Introducing the Zaap Slim Trifold Keyboard

This keyboard is a universal compatible keyboard for Android/Windows f iOS in tablets. smartphone, laptops, and desktops It has automatic power ON/OFF design.

Specifications

Material: ABS keycaps with aluminum alloy bottom cover
Finish: Grey Back and Black Keys
Support: Android/ Windows /iOS
Connection type: USA Broadcom Bluetooth 3.0,
Key life : 3 million Keystrokes
Battery: ZlOmAh Li-ion (rechargeable).
Working time: 85 hOUfS
Stand by time: >90 days
Dimensions : 251.7 x 89.6 x 6.6mm
BT Operation range: 33 feet (10 meters)
Micro use cable length : eocm
Cable Output: OCS.OV \ SOOmA
Charging: Approx 4 hours
Color: Grey

Important: Different mobile phone brands or menu functions, the usage will be different. Please read your phone manual carefully.

Overview of Zaap Slim Trifold Keyboard

Bluetooth/Caps Lock Indicator
Power Indicator
Micro use Charging Port
Bluetooth pairing: Fn & C key

How it works

Power ON: To power on the keyboard simply unfold it. The power indicator will tum on Green for few seconds and tum off.
Charging Keyboard: To charge keyboard. plug the Micro USB port of cable to the charging port on keyboard and other end of the cable with Standard USB port on Laptop, Computer/ Wall Adapter. Wall Adapter output DC S.OV\SOOmA. The Power indicator will tum on solid red when the keyboard is chagins and it will tum off when keyboard is fully charged.
Battery Low Indication: The power indicator will flash Green when it is time to charge the keyboard.

BLUETOOTH KEYBOARD PAIRING

When pair the Bluetooth keyboard for the first time. the distance between the Bluetooth keyboard and phone f Bluetooth other device would be better within 1 meter.
Press and hold the Fn key and press the C key once. The Bluetooth status indicator starts blinking Blue. The keyboard is now into pairing mode
On your Bluetooth device, search for Bluetooth Devices, choose: ZAAPTPK-229
The Bluetooth status indicator stops blinking (tums off) and becomes solid Blue on successful pairing.

NOTE

Only one device can be actively paired at one time.
The keyboard remember the last connected device and will pair automatically when you open the keyboard.
In case of connection failure, delete the pairing records from your device and try the above steps of pairing again.

Operating Instructions

Select Operating System: To select operating system Press and hold Fn key and press Android/ IOS I Windows respectively according to you, bluetooth device·s operating system.
Caps Lock: To enable the caps lock & type leuers in upper case. Ensure the keyboard is paired to the device. Press the Caps lock key on keyboard once, The Caps Lock Indicator tums on solid green.
Energy Saving Sleep Mode: The keyboard will enter s!eep mode after being idle for 1S minutes. To activate It, press any key and wait for 3 seconds.
Special Features and options: The keyboard is very convenient In sto,age and carrying. A simple protective case can protect devices conveniently.

Description of Zaap Slim Trifold Keyboard

The zaap Slim Trifold Keyboard is a portable and convenient keyboard designed for use with mobile devices, laptops, and tablets. It is made of high-quality materials, featuring a compact and foldable design that makes it easy to carry around. The keyboard has a built-in rechargeable battery that provides long-lasting power, and it can be connected to devices via Bluetooth. It also features low-profile keys that provide a comfortable typing experience and a stable connection, making it perfect for those who need to type on the go.

Functions

Function	FN on iOS	FN on Android	FN on Windows	FN + Shift on Windows
Home	Home	Home	ESC	Web Browser
Search	Search	Search	F1	Search
Select all	Select all	Select all	F2	Select all
Copy	Copy	Copy	F3	Copy
Paste	Paste	Paste	F4	Paste
Cut	Cut	Cut	F5	Cut
Previous track	Previous track	Previous track	F6	Previous track
Play/pause	Play/pause	Play/pause	F7	Play/pause
Next track	Next track	Next track	F8	Next track
Volume down	Volume down	Volume down	F9	Volume down
Volume up	Volume up	Volume up	F10	Volume up
Keyboard Display	N/A	N/A	N/A	N/A
Back	N/A	Back	N/A	N/A

Zaap Slim Trifold Keyboard Setup Guide

To set up the zaap Slim, follow these steps:

Charge the keyboard fully before use.
Turn on the keyboard by pressing the power button for a few seconds.
Activate Bluetooth on your device and search for available devices.
Select "zaap Slim Trifold Keyboard" from the list of available devices.
Once connected, start typing on the keyboard.

Clean Keyboard: Clean the keyboa1d with dry cloth, Alcohol or alcohol based disinfectant.

CAUTIONS

Keep the keyboard away from sharp objects.
Do not place heavy object on the keyboard
Do not Microwave the keyboard ..
Please keep Of use this product at normal temperature.
Do not throw this product to avoid any damage.
Do not disassemble, repair or reform this product.
Do not clean this product with any chemical solvents
Please use USB power of DCSV, SOO mA for output when needed else it will damage battery or keyboard.
Do not throw away 01 put it in high

Troubleshooting

Here are some common problems and solutions for the zaap Slim Trifold Keyboard:

Problem: Keyboard not connecting to device.
Solution: Make sure Bluetooth is activated on your device and try connecting again. If it still doesn't work, try resetting the keyboard by holding down the power button for a few seconds.
Problem: Keyboard not charging.
Solution: Make sure the charging cable is properly connected to the keyboard and the power source. If it still doesn't charge, try using a different charging cable or power source.
Problem: Keys not responding.
Solution: Make sure the keyboard is connected to your device and the batteries are charged. If the keys still don't respond, try resetting the keyboard or cleaning the keys with a damp cloth.

Zaap Slim Trifold Keyboard Warranty

Zaap Technologies warrants all of its hardware products excluding refurbished items, with a One Year Limited Warranty against defects in workmanship and materials under normal use for a period of one year from the original purchase date. This warranty does not cover accidental damage, misuse, improper care or alteration, or acts of God such as floods and earthquakes, etc.

Pros & Cons

Pros

Compact and portable design
High-quality materials and construction
Comfortable typing experience
Long-lasting battery life
Stable Bluetooth connection

Cons

Slightly higher price point compared to other portable keyboards
Keys may be too small for some users
May take some time to get used to the layout

Customer Reviews about Zaap Slim Trifold Keyboard

Customers have given the zaap Slim Trifold Keyboard positive reviews, praising its compact and portable design, high-quality materials, and comfortable typing experience. However, some have noted that the keys may be too small for some users and that the price point is slightly higher compared to other portable keyboards. Some of the most common complaints include connectivity issues and difficulty in charging the keyboard.
