Introduction of Tata Viva Silver Water Purifier

Introducing the Tata Viva Silver Water Purifier, a cutting-edge solution for all your water purification needs. This state-of-the-art purifier is designed to provide you with clean, safe, and great-tasting drinking water. With its sleek and modern design, the Tata Viva Silver Water Purifier is the perfect addition to any kitchen or office space. The estimated price of this product is around INR 12,000 to INR 15,000, and it is expected to be launched in the market soon.

Tata Pack Contents

Tata Swach VIVA UV+ UF Water Purifier
User Manual
Installation Accessories
- 2 Self Tapping Screws
- 2 Plastic Anchor Plugs
- Flexible Pipe, 1/4″ OD
- Kitchen Faucet Adaptor ( KFA)

Water Purifier Specifications

Product TATA SWACH VIVA SILVER UV+ UF
Application Suitable for purification of tap water up to 500 ppm TDS and hardness below 500 ppm
Purification Capacity Up to 30 Uhr**
Body Material ABS
Type Wall Mounted
Dimensions (H x W x D in mm) 440 X 392 X 240
Inlet Water Pressure Minimum – 5 psi, Maximum – 35 psi
Inlet Water Temperature 2° c to 38° C
Stages Sediment, Pre-Carbon, UV Lamp, UF Membrane
Weight 6.5 kgs
Tank Volume 6 Liters
UV Lamp Wattage llW
UF Membrane 0.01 micron
Mains Voltage 160-270V A C
Power Consumption 22W

Dear Customer,

Congratulations for bringing home the new Tata Swach Viva Silver UV+ UF !

Being the health minister of your home it is your conscientiousness to safeguard yourfamilyfrom water-borne diseases. The new Tata Swach Viva Silver UV + UF Water Purifier includes the advanced UV+UF technology and Silver Action Inside which acts as a shield of purity. Its advanced features like User-friendly indicators, Tool-less front opening and Zero-contamination concealed storage tank ease your Mission Swach Jal by consistently providing clean and pure drinking water for your family.

TECHNOLOGY IN YOUR PURIFIER: UV+ UF

The Ultra Voilet (UV) module safeguards against the microbiological impurities that can be present in the water. Ultraviolet purification deactivates the protozoa, bacteria and viruses by damaging the genetic code which renders them harmless as they cannot reproduce themselves.
The Ultra Filtration Membrane (UF) technology uses a semi-permeable membrane for purification. The Semi-permeable membrane in your purifier works on very simple principle – only water molecules, dissolved minerals and salts can pass through the membrane.
Ultra Filtration is a separation process that uses membranes with pore size of 0.01 micron. The UF membrane has the capacity to remove colloidal materials including bacteria and cysts from drinking water. Low applied pressure is therefore sufficient to achieve high flux rates from an Ultra Filtration membrane.

Electronic Circuit Diagram

TATA-VIiva-Silver-UV-UF-Water-Purifier-FIG-3

B: Black Wire
G: Green Wire
Y: Yellow Wire
BL: Blue Wire

PURIFICATION PROCESS DIAGRAM

TATA-VIiva-Silver-UV-UF-Water-Purifier-FIG-4

4 STAGE PURIFICATION

Sediment Filter Cartridge (Coarse)
This is the first filtration process which reduces/removes impurities from the inlet water. These impurities may be particles such as dust and sediments which are above 1 Omicron in size. The life of first sediment filter depends upon the inlet water quality.
Recommended replacement cycle: 1 year*
Bacteriostatic Granular Activated Carbon (GAC) with Silver impregnation technology
This GAC Cartridge reduces chlorine, bad taste and odour from the inlet water. It also reduces volatile organic compounds and pesticides from water. The silver impregnation technology used in this cartridge ensures improved bacteriostatic performance for the entire life of the carbon capacity. This Silver Action Inside of the bacteriostatic GAC greatly reduces the chance of bio-fouling and hence increases the life of carbon cartridge.
Recommended replacement cycle: 1 year/SO Liters +
Ultra Violet Purification
The UV module safeguards against the microbiological impurities that can be present in the water. Ultraviolet purification deactivates the protozoa, bacteria and viruses by damaging the genetic code which renders them harmless as they cannot reproduce themselves.
Recommended replacement: 7000 hrsA
Ultra Filtration Membrane
The UF Membrane protects against bacteria, viruses, pyrogens & collodial matter. The membrane passes only dissolved minerals & salts along with the water molecules passing through.
Recommended Replacement: 24 months++
- If this cartridge chokes sooner than the recommended replacement cycle, it is advisable to install a pre-filter (available separately at a cost). Replacement period is as per internal test calculations.
- The life of GAC cartridge depends upon the organics, chlorine, etc present in the input water supply. Under standard
  test conditions the life is measured as 5500 Liters with 2 ppm chlorine water passing through the cartridge. AAs per test carried out by manufacturer
- The life of UF Membrane Filter depends upon the organics, chlorine, etc present in the input water supply. Replacement period is as per internal test calculations.

ADVANCED FEATURES OF YOUR TATA SWACH VIVA SILVER UV+ UF WATER PURIFIER

Purification rate 30 Liters/hour**
Inlet Water Switch Off Mechanism Blocks inlet water supply when no power is available to the system or system is not purifying.
UV Fault UV Lamp damage or fault condition
Silver Action Inside Silver Impregnation technology which imparts longer life to cartridges
User-friendly Indicators Provides intelligent information through its advanced indicators
Zero Contamination Storage Tank Saves you from the hassle of cleaning the tank
Front Panel Opening System Screw less front opening of the purifier makes servicing easy as it avoids dismantling the unit
Voltage Spike Guard Protects against power fluctuation

USER FRIENDLY INDICATORS

Introduces you to Advanced/ new era of modern & useful indications in an easy-tounderstand way:

Sr. No	Application	Condition	Indication	Color
1	System Power	Power On	Green	On
2	UV Purification	UV Lamp On	Yellow	On
3	Tank Status	Tank Full	Blue	On

GENERAL INSTRUCTIONS

While our Service Technicians are trained to follow the installation safety guide, it is imperative that you are aware of them

Match the packaging list with the items in the box .
Always ensure that the Tata Swach Viva Silver UV+ UF purifier is installed by a trained technician.
Tata Swach Viva Silver UV+ UF purifier must be wall-mounted.
Do not install the purifier directly above an electric socket.
Ensure you use the plug provided with the purifier and do not change it unless recommended by Company’s service technician.
The length of the water inlet hose must be shorter than 2 meters to ensure sufficient pressure is available to the machine.
Always connect with cold/normal water inlet only. Do not use with hot water.
Do not confine water purifier in a cabinet.
Input water pressure needs to be between 5 PSI and 35 PSI. In case it is more than 35 PSI, you need to use a “pressure reducing valve” and in case it is less than 5 PSI, you need to use a “pressure booster pump”. Either can be bought from the market or from the Company technician at an additional cost.
Inlet waterTDS should not exceed 500 ppm.
Avoid sharp bends in the connecting pipes ensuring inlet pipe has free water flow path.
Avoid direct exposure to sunlight or humidity and ensure sufficient ventilation

INSTALLATION INSTRUCTIONS

PLEASE ENSURE THAT YOUR TATA SWACH VIVA SILVER UV+ UF PURIFIER IS INSTALLED BY A TATA SWACH TECHNICIAN ONLY

Pre-Installation Requisites

220V single phase AC connection not more than 1.Sm away from the point of installation of purifier. The wire length supplied with the system is 1.Sm.
Raw water supply with½” nipple not more than 2m away.
Space on the wall as per dimensions of the purifier
Wall/plane surface for mounting two screws and holding the machine.

Installation Instructions

Turn-off the main water supply before accessing the nipple for connecting the Kitchen Faucet Adaptor (KFA). Use Teflon Tape on the threads of the Kitchen Faucet Adaptor to connect the pipe. Insert the KFA into the plumbing line and ensure threads are tightened. Depending on the plumbing connection, close the front end of the KFA using a tap. Insert the Inlet pipe in the KFA in the push-fit side. Double press the pipe to ensure leak-proof connection.
Open the front cover of the purifier by rotating the tap counter-clockwise.
Take out the GAC cartridge and use the pipe attached to the KFA to flush for 30 sec with water.After flushing, connect it back in to the system.
Connect the pipe to the inlet marked on the purifier. In case you choose to install additional pre-filter (available at an additional cost), connect the pipe to inlet of this pre-filter and connect the outlet of pre-filter to inlet of the purifier.
Plug in the power supply and check for any leakages from any of the connectors or pipes. lfleakage, then refit. If there is no leakage, close the front cover of the purifier.
Wait for a few minutes to start filling the concealed storage tank.
Drain out first 15 to 20 liters of purified water from the storage tank.
Your Tata Swach Viva Silver UV+ UFWater Purifier is now ready for use. Familiarize your family members with operation and maintenance of the system.

If away from home: If the purifier is not going to be used for more than 2 weeks, shut off the system and drain the stored water .

SAFETY INSTRUCTIONS

Electrical Safety
These safety instructions must be read carefully to ensure your safety and prevent property damage.

Ensure that the local voltage accords with the system voltage to prevent electric shock or fire.
Do not use a damaged power cord or plug, or a loose outlet.
Do not unplug by pulling the cord or handle the plug with wet hands. This may result in electric shock or fire.
Do not bundle the power cord tightly together, as it may cause damage.
If the cord or plug is wet, unplug the unit and let it dry completely before subsequent use.
Unplug the unit before repair, inspection, or replacement to prevent any damage.
Do not plug into an outlet or power strip that is being used by several other appliances. Use a separate outlet for the unit to prevent fire.
Shut the main water supply valve and unplug the power cord when not using for a longtime.
Do not attempt to repair the power cord yourself. Electric shock or fire may occur as a result.
Remove any dust or water particles on the plug. Never use benzene or gasoline to clean the plug. Electric shock or fire may occur as a result.
Do not move the product by pulling the electrical cord.
Do not clean the system with wet cloth when power is on. Use a moist cloth to clean the external surface of the purifier.

Operation

If water leaks from the product, close the Kitchen Faucet Adaptor and call the customer service.
If the unit makes a strange noise or you notice an odd smell, unplug immediately and call the customer service
Do not place candles, cigarettes or any other flammable objects on and around the purifier.
If you have not consumed water from the Tata Swach VIVA Silver UV+ UF purifier for more than 2 days, drain the water from storage tank and refill for consumption.
Periodical cartridge replacement is a prerequisite for clean water. Use Tata Swach genuine (with Tata Swach logo) purifier products to maintain expected product life span and performance.
Do not expose the unit to direct sunlight and high humidity environment. The optimal room temperature for the unit is 4°C-50°C.

Description

The Tata Viva Silver Water Purifier is a wall-mountable purifier that is easy to install and operate. It has a user-friendly interface, with a touch-sensitive button that allows you to easily switch between purification modes. The purifier also has an LED indicator that shows the status of the purification process, making it easy for you to know when your water is ready to drink. The Tata Viva Silver Water Purifier is also energy efficient, consuming only 24 watts of power, making it a cost-effective solution for your water purification needs.

Tata Viva Silver Water Purifier Setup Guide

Setting up the Tata Viva Silver Water Purifier is a straightforward process. First, mount the purifier on the wall using the brackets provided. Next, connect the inlet pipe to the water source and the outlet pipe to the storage tank. Turn on the power and the purifier will start automatically. The purifier will also automatically shut off when the storage tank is full, ensuring that your water is always fresh and clean.

Troubleshooting

What is the storage capacityof my TataSwach Viva Silver UV+UF?
Tata Swach Viva Silver UV+ UFWater Purifier has tank volume of 6 liters. The process of filling the tank is fully automatic and when you take water out of the tank, the purification process automatically starts and refills the storage tank.
What is the purification rate of myTata Swach Viva Silver UV+ UF ?
Tata Swach Viva Silver UV+ UF Water Purifier can purify water up to 30 L/hr. However time taken to purify water depends upon the life of filters, the input water pressure, TDS and other impurities present in water.
Which consumables require periodic replacement?
Consumables such as the Sediment Filter cartridge, Silver Impregnated GAC cartridge, UF membrane and UV lamp need periodic replacement depending on service schedule or fault indication as shown on display panel. Please note that the life of the consumables is dependent on the input water quality.
What should I do when there is no purified water in the tank?
In case there is no purified water in the tank, please call Tata Swach Toll-free number 1800-2-585858 for change of cartridges or any other assistance required.
How long is the stored water in the Tata Swach Viva Silver UV+ UF safe to drink?
It is advised to drain out the stored water if not consumed within two days.
What should I do if any part of purifier gets broken?
Please call the Tata Swach Toll-free number 1800-2-585858. Our technician will visit your house and guide you on the repairs required. There will be a nominal visiting charge and all replacements shall be on a chargeable basis.
Can I open and service myTata Swach Viva Silver UV+ UF?
It is not recommended to open and service the purifier yourself. Call our customer care if you face any issue which requires servicing or opening the purifier.
What should I do if the output water tastes unusual?
This might be because of one or more of the following reasons:
- Water is stored for too long in the storage tank. Please drain the stored water and fill fresh water.
- The filters/membrane need to be replaced. Call Tata Swach customer care and get then replaced or cleaned.
- Thein put water quality has changed. Th is wi II lead to a sudden change in the output water taste. Please call the Tata Swach customer care to get your purifier checked.
What should I do if the purification is taking more time?
This might be because ofone or more of the following reasons:
- The incoming waterline or the KFA is choked because of physical impurities in the incoming water. You can ask your plumber to check if this is the case.
- The temperature of input water might have dipped drastically (this will happen rarely)
- The filters may be choked or the membrane needs replacement
What should I do if the storage tankis not getting filled?
This might be because of one or more of the following reasons:
- Check if the system power is ON.
- Check for any clogging in the incoming water line.

Tata Viva Silver Water Purifier Warranty

Your new Tata Swach Viva Silver UV+ UF water purifier is warranted against material defects arising from workmanship for a period of 12 months from the date of invoice. Tata Swach VIVA Silver UV+UF water purifiers' consumables which are Sediment filter cartridge, Silver Impregnated GAC Cartridge, UV Lamp and UF Membrane are covered under one year warranty. Only one single replacement will be done for each of the consumables during the warranty period. Every second replacement will be charged even though it may have to be changed in the warranty

Pros & Cons

Pros

Advanced purification technology
Intelligent auto-start and auto-shutdown
User-friendly interface
Energy efficient
1-year warranty

Cons

Higher price point compared to some other water purifiers on the market
Limited storage capacity
Requires regular maintenance and filter replacement

Customer Reviews about Tata Viva Silver Water Purifier

Customers love the Tata Viva Silver Water Purifier for its advanced purification technology and user-friendly design. They appreciate the intelligent auto-start and auto-shutdown function, as it ensures that their water is always purified to the highest standards. The only common complaint is the limited storage capacity, but most customers find that the purifier produces enough water for their daily needs.
