Introduction of La Crosse Curved LED Alarm Clock

The La Crosse Curved LED Alarm Clock is a stylish and functional addition to any bedroom. This clock features a large, easy-to-read curved LED display that shows the time, date, and temperature. It also has a built-in alarm and snooze function, making it the perfect choice for those who need a little extra help waking up in the morning. The estimated price of this product is $29.99, and it is now available for purchase.

SPECIFICATIONS

• Power Requirements: 5V 1.2A AC/DC adapter HX06-0501200AU-001
  Optional CR2032 battery (not included)
• USB output: 1A maximum current.

POWER UP

1. Insert the provided stand into bottom of clock.

2. Insert the 5.0 volt power cord into an outlet, then into your clock. Optional: Install 1-CR2032 battery (not included).



SETTINGS

• Hold then release the SET button to enter settings menu.
• Press and release the + or - buttons to adjust the values. Hold to adjust quickly.
• Press and release the SET button to confirm and move to the next item.

Settings menu order

1. Hour
2. Minutes
3. 12/24 hour time
4. Year
5. Month
6. Date
7. Snooze Duration “n05” (5-60 minutes)

TIME ALARMS

• Hold then release the AL 1∙2 button to enter alarm set mode.
• Press and release the + or - buttons to adjust the values. Hold to adjust quickly.
• Press and release the AL 1∙2 button to confirm and move to the next item.
• Press SET button anytime to exit alarm set mode.

Alarm setting order

1. Alarm 1 Hour
2. Alarm 1 Minutes
3. Alarm volume “HI” or “LO”
4. Number of days for alarm:
   1. 1-7 = Monday to Sunday
   2. 1-5 = Monday to Friday
   3. 6-7 = Saturday and Sunday
   4. 1-1 = one day alarm.
5. Alarm 2 settings (follow steps 1-4)

Turn off sounding alarm for 1 day

• When alarm 1 or 2 is sounding, the alarm icon A1 or A2 flashes.
• Press the AL 1.2 button once to stop the alarm and reset it to come on the following day.
• The A1 and/or A2 icon will remain on, indicating it is still active for the next time set to alarm.

Activate | Deactivate Time Alarms

1. Press the AL1.2 button once to activate Alarm 1, A1 will appear
2. Press the AL1.2 button a second time to activate Alarm 2. A2 will appear.
3. Press the AL1.2 button a third time to activate both Alarm 1 and 2. Both A1 and A2 will appear.
4. Press the AL1.2 button a fourth time to deactivate both alarms. Both the A1 and A2 icons will disappear.

Snooze

When an alarm sounds, press the button to silence the alarm for the 5 minutes or the snooze duration selected in the settings menu. AL1 or AL2 will flash.

ADJUSTABLE BACKLIGHT & AUTO DIM

Adjustable Backlight: Press and release the AUTO DIM SET button to adjust backlight HI-LO-OFF.
Auto Dim: Customize your clock to dim automatically.

1. Hold AUTO DIM SET button for 3 seconds to enter Auto Dim settings. Press and release the + or - button to turn Auto Dim feature ON.”
2. Press and release AUTO DIM SET button to confirm and move to the Auto Dim start time. Press and release the + or -button to select start time.
3. Press and release AUTO DIM SET button to confirm and move to the duration (1-12 hours).  Press and release the + or -button to select duration.
4. Press and release AUTO DIM SET button to confirm and exit.

Auto Dim setting order

• ON/OFF
• Start time
• Duration (1-12 hours)

TIP: The light indicator will show when Auto Dim is set.

DAYLIGHT SAVING TIME ADJUSTMENT

• When observing Daylight Saving time: Hold the DST/- button for 3 seconds to move your time ahead 1 hour.
• The letter “D” will show between the hours and minutes when DST is active.
• When observing Standard time: Hold the DST/- button for 3 seconds to move your time back 1 hour.

MIN/MAX MEMORY La Crosse Curved LED Alarm Clock

Select MIN/MAX duration:

• Hold the MEMORY/+ button to select  MIN/MAX duration (24 / 48 / 72 or 96 hours).  “24 Hr” andwill flash.
• Press and release the MEMORY/+ or DST/- buttons to select.
• Hold the MEMORY button to exit.

View MIN/MAX Temperature/Humidity Readings

Press and release the MEMORY button to view: maximum, then minimum temperature/humidity readings for the duration selected.

USB CHARGING PORT

Note: This is a power-output charging port. It does not provide power to the alarm clock.

• Connect your external device’s USB charging cable (not included) to the USB charging port.
• Charging times will vary.
• USB Power Output: 1A maximum current.
• Charge 1A devices or devices that are self- regulating.

Description

The La Crosse Curved LED Alarm Clock has a sleek and modern design, with a curved LED display that is easy on the eyes. The display shows the time, date, and temperature, and it can be adjusted for brightness to suit your preferences. The clock also has a built-in alarm and snooze function, with a large snooze button on the top of the clock for easy access. The clock is powered by an AC adapter (included), and it also has a backup battery compartment for added peace of mind.

CARE AND MAINTENANCE

• Do not mix old and new batteries.
• Do not mix Alkaline, Lithium, standard, or rechargeable batteries.
• Always purchase the correct size and grade of battery most suitable for intended use.
• Clean the battery contacts and also those of the device prior to battery installation.
• Ensure the batteries have with correct polarity (+ / -).
• Remove batteries from equipment that will not to be used for an extended period.
• Promptly remove expired batteries.

Troubleshooting

If you are having trouble with your La Crosse Curved LED Alarm Clock, here are some common problems and solutions:

• The clock is not keeping time: Make sure that the clock is plugged in and that the AC adapter is working properly. If the problem persists, try resetting the clock by unplugging it, waiting a few seconds, and then plugging it back in.
• The alarm is not going off: Make sure that the alarm is set to the correct time and that the alarm volume is turned up. If the problem persists, try resetting the clock as described above.
• The display is too bright/dim: The display brightness can be adjusted by pressing the "Brightness" button on the back of the clock. If the problem persists, try resetting the clock as described above.

Warranty Info La Crosse Curved LED Alarm Clock

• La Crosse Technology, Ltd. provides a 1-year limited time warranty (from date of purchase) on this product relating to manufacturing defects in materials & workmanship.
  For Full Warranty Details, Visit: https://lacrossetechnology.zendesk.com/hc/en-us

La Crosse Curved LED Alarm Clock Pros & Cons

• Pros
  • Large, easy-to-read curved LED display
  • Displays time, date, and temperature
  • Built-in alarm and snooze function
  • Adjustable display brightness
  • Powered by AC adapter (included) with backup battery compartment
• Cons
  • No radio or other additional features
  • Some users may find the display too bright, even at the lowest setting

Customer Reviews

Customers who have purchased the La Crosse Curved LED Alarm Clock have praised its sleek design and easy-to-read display. However, some have noted that the display can be too bright, even at the lowest setting. Overall, customers have found this clock to be a reliable and functional addition to their bedrooms.
