Introduction

The GE Jasco Z-Wave Smart Switch 14280 is a versatile home automation device that allows users to control their lighting remotely via Z-Wave technology. Designed for easy installation, it replaces standard wall switches and integrates seamlessly with various smart home systems. The switch features a sleek design and can be controlled through mobile apps or voice commands, enhancing convenience and energy efficiency. Priced at approximately $39.99, it offers an affordable solution for modernizing your home.

Related Products

  • 28169
    Plug-In Smart Switch

  • 28167
    Plug-In Smart Dimmer

  • 14280
    Plug-In Dual Outlet Smart Dimmer

  • 28177
    Plug-In Dual Outlet Smart Switch with USB Charging

  • 28175
    Plug-In Dual Outlet Smart Dimmer with USB Charging

  • 14284
    Plug-In Outdoor Smart Switch


GE Jasco Z-Wave Smart Switch 14280 Specifications

  • Power: 120VAC, 60Hz Signal Frequency: 908.4/916
  • Maximum load for the Z-Wave controlled outlets: 600W (5A) Incandescent / 1/2 HP Motor or 1800W (15A)
  • Maximum load for the Z-Wave controlled outlet: Resistive Z-Wave controlled outlet is fused @ 5A. This fuse is not user-serviceable
  • Range: Up to 150 feet from the controller or closest Z-Wave device
  • Operating Temperature: 32-104° F (0-40° C)
  • Warranty: 2-year limited product warranty

For Indoor Use Only

Design Features

  • Turn the connected device On/Off manually via Z- Wave remote control
  • Remotely monitor with any mobile device*
  • Can be Included in multiple Groups and Scenes
  • Two Z-wave controlled AC outlets
  • Both Outlets controlled together (Cannot be controlled independently)
  • Remote ON/OFF control via the Z-Wave controller
  • Manual ON/OFF control with the top push-button
  • Space efficient design
  • Does not block the lower outlet when plugged in to the upper outlet of a duplex wall receptacle. (This assumes that the duplex receptacle is mounted with the ground pin down.)
  • Plugs and cords for connected devices route to the side allowing close placement of furniture
  • Utilizes the Z-Wave Firmware Update Meta Data command class for standardized firmware updates Over the Air
  • Z-Wave Plus certified
  • Two Toned coloring
  • Visit http://www.ezzwave.com/hubs/  for hub compatibility
  • Trilingual Instruction manual –(English, French, Spanish)

Z-Wave Plus Features

  • Works with Z-Wave Classic and Z-Wave Plus Products
  • 50% more wireless range
  • 250% faster processor
  • 400% more memory
  • 50% more energy efficient
  • Supports wireless upgrades to future-proof your home

Requires Z-Wave hub or controller, functions may vary depending on brand.

Description

In-wall installation is possible with the GE Jasco Z-Wave Smart Switch 14280, which takes the place of your current light switch. Its modern style goes well with the majority of home decor. The switch is adaptable for a range of lighting applications because it works with both incandescent and LED lights. You can manage your lights from anywhere in your home network thanks to its cutting-edge Z-Wave technology, which guarantees dependable connection between devices.

With just a few phrases, you can now effortlessly adjust your lighting with this smart switch's voice control capabilities via Google Assistant and Amazon Alexa. It also has scene management features, which let you create personalized lighting arrangements for different times of the day or occasions.

Two-Outlet Smart Switch

Wirelessly control both outlets simultaneously


Device Configuration

Adding your device to a Z-Wave network
Once the hub is ready to add your smart switch, press and release the top button on the smart switch to  add it in   the network.
To remove and reset the device
Once the controller is ready to remove your device, press and release the top button on the smart switch to remove it from  the network.
To return to factory defaults
If plugged in, unplug from the receptacle. Press and hold the  top button for at least 3 seconds while you plug the switch into the receptacle.
Certifications & Compliances
Compliances, specifications and availability are subject to change without notice Distributed by Jasco Products Company LLC 10 E. Memorial Rd., Oklahoma City, OK Jasco 2018


Setup Guide of GE Jasco Z-Wave Smart Switch 14280

  1. Turn Off Power: Ensure the power to the circuit is turned off at the main electrical panel before starting the installation.
  2. Remove Old Switch: Take out the existing light switch from the wall plate.
  3. Connect Wires: Connect the black (hot) wire to the brass terminal on the new switch, white (neutral) wire to the silver terminal, and ground wire to the green terminal.
  4. Mount New Switch: Securely fasten the new smart switch into place using screws provided.
  5. Pair Device: Follow instructions provided by your Z-Wave hub to pair the device with your network.
  6. Test Functionality: Turn on power and test that all functions are working correctly.

Troubleshooting

  • No Power: Check if power has been restored at the main electrical panel and ensure all connections are secure.
  • Device Not Pairing: Reset device by pressing reset button for 3 seconds then try pairing again.

Pros & Cons

Pros

  • Easy Installation: Step-by-step instructions make installation straightforward even for non-experts.
  • Wide Compatibility: Works seamlessly with various Z-Wave hubs and voice assistants.
  • Energy Efficiency: Allows real-time energy monitoring helping you reduce energy consumption.

Cons

  • Neutral Wire Requirement: Requires a neutral wire which may not be present in older homes.

Customer Reviews

Customers have generally praised the GE Jasco Z-Wave Smart Switch 14280 for its reliability and ease of use. Many appreciate how seamlessly it integrates into their existing smart home setups. However, some users have noted issues with connectivity when placed far from their hubs or in areas with high interference. Overall satisfaction remains high due to its robust feature set and user-friendly interface.

Faqs

First off, what is the Wave Smart Switch?

Using Z-Wave technology, the GE Jasco Z-Wave Smart Switch 14280 is a wireless smart switch with two outlets that enhances your home automation system by enabling remote control of connected devices.

What special design elements distinguish the GE?

This switch has two outlets—one that is Z-Wave controlled and the other that is always on—and a sleek, small design. It's ideal for configurations of smart homes that call for adaptable automation.

How does the Smart Switch two-outlet feature operate?

One Z-Wave-controlled outlet is provided by the GE for smart home automation, while the second outlet is always powered for conventional use.

How can I set up my smart hub to work with the GE Switch 14280?

Make sure your Z-Wave hub is in pairing mode before configuring the GE by pressing the switch's button to connect it. To further customize your hub, refer to the app's instructions.

Is Alexa and Google Assistant compatible with the GE Jasco Z-Wave?

When paired with a Z-Wave hub that is compatible, the GE 14280 is indeed compatible with voice control services like Alexa and Google Assistant.

What are the GE Jasco Z-Wave Smart Switch power requirements?

For resistive loads, the GE can support up to 600 watts of power, so you can connect a range of appliances, including fans, lights, and electronics.

What should I do if my GE Jasco 14280's Z-Wave outlet isn't functioning?

Verify that your hub is operating appropriately, examine the wire connections.

How energy-efficient is the Smart Switch?

Indeed, the GE aids in energy management by enabling you to remotely control and schedule devices, thereby guaranteeing their shutdown when not in use.

How can I set up the GE Jasco Z-Wave Smart Switch linked devices for automation?

Create automation rules, establish schedules, and remotely control the linked devices with the help of the Z-Wave hub app. You can alter when and how devices work with this app.
