Introduction

The Samsung French Door Refrigerator RF67VB combines modern design with advanced features to enhance your kitchen experience. With a spacious interior and flexible storage options, it allows for easy organization of groceries and beverages. The refrigerator includes a water and ice dispenser, ensuring chilled drinks at your fingertips. Energy-efficient and equipped with smart technology, it helps you monitor food freshness. The Samsung RF67VB is priced at approximately $2,199.00.

Names and basic functions

NAME OF EACH COMPONENT

Fridge Light
Door Bin
Glass Shelf
Vegetable & Fruit Drawer
Pull Out Drawer
Freezer Drawer Bin
Moving Tray (Location is adjustable)
Door Bin
Bottle Bin
Freezer Light

Detailed Specifications

The Samsung French Door Refrigerator RF67VB boasts several key features that make it a standout in its category:

Capacity: 36 cu. ft.
French door design with bottom freezer
Through-the-door ice and water dispensers
Adjustable shelves and storage bins
Multi-air flow technology for consistent cooling
Energy Star certified for energy efficiency
Twin Cooling Plus system to maintain optimal humidity levels
LED interior lighting for better visibility
Smart Home integration with Samsung SmartThings

Product Features

Surround Multi Flow
A center-positioned fan and ducts with multiple flow effluences provide uniform cooling for each shelf and fresh food compartment corners.


Twin Cooling System
The refrigerator and the freezer have two evaporators.
Given this independent system, the freezer and the refrigerator are cooled individually and more efficiently.
Food odor from the refrigerator does not affect food in the freezer due to separate air flow circulation.

Easy Handle System
The freezer door is more user-friendly and convenient.

Moving Tray
The Deli Drawer can be moved side to side for easier access.

Digital Display & Temperature Control
Digital Display & Temperature Control enable easy setting of your refrigerator.

Installation Space

Selecting the best location for the Refrigerator

A Location with easy access to the water supply.
A Location without direct exposure to sunlight.
A Location with level (or nearly level) flooring.
A Location with enough space for the Refrigerator doors to open easily.
Allow sufficient space for air circulation of the internal cooling system.
If the Refrigerator does not have enough space, the internal cooling system may not work properly.

First thing! Make sure that you can easily move your Refrigerator to its final location by measuring doorways (both width and height), thresholds, ceilings, stairways, etc.
The following chart details the exact height and depth of the Samsung French Door Refrigerator.

Model			RF62HE/RF62QE RF62UB/	RF67VB
Capacity (ℓ)			504.0	557.8
Dimension (mm)	Width (A)		817	817
	Depth	without door (B)	617	667
	Depth	with door (C)	774	824
	Height	without hinge (D)	1743	1743
		with hinge (E)	1772	1772
		with cover pcb panel (F)	1798	1798

Allow clearance to the right, left, back and top when installing.
This will help reduce power consumption and keep your energy bills lower.
If you install the Refrigerator where is below 10ºC, it may not function optimally.
Do not locate the refrigerator where the wet condition.

FLOORING

CAUTION
For proper installation, this refrigerator must be placed on a level surface of hard material that is the same height as the rest of the flooring. This surface should be strong enough to support a fully loaded refrigerator, or approximately 106kg. To protect the finish of the flooring, cut a large section of the cardboard carton and place under the refrigerator where you are working. When moving the refrigerator, be sure to pull it straight out and return it to position by pushing it straight in.

Description

The RF67VB features a sleek and modern exterior with a stainless steel finish, complementing any kitchen decor. The interior is equally impressive, with adjustable shelves and storage bins that allow for customizable storage solutions. The through-the-door ice and water dispenser is a convenient feature that eliminates the need to open the doors frequently, helping to maintain the internal temperature and reduce energy consumption.

The Twin Cooling Plus system ensures that both the refrigerator and freezer compartments maintain optimal temperature and humidity levels, keeping your food fresh for longer. Additionally, the multi-air flow technology distributes cold air evenly throughout the refrigerator, preventing hot spots and ensuring consistent cooling.

Operating your French Door Refrigerator

USING THE CONTROL PANEL

Ice Off Button
When the Ice Off Button is pressed, ice will not be produced. Use this function only when it is needed.
Power Freeze Button
Press this button to freeze food quickly.
(Power Freeze will last 72 hours.)
Freezer Button
Freezer temperature set button.
Press this button to set the Freezer temp between -14ºC and -22ºC.(At initial power on, the default setting is -19ºC.)
Fridge Button
Fridge temperature set button.
Press this button to set the Fridge temperature in 1ºC intervals between 7ºC and 1ºC.(At initial power on, the default setting is 3ºC.)
Power Cool Button
Press this button to cool the food in the fridge quickly.
(Power Cool will shut off when -4ºC is reached or after 2 and a half hours.
E.Saver Button
Press the Energy Saver button for better energy efficiency.
If water drops appear on the doors, turn the Energy Saver function off.

CONTROLLING THE TEMPERATURE

Setting the freezer temperature
If you want to control the freezer temperature, follow as below.

Press the Freezer Button (Refer to the picture)
The temperature can be set in 1ºC interval between -22ºC and -14ºC.

When selecting the temperature, the set temperature is displayed initially for 5 seconds, then the actual temperature is displayed.
( There may be slight difference between the set temperature and displayed actual temperature, but it will be corrected to the set temperature automatically.)

The Freezer temperature will change depending on the number of door openings, quantity of food, ambient temperature, etc.
The temperature display will blink when freezer temperature increases due to frequent door opening, keeping warm food, etc.
( Blinking will stop when the refrigerator reaches normal temperature.
If for some reason it does not stop after a long period of time, contact a Samsung service center.)

Setting the fridge temperature
If you want to control the fridge temperature, follow as below.

Press the Fridge Button (Refer the picture)
The temperature can be set in 1ºC interval between 1ºC and 7ºC.

When selecting the fridge temperature, the set temperature is displayed initially for 5 seconds, then the actual temperature is displayed.
( There may be slight difference between the set temperature and displayed actual temperature, but it will be corrected to the set temperature automatically.)

The Fridge temperature will change depending on the number of door openings, quantity of food, ambient temperature, etc.
Temperature of each shelf or container in the fridge may be different.
The temperature display will blink when fridge temperature increases due to frequent door opening, keeping warm food, etc.
( Blinking will stop when the refrigerator reaches normal temperature.
If for some reason it does not stop after a long period of time, contact a Samsung service center.)

If you want to make ice faster (controlling the Power Freeze)

Press the Power Freeze Button. (Refer to the picture.)
The Power Freeze light on the display comes on (see the arrow mark) and this function begins to operate regardless of the set freezer temperature.
Press the Power Freeze Button again to cancel this function.
The light goes off and it operates at the set freezer temperature again.

TIP: The Power Freeze function operates for 72 hours regardless of the set temperature.

If you want to speed up the cooling in the Fridge (Power Cool)

Press the Power Cool Button. (Refer to the picture.)
The Power cool light on the display comes on (see the arrow mark) and this function begins to operate regardless of the set fridge temperature.
Press the Power Cool Button again to cancel this function.
The light goes off and it operates at the set fridge temperature again.

TIP: The Power Cool function operates for 2 and a half hours regardless of the set temperature.

Exhibition Mode (“OF & OF” code on the display)

TIP: This function is for store display refrigerators. It is not for customer use.

In Exhibition Mode, the refrigerator works but doesn’t make cool air. To cancel this mode, press the Power Freeze and Freezer buttons at the same time for 3 seconds until a “Ding-dong” sound is heard. The unit will now cool.

Setup Guide

To set up your Samsung French Door Refrigerator RF67VB, follow these steps:

Unpack the refrigerator carefully and remove all packaging materials.
Place the refrigerator in its designated location, ensuring it is level and stable.
Connect the water supply lines to the ice maker and water dispenser if applicable.
Plug in the refrigerator and allow it to cool down for a few hours before loading food.
Configure the shelves and storage bins according to your needs.
Pair the refrigerator with your Samsung SmartThings app for smart home integration if desired.

Troubleshooting

proBlEM	SolUTion
The refrigerator does not work at all or it does not chill sufficiently.	• Check that the power plug is properly connected. • Is the temperature control on the display panel set to the correct temperature? Try setting it to a lower temperature. • Is the Refrigerator in direct sunlight or located near a heat source? • Is the back of the Refrigerator so close to the wall that air cannot keep circulating? (Refer to page 10 for the best location.)
The food in the refrigerator is frozen.	• Is the temperature control on the display set to the correct temperature? Try setting it to a warmer temperature. • Is the temperature in the room too low? • Did you store the food too close to the air vent at the back of the Refrigerator? Move the food away from the air vent.
You hear sounds.	• Check that the Refrigerator is level and stable. • Is the back of the Refrigerator too close to the wall and therefore keeping air from circulating? • Was anything dropped behind or under the Refrigerator? • A “ticking” sound is heard from inside the Refrigerator. It is normal and occurs because various accessories are contracting or expanding according to the temperature of the Refrigerator interior.
The front corners and vertical hinged section of the appliance are hot and condensation is occurring.	• Some heat is normal as anti-condensators are installed in the vertical hinged section of the Refrigerator to prevent condensation. • Is the Refrigerator door ajar? Condensation can occur when you leave the door open for a long time.
Ice Maker is not producing ice.	• Did you wait for 12 hours after installation of the water supply line before making ice? • Is the water line connected and the shut-off valve opened? • Did you manually stop the ice making function? • Is the Freezer temperature too warm? Try setting the Freezer temperature lower.
You hear water bubbling in the refrigerator.	• This is normal. The bubbling comes from the Refrigerator coolant liquid circulating through the Refrigerator.
There is a bad smell in the refrigerator.	• Check for spoiled food. • Foods with strong odors(for example, fish) should be tightly covered. • Clean out your Freezer periodically and throw away any spoiled or suspicious food.
Frost forms on the walls of the Freezer.	• Is the air vent blocked? Remove any obstructions so air can circulate freely. • Allow sufficient space between the foods stored for efficient air circulation. • Is the Freezer drawer closed properly?
Water dispenser is not functioning. (Water dispenser models only)	• Is the water line connected and the shut-off valve opened? • Has the water supply line tubing been crushed or kinked? Make sure the tubing is free and clear of any obstruction. • Is the water tank frozen because the Refrigerator temperature is too low? Try selecting a warmer setting on the main display panel.

Pros & Cons

Pros

Spacious interior with customizable storage solutions
Advanced cooling technology for consistent temperatures
Energy-efficient design with Energy Star certification
Convenient through-the-door ice and water dispensers
Sleek and modern design that complements any kitchen
Smart Home integration capabilities

Cons

Higher price point compared to other models
Some users report issues with the ice maker and water dispenser
Requires regular maintenance to ensure optimal performance

Customer Reviews

Customers have generally praised the Samsung French Door Refrigerator RF67VB for its spacious interior, advanced cooling features, and sleek design. However, some users have reported issues with the ice maker and water dispenser, such as occasional clogs or slow dispensing. Despite these minor complaints, the overall consensus is that this refrigerator offers excellent value for its price.

Common complaints include

Icemaker issues such as clogs or slow production
Noise from the compressor or ice maker
Higher than expected energy consumption in some cases
