Introduction

Midea Window Air Conditioner MAP14HS1TBL can cool rooms up to 14,000 BTU and heat rooms up to 700 square feet, so it works well in big rooms. This energy-efficient air conditioner has several modes, such as cooling, heating, fan, and dehumidification, so you can easily control the temperature inside. The MAP14HS1TBL has a 24-hour programmable timer, a washable filter, and digital controls that are easy to use. This makes it a reliable and simple choice for keeping your home comfortable.

Tools Needed

• Phillips screwdriver
• Tape measure or ruler
• Knife or scissors
• Saw (optional, to shorten window adaptor for narrow windows).

Accessories

Remote Control Specifications

Function Buttons

Remote Screen Indicators

Information is displayed when the remote control is powered on.

The Comfort SENSE function enables the remote control to measure the temperature at its current location and send this signal to the air conditioner every 3 minutes interval. When using AUTO, COOL or HEAT modes, measuring ambient temperature from the remote control(instead of from the indoor unit itself) will enable the air conditioner to optimize the temperature around you and ensure maximum comfort.

Setting the Timer

TIMER ON/OFF – Set the amount of time after which the unit will automatically turn on/off.

TIMER ON SETTING

• Press the TIMER ON button to initiate the ON time sequence.
• Press the up or down button for multiple times to set the desired time to turn on the unit.
• Point remote to unit and wait 1sec, the TIMER ON will be activated.

TIMER OFF SETTING

• Press the TIMER OFF button to initiate the OFF time sequence.
• Press up or down button for multiple times to set the desired time to turn off the unit.
• Point the remote to unit and wait 1sec, the TIMER OFF will be activated.

NOTICE

1. When setting the TIMER ON or TIMER OFF, the time will increase by 30 minutes increments with each press, up to 10 hours. After 10 hours and up to 24, it will increase in 1 hour increments. (For example, press 5 times to get 2.5h, and press 10 times to get 5h,). The timer will revert to 0.0 after 24.
2. Cancel either function by setting its timer to 0.0h.

TIMER ON & OFF setting (example)
Keep in mind that the time periods you set for both functions refer to hours after the current time.

Example: If current timer is 1:00PM, to set the timer as above steps, the unit will turn on 2.5h later (3:30PM) and turn o at 6:00PM.

SPECIFICATION OF WIRELESS MODULE

PRECAUTIONS

1. Supports operating systems: iOS 7+ or Android 4+.
2. In the event of a OS update, there may be a delay between the update of the OS and a related software update during which your OS may or may not be supported until a new version is from working and Toshiba will not be responsible for any problems that could be caused by incompatibility or network issues.
3. This Smart AC only supports WPA-PSK/WPA2-PSK (recommended) encryption.
   Please check the Toshiba Lifestyle website, us.toshiba-lifestyle.com, for updated information.
4. To ensure proper scanning of the QR code, your smartphone must have at least a 5-megapixel camera.
5. Due to unstable network connectivity, requests may time out. If this happens, re-run the network duration.
6. Due to unstable network connectivity, commands may time out. If this happens, the smartphone’s actual product is always the most accurate available. Refresh the app to re-sync.

NOTICE
Toshiba will not be responsible for any problems that could be caused by incompatibility or network issues, your wireless router, and mobile phone.

OPERATING INSTRUCTIONS

Preparation

Unit Operating Temperature Range

Control Panel Features

• Swing Button
  Used to initiate the Auto Swing feature. When the operation is ON, pressing the SWING button can stop the louver at the desired angle.

• Connect Button is Also used to initiate the wireless connection mode. To initiate the wireless connection mode, power on the air conditioner then press the SWING button for 3 seconds. The LED DISPLAY will show ‘AP’ to indicate the unit is in wireless connection mode. Refer to the app connection instructions to sh the connection process.
  If the connection is successful, the unit will exit wireless connection mode and illuminate the wireless LED. If the connection fails, the unit will exit wireless connection mode automatically after 8 minutes and the wireless LED does not illuminate.
  Note: The wireless connection process must be completed within 8 minutes after powering the air conditioner on.

• Timer button
  Used to initiate the AUTO ON start time and AUTO OFF stop time program. The timer on or off will illuminate depending on the selected setting.

• Fan button
  Controls the fan speed. Press to control the fan speed in four steps – LOW, MID, HIGH, and AUTO. The selected fan speed light will illuminate.
  NOTE: Applicable to models with the Constant Fan feature. In COOL or DRY mode, press the Fan button forthe constant fan function.

• When the function is turned on, the constant fan light will illuminate, indicating the fan will run constantly, independent of compressor operation. light will go out, indicating that the fan will stop when the compressor stops.
  Mode button
  Select the desired operating mode. Each time you press the button, a mode is selected in a sequence that goes from AUTO, COOL, DRY, FAN, and HEAT (cooling-only models excluded). The mode light illuminates and indicates the selected mode.

• Up () and Down () buttons
  Used to increase/decrease temperature settings in 1° increments in a range of 60°F/16°C to 86°F/30°C or the TIMER setting in a range of 0 ~ 24hrs. To change between °F or °C, simultaneously press and hold the Up and Down buttons for 3 seconds.

• Power button
  Power switch on/off

• Sleep button
  Press the SLEEP button to initiate the SLEEP operation and the sleep light illuminates. Press the SLEEP button again to stop the SLEEP operation and the sleep light turns dark. Press SLEEP button for 3 seconds operation. The LED(the light above the button) will illuminate after 250 hours of operation.

• LED display
  Shows the set temperature in °F (Degrees Fahrenheit) or °C (Degrees Celsius) and the Auto-timer settings. While on FAN modes, it shows the room temperature.

Shows Error codes and protection codes The unit may stop operation or continue to run safely. If the error codes appear, wait for about 10 minutes. The problem may resolve itself. If not, disconnect the power, then connect it again. Turn the unit on. If the problem persists, disconnect the power and contact your nearest customer service center. Error code appears and begins with the letters as the following in the window display of the indoor unit: EH(xx), EL(xx), EC(xx), PH(xx), PL(xx), PC(xx)
The bottom tray is full – Connect the drain hose and drain the collected water away. If the protection code repeats, call for service.

Description

The Midea Window Air Conditioner MAP14HS1TBL is a powerful and energy-efficient air conditioning unit that is perfect for small to medium-sized rooms. With its 14,000 BTU cooling capacity and 11.2 EER, this window AC unit can cool down a room quickly and efficiently. The 3 cooling speeds allow for customized cooling, while the 24-hour timer and remote control provide added convenience. The washable filter reduces the need for expensive replacements and helps maintain clean air. With its low noise level of only 51 dB, this window AC unit is perfect for bedrooms, living rooms, and offices.

Operating Instructions

COOL operation

• Press the “MODE” button until the “COOL” indicator light comes on.
• Press the ADJUST buttons Up () or Down () to select your desired room temperature. The temperature can be set within a range of 60°F~86°F/16°C~30°C.
• Press the “FAN SPEED” button to choose the fan speed.

HEAT operation

• Press the “MODE” button until the “ HEAT ” indicator light comes on.
• Press the ADJUST buttons Up () or Down () to select your desired room temperature. The temperature can be set within a range of 60°F~86°F/16°C~30°C.
• Press the “FAN SPEED” button to choose the fan speed. For some models, the fan speed cannot be adjusted while in HEAT mode.

DRY operation

• Press the “MODE” button until the “DRY” indicator light comes on.
• While in this mode, you cannot select a fan speed
• The fan motor operates at AUTO speed.
• Keep window Do not put the duct to window ws and doors closed for the best etc.

AUTO operation

• When you set the air conditioner to AUTO mode, it will automatically select cooling, heating (cooling-only models excluded), or fan-only operation depending on what temperature you have selected and the current room temperature.
• The air conditioner will control room temperature automatically according to the temperature point set by you.
• Under AUTO mode, you cannot select the fan speed.

FAN operation

• Press the “MODE” button until the ”FAN“ indicator light comes on.
• Press the “FAN SPEED” button to choose the fan speed. The temperature cannot be adjusted.
• Do not connect the duct to a window.

TIMER: Auto Start/Stop Operation

• When the unit is on, pressing the Timer button will initiate the Auto-stop program. The TIMER OFF indicator light illuminates. Press the Up() or Down () button to select the desired time. Press the TIMER button again within 5 seconds. The Autostart program is initiated and the TIMER ON indicator light illuminates. Press the Up () or Down () button to select the desired Auto start time. , press the Timer button to initiate the Auto Start program. Pressing it again ve seconds will initiate the Auto-stop program.
• Press or hold the Up () or Down () button to change the Auto time by 0.5-hour increments, up to 10 hours, then at 1-hour increments up to 24 hours. The control will count down the time remaining until the start.
• The system will automatically revert back to display the previous temperature setting if there is no operation within 5 seconds.
• Turning the unit ON or OFF at any time or adjusting the timer setting to 0.0 will cancel the Auto Start/Stop timer program.
• Should a malfunction occur, the Auto Start/Stop timed program will also be canceled.

SLEEP operation
Pressing this button will increase (during cooling operation) or decrease (during heating operation, applicable models) by 2°F/1°C after 30 minutes. The temperature will again increase (cooling) or decrease (heating) by another 2°F/1°C after an additional 30 minutes. This new temperature will be maintained for 7 hours before returning to the originally selected temperature. This ends the Sleep mode and the unit will continue to operate as originally programmed.

NOTICE
The SLEEP operation feature is unavailable in FAN or DRY mode.

Other Features

COMFORT SENSE feature
This feature can ONLY be activated from the remote control. The remote control serves as a remote thermostat allowing for precise temperature control at its location, which must be within 26 feet of the air conditioner. To activate the Comfort Sense feature, point the remote control towards the unit and press the set button to select. The remote’s display will show the actual temperature at its location (as long as it is within 26 feet of the air conditioner). The remote control will send this signal to the air conditioner every 3 minutes until the C-Sense function is selected again. If the unit does not receive the Comfort Sense signal during any 7 minutes interval, the unit will exit the Comfort Sense mode.
NOTE: This feature is unavailable under FAN or DRY mode.
AUTO-RESTART
If the unit shuts off unexpectedly due to a power outage, it will restart with the previously set function automatically when the power resumes.
WAIT 3 MINUTES BEFORE RESUMING THE OPERATION
After the unit has stopped, it cannot be restarted until 3 minutes have elapsed. This is to protect the unit. The operation will automatically resume after 3 minutes.
AIRFLOW DIRECTION ADJUSTMENT
The louver can be adjusted automatically using the SWING button.

• When the Power is ON, the louver opens fully.
• Press the SWING button on the panel or remote controller to initiate the Auto Swing feature. The louver will swing up and down automatically.
• Please do not adjust the louver manually.

WATER DRAINAGE
During Dry modes, remove the upper drain plug from the back of the unit and install the drain connector (5/8” universal female adapter) with a 3/4“ hose (not included) For models without drain connector, just attach the drain hose to the hole. Place the end of the hose directly in the drain area you’re using.

WATER DRAINAGE (Under heat mode)

Remove the middle drain plug from the back of the unit and install the drain connector (5/8” universal female adapter) with a 3/4“ hose (not included). For models without the drain connector, attach the drain hose to the connector. Place the end of the hose in the drain area you’re using.

NOTICE

• The drain hose can be elevated up to 6ft (1.8m). Direct the hose toward the drain, making sure that there are no kinks that will restrict water flow. Place the end of the hose into the drain and make sure the end of the hose is directed downward (See Figs with ).

• Figures with X are installations not recommended by the manufacturer. When the continuous drain hose is not used, ensure the drain hose can be elevated up to 6ft (1.8m). Direct the hose toward the drain, making sure that there are no kinks that will restrict water flow. Place the end of the hose into the drain and make sure the end of the hose is directed downward (See Figs with ).

• Figures with X are installations not recommended by the manufacturer. When the continuous drain hose is not used, ensure prevent leaks.



• When the water level of the bottom tray reaches a predetermined level, the unit beeps 8 times. The digital display shows “P1.” At this time the air conditioning/ cation process will immediately stop. However, the fan motor will continue to operate (this is normal). Carefully move the unit to a drain location, remove the bottom drain plug and let the water drain away. Reinstall the bottom drain plug and restart the machine until the “P1” symbol disappears. If the error repeats, call for service.



INSTALLATION INSTRUCTIONS

Choosing the Right Location

Your installation location should meet the following requirements:

• Make sure that you install your unit on an even surface to minimize noise and vibration.
• The unit must be installed near a grounded plug, and the Collection Tray Drain (found on the back of the unit) must be accessible.
• The unit should be located at least 9.8” (25cm) from the nearest wall to ensure proper air conditioning. The horizontal louver blade should be at least 50cm (19.7”) away from obstacles.
• DO NOT cover the Intakes, Outlets or Remote Signal Receptor of the unit, as this could cause damage to the unit.

Recommended Installation

NOTICE

The appearance of your unit might be slightly different.

WARNING

• This air-conditioning unit is a hermetically sealed unit that contains c information on the type of gas and the amount, please refer to the relevant label on the unit itself.
• Service, maintenance or repair of this unit must be performed certified technician.
• Product recycling must be done according to local regulations.
  Scan this QR code to watch an installation video for your Toshiba portable air conditioner:

Window Installation Kit

1. For Hung Window types only
   Insert the Air Exhaust Adapter into the exhaust of the hose (the circle opening). Rotate the adapter clockwise until the locking tabs click and no longer rotates.
   Skip this step if installing into a horizontal sliding window.



2. Preparing the adjustable window slider



   1. Depending on the size of your window, adjust the size of the window slider.

   2. If the length of the window requires two or more window sliders, use the bolt to fasten the window sliders once they are adjusted to the proper length.



   3. Paste the insulator on the inside of the Window sliders.



3. Assembling the Sliding Window Adapter (Only needed for Sliding Window applications).
   Align both halves of the sliding window adapter and connect them. Then, attach the air divider to the newly formed window adapter on the outdoor side. The fully assembled adapter should look like the image at the left.



Type 1: Hung window installation

1. Cut the adhesive foam seal A and B strips to the proper lengths, and attach them to the window sash and frame as shown.



2. Insert the window slider assembly into the window opening. If the hose opening is covered by the window frame, rotate the panel so the thicker side faces the window frame.
   Attach the Window Kit Brace to the back of the hose panel – trim the brace if necessary.



3. Cut the non-adhesive foam seal C strip to match the width of the window. Insert the seal between the glass and the window frame to prevent air and insects from getting into the room.
4. If desired, install the security bracket with 2 screws as shown.

5. Attach the Hung Window Adapter to the hose by lining up the circles on the adapter the hose. Insert the window slider adapter into the hole of the window slider.



Type 2: Sliding window Installation (Optional)

1. Cut the adhesive foam seal A and B strips to the proper lengths, and attach them to the window sash and frame as shown.



2. Insert the window slider assembly into the window opening. Insert the slider assembly into the window opening. If the hose opening is covered by the window frame, rotate the panel so the thicker side faces the window frame.
   Attach the Window Kit Brace to the back of the hose panel – trim the brace if necessary.



3. Cut the non-adhesive foam seal C strip to match the window height. Insert the foam seal between the glass and the window frame to prevent air and insects from getting into the room.
4. If desired, install the security bracket with 2 screws as shown.

5. Attach the Sliding Window Adapter to the hose by lining up the circles on the adapter the hose. Insert the window slider adapter into the hole of the window slider.



Air hose insulator Installation(only for heat pump mode) (only for heat pump mode)

NOTE: When the unit is at heat mode, the Air Hose insulator must be fixed in the hose of the unit.

1. Cover the Air Hose with the Air Hose insulator.
2. Pull out the Air Hose and cut the useless part of the Air Hose insulator.
3. Tighten the air hose with the Ribbons and cut useless parts.

NOTICE
To ensure proper function, DO NOT overextend or bend the hose. Make sure that there are no objects within 20in (~500mm) of the inlet and outlet hose. All illustrations in this manual are for explanation purposes only, your air conditioner may be slightly different than shown.

Setup Guide

To set up the Midea Window Air Conditioner MAP14HS1TBL, follow these steps:

1. Select a window with sufficient space for the unit.
2. Slide the side panels outwards and secure them in place.
3. Mount the unit in the window by extending the panels and securing them with the provided brackets and screws.
4. Plug in the unit and turn it on using the remote control.
5. Adjust the cooling settings to your preference.

CARE AND CLEANING

Safety Precautions

• Always unplug the unit before cleaning or servicing.
• DO NOT use flammable liquids or chemicals to clean the unit.
• DO NOT wash the unit under running water. Doing so causes electrical danger.
• DO NOT operate the machine if the power supply was damaged during cleaning. A damaged power cord must be replaced with a new cord from the manufacturer.

Air Filter Cleaning

CAUTION

DO NOT operate the unit without fi lter because dirt and lint will clog it and reduce performance.

Maintenance Tips

• Be sure to clean the air filter every 2 weeks for optimal performance.
• The water collection tray should be drained immediately after P1 error occurs, and before storage to prevent mold.
• In households with animals, you will have to periodically wipe down the grill to prevent blocked airflow due to animal hair.

Unit Cleaning

Clean with a soft cloth only. Do not use strong detergents that contain wax or thinners as it may damage the product.

Store the Unit When Not in Use

• Drain the unit’s water collection tray according to the instructions in the following section.
• Run the unit on FAN mode for 12 hours in a warm room to dry it and prevent mold.
• Turn off the unit and unplug it.
• Clean the air filter according to the instructions in the previous section. Reinstall the clean, dry filter before storing.
• Remove the batteries from the remote control.

NOTICE
Be sure to store the unit in a cool, dark place. Exposure to direct sunlight or extreme heat can shorten the lifespan of the unit.

REMOTE CONTROL AND APP INSTRUCTIONS

Handling the Remote Control

LOCATION OF THE REMOTE CONTROL

Use the remote control within a distance of 26 ft. (8m) from the air conditioner, pointing it towards the unit. The unit will beep when it receives a signal.

CAUTION

• The air conditioner will not operate if curtains, doors or other materials block the signals from the remote control to the unit.
• Prevent any liquid from spilling onto the remote control.
  Do not expose the remote control to direct sunlight or heat.
• If the infrared signal receiver on the indoor unit is exposed to direct sunlight, the air conditioner may not function properly.
  Use curtains to prevent the sunlight from falling on the receiver.
• If other electrical appliances react to the remote control, either move these appliances or consult your local dealer.

Inserting and Replacing Batteries

Your air conditioning unit may come with two AAA batteries (some units). Put the batteries in the remote control before use.

1. Slide the back cover from the remote control downward, exposing the battery compartment.
2. Insert the batteries, paying attention to match up the (+) and (-) ends of the batteries with the symbols inside the battery compartment.
3. Slide the battery cover back into place.

BATTERY NOTES
For optimum product performance:

• Do not leave batteries in the remote control if
• Do not mix old and new batteries or batteries of different types. you don’t plan on using the device for more than 2 months.

BATTERY DISPOSAL
Ensure used batteries are disposed of properly.
TIPS FOR USING REMOTE CONTROL

• The remote control must be used within 26 feet / 8 meters of the unit.
• The unit will beep when it receives a signal from the remote. Curtains, other materials and direct sunlight can interfere with the IR signal receiver.
• In order to properly transmit a command, the ON/OFF indicator must be illuminated on the remote’s display. (See the Remote LED Screen Indicators section for more information.)

SAFETY PRECAUTIONS

To prevent injury to the user or other people and property damage, the instructions shown here must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The level of risk is shown by the following indications.
WARNING This symbol indicates a hazardous situation that, if not avoided, could result in death or serious injury.
CAUTION This symbol indicates a hazardous situation, which, if not avoided, could result in minor or moderate injury.
NOTICE This symbol addresses practices not related to physical injury.

WARNING

• Be sure the air conditioner has been securely and correctly installed according to the installation instructions in this manual. Save this manual for possible future use in removing or installing this unit.
• Plug in the power cord plug properly. Otherwise, it may cause electric shock or fire due to excess heat generation.
• Do not modify the power cord length or share the outlet with other appliances as it may cause electric shock or fire due to overheating.
• Always ensure effective grounding. The incorrect grounding may cause electric shock.
• Unplug the unit if you notice unusual sounds or smells or smoke coming from it. A damaged product may cause fire and electric shock.
• Ventilate the room before operating the air conditioner if there is a gas leakage from another appliance.
• Do not operate or stop the unit by inserting or pulling out the power cord plug.
• Do not operate with wet hands or in very humid environments. It may cause electric shock.
• Do not allow water to come into contact with any electric parts. It may cause failure or electric shock.
• Do not use the socket if it is loose or damaged. It may cause fi re and electric shock.
• Do not use or keep the power cord close to heating appliances. It may cause fi re and electric shock.
• Do not use any devices or materials for installation that are not recommended in this manual.
• Do not disassemble or modify unit. It may cause failure and electric shock.
• Do not damage or use an alternate power cord. It may cause fire and electric shock. If the power cord is damaged, it must be replaced by the manufacturer in order to avoid a hazard.
• Do not direct airflow straight into persons to avoid possible health hazard.
• Do not open the unit during operation. It may cause electric shock.
• Do not use the power cord near flammable gas or combustibles, such as gasoline, benzene, thinner, etc. It may cause an explosion or fire.
• Do not let children on the air conditioner. A serious injury may occur.
• Avoid fi re hazard or electric shock. Do not use an extension cord or an adaptor plug. Do not remove any prongs from the power cord.
• Be sure the air conditioner is properly grounded. To minimize shock and fi re hazards, proper grounding is important. The power cord is equipped with a three-prong grounding plug for protection against shock hazards.
• Your air conditioner must be used in a properly grounded wall receptacle. If the wall receptacle you intend to use is not adequately grounded or protected by a time delay fuse or circuit breaker, have a qualifi ed electrician install the proper receptacle. Ensure the receptacle is accessible after the unit installation.
• Be sure the electrical service is adequate for the model you have chosen. This information can be found on the serial plate, which is located on the side of the cabinet and behind the grille.

CAUTION

• When the air filter is to be removed, do not touch the metal parts of the unit. It may cause injury.
• Always unplug the unit before cleaning. Do not clean the unit when power is on as it may cause fire, electric shock or injury.
• Do not place obstacles around air inlets or inside of air outlets. It may cause failure or an accident.
• Clean with a soft cloth only. Do not use strong detergents that contain wax or thinners as it may damage the product.
• Use caution when unpacking and installing. Sharp edges could cause injury.
• Do not clean the air conditioner with water. Water may enter the unit and degrade the insulation which could lead to electric shock.
• Hold the plug by the head of the power plug when taking it out. Otherwise, it may cause electric shock and damage.
• Ensure that the installation is properly secured to prevent the product from potentially falling.
• Do not place heavy objects on the power cord and ensure that the cord is not compressed. Otherwise, there is a danger of fire or electric shock.
• If water is spilled on the unit, turn off the unit and switch off the circuit breaker. Isolate the supply by taking the power plug out and contacting a qualified service technician.
• Do not use a near gas stoves or other gas-burning appliances, as air flow may affect gas combustion.
• Do not use it for any purpose other than room comfort. Do not use this air conditioner to preserve precision devices, food, pets, plants, and art objects. It may cause deterioration.
• Turn off the main power switch if the unit is not to be used for an extended time.
• Always insert the filters securely. Clean the litter once every two weeks. Operation without filters may cause failure.
• Do not drink water drained from the air conditioner.

Caution: Risk of fire/ flammable materials (Required for R32/R290 units only)
IMPORTANT NOTE: Read this manual carefully before installing or operating your new air conditioning unit. Make sure to save this manual for future reference.

EXPLANATION OF SYMBOLS DISPLAYED ON THE UNIT

WARNING
This symbol shows that this appliance used a flammable refrigerant. If the refrigerant is leaked and exposed to an external ignition source, there is a risk of fi re.
CAUTION This symbol shows that the operation manual should be read carefully.
CAUTION This symbol shows that service personnel should be handling this equipment with reference to the installation manual.
CAUTION This symbol shows that information is available such as the operating manual or installation manual.

WARNING (for using R32 refrigerant only)

• Do not try to accelerate the defrosting process or methods of cleaning that are not recommended by the manufacturer.
• The appliance shall be stored in a room without a continuously operating ignition source (for example, open flames or an operating gas appliance) or an ignition source (for example, an operating electric heater) close to the appliance. The appliance shall also be stored in a room without ignition sources.
  Do not pierce or burn.
  Be aware that the refrigerants may not contain an odor.
• Keep ventilation openings clear of obstruction. Unit is only to be serviced by a Toshiba-authorized servicer.
• Flammable refrigerant R32 is used within the air conditioner. Please follow the instructions carefully to handle, install, clean, and service the air conditioner to avoid damage or hazards. Do not dispose of the air conditioner in the regular trash. Contact a qualified agency for proper disposal.
• No open fire or devices that generate spark/arcing shall be around the air conditioner to avoid causing ignition of the flammable refrigerant used. Please follow the instructions carefully to store or maintain the air conditioner to prevent mechanical damage from occurring.

Operation of Current Device

The power supply cord contains a current a measuring device that detects damage to the power cord. Test your power supply cord as follows:

1. Plug in the air conditioner.
2. The power supply cord will have TWO buttons on the plug head. Press the TEST button. You will notice a click as the RESET button pops out.
3. Press the RESET Button. You will notice a click as the button engages.
4. The power supply cord is now supplying electricity to the unit. (On some products this is also indicated by a light on the plug head.)

NOTICE

The power supply cord with this air conditioner contains a current detection device designed to reduce the risk of fire. In the event that the power supply cord is damaged, it can not be repaired. It must be replaced with a cord from the manufacturer.

• Do not use this device to turn the unit on or off.
• Always make sure the RESET button is pushed in for a correct operation.
• The power supply cord must be replaced if it fails to reset when either the TEST button is pushed, or it can not be reset. Please contact Customer Service.

TROUBLESHOOTING TIPS

Before calling the service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workmanship or materials of these appliances.

NOTICE
Do not add an extension to the exhaust hose(s)!

Warranty

Air Conditioner Warranty
Your product is protected by this Limited Warranty: Warranty service must be obtained from Midea Consumer Services or an authorized Midea servicer.
Warranty

One-year limited warranty from original purchase date. Five-year compressor warranty from original purchase date.

Pros & Cons

Pros

• 14,000 BTU cooling capacity
• 3 cooling speeds
• 24-hour timer
• Remote control
• Washable filter
• Low noise level

Cons

• May be too large for smaller windows
• May be expensive for some consumers

Customer Reviews

Customers love the Midea Window Air Conditioner MAP14HS1TBL for its powerful cooling capacity and energy efficiency. They also appreciate the convenience of the remote control and 24-hour timer. However, some customers have reported issues with the remote control and noise level. Overall, the Midea Window Air Conditioner MAP14HS1TBL is a great choice for anyone looking for a powerful and efficient window AC unit.

Most Common Complaints

You can directly drain the unit through the drainage system, or you can connect a hose to the drain outlet and set it up to drain all the time.
