Introduction

A small and dependable C instrument that can help you avoid overweight baggage fines. This compact scale has a high-precision sensor technology, an easy-to-read LCD display, and a durable strap and hook for safe weighing. It is ideal for frequent travelers since it provides exact measurements and ease of use, reducing stress during packing and travel.

Etekcity Digital Luggage Scale EL19 Package Contents

• 1 x Digital Luggage Scale
• 1 x 3V CR2032 Battery (Pre-Installed)
• 1 x User Manual

Specifications

• Weight Capacity: 110 lb / 50 kg
• Units: oz / kg / g / lb
• Graduation: 0.35 oz / 10 g
• Battery: 1 x 3V CR2032 Battery (Lithium)
• Dimensions: 5.7 x 1.4 x 1.2 in / 145 x 35 x 30 mm
• Auto-Off: 60 seconds

Function Diagram

• A. Display
• B. Power Button
• C. Scale Body
• D. Battery Compartment
• E. Triangle Ring
• F. Belt
• G. Hook

Description

The Etekcity Digital Luggage Scale EL19 is a lightweight and compact device that can easily fit in your luggage or purse. It features a sturdy stainless steel hook that can attach to any handle or strap, allowing you to weigh your luggage with precision. The LCD screen displays the weight in both pounds and kilograms, and it has a tare function that can subtract the weight of the luggage carrier. The EL19 is powered by a long-lasting LR44 button cell battery, which is already included in the package. The backlit LCD screen ensures easy reading in any lighting condition, making it convenient to use in airports, train stations, or at home.

Before First Use

1. Open the battery cover. If necessary, use a tool to open.
2. Remove the insulation strip from the battery. [Figure 1.1]
3. When replacing the battery, make sure the + side of the battery is facing up. [Figure 1.2]

4. Replace the battery cover.



General Operation

Weight Measurement

1. Press the POWER button to turn on the scale. Wait for “000” to appear on the display.



2. Wrap the belt around the handle of your luggage and place the hook on the bottom of the triangle ring.
3. Lift the luggage with the scale and hold still until the weight measurement stabilizes. The display will show the weight and “H” (Data Hold).
   • Note: Do not move the scale during measurement.
4. To measure another item, remove the luggage and repeat steps 2 and 3.
5. Press and hold the POWER button for 3 seconds to turn the scale off.

Data Hold Function

Once the weight has stabilized and “H” appears on the display, the weight will stay on the screen for 60 seconds, or until you measure another object. You can also press to reset POWER button the display.

Unit Conversion

1. Press the POWER button to turn the scale on.
2. Before the display reads “000”, press the POWER button repeatedly to switch between grams (g), pounds (lb), ounces (oz), and kilograms (kg).

Tare Function

You can use the Tare function to weigh an object inside a container by subtracting the weight of the container from the total weight.

1. Press the POWER button to turn on the scale. Make sure the display reads “000”.
2. Wrap the belt around the handle of the container and place the hook on the bottom of the triangle ring. Allow the weight to stabilize until “H” appears on the display.
3. Hold the scale stable and press to tare. The display will show “T”.
4. Place the item you want to weigh inside the container. The scale will measure the contents without including the weight of the container.

Setup Guide

To operate the Etekcity Digital Luggage Scale EL19, follow these steps:

1. Insert the LR44 button cell battery in the compartment located at the back of the scale.
2. Turn on the scale by sliding the power button to the "on" position.
3. Attach the hook to the handle or strap of your luggage.
4. Lift the luggage and wait for the scale to stabilize.
5. Read the weight on the LCD screen and record it for reference.

Care & Maintenance

• Do not immerse the scale in water or use chemical detergents to clean the scale.
• Use a damp cloth to wipe the scale clean.
• Do not place stress on the triangle ring when not using the scale.

Replacing the Batteries

When the display reads “LO”, battery power is low. Replace the battery.

1. Turn the scale over and open the battery compartment.
2. Remove the used battery and replace it with 1 new 3V CR2032 battery. Make sure the + side of the battery is facing up.
3. Replace the battery compartment cover.

Important Safety Information

Follow all instructions and safety guidelines. Read all instructions before using.

• Do not exceed 110 lb / 50 kg, including the tared weight of the container. The display will read “Err” if the weight exceeds the limit.
• This scale is not intended for commercial or heavy-duty use. Household use only.
• Do not throw or strike the scale and do not submerge the scale in water.

SAVE THESE INSTRUCTIONS

Troubleshooting

If you encounter any issues with the Etekcity Digital Luggage Scale EL19, try the following solutions:

• Make sure the battery is properly inserted and the scale is turned on.
• Ensure that the hook is securely attached to the luggage handle or strap.
• Allow the scale to stabilize before reading the weight.
• Avoid shaking or jolting the scale while weighing your luggage.
• Do not exceed the maximum weighing capacity of 110 pounds (50 kilograms).

Warnings

• Do not use the scale to weigh any objects other than luggage.
• Do not expose the scale to water or extreme temperatures.
• Do not drop or mishandle the scale.

Warranty Information

• Product: Digital Luggage Scale
• Model: EL19
• Default Warranty Period: 1 year

Extend Your Warranty by 1 Year

Register your product at https://www.etekcity.com/warranty to extend your 1-year warranty by an additional year.

Pros & Cons

Pros

• Compact and portable design
• Sturdy stainless steel hook
• Easy-to-read LCD screen
• Tare function for accurate weighing
• Affordable price

Cons

• May not be suitable for larger or heavier luggage
• Battery life may be short-lived with frequent use

Customer Reviews

The Etekcity Digital Luggage Scale EL19 has received mostly positive reviews from customers, with many praising its compact size, easy-to-read display, and accuracy. Some have reported issues with the tare function and battery life, but overall, the EL19 is considered a reliable and affordable solution for travelers. The most common complaints include the lack of a hold function for stable weight readings and the difficulty in reading the weight in bright lighting conditions.
