Bottom Freezer Refrigerator Introduction

The Kenmore Bottom Freezer Refrigerator 111.7302 is designed to provide efficient food storage and organization for modern kitchens. Featuring a spacious bottom freezer layout, it allows easy access to fresh foods at eye level while keeping frozen items conveniently stored below. This refrigerator is equipped with adjustable shelves and humidity-controlled crisper drawers to help maintain optimal freshness. With its sleek design and reliable performance, the Kenmore 111.7302 is an excellent choice for families. Priced at approximately $1,199, it offers great functionality and style.

Specifications

Capacity: 21.7 cu. ft.
Bottom Freezer Design
Adjustable Shelving and Baskets
Humidity-Controlled Crisper Drawers
Advanced Temperature Control System
Energy Star Certified
Ice Maker and Water Dispenser (optional)
LED Lighting Inside the Refrigerator

IMPORTANT SAFETY INSTRUCTIONS

BASIC SAFETY PRECAUTIONS
This guide contains many important safety messages. Always read and obey all safety messages.

NOTICE
This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others, or cause damage to the product. All safety messages will be preceded by the safety alert symbol and the hazard signal word DANGER, WARNING or CAUTION. These words mean:

DANGER
You will be killed or seriously injured if you do not follow instructions.
WARNING
You can be killed or seriously injured if you do not follow instructions.
CAUTION
Indicates an imminently hazardous situation which, if not avoided, may result in minor or moderate injury, or product damage.

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

WARNING

To reduce the risk of ﬁre, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following.

Read all instructions before using this appliance.

NEVER unplug your refrigerator by pulling on the power cord. Always grip the plug ﬁrmly and pull it straight out from the outlet.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualiﬁed person in order to avoid a hazard. Do not use a cord that shows cracks or abrasion damage along its length or at either the plug or connector end.
Do not modify or extend the power cord length. It could cause electric shock or ﬁre.
When moving your refrigerator away from the wall, be careful not to roll over or damage the power cord.
NEVER unplug your refrigerator by pulling on the power cord. Always grip the plug ﬁrmly and pull it straight out from the outlet.
If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualiﬁed person in order to avoid a hazard. Do not use a cord that shows cracks or abrasion damage along its length or at either the plug or connector end.
Do not modify or extend the power cord length. It could cause electric shock or ﬁre.
When moving your refrigerator away from the wall, be careful not to roll over or damage the power cord.

NOTE: It is strongly recommended that any service be performed by a qualiﬁed technician.

PARTS AND FEATURES

* This instruction manual refers to several models. Features may vary according to model.

Covered Dairy Bin or Covered Storage Bin for storing butter and cheese.
Gallon door storage bin for items of medium to large size.
Low proﬁle door storage bin for items of medium to large size.
Ice maker for making ice.
Adjustable glass shelf for items of medium to large size.
Humidity controlled Crisper Bin for storage of fruits and vegetables
Full width pantry drawer for storage of miscellaneous small items
Pull out freezer drawer
Lower freezer basket for general freezer storage
Control and display panel
Ice storage bin

REFRIGERATOR INSTALLATION

WARNING

Excessive Weight Hazard: Use two or more people to move and install the refrigerator. Failure to do so can result in back or other injury.

Description

The Kenmore Bottom Freezer Refrigerator 111.7302 is designed with functionality and style in mind. The exterior features a stainless steel finish that resists fingerprints and smudges, while the interior boasts LED lighting to illuminate your food and drinks. The adjustable shelving and baskets allow for customizable storage, ensuring that you can organize your groceries efficiently.

The humidity-controlled crisper drawers help maintain optimal freshness for fruits and vegetables, and the advanced temperature control system ensures consistent cooling throughout the refrigerator. The bottom freezer compartment is spacious and features a pull-out drawer for easy access to frozen foods.

UNPACKING YOUR REFRIGERATOR

Remove tape and any temporary labels from your refrigerator before using. Do not remove any warning- type labels, the model and serial number label, or
the Tech Sheet that is located under the front of the refrigerator.
To remove any remaining tape or glue, rub the area briskly with your thumb. Tape or glue residue can also be easily removed by rubbing a small amount of liquid dish soap over the adhesive with your ﬁngers. Wipe with warm water and dry.
Do not use sharp instruments, rubbing alcohol, ﬂammable ﬂuids, or abrasive cleaners to remove tape or glue. These products can damage the surface of your refrigerator.
Refrigerator shelves are installed in the shipping position. Please reinstall shelves according to your individual storage needs.

WARNING

Excessive Weight Hazard:
Your refrigerator is heavy. When moving the refrigerator for cleaning or service, be sure to protect the ﬂoor. Always pull the refrigerator straight out when moving it. Do not wiggle or walk the refrigerator when trying to move it, as ﬂoor damage could occur.

WARNING

Explosion Hazard:
Keep ﬂammable materials and vapors, such as gasoline, away from the refrigerator. Failure to do so can result in ﬁre, explosion, or death.

PRIOR TO USE

Clean your refrigerator thoroughly and wipe oﬀ all dust that accumulated during shipping.
Install accessories such as ice cube bin, drawers, shelves, etc., in their proper places. They are packed together to prevent possible damage during shipment.
Allow your refrigerator to run for at least two to three hours before putting food in it. Check the ﬂow of cold air in the freezer compartment to ensure proper cooling. Your refrigerator is now ready for use.

INSTALLATION
The refrigerator should always be plugged into its own individual properly grounded electrical outlet rated for 115 Volts, 60 Hz, AC only, and fused at 15 or 20 amperes. This provides the best performance and also prevents overloading house wiring circuits which could cause a ﬁre hazard from overheated wires. It is recommended that a separate circuit serving only this appliance be provided.

WARNING

Shock Hazard: To reduce the risk of electric shock, do not install the refrigerator in a wet or damp area.

To avoid noise and vibration, the unit must be leveled and installed on a solidly constructed ﬂoor. If required, adjust the leveling legs to compensate for unevenness of the ﬂoor. The front should be slightly higher than the rear to aid in door closing. Leveling legs can be turned easily by tipping the cabinet slightly. Turn the leveling legs to the left to raise the unit or to the right to lower it. (See Leveling and door AlIgnment.)
NOTE: Installing on carpeting, soft tile surfaces, a platform or weakly supported structure is not recommended.
Install this appliance in an area where the temperature is between 55°F (13°C) and 110°F (43°C). If the temperature around the appliance is too low or high, cooling ability may be adversely aﬀected.
Select a place where a water supply can be easily connected for the automatic icemaker.
NOTE: The water pressure must be from 30 to 125 psi or 207-862 kPa or 2.1-8.8 kgf/cm². If the refrigerator is installed in an area with low water pressure below 30 psi, you can install a booster pump to compensate for the low pressure.
Too small of a distance from adjacent items may result in lowered freezing capability and increased electricity consumption charges. Allow at least 2 inch (5 cm) between the back of the refrigerator and the wall.

NOTE: Removing the doors is always recommended when it is necessary to move the refrigerator through a narrow opening. If it is necessary to remove the handles, follow the directions below.

HOW TO REMOVE REFRIGERATOR DOOR HANDLE

NOTE: Handle appearance may vary from the illustrations on this page.

Removing Refrigerator Handle
Loosen the set screws with the 2.5mm hex key provided and remove the handle.

HOW TO REPLACE REFRIGERATOR DOOR HANDLE

NOTE: Handle appearance may vary from the illustrations on this page.

Removing Refrigerator Handle
Place the handle on the door by ﬁtting the handle footprints over the mounting fasteners and tightening the set screws with a hex key.

how_to_replace_refrigerator_door_handle_kenmore_bottom_freezer_refrigerator_111.7302.png

NOTE: Removing the doors is always recommended when it is necessary to move the refrigerator through a narrow opening. If it is necessary to remove the handles, follow the directions below.

HOW TO REMOVE FREEZER DOOR HANDLE

NOTE: Handle appearance may vary from the illustrations on this page.

Removing Freezer Drawer Handle
Loosen the set screws located on the lower side of the handle with the hex key provided and remove the handle.

HOW TO REPLACE FREEZER DOOR HANDLE
NOTE: Handle appearance may vary from the illustrations on this page.

Replacing Freezer Drawer Handle
Place the handle on the door by ﬁtting the handle footprints over the mounting fasteners and tightening the set screws with a hex key.

WARNING

When assembling or disassembling the handles:

Grasp the handle ﬁrmly to ensure it will not drop or cause injury.
Prevent the handle from swinging toward nearby people or animals.
Insert the handle footprints over the door mounting fasteners and tighten the hex screws to ﬁx the handle in place.
Check for any gap between the door and handle after the handle is ﬁxed in place.

REMOVING AND REPLACING REFRIGERATOR DOORS

WARNING

Risk of electric shock!

Before removing top hinge cover
Shut off the water supply to the appliance.
Unplug the appliance or switch off power from the breaker or fuse panel.

To remove the left refrigerator door:

Remove top hinge cover using a phillips type screwdriver by removing 5 screws
Remove the grounding wire screw and pull out the grounding wire (green with yellow stripe). Disconnect the main wire harness (blue and yellow wires).
Using a large phillips screwdriver, turn top hinge fastener counterclockwise to remove the top hinge plate.
CAUTION: After the hinge is removed, the door can fall down forward. Hold the door to prevent it from falling.
Lift the door from the middle hinge pin and remove the door. Place the door, inside facing up, on a nonscratch surface.

To remove the right refrigerator door:

Remove top hinge cover using a phillips type screwdriver by removing 5 screws.
Using a large phillips screwdriver, turn top hinge fastener counterclockwise to remove the top hinge/ plate.
CAUTION: After the hinge is removed, the door can fall down forward. Please secure door during this process.
Lift the door from the middle hinge pin and remove the door. Place the door, inside facing up, on a nonscratch surface.

Reinstalling the Left Refrigerator Door

Lower the door onto the middle hinge.
Fit the top hinge over the mounting holes and align to proper position before tightening. Turn top hinge screw clockwise to secure the hinge. Insert the ground wire screw and tighten the ground wire (green with yellow stripe) securely beneath it. Reconnect the main wire harness (blue and yellow wires).
Screw top hinge cover into place with a screwdriver.

Reinstalling the Right Refrigerator Door

Lower the door onto the middle hinge.
Fit the top hinge over the mounting holes and align to the proper position before tightening.
Turn the top hinge fastener clockwise to secure the hinge.
Screw the top hinge cover into place with a screwdriver.

HOW TO REMOVE THE FREEZER DRAWER

WARNING: Use two or more people to remove and install the freezer drawer. Failure to do so can result in personal injury, product or property damage.

Take out the ice bin first, and then take out the upper freezer drawer by lifting it up.
Remove lower freezer basket by pulling up and tilting toward refrigerator until it can be removed from the freezer drawer/door assembly.
Push the rail support locking tabs to release the main freezer drawer rails from the cabinet while slightly pulling the exterior freezer drawer outwards, so that the locking tab does not return to the locked position. The locking tabs are located in the freezer compartment to the rear of the main rail assembly (which is attached to main exterior freezer drawer) as shown in the illustration below.
Pull exterior freezer drawer to fully disengage the rail assembly from the unit. Use 2 people for this task as the door is heavy and awkward to handle.
CAUTION: Do not hold the handle when removing or replacing the drawer. The handle may come off and it could cause personal injury.
Place the door on a non-scratch surface.

HOW TO INSTALL THE FREEZER DRAWER

Using 2 people (recommended), align end of the exterior drawer rails to the lower rail guides located on the sidewalls of the freezer compartment. Make sure the gear teeth are engaged to the gear rail the same amount on both sides.
Fully push in and close freezer drawer to engage rails with rail support locking tab, applying a bit of pressure after the door is closed to seat the tabs to the rail.
CAUTION: Make sure the tabs are completely engaged to the rail or the refrigerator drawer could be pulled out of the refrigerator by the customer. Fully open the freezer door to check and see if the locking tabs are fully engaged. If they are not engaged, gently push each freezer rail with a flat head screwdriver towards the freezer compartment until the locking tabs snap to the locked position.
Replace the lower freezer drawer basket
Insert the upper freezer drawer above the lower basket, and replace ice bin.
Open and close the freezer drawer several times to make sure operation is smooth and seal is consistent all the way around the freezer compartment.

REFRIGERATOR LEVELING & DOOR ADJUSTMENT

The refrigerator must be level in order to maintain optimal performance and desirable front appearance.
(If the floor beneath the refrigerator is uneven, the freezer and refrigerator doors look unbalanced.)

Leveling Refrigerator

Fully open the freezer drawer and remove the freezer drawer basket to gain access to the lower toe guard fasteners.
Remove the lower toe guard using a Phillips screwdriver.
NOTE: Put screws in safe location so they are not lost.
Using the wrench provided, turn the leveling leg clockwise to lower and counterclockwise to raise the front corners of the refrigerator.
Install lower toe guard/grille using a Phillips screwdriver.
Install freezer drawer basket, then open and close the freezer drawer several times to make sure operation is smooth without hindrance.

Adjusting a refrigerator door
If the height of the refrigerator doors is uneven, turn the screw nut on the middle hinge to adjust the refrigerator door.

To raise a refrigerator door turn the screw counterclockwise.
To lower a refrigerator door turn the screw clockwise.

Adjusting the freezer drawer

If the freezer drawer is higher on one side than the other (not even):

Loosen the four side screws on the side where adjustment is needed.
Move the Stopper from ‘left picture position’ to ‘right picture position’.
Adjust the leveling by rotating the Position Knob.
(Pull and rotate the Position Knob)
After adjusting the leveling, tighten the four side screws

CONNECTING THE WATER LINE

This water line installation is not covered by the refrigerator warranty. Follow these instructions carefully to minimize the risk of expensive water damage.

Water hammer (water banging in the pipes) in house plumbing can cause damage to refrigerator parts and can lead to water leakage or ﬂooding. Call a qualiﬁed plumber to correct water hamme

CAUTION: To prevent burns and product damage, only connect the refrigerator water line to a cold water supply.

If you use your refrigerator before connecting the water line, make sure the icemaker is turned OFF at the control panel.

CAUTION: Do not install the icemaker tubing in areas where temperatures fall below freezing.

WATER PRESSURE
The water pressure must be from 30 to 125 psi or 207-862 kPa or 2.1-8.8 kgf/cm2. If the refrigerator is installed in an area with low water pressure “below 30 psi”, you can install a booster pump to compensate for the low pressure.

WATER SUPPLY KIT
* Connecting the water line to the refrigerator.


Parts that are not supplied are available from local service dealers.

Connect water line to the compression ﬁtting.
- If you are using copper tubing (not supplied), slip the compression nut (not supplied) and ferrule (not supplied) onto copper tubing.
- If you are using plastic tubing (not supplied), insert the molded ending of the plastic tubing into the compression ﬁtting.
Tighten the compression nut onto the compression ﬁtting.
Turn the water on and check for any leakage.

WARNING

To reduce the risk associated with ingestion of contaminants: Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before and after the system.

Setup Guide

To set up your Kenmore Bottom Freezer Refrigerator 111.7302,

Start by carefully unpacking the appliance and removing all packing materials.
Place the refrigerator on a level surface and ensure it has adequate ventilation around it.
Connect the water supply lines if you have opted for the ice maker and water dispenser features.
Plug in the refrigerator and allow it to cool down for a few hours before loading it with food.
Adjust the shelves and baskets to your desired configuration.

CARE AND CLEANING

Ice Storage Bin
Cleaning: Empty the ice cube bin and clean with lukewarm water. Thoroughly dry the bin and screw conveyor to prevent new ice cubes from sticking together.
Freezer & Refrigerator Bins
Hold both ends and pull up.
Refrigerator Shelves
To remove a shelf: Lift up on front of shelf with one hand and with other hand push up on back of shelf to release attachment hooks from attachment slots. Pull the shelf out.
To reinstall a shelf: With front of shelf angled slightly up, engage hooks on back of shelf into attachment slots, and then lower front of shelf into place.


CAUTION: Make sure that shelves are level from one side to the other. Failure to do so may result in the shelf falling or spilling food.

LIGHT BULB REPLACEMENT

WARNING: Electrical Shock Hazard

Before replacing a Compartment Lamp, either unplug the refrigerator or turn oﬀ power at the circuit breaker or fuse box.

NOTE: The refrigerator and freezer compartment lights have LED interior lighting, and service should be performed by a qualiﬁed technician.

POWER INTERRUPTIONS

If the power will be out for 24 hours or less, keep all refrigerator doors closed to help foods stay cold and frozen.
If the power will be out for more than 24 hours, remove all frozen food and store it in a frozen food locker.

WHEN YOU GO ON VACATION
If you choose to leave the refrigerator on while you are away, follow these steps to prepare your refrigerator before you leave.

Use up any perishables and freeze other items.
Turn oﬀ the icemaker and empty the ice bin.

If you choose to turn the refrigerator off before you leave, follow these steps.

Remove all food from the refrigerator.
Clean the refrigerator, wipe it and dry well.
Tape rubber or wood blocks to the tops of both doors to prop them open far enough for air to get in. This stops odor and mold from building up.

WHEN YOU MOVE
When you are moving your refrigerator to a new home, follow these steps to prepare it for the move.

Remove all food from the refrigerator and pack all frozen food in dry ice.
Unplug the refrigerator.
Clean, wipe and dry thoroughly.
Take out all removable parts, wrap them well and tape them together so they do not shift and rattle during the move. Refer to the Using your Refrigerator section for removing instructions.
Tape the doors shut and tape the power cord to the refrigerator cabinet.

TROUBLESHOOTING GUIDE

COOLING

Problem	Possible Causes	Solutions
Refrigeratorand Freezer section are not cooling.	Refrigerator is set to demo mode.	Demo Mode allows the lights and control display to work normally while disabling cooling to save energy while on the showroom floor. Refer to the Setting the Controls section for instructions on how to disable Demo Mode.
	Refrigerator is in the defrost cycle.	During the defrost cycle, the temperature of each compartment may raise slightly. Wait 30 minutes and confirm the proper temperature has been restored once the defrost cycle has completed.
	Refrigerator was recently installed.	It may takeup to 24 hours for each compartment to reach the desired temperature.
	Refrigerator was recently relocated.	If the refrigerator was stored for a longperiod of timeor moved on its side, it is necessary for the refrigerator to stand upright for 24 hours before connecting it to power.
Cooling System runs too much.	Refrigerator is replacing an older model.	Modern refrigerators require more operating time but use less energy due to more efficient technology.
	Refrigerator was recently plugged in orpower restored.	The refrigerator will take up to 24 hours to cool completely.
	Door opened often or a large amount of food / hot food was added.	Adding food and opening the door warms the refrigerator, requiring the compressor to run longer in order to cool the refrigerator back down. In order to conserve energy, try to get everything you need out of the refrigerator at once, keep food organized so it is easy to find, and close the door as soon as the food is removed. (Refer to the FoodStorage Guide.)
	Doors are not closed completely.	Firmly push thedoors shut. If they willnot shut allthe way, see the Doors will not close completely or pop open section in Parts & Features Troubleshooting.
	Refrigerator is installed in a hot location.	The compressor will run longer under warm conditions. At normal room temperatures (70°F) expect your compressor to run about 40% to 80% of the time. Under warmer conditions, expect it to run even more often. The refrigerator should not be operated above 110°F.
	Condenser / back cover is clogged.	Use a vacuum cleaner with an attachment to clean the condenser coverand vents. Do not removethe panel covering the condenser coil area.

Problem	Possible Causes	Solutions
Refrigerator or Freezer section is too warm.	Refrigerator was recently installed.	It may takeup to 24 hours for each compartment to reach the desired temperature.
	Doors are opened often or for long periods of time.	When the doors are opened often or for long periods of time, warm, humidair enters thecompartment. This raises the temperature and moisture levelwithin the compartment. To lessenthe effect, reducethe frequency and duration of door openings.
	Unit is installed in a hot location.	The refrigerator should not be operated in temperatures above 110F.
	A large amountof food or hot food was added to eithercompartment.	Adding food warms the compartment requiring the cooling system to run. Allowing hot food to cool to room temperature before putting it in the refrigerator will reduce this effect.
	Doors not closed correctly.	See the Doors will not close correctly or pop open section in Parts & Features Troubleshooting
	Temperature control is not set correctly.	If the temperature is too warm, adjust the control one increment at a time and wait for the temperature to stabilize. Refer to the Setting the Controls section for more information.
	Defrost cycle has recently completed.	During the defrost cycle, the temperature of each compartment mayraise slightly andcondensation may form on the backwall. Wait 30 minutes and confirm the proper temperature has beenrestored once the defrost cyclehas completed.
Interior moisture buildup.	Doors are opened often or for long periods of time.	When the doors are opened oftenor for longperiods of time, warm,humid air entersthe compartment. This raises the temperature and moisture levelwithin the compartment. To lessen the effect, reducethe frequency and duration of door openings.
	Doors not closed correctly.	See the Doors will not close correctly section in the Troubleshooting section.
	Weather is humid.	Humid weather allowsadditional moisture to enter the compartments when the doorsare opened leadingto condensation or frost. Maintaining a reasonable level of humidity in the homewill help to control the amount of moisture that can enterthe compartments.
	Defrost cycle recently completed.	During the defrost cycle, the temperature of each compartment may raise slightly and condensation may form on the back wall. Wait 30 minutes and confirm that the proper temperature has been restored once the defrost cycle has completed.
	Food is not packaged correctly.	Food stored uncovered or unwrapped, and damp containers can lead to moisture accumulation within each compartment. Wipe all containers dry and store food in sealed packaging to prevent condensation and frost.

COOLING/ICE & WATER

Problem	Possible Causes	Solutions
Food is freezing in the refrigerator compartment.	Food with high water content was placed near an air vent.	Rearrange items with high water content away from air vents.
	Refrigerator temperature control is set incorrectly.	If the temperature is too cold, adjust the control one increment at a time and wait for the temperature to stabilize. Refer to the Setting the Controls section for more information.
	Refrigerator is installed in a cold location.	When the refrigerator is operated in temperature below 41°F (5°C), food can freeze in the refrigerator compartment. The refrigerator should not be operated in temperature below 55°F(13°C).
Frost or icecrystals form on frozenfood (outside of package).	Door is opened frequently or for long periods of time.	When the doors are opened often or for long periods of time, warm, humidair enters the compartment. This raises the temperature and moisture levelwithin the compartment. Increased moisture will leadto frost and condensation. To lessen the effect, reducethe frequency and duration of door openings.
	Door is not closing properly.	Refer to the Doors will not close correctly or pop open section in the Troubleshooting section.
Refrigerator or Freezer section is too cold.	Incorrect temperature control settings.	If the temperature is too cold, adjust the control one increment at a time and wait for the temperature to stabilize. Refer to the Setting the Controls section for more information.
Frost or ice crystals on frozen food (inside of sealed package).	Condensation from food with a high water content has frozen inside of the food package.	This is normal for food items with a high water content.
	Food has been left in the freezer for a long periodof time.	Do not store food items with high water content in the freezer for a long periodof time.
Icemaker is not making enoughice.	Demand exceeds ice storage capacity.	The ice maker will product approximately 50 to 70 cubes in a 24 hour period.
	House water supply is not connected, valve is not turned on fully, or valve is clogged.	Connect the refrigerator to a cold water supply with adequate pressure and turn the water shutoff valve fully open. If the problem persists, it may be necessary to contact a plumber.
	Low housewater supply pressure.	NOTE: The water pressure must be from 30 to 125 psi or 207-862 kPa or 2.1-8.8 kgf/cm². If the refrigerator is installed in an areawith low waterpressure below 30 psi, you can installa booster pump to compensate for the low pressure. If the problem persists, it may be necessary to contact a plumber or install a booster pump to compensate for the low pressure.
	Reverse Osmosis filtration system is used.	Reverse osmosis filtration systems can reduce the water pressure belowthe minimum amountand result in icemaker issues. (Refer to Water Pressure section.)
	Tubing connecting refrigerator to house supply valveis kinked.	The tubing cankink when the refrigerator is moved during installation or cleaning resulting in reduced water flow. Straighten or repair the water supply line and arrange it to prevent future kinks.

Problem	Possible Causes	Solutions
Icemaker is not making ice.	Refrigerator was recently installed or icemaker recently connected.	It may take up to 24 hours for each compartment to reach the desired temperature and for the icemaker to begin making ice.
	Icemaker not turnedon.	Locate the icemaker on/of button and confirm that it is turned ON.
	The refrigerator is not connected to a water supply or the supply shutoff valve is notturned on.	Connect refrigerator to the water supply and turn the water shutoff valve fully open.
	Icemaker shutoff (feeler arm) obstructed.	If your icemaker is equipped with an ice shutoff arm, make sure that the arm moves freely.
Ice has bad taste or odor.	Water supply contains minerals such as sulfur.	Awater filter mayneed to be installed to eliminate taste and odor problems. NOTE: In some cases, a filter may not help. It may not be possible to remove all minerals / odor / taste in all water supplies.
	Icemaker was recently installed.	Discard the first few batches of ice to avoid discolored or bad tasting ice.
	Ice has been stored for too long.	Ice that has been stored for too long will shrink, become cloudy, and may develop a stale taste. Throw away old ice and make a new supply.
	The food has not been stored properly in either compartment.	Rewrap the food.Odors may migrate to the ice if foodis not wrapped properly.
	The interior of the refrigerator needs to be cleaned.	See the Care and Cleaning section for more information.
	The ice storagebin needs to be cleaned.	Empty and wash the bin (discard old cubes). Make sure that the bin is completely dry before reinstalling it.
Icemaker is making too much ice.	Icemaker shutoff (feeler arm)is obstructed.	Empty the ice bin. If your icemaker is equipped with an ice shutoff arm, make sure that the arm moves freely. Reinstall the ice bin and wait 24 hours to confirm properoperation.

NOISE

Problem	Possible Causes	Solutions
Clicking	The defrost control will click when the automatic defrost cycle begins and ends. The thermostat control (or refrigerator control on some models) will also click when cycling on and off.	Normal Operation
Rattling	Rattling noises may come fromthe flow of refrigerant, the water lineon the back of the unit,or items stored on top of or around the refrigerator.	Normal Operation
	Refrigerator is not resting solidly on the floor.	Floor is weak or uneven or leveling legs need to be adjusted. See the Door Alignment section.
	Refrigerator with linear compressor was jarred whilerunning.	Normal Operation
Whooshing	Evaporator fan motor is circulating air through the refrigerator and freezer compartments.	Normal Operation
Whooshing	Air is being forced over the condenser by the condenser fan.	Normal Operation
Gurgling	Refrigerant flowing through the cooling system.	Normal Operation
Popping	Contraction and expansion of the inside walls due to changes in temperature.	Normal Operation
Sizzling	Water dripping on the defrostheater during a defrost cycle.	Normal Operation
Vibrating	If the side or back of the refrigerator is touching a cabinet or wall, some of the normal vibrations may make an audible sound.	To eliminate thenoise, make surethat the sidesand back cannot vibrate against any wall or cabinet.
Dripping	Water running intothe drain pan during thedefrost cycle.	Normal Operation
Pulsating or High- Pitched Sound	Your refrigerator is designed to run more efficiently to keep yourfood items at the desired temperature. The high efficiency compressor may cause your new refrigerator to run longer than your old one, but it is still more energy efficient than previous models. While the refrigerator is running, it is normal to hear a pulsating or highpitched sound.	Normal Operation

PARTS & FEATURES

Problem	Possible Causes	Solutions
Doors will not close correctly or pop open.	Food packages are blocking the door open.	Rearrange food containers to clear the door and door shelves.
	Ice bin, crisper cover, pans, shelves, door bins, or baskets are out of position.	Push bins all the way in and put crisper cover, pans, shelves and basketsinto their correctpositions. See the Using Your Refrigerator section for more information.
	The doors were removed during product installation and not properly replaced.	Remove and replacethe doors according to the Removing and Replacing Refrigerator Handles and Doors section.
	Refrigerator is not leveled properly.	See Door Alignment in the Refrigeration Installation section to level refrigerator.
Doors are difficult to open.	The gaskets are dirty or sticky.	Clean the gaskets and the surfaces that they touch. Rub a thin coat of appliance polish or kitchen wax on the gaskets after cleaning.
Doors are difficult to open.	Door was recently closed.	When you openthe door, warmer air enters the refrigerator. As the warm air cools, it can create a vacuum. If the door is hard to open, wait one minute to allow the air pressure to equalize, thensee if it opens more easily.
Refrigerator wobbles or seemsunstable.	Leveling legs are not adjusted properly.	Refer to the Leveling and Door Alignment section.
Refrigerator wobbles or seemsunstable.	Floor is not level.	It may be necessary to add shims under the leveling legs or rollers to complete installation.
Lights do not work.	LED interior lighting failure.	The refrigerator compartment lamp is LED interior lighting, and service should be performed by a qualified technician. Refer to the Light Bulb Replacement section.
The interior of the refrigerator is covered with dust or soot.	The refrigerator is located near a fire source, such as a fireplace, chimney or candle.	Make sure that the refrigerator is not located near a fire source, suchas a fireplace, chimney or candle.

KENMORE LIMITED WARRANTY

FOR ONE YEAR from the date of sale this appliance is warranted against defects in material or workmanship when it is correctly installed, operated and maintained according to all supplied instructions.

For warranty coverage details to obtain free repair or replacement, visit the web page: https://www.kenmore.com/warranty This warranty applies for only 90 DAYS if this appliance is ever used for other than private household purposes.

Pros & Cons

Pros:

Spacious Interior with Adjustable Shelving
Energy Efficient with Energy Star Certification
Advanced Temperature Control System
Humidity-Controlled Crisper Drawers
Sleek and Contemporary Design
Optional Ice Maker and Water Dispenser

Cons:

Potential Noise from Compressor and Fans
Higher Cost Compared to Basic Models
Some Users Report Issues with Ice Maker Reliability
Requires Regular Maintenance of Condenser Coils

Customer Reviews

Customers generally praise the Kenmore Bottom Freezer Refrigerator 111.7302 for its spacious interior, efficient cooling, and stylish design. However, some users have reported issues with the ice maker's reliability and occasional noise from the compressor and fans.

Many reviewers appreciate the adjustable shelving and humidity-controlled crisper drawers, which help in maintaining the freshness of groceries. Overall, it is considered a reliable and feature-rich appliance suitable for various household needs.

Search Manuals in: freezer-refrigerator

Read More

Read More
