Introduction

The Black+Decker Cordless Pet Dustbuster Hand Vacuum DVJ325BF is a powerful, lightweight handheld vacuum specifically designed for pet owners. Featuring Smart Tech sensors, it efficiently detects dirt and adjusts suction power accordingly, making it ideal for tackling pet hair and debris on various surfaces. Its cordless design enhances portability, allowing for easy cleaning in hard-to-reach areas. The cost of this convenient vacuum is approximately $79.99.

Technical Data

Original instructions

Intended use

Your BLACK+DECKER DVJ215J, DVJ315J, DVJ320J, DVJ325J, DVJ325BF and DVJ325BFS Dustbuster® handheld vacuum cleaners have been designed for vacuum cleaning purposes. These appliances are intended for household use only.
Read all of this manual carefully before operating the appliance.

Safety instructions

Warning! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions listed below may result in electric shock, fire and/or serious injury. The intended use is described in this manual. The use of any accessory or attachment or the performance of any operation with this appliance other than those recommended in this instruction manual may present a risk of personal injury. Retain this manual for future reference.

Using your appliance

• Do not use the appliance to pick up liquids or any materials that could catch fire.

• Do not use the appliance near water.

• Do not immerse the appliance in water.

• Never pull the charger lead to disconnect the charger from the socket. Keep the charger lead away from heat, oil and sharp edges.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

Inspection and repairs

Before use, check the appliance for damaged or defective parts. Check for breakage of parts, damage to switches and any other conditions that may affect its operation.

• Do not use the appliance if any part is damaged or defective.
• Have any damaged or defective parts repaired or replaced by an authorized repair agent.
• Regularly check the charger lead for damage. Replace the charger if the lead is damaged or defective.
• Never attempt to remove or replace any parts other than those specified in this manual.

Additional safety instructions

After use

• Unplug the charger before cleaning the charger or charging base.
• When not in use, the appliance should be stored in a dry place.
• Children should not have access to stored appliances.

Residual risks

Additional residual risks may arise when using the tool which may not be included in the enclosed safety warnings. These risks can arise from misuse, prolonged use etc.

Even with the application of the relevant safety regulations and the implementation of safety devices, certain residual risks can not be avoided. These include:

• Injuries caused by touching any rotating/moving parts.
• Injuries caused when changing any parts, blades or accessories.
• Injuries caused by prolonged use of a tool. When using any tool for prolonged periods ensure you take regular breaks.
• Impairment of hearing.
• Health hazards caused by breathing dust developed when using your tool (example:- working with wood, especially oak, beech and MDF.)

Chargers

Your charger has been designed for a specific voltage. Always check that the mains voltage corresponds to the voltage on the rating plate.
Warning! Never attempt to replace the charger unit with a regular mains plug.

• Use your BLACK+DECKER charger only to charge the battery in the appliance with which it was supplied. Other batteries could burst, causing personal injury and damage.
• Never attempt to charge nonrechargeable batteries.
• If the supply cord is damaged, it must be replaced by the manufacturer or an authorised BLACK+DECKER Service Centre in order to avoid a hazard.
• Do not expose the charger to water.
• Do not open the charger.
• Do not probe the charger.
• The appliance/battery must be placed in a well ventilated area when charging.

Electrical safety

Symbols on the charger

Read all of this manual carefully before using the appliance.
This tool is double insulated; therefore no earth wire is required. Always check that the power supply corresponds to the voltage on the rating plate.
Short circuit proof safety isolating transformer. The mains supply is electrically separated from the transformer output.
The charger automatically shuts off if the ambient temperature becomes too high. As a consequence the charger will be inoperable. The charging base must be disconnected from the mains supply and taken to an authorised service centre for repair.
The charging base is intended for indoor use only.

Labels on appliance

The following symbols appear on this appliance along with the date code
Read all of this manual carefully before using the appliance
Only use with charger S010Q 14

Features

This tool includes some or all of the following features.

1. On/off power switch
2. Handle
3. Nozzle
4. Pull out crevice tool
5. LED charging indicator
6. Dust bowl
7. Charging base
8. Flip down brush
9. Charger

Description

The Black+Decker Cordless Pet Dustbuster Hand Vacuum DVJ325BF is engineered with pet owners in mind. Its compact design makes it easy to maneuver around furniture and into tight spaces. The vacuum features a powerful motor that delivers strong suction, capturing pet hair and dust efficiently. The LED light at the front helps illuminate dark areas, ensuring no dust or hair is missed. The vacuum comes with two tools: a crevice tool for reaching tight spaces and a brush tool specifically designed to remove pet hair from upholstery and stairs. The 0.5-liter dustbin is easy to empty, reducing maintenance time.

Use

Switching on and off

(Fig. A)

• Press the button to turn, on the unit operates in slow speed, low power mode, conserving the battery life.
• Press the button again, and the unit goes to a BOOST mode.
• Pressing the button again will turn the product off.

Using the pull-out crevice tool

(Fig. B,C)

• Extend the crevice tool (4) as shown in figure C, until it clicks in place.
• To retract the crevice tool (4) press the crevice tool release button (4a) allowing it to return to its normal position (Fig. B).
  Note: The flip down brush (8) can only be utilised when the crevice tool is in the retracted position.

Charging

DVJ325BF, DVJ325BFS

(Fig. D)

• Place the appliance onto the charging base (7) and plug into the electrical outlet.
• Switch the electrical outlet on. The LED charging indicator (B) will illuminate.

DVJ215J, DVJ315J, DVJ320J, DVJ325J

• Place the charger (9) into the charging port at the rear of the handle (2) and plug into the electrical outlet.
• Switch the electrical outlet on. The LED charging indicator (B) will illuminate.

Multi LED Display

DVJ325BF, DVJ325BFS

1. A. Filter sensor
   Whenever a filter is Blocked and needs cleaning, the red filter LED (A) in the handle will illuminate. Clean fine dust from filter (See section on `cleaning filters’ in this manual).

2. B. LED Charging display
   The charging display LED (B) will illuminate when the unit is charging and will indicate (flash) when further charging is required.

3. C. BOOST mode
   LED (C) Illuminates when the appliance is in BOOST mode.

Dual LED Display

DVJ215J, DVJ 315J, DVJ320J, DVJ325J

1. B. LED Charging display
   Battery icon is illuminated when appliance is switched on and will flash when the battery is almost depleted charging. It will also flash during charging (See LED pattern chart in this manual).

2. C. BOOST mode
   Illuminates when the appliance is in BOOST mode.

LED Patterns

Cleaning the filters

• Press the dust bowl release button (12) (Fig. E)



• Eject the dust bowl (6) (Fig.F)



• Lift the filter assembly (10) using the metal handle provid-ed from the dust bowl (6)

Note: On unit DVJ325BFS the pre filter is impregnated with a fragrance allowing for a pleasing odour to be released when the appliance is in use.

• Empty the dust bowl (6) by lightly shaking over a dustbin (Fig. H).



• The filter (11) can now be removed from the filter assembly (10) DVJ215J, DVJ315J, DVJ320J, DVJ325J (Fig.I1). DVJ325BF, DVJ325BFS (Fig. I).



• Empty any remaining dust from the dust bowl.
• Rinse out the dust-bowl with warm soapy water.

• Wash the filters with warm soapy water (Fig. J).



• Make sure the filters are dry
• Refit the filters into the appliance.
• Close the dust-bowl. Make sure the release latch (8) clicks into place.

Warning! Before performing any maintenance or cleaning on the appliance, unplug the appliance.

From time to time wipe the appliance with a damp cloth. Do not use any abrasive or solvent-based cleaner. Do not immerse the appliance in water

Setup Guide

To operate the Black+Decker Cordless Pet Dustbuster Hand Vacuum DVJ325BF:

1. Charging: Place the battery on the charger provided. It takes approximately 4 hours to fully charge.
2. Assembly: Attach the desired tool (crevice or brush) to the end of the vacuum.
3. Operation: Press the power button to turn on the vacuum.
4. Emptying Dustbin: Release the dustbin by pressing the latch button and empty it over a trash can.

Black & Decker Maintenance

Your BLACK+DECKER cordless appliance has been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper tool care and regular cleaning.
Warning! Before performing any maintenance on cordless appliances:

• Run the battery down completely if it is integral and then switch off.
• Unplug the charger before cleaning it. Your charger does not require any maintenance apart from regular cleaning.
• Regularly clean the ventilation slots in your appliance/charger using a soft brush or dry cloth.
• Regularly clean the motor housing using a damp cloth. Do not use any abrasive or solvent-based cleaner.

Replacing the filters

The filters should be replaced every 6 to 9 months and whenever worn or damaged. Replacement filters are available from your BLACK+DECKER dealer (cat. noVBF10). There are also pre-scented filters available to be purchased (cat. no: VSPF10LC). These fit all units. When these filters reach the end of their lifespan they must be disposed of at a local recycling centre.
Warning!
Cotton linen fragrance.
Wash face, hands and any exposed skin thoroughly after handling. Wear protective gloves/protective clothing/eye protection/ face protection. If in eyes: Rinse cautiously with water for several minutes. Remove contact lenses if present and easy to do. Continue rinsing. If skin irritation occurs: Get medical advice/attention. Avoid release into the environment. Do not ingest.

• Remove the old filters as described above.
• Fit the new filters as described above.

Protecting the environment
Separate collection. Products and batteries marked with this symbol must not be disposed of with normal household waste. Products and batteries contain materials that can be recovered or recycled reducing the demand for raw materials. Please recycle electrical products and batteries according to local provisions.

Troubleshooting

Common problems and solutions include:

• Reduced Suction Power: Check if the filter is clogged or if the dustbin needs to be emptied.
• Battery Not Charging: Ensure proper contact between the battery and charger. Also, check if there are any blockages in the charging port.
• LED Light Not Working: Verify that there are no obstructions blocking the LED light. If still not working, contact customer support.

Instructions and warnings

• Always charge the battery in a well-ventilated area away from moisture.
• Avoid overcharging as it may damage battery life.

Guarantee

Black & Decker is confident of the quality of its products and offers consumers a 24-month guarantee from the date of purchase. This guarantee is in addition to and in no way prejudices your statutory rights. The guarantee is valid within the territories of the Member States of the European Union and the European Free Trade Area. To claim on the guarantee, the claim must be in accordance with Black&Decker Terms and Conditions and you will need to submit proof of purchase to the seller or an authorised repair agent. Terms and conditions of the Black&Decker 2 year guarantee and the location of your nearest authorised repair agent can be obtained on the Internet at http://www.2helpu.com/ , or by contacting your local Black & Decker office at the address indicated in this manual.

Pros & Cons

Pros

• Lightweight & Portable: Easy to carry around without fatigue.
• Versatile Tools: Includes crevice and brush tools for various cleaning tasks.
• LED Light: Illuminates dark areas for thorough cleaning.
• Affordable: Priced competitively compared to other handheld vacuums.
• Cordless Freedom: No need to worry about cords getting in the way.

Cons

• Short Runtime: Battery lasts up to 20 minutes before needing a recharge.
• Limited Dustbin Capacity: Requires frequent emptying of dustbin during extended use.
• Filter Maintenance: Requires occasional cleaning or replacement of filter.

Customer Reviews

Customers praise the Black+Decker Cordless Pet Dustbuster Hand Vacuum DVJ325BF for its ease of use, lightweight design, and effectiveness in removing pet hair. However, some users have mentioned that the battery life could be longer and that the dustbin capacity is somewhat small. Most common complaints include:

• Short battery life during prolonged use.
• Need for frequent dustbin emptying due to small capacity.
