices is less than the rated power.

Charge RIVER 2 Pro

AC Charging (Grid Charging)

For AC charging, we recommend that you use a power socket with a capacity of more than 10A and ensure that the working current of the socket is constantly greater than 10A.
For AC charging, please use the AC charging cable included in the package and plug the cable directly into a wall outlet instead of an extension socket.

Solar Charging

The solar charging cable (MC4-XT60 adapter cable) and the solar panel are supplied separately.
When using an EcoFlow solar panel to charge the product, connect them according to the instructions in the user manual.
Before connecting the solar panel, ensure that the output voltage of the solar panel is less than 50 V to avoid product damage.

Car Charging

You can recharge the product through the car power outlet. The product supports 12V/24V car chargers and a maximum charging current of 8A. Please charge using the car charger after the car is started to avoid failure to start due to insufficient car battery. In addition, please make sure that the car power outlet is securely connected to the cigarette lighter of the car charger input cable. EcoFlow takes no responsibilities for any loss or damage caused by failure to follow instructions.

USB-C charging

NOTE: The USB-C charging cable (Type-C plug) and adapter are supplied separately.

Additional Features

X-Boost

The product supports X-Boost. It can power devices rated at up to 1600W without incurring operation failure due to overload protection. Observe the following tips when using the X-Boost feature:

The X-Boost feature is not suitable for appliances with voltage protection (such as precise instruments).
It is suitable for heating and motor devices. Please conduct your own tests to check whether your devices support X-Boost.

EPS

The product supports emergency power supply (EPS). When you connect the grid power to the AC input port of the product through an AC cable, you can power electrical devices through the AC output port (AC power will come from the grid instead of the power station in this situation). In case of a sudden blackout, the product can automatically switch to the battery-powered supply mode within 30ms.

As a basic UPS feature, the EPS does not support 0ms switching. Please do not connect the product to any device that requires 0ms UPS (such as data servers and workstations). Please test and confirm the compatibility before using the product. We recommend that you charge only one device (with maximum power <1000W and AC input ≥110V) at a time and do not use multiple ones at the same time to avoid triggering overload protection. EcoFlow takes no responsibilities for any device failure or data loss caused by failure to follow instructions.

Setup Guide

To set up the EcoFlow RIVER 2 Pro Power Station, follow these steps:

Unbox the unit and inspect for any damage.
Charge the battery fully before first use using the provided AC charger.
Connect your devices to the appropriate output ports (AC, DC, USB).
If using solar panels, connect them to the DC input port.
Monitor the LCD display for status updates.

Safety Instructions

WARNING – When using this product, basic precautions should always be followed, including the following:

Usage

Do not use the product near a heat source, such as a fire source or a heating furnace.
When using the product, please strictly follow the operating environment temperature specified in this user manual. If the temperature is too high, it may result in a fire or explosion; if the temperature is too low, the product performance may be severely reduced, or the product may cease to work.
If this product accidentally catches fire, we recommend that you use the fire extinguishers in the following order: Water or water mist, sand, fire blanket, dry powder, and carbon dioxide fire extinguishers.
Do not allow this product to come into contact with any liquid. Do not use this product in the rain or high humidity.
It is recommended that you use moisture barrier bags in humid environments (for example, places by the sea or waterways) to prevent the product from getting soaked.
If water is found inside the product, or the product is accidentally dropped into water, it must not be used or turned on again. Please place it in a safe open area, and stay away from it until it is completely dry. Please do not approach the product before it is dry. Please take anti-electric shock measures before touching the product. The dried product should not be used or discarded at will. Please properly dispose of it after contacting Customer Service.
Use a dry cloth to clean off dirt on the product ports.
Do not use this product in an environment with strong static electricity or strong magnetic field.
Do not stack any heavy objects on the product.
Store the product in a dry and ventilated place.
Keep this product out of reach of children and pets.
Do not place the battery under extremely low air pressure, otherwise events like explosion or leakage of flammable liquid or gas may occur.
Do not disassemble or puncture this product in any way with sharp objects.
Do not block the fan forcibly during use.
Do not touch the product port with wires or other metal objects to avoid short circuit or other risks.
When using or transporting this product, please avoid shocks, drops and violent vibrations. In case of severe external shock, please stop using this product immediately and turn off the power.
Do not use unofficial components or accessories as this will void the warranty. Consult official EcoFlow channels if you need to replace any component or accessory.
This product is not recommended for powering medical emergency equipment related to personal safety, including but not limited to medical grade ventilators (hospital version CPAP: Continuous Positive Airway Pressure), artificial lungs (ECMO: Extracorporeal Membrane Oxygenation). It can normally work with a home ventilator (home version CPAP), and does not have to be continuously monitored by professionals. Please follow your doctor's instructions and consult with the manufacturer for restrictions on the use of the equipment. If it is used for general medical equipment, please be sure to monitor the power status to ensure that the power does not run out.
When in use, power supply products will inevitably generate electromagnetic fields, which are likely to affect the normal operation of medical implants or personal medical equipment such as pacemakers, cochlear implants, hearing aids, defibrillators etc. If these types of medical equipment are being used, please contact the manufacturer to inquire about any restrictions on the use of such equipment. These measures are fundamental to ensure a safe distance between the medical implants (for example, pacemakers, cochlear implants, hearing aids, defibrillators, etc.) and this product while in use.
When the power supply is connected in the normal mode to a refrigerator, the power supply may be automatically shut down due to the power fluctuation property of the refrigerator. If the refrigerator stores medicines, vaccines or other high-value items, it is highly recommended that you set the AC output to "Never Turn Off" through the APP when connecting the power supply product to ensure continuous power supply. Users should pay attention to the power consumption of the power supply.
Do not put fingers or hands into the product.
To reduce risk of damage to the electric plug and cord, pull the plug rather than the cord when disconnecting the power pack.
Do not operate the power pack with a damaged cord or plug, or a damaged output cable.
To reduce the risk of electric shock, unplug the power pack form the outlet before attempting any instructed servicing.
Have servicing performed by a qualified repair person using only identical replacement parts. This will ensure that the safety of the product is maintained.
Do not use a battery pack or appliance that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in fire, explosion or risk of injury.
Users not to place the product on the floor, or at a height less than 457 mm (18 inches) above the floor, during use in a repair facility.
For long-term storage, please discharge the product every three months (firstly discharge it to 0%, then recharge it to 60%); the product will not be covered by the warranty if it is not charged or discharged for more than 6 months.

Disposal Guide

Whenever possible, please completely discharge the battery of this product before placing the product in the designated battery recycling bin. This product contains batteries. Batteries are hazardous chemicals and should not be disposed of in ordinary trash cans. For details, please follow local laws and regulations on battery recycling and disposal.
If the battery cannot be completely discharged due to the failure of the product itself, please do not dispose of the battery directly in the battery recycling bin, and contact a professional battery recycling company for further processing.
The battery will not start after over-discharge, please dispose of it.

Grounding Instructions

This product must be grounded. When charging it should malfunction or break down, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a power cord that has an equipment grounding conductor and a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded in accordance with all local codes ordinances.
Improper connection of the equipment grounding conductor is able to result in a risk of electric shock. Check with a qualified electrician if you are in doubt as to whether the product is properly grounded. Do not modify the plug provided with the product – if it will not fit the outlet, have a proper outlet installed by a qualified electrician.

SAVE THESE INSTRUCTIONS

Care and Maintenance

For safety, please do not store the product in an environment temperature higher than 45°C or lower than -10°C for a long time.
For long-term storage, please recharge the product every three months (firstly discharge it to 0%, then recharge it to 60%). The product will not be covered by the warranty if it is not charged or discharged for more than 6 months.
If the product has been idle for too long and the battery is severely low, it will enter a deep sleep protection mode. In such case, please charge the product before using it again.

Troubleshooting

If a warning is prompted during the use of the product and the warning icon persists after restart, please stop using the product immediately (do not attempt to charge or discharge it). For problems not covered in the preceding table, please consult EcoFlow customer service.

EcoFlow RIVER 2 Pro Power Station Pros & Cons

Pros

High Capacity: Offers ample power for multiple devices.
Expandable Battery: Allows for increased capacity with an additional battery pack.
Fast Charging: Supports rapid charging via AC and solar panels.
Portable Design: Compact size with a carry handle for easy transport.

Cons

Weight: Although portable, it can be heavy for some users.
Cost: While affordable compared to some competitors, it may still be out of budget for casual users.
No Built-in Wheels: Requires manual lifting for transport over long distances.

Customer Reviews

Customers have praised the RIVER 2 Pro for its reliability and performance in off-grid scenarios. Many have appreciated its ease of use and fast charging capabilities. However, some users have noted that while it is portable, it can be cumbersome to carry over long distances due to its weight.
