Introduction of Adcraft Belgian Waffle Makers BWM-7R2

The Adcraft Belgian Waffle Maker BWM-7R2 is a high-quality kitchen appliance designed to make delicious, restaurant-style waffles in the comfort of your own home. With its non-stick plates, adjustable temperature control, and compact design, this waffle maker is perfect for both personal and family use. The BWM-7R2 is available for an estimated price of $50 to $60 and was launched in 2021.

Detailed Specifications

The Adcraft Belgian Waffle Maker BWM-7R2 has the following key features:

• Non-stick plates for easy food release and quick cleanup
• Adjustable temperature control for consistent cooking
• Ready-to-cook and ready-to-eat indicator lights for convenience
• Cool-touch handle for safe handling
• Compact design for easy storage

Adcraft Belgian Waffle Maker BWM-7R2 To Use

1. Turn on power switch. Three beeps will sound indicating that the machine has power and the heating process has been initiated.

2. After this, the LED display will show a time in minutes and seconds. Before you set the time, you must set the heating temperature that you would like to cook your waffles at. In order to do this, hold the “SET” button and then press the “START/STOP” button. This will then display the temperature that the unit is currently set to. Use the “+ and –“ buttons in order to change the displayed temperature to the one desired and then press “SET” to finalize this parameter. The unit will then continue heating to this set temperature and will continue to maintain this temperature for the remainder of the cooking process and the whole time the unit’s power switch is turned on.

3. In order to begin the time feature, press and hold the “START/STOP” button and use the “+ and –“ buttons in order to change the minutes and seconds displayed on the LED display. Once you have set your desired time, press the “START/STOP” button once to begin the time countdown. Once the time on the display has reached “00:00” an alarm will sound indicating the timer has run out of time.

NOTE: The timer feature has NO EFFECT on the heating process. It is just a timer for your convenience to help you keep track of your cooking times. The unit will always maintain the set temperature you have input as long as the power switch is turned on, regardless if the timer has run out or not.

MAKING WAFFLES

Turn the unit on and pre-heat for 15 minutes with the waffle grids closed. To make waffles follow these instructions:

1. Spray or brush on releasing agent.

2. Lift the top lid, pour in the mix and close. Allow waffle batter to sit for 10 seconds.

3. Start timer by pressing the start/stop button.

4. Rotate grids 180°.

5. Cook until the timer beeps and press the start/stop button to stop the timer.

6. Rotate grids 180°.

7. Remove waffle. Do not use metal utensils on non-stick waffle irons.

8. To cook more waffles, repeat steps 1 through 7.

Description

The Adcraft Belgian Waffle Maker BWM-7R2 is a versatile and easy-to-use kitchen appliance that can make a variety of waffle styles and sizes. The non-stick plates ensure even cooking and easy food release, while the adjustable temperature control allows you to customize the cooking process to your liking. The ready-to-cook and ready-to-eat indicator lights take the guesswork out of waffle making, and the cool-touch handle ensures safe handling. The compact design of the BWM-7R2 makes it easy to store in your kitchen, and the non-stick plates make cleanup a breeze.

Wiring Diagram for the Waffle Makers

Parts Diagram and Replacement Parts for the Single Waffle Maker

Replacement Parts for the Single Waffle Maker BWM-7/R - Belgian Waffle Maker 7" Round

Parts Diagram and Replacement Parts for the Double Waffle Maker

Replacement Parts for the Double Waffle Maker BWM-7/R-2 - Belgian Waffle Maker - Double Round 7”

Setup Guide

To set up the Adcraft Belgian Waffle Maker BWM-7R2, follow these steps:

1. Plug in the waffle maker and let it heat up for a few minutes.
2. Pour the waffle batter onto the non-stick plates, being careful not to overfill.
3. Close the lid and let the waffle cook until the ready-to-eat indicator light turns on.
4. Use the cool-touch handle to remove the waffle from the waffle maker.
5. Clean the waffle maker by wiping down the non-stick plates with a damp cloth.

Adcraft Belgian Waffle Maker BWM-7R2 Cleaning

NOTE: To maintain cleanliness and increase service life, this item should be cleaned daily. Do not immerse the unit in water or any other liquid. If liquid enters the electrical compartment it may cause a short circuit or electrical shock.

1. Unplug the unit and let cool down.

2. Clean the waffle iron plates with a wet towel only.

3. Do not use a wire scrub brush or metal utensils on the waffle iron plates.

WARNINGS

• Do not touch any hot surfaces.

• Plug only into a 3-hole grounded electrical outlet of the appropriate voltage.

• Do not immerse unit, cord, or plug in liquid at any time.

• Unplug cord from outlet when not in use and before cleaning.

• Do not operate unattended.

• Do not use this unit for anything other than intended use.

• Do not use outdoors.

• Always use on a firm, dry, and level surface.

• Do not use if unit has a damaged cord or plug, in the event the appliance malfunctions, or has been damaged in any manner.

• Keep children and animals away from unit.

• Any incorrect installation, alterations, adjustments and/or improper maintenance can lead to property loss and injury. All repairs should be done by authorized professionals only.

Troubleshooting

Here are some common problems and solutions for the Adcraft Belgian Waffle Maker BWM-7R2:

• Waffles are not cooking evenly: Make sure to evenly distribute the batter on the non-stick plates and adjust the temperature control as needed.
• Waffles are sticking to the non-stick plates: Make sure the waffle maker is fully heated before adding the batter, and use a non-stick cooking spray if necessary.
• Waffle maker is not turning on: Check to make sure the waffle maker is properly plugged in and the power switch is turned on.

Warranty

ACE Equipment is warranted for one year, effective from the date of purchase by the original owner. A copy of the original receipt or other proof of purchase is required to obtain warranty coverage. This warranty applies to the original owner only, and is not assignable.

Pros & Cons

Pros

• Non-stick plates for easy food release and quick cleanup
• Adjustable temperature control for consistent cooking
• Ready-to-cook and ready-to-eat indicator lights for convenience
• Cool-touch handle for safe handling
• Compact design for easy storage

Cons

• May not make large, restaurant-style waffles
• May not be as durable as higher-end waffle makers

Customer Reviews of Adcraft Belgian Waffle Maker BWM-7R2

Customers love the Adcraft Belgian Waffle Maker BWM-7R2 for its easy-to-use design, non-stick plates, and adjustable temperature control. Some common complaints include the size of the waffles and the durability of the waffle maker. Overall, the BWM-7R2 is a great value for the price and is highly recommended for those looking for a reliable and convenient waffle maker.
