Introduction of Fisher-Price Power Wheels Replacement Battery 74522

The Fisher-Price Power Wheels Replacement Battery 74522 is a must-have accessory for anyone who owns a Power Wheels vehicle. This 12-volt battery is designed to provide reliable and long-lasting power for your child's ride-on toy, ensuring they can have hours of fun and enjoyment. The battery is easy to install and is compatible with a wide range of Power Wheels vehicles. With an estimated price of $40 to $50, this battery is a cost-effective way to keep your child's Power Wheels running smoothly. The battery was launched in 2015 and has been a popular choice among Power Wheels owners ever since.

Detailed Specifications

The Fisher-Price Power Wheels Replacement Battery 74522 has the following specifications:

• 12-volt rechargeable battery
• Compatible with Power Wheels vehicles that use a 12-volt battery
• Includes battery and battery connector
• Measures 5.9 x 4.6 x 4.2 inches
• Weighs 6.4 pounds

Description

The Fisher-Price Power Wheels Replacement Battery 74522 is a high-quality and reliable battery that is designed to provide long-lasting power for your child's Power Wheels vehicle. The battery is easy to install and is compatible with a wide range of Power Wheels vehicles that use a 12-volt battery. It is made from high-quality materials and is built to withstand the wear and tear of frequent use. The battery connector is designed to ensure a secure and reliable connection, reducing the risk of damage to the battery or the Power Wheels vehicle. With its compact size and lightweight design, this battery is easy to transport and store when not in use.

Getting Started

Your new Power Wheels 6 volt battery has a built-in, self-resetting thermal fuse and an A-style connector. The A-style connector on this battery is NOT immediately compatible with a vehicle that has a motor harness with either an H-Style or Blue Cover connector. Please identify the type of motor harness connector you have on your vehicle by reviewing the diagrams below.

• If your vehicle has a connector that looks like the one pictured above, this battery is compatible for use in your vehicle.



• If your vehicle has a connector that looks like either one pictured above, this battery is NOT immediately compatible for use in your vehicle.



Charging the Battery

• Plug the charger and battery connectors together. Push firmly to make sure the two connectors are completely joined.



• Plug the charger into a standard wall outlet. If your charger has an LED, the LED lights. The LED on the charger does not indicate the charge status of your battery. The LED allows you to see that there is power from the wall outlet to the charger.
  • Notes: If power flow to the wall outlet is controlled by a switch, make sure the switch is “ON”. Use the charger only in a wall outlet. Do not plug the charger into a ceiling outlet.
• Before first-time use, charge the battery for at least 18 hours.
• Recharge the battery for at least 14 hours after each use of your vehicle.
• Never charge the battery longer than 30 hours.
• Once the battery is charged, disconnect the charger connector from the battery connector. Unplug the charger from the wall outlet. The battery is now charged and is ready to be installed in your vehicle. Please see “Battery Installation” in your vehicle’s Owner’s Manual.

Fisher-Price Power Wheels Replacement Battery 74522 Battery Care

• If a battery leak develops, avoid contact with the leaking acid and place the damaged battery in a plastic bag. See information below for proper disposal.
• If acid comes in contact with skin or eyes, flush with cool water for at least 15 minutes and call a physician.
• If acid is internally ingested, give water, milk of magnesia, or egg whites immediately. Never give emetics or induce vomiting. Call a physician.
  • Charge a new battery for at least 18 hours before using in your vehicle. Never charge the battery longer than 30 hours. Overcharging or undercharging the battery may shorten battery life and decrease vehicle running time.
  • Charge the battery after each use, regardless of how long the vehicle was used.
  • Do not allow the battery to run down completely before charging.
  • Charge the battery before storing the vehicle.
  • Charge the battery at least once per month, even if the vehicle has not been used.
  • Leaving the battery in a discharged condition will ruin it.
  • Always remove an exhausted battery from the vehicle. Battery leakage and corrosion can damage the vehicle.
  • Do not store the battery on a surface (such as a kitchen countertop) which could be damaged by the acid contained inside the battery. Take precautions to protect the surface on which you store the battery.
  • Do not store the battery in temperatures above 75° F or below -10° F.

Setup Guide

To set up the Fisher-Price Power Wheels Replacement Battery 74522, follow these steps:

1. Make sure the Power Wheels vehicle is turned off and disconnected from the power source.
2. Locate the battery compartment on the Power Wheels vehicle and remove the old battery.
3. Connect the new battery to the battery connector, ensuring a secure and reliable connection.
4. Insert the new battery into the battery compartment and close the compartment door tightly.
5. Connect the Power Wheels vehicle to the power source and turn it on to test the new battery.

WARNING: Electrical Hazard

PREVENT FIRE

• Never modify the electrical system. Alterations could cause a fire resulting in serious injury and could also ruin the electrical system.
• Use of the wrong type battery or charger could cause a fire or explosion resulting in serious injury.
• Use of Power Wheels® components in products other than Power Wheels® vehicles could cause overheating, fire, or explosion.
• The battery must be handled by adults only. The battery is heavy and contains sulfuric acid (electrolyte). Dropping the battery could result in serious injury.
• Never allow children to charge the battery. Battery charging must be done by adults only. A child could be injured by the electricity involved in charging the battery.

WARNING

• Never lift or carry the battery by the wires or connector. This can damage the battery and possibly cause a fire resulting in serious injury. Lift and carry the battery by the case only.
• Read the safety instructions on the battery.
• Examine the battery, charger, and their connectors for excessive wear or damage each time you charge the battery. If damage or excessive wear is detected, do not use the charger or the battery until you have replaced the worn or damaged part.

CAUTION: Use the charger in dry locations only.

Important Information

• You must charge your battery for 18 - 30 hours before use in your vehicle for the first time.
• The battery must be upright while charging.
• Do not short circuit the battery.
• You do not need to remove the battery from your vehicle to recharge it.
• Before charging the battery, examine the battery case for cracks and other damage which may cause sulfuric acid (electrolyte) to leak during the charging process. If damage is detected, do not charge the battery or use it in your vehicle. Battery acid is very corrosive and can cause severe damage to surfaces it contacts.
• Do not charge the battery on a surface (such as kitchen countertops) which could be damaged by the acid contained inside the battery. Take precautions to protect the surface on which you charge your battery.
• Use only a Power Wheels® Super 6 volt charger with an A-style connector (120 VAC, 60 Hz, 15W with an output of 6 VDC, 1200mA, 7.2W) to charge your Power Wheels® 6 volt battery.
• The charger is not a toy.
• Adults Note: Regularly examine the charger for damage to the cord, plug, housing, or other parts that may result in the risk of fire, electric shock, or injury. In the event of any damage, do not use the charger until the damage has been properly repaired. Please call 1-800-348-0751.

About Thermal Fuses

Your Power Wheels 6 volt battery is equipped with a built-in thermal fuse. The thermal fuse is a self-resetting safety device which automatically “trips” and shuts down operation of the vehicle if the vehicle is overloaded or the driving conditions too severe. Once a fuse has “tripped”, remove your foot from the pedal or hand from the button and wait approximately 25 seconds before operating the vehicle again. To avoid repeated automatic shutdowns, do not overload the vehicle by exceeding the maximum weight capacity (as listed in your vehicle’s Owner’s Manual) or by towing anything behind the vehicle. Avoid severe driving conditions, such as driving up slopes or running into fixed objects, which can cause the wheels to stop spinning while power is still being supplied to the motors and make sure your child stops the vehicle before switching speeds or direction.

Troubleshooting

If you experience any issues with the Fisher-Price Power Wheels Replacement Battery 74522, try the following troubleshooting steps:

1. Make sure the battery is properly connected to the battery connector and the Power Wheels vehicle.
2. Check that the battery is fully charged before use.
3. Ensure that the Power Wheels vehicle is turned off when connecting or disconnecting the battery.
4. If the battery still does not work, contact Fisher-Price customer service for further assistance.

Warranty

This 6-month limited warranty covers the Power Wheels® 6 volt battery purchased from Power Wheels® by the original purchaser, against defects in materials and workmanship.

Pros & Cons about Fisher-Price Power Wheels Replacement Battery 74522

Pros

• Reliable and long-lasting power
• Easy to install
• Compatible with a wide range of Power Wheels vehicles
• Made from high-quality materials
• Compact and lightweight design

Cons

• May not be compatible with some older Power Wheels vehicles
• May not provide as much power as the original battery
• May require frequent charging

Customer Reviews

Customers have given the Fisher-Price Power Wheels Replacement Battery 74522 mostly positive reviews, with many praising its reliability and ease of use. Many customers have reported that the battery provides long-lasting power and is easy to install. However, some customers have reported issues with the battery not holding a charge or not fitting their Power Wheels vehicle properly.
