Introduction

The Ivation IVFWCC181LBW Smart Freestanding Compressor Wine Cooler is a sophisticated solution for wine enthusiasts looking to preserve their collection at optimal temperatures. With a capacity to hold up to 34 standard 750ml bottles, it features advanced compressor technology for stable cooling and a temperature range of 41°F to 64°F. The wine cooler is Wi-Fi enabled, allowing users to monitor and adjust settings via the My Ivation app on their smartphones. Its UV-resistant double-paned glass door protects wine from harmful light, while soft interior lighting enhances visibility. Priced at $449.99, this wine cooler combines style and functionality for any wine lover.

PRODUCT OVERVIEW

GET TO KNOW YOUR WINE COOLER

1. Exterior
2. Shelves
3. Retainer bar
4. Feet
5. Upper door hinge with cover
6. Control panel
7. Glassdoor
8. Door gasket
9. Security lock
10. Bottom hinge

RECOMMENDED TEMPERATURE

TECHNICAL SPECIFICATIONS

• IVFWCC181LBW:
  • Power Supply: 115 V, 60 Hz
  • Rated Power: 95 W
  • Unit Dimensions (W x D x H):  13.6" x 17.7" x 30.3" (345 x 450 x 770 mm)
  • Net Weight: 45.65 lbs. (20.71 kg)
• IVFWCC341LBW:
  • Power Supply: 115 V, 60 Hz
  • Rated Power: 90 W
  • Unit Dimensions (W x D x H): 18.7" x 17.3" x 33.1" (474 x 440 x 840 mm)
  • Net Weight: 55.57 lbs. (25.21 kg)
• IVFWCC281LBW:
  • Power Supply: 115 V, 60 Hz
  • Rated Power: 95 W
  • Unit Dimensions (W x D x H): 16.9" x 17.7" x 33.1" (430 x 450 x 840 mm)
  • Net Weight: 49.6 lbs. (22.5 kg)

FEATURES

YOUR WINE COOLER FEATURES

• Control cooler from your smartphone with Wi-Fi® connectivity
• Keeps red and/or white wines at their proper temperature
• One-touch controls and LCD display
• Interior lighting with independent on/off control
• Celsius or Fahrenheit, adjustable by one-degree increments
• Chrome shelves are easy to pull out
• Automatic panel lock
• Tempered smoked glass door protects from UV rays
• Black metal exterior
• CFC-free solid polyurethane foam insulation
• Lockable door for added security and peace of mind

SAFETY PRECAUTIONS

 WARNING: Please read and understand all instructions before operating this appliance.

1. WARNING: CHOKING HAZARD – Small parts. This product contains small parts and is not suitable for children under 3 years old.
2. Remove all packaging before using this device. Please keep all packaging materials out of reach of children and pets.
3. Properly dispose of all packing materials immediately after unpacking product, as the bags used for packaging could present a suffocation or choking hazard.
4. Read all instructions carefully before attempting to operate this device. Improper usage could result in injury or a reduction in efficacy.
5. Never allow children to operate, play with, or crawl inside the appliance.
6. Keep all flammable liquids or materials away from this unit. Failure to do so may result in a fire or explosion.
7. Keep out of direct sunlight and away from heat sources.
8. Do not attempt to repair or replace any parts or service this unit unless specifically recommended in this User Guide.
9. Use only with a properly grounded, standard 115 V 60 Hz electrical outlet to avoid the risk of electrical shock.
10. Do not use with an extension cord.
11. Do not place any objects on the top of the unit.

IMPORTANT SETUP NOTES

• Before plugging in your Wine Cooler, allow it to stand upright for three (3) hours.
• Place only on a flat, level surface that will support the full weight once the wine cooler has been fully loaded. You can ensure the unit is level by placing a small ball on top and checking to make sure it does not roll in any direction.
• Position the cooler in a dry, well-ventilated space with temperatures between 41 °F – 90 °F (5 °C – 32 °C).
• Leave a space of at least 6" in the back of the unit and 10" on both sides.
• Do not use without feet: the unit requires 2" of ground clearance.
• If you are discarding an old unit, remove its door and leave shelves in place to avoid an entrapment hazard.

NOTE: It is normal for your wine cooler to make a whirring sound that will cycle up when the compressor is working harder to chill your wine, and cycle down as the temperature lowers.

Description

The Ivation IVFWCC181LBW Smart Freestanding Compressor Wine Cooler is designed with both form and function in mind. Its sleek and modern exterior fits seamlessly into any home decor, while the interior features adjustable shelving to accommodate various bottle sizes. The LED touchscreen interface allows for easy temperature adjustments and monitoring, ensuring your wines are stored at the perfect temperature. The unit also includes a built-in humidity control system to maintain optimal conditions for wine aging.

One of the most innovative features of this cooler is its smart technology. With Wi-Fi connectivity, you can control and monitor the cooler remotely through the ivation app. This allows you to adjust settings, receive notifications, and ensure your wines are always at the right temperature, even when you're not at home.

Ivation IVFWCC181LBW USAGE

USING YOUR CONTROL PANEL

1. Unlock the control panel by pressing and holding the button for two (2) seconds. A beep will alert you that the panel has been unlocked.
2. Adjust the temperature in one (1) degree increments by pressing and holding the ( and ) buttons until the desired temperature is reached.
3. To switch between Fahrenheit and Celsius, press and hold the button for two (2) seconds.
4. You can also turn the interior light on or off by pressing the button. The light will stay on until you turn it off.

SETTING UP WI-FI

INTERNET ACCESS MODE
Press and hold the and buttons for more than three (3) seconds to switch to Internet access mode. Then, the indicator will start to blink rapidly.
NOTE: The wine cooler will exit set-up mode after three (3) minutes of nonuse.
PREPARATION BEFORE USE

1. Make sure your wine cooler is on and ensure that your smartphone is connected to 2.4 GHz Wi-Fi network.
   NOTE: This device works only on 2.4 GHz Wi-Fi network.
2. Download the My Ivation app from the App Store or Google Play.
   NOTE: Authorize the app to access network and location services.
3. If you are using the app for the first time, click the “Sign up” button and register. If you already have an account, click the “Log in” button.

ADD DEVICE TO YOUR SMARTPHONE

1. From the Home Page, click “Add Device.”
2. You may also add a device by selecting + in the top right corner of the screen. (If you already have a device added to your account, the "Add Device" button will not appear.)
3. 3.    Select the wine cooler device you are trying to connect to.
   4.    When the indicator blinks rapidly, click “Confirm.” Select your Wi-Fi® network. Then, enter your router password.
   5.    Wait up to 60 seconds for the process to be complete. Once complete, the indicator will stop blinking and remain lit.
   6.    Once the device is added, you can use the menu to change the name and location of the device.
   7.    When you are finished, click “Done.”

NOTE: If the indicator light on the wine cooler blinks rapidly, the wine cooler is in EZ mode (default). If the indicator light blinks slowly, the wine cooler is in AP mode (compatibility).
IF YOU HAVE TROUBLE CONNECTING

1. While the indicator light is blinking rapidly, press and hold and buttons for more than three (3) seconds again to switch to AP mode.
2. Wait for the beep and after a few seconds, the indicator light will start to blink slowly.
3. From the Home Page, click “Add Device.”
4. Click “AP Mode” in the top right corner.
5. Click “Confirm.”
6. Select your Wi-Fi network.
7. Enter your password.
8. Click “Confirm.” The next screen will say “Connect your mobile phone to the device’s hotspot.”
9. Click “Go to connect.” This will take you to your phone’s settings (or Wi-Fi® list for Android®).
10. Select “SL-Ivation-XXXXX.”
11. Navigate back to the My Ivation App.
12. Click “Next.” Your smartphone will automatically connect.
13. Wait up to 60 seconds for the process to complete. Once complete, the indicator will stop blinking and remain lit.
14. Once the device is added, you can use the menu to change the name and location of the device.
15. When you are finished, click “Done.”

REMOVE DEVICE FROM APP

1. First method – Removing connection with the wine cooler: Press and hold the  and buttons for more than three (3) seconds to exit the network connection. The cooler will remove itself from the app and go back to a reset state.
2. Second method – Removing connection with the app: Open the app and go to the device page. Press and hold the wine cooler device. A message showing “Delete device or dismiss group” will appear.” Press “Confirm”, and the device will be disconnected.

WINE COOLER HOMEPAGE MENU

Here are the functions featured in the app to operate your wine cooler.

•    Set and control the degree in the temperature.
•    View the currently set temperature.
•    Turn the interior light on and off.

DE-ICING YOUR WINE COOLER

• The unit’s Auto Defrost feature should prevent ice accumulation from occurring.
• However, should ice accumulation occur, you can do the following:
  • Unplug the Wine Cooler
  • Wait for all ice to melt
  • Once melting is complete, remove water from the unit
  • Plug in and restart the unit

Setup Guide

Setting up the ivation Smart Freestanding Compressor Wine Cooler is straightforward and can be completed in a few steps:

1. Unbox the unit and remove all packaging materials.
2. Place the cooler on a level surface, ensuring proper ventilation around it.
3. Plug in the unit and turn it on.
4. Use the LED touchscreen interface to set your desired temperature and humidity levels.
5. Download and install the ivation app on your mobile device to connect the cooler via Wi-Fi.
6. Configure the app settings according to your preferences.

HOW TO CLEAN YOUR WINE COOLER

TO CLEAN THE EXTERIOR

• Unplug before cleaning.
• Do not use abrasive cleaning products.
• Wash the cabinet exterior only with mild soap and water and rinse thoroughly.
• Clean the glass door with glass cleaner or mild soap and water and a soft cloth.
• Wipe the control panel with a damp cloth and dry thoroughly. To avoid damaging the panel, do not use cleaning sprays or over-saturated.

TO CLEAN THE INTERIOR

• Unplug before cleaning.
• Do not use abrasive cleaning products.
• Cleaning the door gasket:
  • Use mild soap or baking soda solution
  • Rinse well
  • Apply a thin layer of petroleum jelly to the gasket at the hinge side to prevent sticking
• Use a warm water and baking soda solution inside the unit (about one tablespoon of baking soda to one quart of water) to clean and neutralize odors.

TROUBLESHOOTING

• If the unit doesn’t work:
  Check to make sure the power supply has the correct voltage. Also, check to make sure there is not a circuit breaker that has been tripped or has blown a fuse.
• If the unit isn’t getting cold enough:
  Make sure the temperature settings are adjusted correctly.
• If so, the room in which the unit is operating might be too hot:
  Also, check whether the door has been opened too frequently or has not been completely closed. Check the seal on the door to make sure it is intact. Make sure the unit has sufficient clearance on all sides.
• If the unit vibrates or makes excessive noise:
  Make sure the unit has been placed on a level, stable surface. Also, check to make sure the fan is working properly.
• If the LED display is not working or shows an error message:
  Check to see if the unit is plugged in properly. If so, there may be a problem with the main circuit board that requires professional servicing.
• If the buttons don’t work:
  The control panel may be damaged.

WARRANTY

EXCLUSIONS AND LIMITATIONS
The Company warrants the Product against defects in materials and workmanship under normal use for a period of ONE (1) YEAR from the date of retail purchase by the original end-user purchaser (“Warranty Period”).

Pros & Cons

Pros:

• Advanced compressor cooling system for consistent temperature control.
• Smart technology with Wi-Fi connectivity and mobile app control.
• Large capacity to hold up to 18 standard wine bottles.
• Adjustable shelving and humidity control system.
• Sleek and modern design that fits well with home decor.

Cons:

• Higher power consumption compared to thermoelectric coolers.
• Noisy operation due to the compressor.
• Requires regular maintenance to ensure optimal performance.
• More expensive than basic wine coolers on the market.

Customer Reviews

Customers have praised the Ivation IVFWCC181LBW Smart Freestanding Compressor Wine Cooler for its reliable temperature control and user-friendly interface. Many have appreciated the smart features that allow remote monitoring and control. However, some users have noted that the unit can be noisy and consumes more power than expected.
